Airgo AGF01UK User manual

IMPORTANT SAFEGUARDS
The fan is intended for household and indoor used only.
Ensure that the fan is switched off from the supply mains before
removing the guard.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge, if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or similarly qualied person
in order to a void hazard.

CONTENTS
Page 4-5 - Warnings and Cautions
Page 6-7 -Smart Fan Assembly
Page 8-9 - Operating Instructions
Page 10 - Cleaning, Maintenance and
Specications
Page 11 Cleaning, Maintenance and
Storage
Page 12 - Warranty
Page 13-14 - Connect to the App
What’s in the box
1. Motor with control panel 4. Plastic grille nut 7. Base
2. Front grille 5. Blade 8. Base ring/ cap
3. Back grille 6. Blade cap 9. Pedestal bar
10. Four screws, four bolts, four washers.

4
WARNINGS
- This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
- Ensure that the fan is switched off from the supply mains before
removing the guard.
- If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
- Never place the fan near any gas appliances, re or ammable
liquids.
- Never hit or shake the fan to prevent damage.
- Never cover or obstruct the air inlet or outlet to prevent
overheating.
- Never spray water or place the fan near water to prevent
electric shock.
- Make sure to have a professional technician, manufacturer
or a service agent to replace a damaged power cord.
- Never share the power outlet with other appliances.
- Never connect or disconnect the power plug with wet hands
to avoid electric shocks.
- Never put rods or objects into the opening of the unit.
- Never use an extension cord.

5
CAUTIONS
- Be sure the fan is placed on a stable surface when operating to avoid overturning.
- The fan must not be used if the guards are not fastened according to instructions.
- The appliance is for indoor use only.
- Do not plug into the power socket before installation is complete.
- Never insert ngers, pencils, or any other object through the guard when fan is
running.
- Power plug must be removed from power socket before cleaning, servicing,
maintenance and move from one location to another.
- The fan should not be placed in a damp place or where humidity is high (such as a
bathroom).
- Keep the unit at least 1 metre away from electric appliances such as TV’s and radios,
to avoid electromagnetic interference.
- Do not expose the unit under direct sunlight to avoid surface colour fading.
- Do not tilt the unit for more than 35 degrees or upside down while transporting.
- Place the unit on a at surface with less than 5 degree inclination.
- Do not use chemical solvents (i.e. Benzene, alcohol-grazer) to clean the unit surface
to avoid scratching and damaging the surface.
- Do not use your appliance with an extension cord unless it has been checked and
tested by a qualied electrician or electrical supplier.
- Children should be supervised to ensure that they do not play with the appliance.

6
SMART FAN ASSEMBLY
Assemble the tube on
the base by tightening
the four screws and
inserting the base ring
down over the round
base.
1. The height of the fan
can be adjusted by
loosening the height
adjustment ring.
Raise or lower the
fan and carefully
tighten the screw.
2. Insert the fan body
in the main tube
and tighten the
screw to secure the
connection tube.
3.

7
SMART FAN ASSEMBLY
Loosen the nut (5) of the motor
(8). Firmly mount the rear grille
(6) on the motor by matching
3 mounting pads. Tighten the
nut (5) on the back grid so as to
block the grille against the
motor.
Mount the fan blades (4) on the
axis (7). Firmly secure them
with the reversed nut (3). At this
point, the blades should turn
freely without touching the nut of
the rear grille.
Loosen the locking strapping clip
(2a) Put the front grille on the
rear grille and tighten the locking
screw.
4.

8
OPERATING
INSTRUCTIONS
Warning: Make sure the fan is fully assembled (and
the grilles are in place and locked) before switching
on. All below functions can be carried out through
the App.
1. Place your fan on a level and dry surface.
2. Plug the fan into a mains socket of suitable
voltage and frequency (see Technical Specifications
for details)
3. Touch ON/OFF button to turn on the fan.
4. Choose the desired SPEED and MODE using
the Control Panel or App.
5. Use the TIMER button to set the desired turn-
off time from 1-8 hours
6. Use the SWING button to start or stop
oscillation.
7. Tilt Adjustment: To adjust the tile, hold the Main
Body with one hand, push the Motor Housing to the
desired vertical position with the other hand.
Caution: The fan should be always be switched off
when making this adjustment.

9
OPERATING
INSTRUCTIONS
Swing:
Press the Swing button to turn on oscillation. The swing
indicator turns on. Press again to turn off oscillation.
Speed:
Press the Speed button to change fan speed. There are 3
possible speeds: Low/Medium/High. The corresponding
indicator turns on.
Mode:
NORM mode: The fan operates in the constant speed set
using the Speed button.
SMRT mode: The unit simulates a natural breeze.
NGHT mode: The unit simulates a gentle breeze suitable
for night-time use.
Timer:
Press this button to set the turn-off delay for the unit.
The turn-off delay can be set in two hour increments from
2 to 8 hours. There are 4 indicators 2H,4H,6H and 8H.

10
CLEANING,
MAINTENANCE AND
SPECIFICATIONS
Warning : Always unplug the appliance before cleaning.
1. Always disconnect the appliance from the mains by switching it off
and removing the plug from the power outlet before cleaning.
2. To clean the outer surface of the appliance, use a lightly damp
cloth. Then, dry it thoroughly with a soft, dry cloth before using again.
3. Do not allow water to penetrate the motor during cleaning.
4. Do not reconnect the unit until it is completely dry.
Product Specications
Model No. -- AGF01UK
Power supply -- 220-240V ~ 50-60Hz
Power -- 55W
Net weight -- 5.6kg
Gross weight -- 6.5kg
Gross dimension --(W x H x D) 495*230*450 mm
Warranty -- 2 years

11
CLEANING,
MAINTENANCE AND
STORAGE
Warning : Always unplug the appliance before cleaning.
Fan Blade Cleaning
1. To access the fan blade, remove the front grille and blade cap.
2. Clean the fan blade, front and rear grilles with a soft moist cloth.
3. Place the fan blade back in its place, tighten the blade cap and securely fasten the
front grille (see Assembly Instructions to ensure the fan blade, front and rear grilles are
assembled properly).
Fan Head, Base and Pole Cleaning
Using a soft, moist cloth with or without a mild soap solution carefully clean the fan
base, pole and head. Please use caution around the motor housing area.
Important: Do not allow the motor or other electrical components to be
exposed to water.
Fan Storage
Your Smart Fan can be stored in the off season, either partially disassembled or
assembled. It is important to keep it in a safe and dry location.
• If stored disassembled, we recommend using the original (or appropriately sized) box.
• If stored assembled or partially assembled, remember to protect the fan head from
dust and to unplug it while not in use.
Idea
Your Smart Fan can
also be used during
the cold winter
season to circulate
warm air throughout
your home.
