Aigis Mechtronics MLA Series User manual

Tilt
an
Sq
MLA SE IES OUTDOO DOMES
MLA2CH211
MLA2WD211
MLA2DN211
IN S T A L L A T I O N A N D OP E AT I N G IN S T U C T I O N S
WWW.A I G I S M E C H .C O M
y

This label may appear on the bottom of the unit due to space limitations.
The lightning flash with an arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to per-
sons.
The exclamation point within an equilateral triangle is intended to
alert the user to presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appli-
ance.
Attention: nstallation should be performed by qualified service
personnel only in accordance with the National Electrical Code
or applicable local codes.
24 AC Units: Do Not Exceed 30 VAC nput.Voltage applied to the unit’s
power input should not exceed 30VAC. Normal input voltage is 24 VAC. User
supplied wiring from 24 VAC supply to unit must be in compliance with elec-
trical codes (Class 2 power levels). Do not ground 24 VAC supply at power
supply terminals or at unit’s power supply terminals.
WARNING: TO PRE ENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE UNITS TO RAIN OR MOISTURE.
SAFETY PRECAUTIONS
CAUTION:TO REDUCETHE RISK OF ELECTRICAL
SHOCK, DO NOT OPEN CO ERS. NO USER SER ICE-
ABLE PARTS INSIDE. REFER SER ICINGTO QUALIFIED
SER ICE PERSONNEL.
2

En raison de limitation de place, cette étiquette peut être placée sur le dessous
de l'appareil.
L'éclair fléché dans un triangle équilatéral,avertit l'utilisateur de la
présence d'une "tension dangereuse" non isolée à l'intérieur de l'ap-
pareil et d'une valeur suffisante pour constituer un risque d'électrocu-
tion.
Le point d'exclamation contenu dans un triangle équilatéral, avertit
l'utilisateur de la présence, dans la documentation qui accompagne
l'appareil, de consignes d'utilisation et de maintenance importantes.
Attention: L'installation doit être effectuée uniquement par
du
personnel de service qualifié conformément à la réglementation
du Code Electrique National ou à la réglementation locale.
Appareils 24 CA
Ne pas excéder 30 VCA. La tension appliquée à l'entrée d'alimentation de l'ap-
pareil ne devrait pas excéder 30 VCA.Toute installation électrique fournissant
du 24 Volts courant alternatif doit être conforme aux codes électriques.
(Niveaux d'alimentation de la Classe 2). Ne pas brancher une prise de terre
sur les bornes d'alimentation 24 Volts ou aux bornes d'alimentation de l'ap-
pareil.
ATTENTION: POUR É ITER LE RISQUE D'ÉLECTROCUTION OU
D'INCENDIE, NE PAS EXPOSER À LA PLUIE OU À L'HUMIDITÉ UN
APPAREIL.
SECURITE
DANGER: POUR É ITERTOUT RISQUE D'ÉLECTROCUTION,
NE PAS OU RIR LE BOÎTIER. IL N'Y A PAS DE PIÈCES REM-
PLAÇABLES À L'INTÉRIEUR. POURTOUTE RÉ ISION,
S'ADRESSER À UN TECHNICIEN SPÉCIALISÉ.
3

Aus Platzgründen kann diese Warnung auf der Unterseite des Gerätes angebracht
sein.
Das Blitzsymbol im gleichseitigen Dreieck soll den Benutzer auf
nicht isolierte "Hochspannung" im Gehäuse aufmerksam machen,
die eventuell stark genug ist, um einen elektrischen Schlag zu verur-
sachen.
Das Ausrufezeichen im gleichseitigen Dreieck soll den Benutzer auf
wichtige Bedienungs- und Wartungsanleitungen in der dem Gerät
beigefügten Literatur aufmerksam machen.
Achtung! Die nstallation sollte nur von qualifiziertem
Kundendienstpersonal gemäß jeweilig zutreffender
Elektrovorschriften ausgeführt werden.
24 VAC Ger te
Achtung! 30 Volt Eingangswechselspannung darf für 24 VAC Modelle nicht
überschritten werden. Normal-betrieb findet bei 24 Volt Wechselspannung
statt. Die Kabel- bzw. Drahtverbindung vom Netzgerät zu dem vor-liegenden
Gerät muß die Bestimmungen der Schutz-klasse erfüllen. Nicht die 24-Volt-
Leitung erden weder am Netzgerät noch an den Anschlußklemmen des vorlie-
genden Gerätes
WARNUNG: UM FEUER ODER ELEKTRISCHE SCHLÄGE ZU
ERMEIDEN, SETZEN SIE DAS GERÄT NIEMALS REGEN ODER
FEUCHTIGKEIT AUS.
ORSICHT: UM EINEN ELEKTRISCHEN SCHLAG ZU ERMEI-
DEN,ABDECKUNG NICHT ENTFERNEN.WARTUNGEN
ALLER ART QUALIFIZIERTEM PERSONAL ÜBERLASSEN.
SICHERHEITS ORKEHRUNGEN
4

Debido a limitaciones de espacio, esta etiqueta puede aparecer en la parte inferior
de la unidad.
El símbolo representado por un relámpago con punta de flecha
dentro de un triángulo equilátero, se muestra con el objetivo de
alertar al usuario que existen "voltages peligrosos" sin aislamiento,
dentro de la cubierta de la unidad. Dichos voltages pueden ser de
tal magnitud que constituyen un riesgo de choque eléctrico a per-
sonas.
El símbolo de exclamación dentro de un triángulo equilátero, se
muestra con el objetivo de alertar al ususario de que instrucciones
de operación y mantenimiento importantes acompañan al equipo.
Atención: La instalación de este equipo debe ser realizada por
personal capacitado, solo en acuerdo, y en cumplimiento de nor-
mas del "National Electric Code" (Código Eléctrico Nacional) ó las
normas del Gobierno Nacional Local.
Unidades de 24 VCA
No exceder 30 VCA de entrada.Voltage suplido a la unidad no debe exceder
30 VCA.Voltage de entrada normal es de 24 VCA. El cableado de 24 VCA
provisto por el usuario debe cumplir con las normas eléctricas (Clase 2 de
niveles de alimentación). No conectar los 24 VCA a tierra en las terminales de
la alimentación ó a las terminales de la fuente de alimentación de la unidad.
PELIGRO: PARA E ITAR EL PELIGRO DE INCENDIO Ó CHOQUE
ELÉCTRICO, NO EXPONGA A LA LLU IA Ó HUMEDAD.
PRECAUCION: PARA REDUCIR EL RIESGO DE CHOQUE
ELÉCTRICO, FA OR NO ABRIR LA CUBIERTA. ESTE EQUIPO
NO CONSTA DE PIEZAS O PARTES QUE REQUIEREN SER ICIO
O MANTENIMIENTO. PARA REPARACIONES FA OR REFERIRSE
A UNTÉCNICO CALIFICADO.
PRECAUCIONES DE SEGURIDAD
5

FCC & ICES INFORMATION
(U.S.A. and Canadian Models Only)
WARN NG - This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules and CES-003 of ndustry Canada.These limits
are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense. ntentional or unintentional changes or modifications not
expressly approved by the party responsible for compliance shall not be made.Any such changes
or modifications could void the user's authority to operate the equipment.
f necessary, the user should consult the dealer or an experienced radio/television technician for
corrective action.The user may find the following booklet prepared by the Federal
Communications Commission helpful: "How to dentify and Resolve Radio-TV nterference
Problems." This booklet is available from the U.S. Government Printing Office,Washington, DC
20402, Stock No.004-000-00345-4.
1. UNPACKING
Unpack carefully.This is an electromechanical device and should be handled
carefully. Check to ensure that the following items are included:
• ntegrated camera/housing unit.
• Hardware kit: special Allen wrench.
• Desiccant Kit
• 2-position terminal block (non-UTP versions)
Model Designation
Compare the model designation printed on the unit’s label to the list below
before reviewing these instructions.
MLA2CH211 Color, Hi-Res, Camera, 2.8-11mm A R lens, 24VAC
MLA2WD211 Wide Dynamic Range Camera, 2.8-11mm A R lens, 24VAC
MLA2DN211 True Day/Night Camera, 2.8-11mm A R lens, 24VAC
-U Part numbers ending in –U: the BNC and Power leads are
replaced with a UTP board and RJ45 jack. Refer to Section
5.1.2 for more information.
2. SE VICE
f the unit needs repair service or parts, the customer should contact
Aigis for authorization to return as well as shipping instructions.
6
Warning: This is a Class A product. n a domestic environment, this
product may cause radio interference in which case the user may be
required to take adequate measures.

Figure 1 Cover Removal and Replacement
Captive Screws
Cover Assembly
Base Assembly
Alternate Surface Mount
Conduit Connection
Base Gasket
Four Mounting Holes
(#10 or M5 Screws)
7
4. COVE EMOVAL & EPLACEMENT
1. Using the special Allen wrench provided, remove the 4 tamper resistant
screws located on the cover.The screws are captive and will remain with
the cover. Refer to Figure 1.
2. Lift the housing off the base to make required camera adjustments. Adjust
the covert liner to position the opening in front of the camera when the
cover is replaced.
3. To replace the cover, align the captive screws with the threaded posts in
the base, fit the cover onto the base and tighten the retaining screws
securely.
5. INSTALLATION
Attention: Installations should be performed by qualified service
personnel only in accordance with the National Electrical Code or
applicable local codes.
5.1 Connecting Low Voltage Power & Video Signal
(Standard Models)
The wiring harness has a BNC jack to accept video coax.When mounting
directly to a wall or ceiling, run power and video lines to the desired location
using 3/4 inch conduit.
3. DESC IPTION & SPECIFICATIONS
These cameras are small, high security surveillance domes containing 1/3-inch
CCD cameras with integral varifocal lenses.The units come ready to use, and
mount easily to a wall or ceiling. Construction/Finish: Polycarbonate
Dome on cast aluminum housing.

8
Figure 2 Front of J45 Plug
Caution: Limit UTP wire runs to 1,000 feet (~330 meters) or less.
Feed the network cable into the housing through the rear or side conduit
hole. Route the cable through the housing and plug it into the RJ 45 jack
shown in Figure 4. Avoid putting any tight bends into the network cable.
Caution: Before proceeding to disconnect the power at its source, be sure
that the unit is of the proper voltage type for the line power.
Connect 24VAC to the unit by inserting the field supply wires into the 2-
position terminal block (supplied) and tighten with a flat blade screwdriver.
Connect Video cable to the unit’s BNC connector.
5.2 Connecting Low Voltage Power & Video Signals
(UTP Models: part number ends in –U)
When powering the unit and transmitting video over unshielded twisted pair
(UTP) wiring, ensure the UTP hub/receiver in the control room is compatible
with the UTP transmitter in the camera housing. Refer to the pinout below
to determine compatibility.
Pin
No. Wire Color Pair Utilization
1 White-O ange 2 Video Signal
2 O ange 2 Video Shield
3 White-G een 3 Data +
4 Blue 1 Powe - (Neut al)
5 White-Blue 1 Powe + (Line)
6 G een 3 Data -
7 White-B own 4 Powe + (Line)
8 B own 4 Powe - (Neut al)

9
IMPO TANT: f mounting outdoors, or after servicing add a generous
seal/bead of RTV or silicone around the cables (on the inside of the
conduit) either at the camera or at the junction box. This will help
reduce moisture accumulation in the dome over long periods of time.
4. f mounting this unit outdoors or after servicing, apply a generous bead of
silicone sealant around the back of the base casting, surrounding all holes.
Apply the rubber base gasket to the back of the base casting and apply
another generous bead of sealant to the outer edge around the exposed
surface of the gasket.
5. Place the unit into position on the wall or ceiling. nstall the mounting
screws securely. f sealant is used, make sure that the sealant between the
wall or ceiling and the gasket forms a complete seal.Add more sealant if
needed. Make all final service connections and secure the conduit.
Important Note on Service:
1. When servicing the unit reapply silicon lubricant to the rubber gasket
between the lid and cover before replacing the cover.
2. When replacing the cover make sure the gasket is aligned with the
housing to ensure a proper seal.
5.3 Mounting and/or Servicing the Unit
Refer to Figure 1.
1. Using the rubber base gasket as a template, mark the mounting hole
locations on the mounting surface.The unit is intended to be mounted
with four #10 screws or four M5 screws (not supplied) through the four
outer holes in the base casting.
2. nstall the appropriate anchors or threaded fasteners.
3. nstall a 3/4-inch threaded service conduit coupling into the back conduit
hole, using pipe sealant on the threads. f conduit is to enter from the
side, use a 2-mm Allen wrench to loosen the set screw from the conduit
hole plug. Remove the plug and reinstall it in the conduit hole on the back
of the unit.

10
6. CAME A POSITION ADJUSTMENT
1. Remove dome cover.
2. Loosen Thumbnuts (x3).
3. Make Pan adjustment by turning camera bracket in clockwise or counter
clockwise motion.
4. Tilt Lens into position, then rotate face plate to square image.
5. Tighten Thumbnuts.
Figure 3 Camera Position Adjustment Points
Tilt
Pan
Square Image

11
9. DESICCANT INSTALLATION
Keep Desiccant sealed in plastic bag until ready for installation.Attach
Desiccant to either surface shown in Figure 4 using the adhesive pad.
Figure 4 Adjustments
Thumb Nuts (x3)
Loosen to adjust
camera orientation Desiccant Kit
Placement
Zoom Knob
Focus Knob
Desiccant Kit
Placement
RJ45 Jack
(-U units only)
7. LENS ADJUSTMENT
7.1 Adjustment Of Variable Focus Lens
1. Remove the dome cover before lens adjustment.
2.Turn the zoom knob (W DE<->TELE) to set the field of view angle as
desired. See Figure 4.
3. Next, adjust the focus by turning the focus knob (FAR<->NEAR).
4. f desired imaging field can not be obtained, repeat the steps (1) and (2).
5.Tighten knobs when adjustments are complete.

100 0040 004 A G 07/10
Printed in U.S.A.
©2010 Aigis Mechtronics
1124 Louise Road,Winston-Salem, NC 27107-5450
Tel: [phone] Fax: [phone]
Data subject to change without notice
97,8
153,5
[6.04]
79
[3.11]
135,6
[5.34]
[3.85]
61,1
[2.41]
153,5
[6.04]
144,3
[5.68]
Threaded for 3/4-inch Conduit
Plug Supplied
DIMENSIONAL OUTLINE
