Airo XP Series User manual

PIATTAFORME AEREE SEMOVENTI
SELF-PROPELLED WORK-PLATFORMS
PLATES-FORMES DE TRAVAIL AUTOMOTRICES
SELBSTFAHRENDE HUBARBEITSBÜHNEN
PLATAFORMAS ELEVADORAS AUTOPROPULSADAS
ZELFRIJDENDE HOOGWERKERS
SJÄLVGÅENDE ARBETSPLATTFORMAR
SAMOKRETNE RADNE PLATFORME
SERIES „XP - XLP“
XP4 E - XP5 E - XLP5 E
XP4 E DUAL - XP5 E DUAL - XLP5 E DUAL
USE AND MAINTENANCE MANUAL
- ENGLISH - ORIGINAL INSTRUCTIONS
AIRO is a division of TIGIEFFE SRL
Via Villasuperiore, 82 -42045 Luzzara (RE) ITALY -
[phone] -[phone]
WEB: www.airo.com
063.20.UEM-EN
2018-01

Use and Maintenance Manual - XP - XLP Series
Page 2
Revision date
Description of revision
2011-01
Issue:
05-2011
Amended information on “Commissioning and first inspection, subsequent inspections and
title transfer report”.
Inserted “Total quantity of battery electrolyte” in Technical Data. (to be checked)
2013-10
Specified instructions for harness anchoring points.
2014-01
Changed battery charger operation.
2014-09
Inserted information on maximum limits of manual forces.
Changed Name and Surname of CEO.
2015-01
CE conformity declaration updated.
Added position of hands instruction.
2015-10
Type of usable hydraulic oil updated.
Added indication for spare parts. They must be original or approved by the manufacturer of
the machine in any way.
Added "Leaving at height”.
2018-01
Added new models DUAL.
Added pictures about fixing machines for transport.

Use and Maintenance Manual - XP - XLP Series
Page 3
Tigieffe thanks you for purchasing a product of its range, and invites you to read this manual. Here you can find all the necessary
information for a correct use of the purchased machine; therefore, you are advised to follow the instructions carefully and to read
the manual thoroughly. The manual should be kept in a suitable place where no damage can occur to it. The content of this manual
may be modified without prior notice and further obligations in order to add changes and improvements to the units already
delivered. No reproduction or translation may take place without the written permission of the owner.
Contents:
1. INTRODUCTION .....................................................................................................................................................................................5
1.1 LEGAL ASPECTS ..................................................................................................................................................................................5
1.1.1 Delivery of the machine ..............................................................................................................................................................5
1.1.2 Declaration of commissioning, first check, further periodical checks and transfers of ownership ..............................................5
1.1.2.1 Declaration of commissioning and first check..............................................................................................................5
1.1.2.2 Further periodical checks.............................................................................................................................................6
1.1.2.3 Transfers of ownership ................................................................................................................................................6
1.1.3 Operator training and information ...............................................................................................................................................6
1.2 TESTS PERFORMED BEFORE DELIVERY .................................................................................................................................................6
1.3 INTENDED USE ....................................................................................................................................................................................6
1.3.1 Leaving at height ........................................................................................................................................................................7
1.4 DESCRIPTION OF THE MACHINE ............................................................................................................................................................7
1.5 CONTROL PANELS ...............................................................................................................................................................................8
1.6 DRIVE POWER .....................................................................................................................................................................................8
1.7 MACHINE LIFE,DEMOLITION AND DECOMMISSIONING..............................................................................................................................8
1.8 IDENTIFICATION ...................................................................................................................................................................................9
1.9 LOCATION OF MAIN COMPONENTS.......................................................................................................................................................10
2. TECHNICAL FEATURES OF STANDARD MACHINES.......................................................................................................................11
2.1 MODEL XP4 E–XP4 EDUAL. .........................................................................................................................................................11
2.2 MODEL XP5 E–XP5 EDUAL. .........................................................................................................................................................13
2.3 MODEL XLP5 E–XLP5 EDUAL. .....................................................................................................................................................15
2.4 VIBRATIONS AND NOISE......................................................................................................................................................................17
3. SAFETY PRECAUTIONS......................................................................................................................................................................18
3.1 PERSONAL PROTECTIVE EQUIPMENT (PPE) ........................................................................................................................................18
3.2 GENERAL SAFETY NORMS ..................................................................................................................................................................18
3.3 USE INSTRUCTIONS ...........................................................................................................................................................................19
3.3.1 General .....................................................................................................................................................................................19
3.3.2 Handling.................................................................................................................................................................................... 19
3.3.3 Operating procedures ...............................................................................................................................................................20
3.3.4 Wind speed according to BEAUFORT SCALE.........................................................................................................................21
3.3.5 Pressure of the machine on ground and load-bearing capacity of ground ...............................................................................22
3.3.6 High-voltage lines .....................................................................................................................................................................23
3.4 HAZARDOUS SITUATIONS AND/OR ACCIDENTS......................................................................................................................................23
4. INSTALLATION AND PRELIMINARY CHECKS..................................................................................................................................24
4.1 BECOMING ACQUAINTED WITH THE MACHINE........................................................................................................................................24
4.2 PRELIMINARY OPERATION CHECKS......................................................................................................................................................24
5. USE INSTRUCTIONS............................................................................................................................................................................25
5.1 MACHINE MOVEMENT.........................................................................................................................................................................25
5.2 MACHINE BRAKING AND START-UP ......................................................................................................................................................26
5.3 PLATFORM ACCESS ...........................................................................................................................................................................27
5.3.1 Standard access with gate (XP4 E - XP5 E - XLP5 E) .............................................................................................................27
5.3.2 Standard access with gravity rod (XP4 E DUAL - XP5 E DUAL - XLP5 E DUAL)....................................................................27
5.3.3 Optional access with gate “SALOON” (XP4 E DUAL - XP5 E DUAL - XLP5 E DUAL) ............................................................28
5.4 ADJUSTING THE TELESCOPIC RAILS FOR DUAL MODELS ......................................................................................................................29
5.5 CONTROLS........................................................................................................................................................................................30
5.5.1 Emergency stop (A) ..................................................................................................................................................................30
5.5.2 Platform lifting/lowering (B-C) ...................................................................................................................................................30
5.6 GROUND CONTROL PANEL..................................................................................................................................................................31
5.6.1 Hour-meter / battery protection voltmeter (A) ........................................................................................................................... 31
5.6.2 Emergency STOP button (B) ....................................................................................................................................................31
5.6.3 Instability danger audible alarm (C) ..........................................................................................................................................31
5.6.4 Battery charger warning lights (D) ............................................................................................................................................31
5.6.5 Battery charger socket (E) ........................................................................................................................................................32

Use and Maintenance Manual - XP - XLP Series
Page 4
5.7 MACHINE START-UP...........................................................................................................................................................................32
5.8 MACHINE STOP.................................................................................................................................................................................. 32
5.8.1 Normal stop...............................................................................................................................................................................32
5.8.2 Emergency stop button............................................................................................................................................................32
5.9 MANUAL EMERGENCY LOWERING........................................................................................................................................................33
5.10 SOCKET FOR ELECTRIC TOOL CONNECTION (OPTIONAL) .......................................................................................................................33
5.11 END OF WORK ...................................................................................................................................................................................34
6. HANDLING AND CARRYING...............................................................................................................................................................35
6.1 HANDLING.........................................................................................................................................................................................35
6.2 CARRYING ........................................................................................................................................................................................36
6.2.1 Removable rails ........................................................................................................................................................................38
6.3 TOWING THE MACHINE. ......................................................................................................................................................................38
7. MAINTENANCE ....................................................................................................................................................................................39
7.1 SAFETY LOCK FOR MAINTENANCE OPERATIONS ...................................................................................................................................39
7.2 MACHINE CLEANING...........................................................................................................................................................................40
7.3 GENERAL MAINTENANCE ....................................................................................................................................................................40
7.3.1 Various adjustments .................................................................................................................................................................41
7.3.2 Greasing ...................................................................................................................................................................................42
7.3.3 Hydraulic circuit oil level check and change .............................................................................................................................43
7.3.3.1 Biodegradable hydraulic oil (Optional) .......................................................................................................................44
7.3.3.2 Emptying ....................................................................................................................................................................44
7.3.3.3 Filters .........................................................................................................................................................................44
7.3.3.4 Washing .....................................................................................................................................................................44
7.3.3.5 Filling..........................................................................................................................................................................44
7.3.3.6 Commissioning / check ..............................................................................................................................................44
7.3.3.7 Mix .............................................................................................................................................................................45
7.3.3.8 Micro-filtration ............................................................................................................................................................ 45
7.3.3.9 Disposal .....................................................................................................................................................................45
7.3.3.10 Topping up .................................................................................................................................................................45
7.3.4 Suction filter replacement .........................................................................................................................................................46
7.3.5 Pressure relief valve operation check.......................................................................................................................................47
7.3.6 Braking system adjustment and operation check .....................................................................................................................48
7.3.6.1 Pedal brakes ..............................................................................................................................................................48
7.3.6.2 Automatic brakes .......................................................................................................................................................49
7.3.7 Inclinometer operation check....................................................................................................................................................50
7.3.8 M1 microswitch efficiency check...............................................................................................................................................51
7.4 BATTERY ..........................................................................................................................................................................................51
7.4.1 General warning instructions ....................................................................................................................................................51
7.4.2 Battery maintenance.................................................................................................................................................................52
7.4.3 Battery recharge .......................................................................................................................................................................52
7.4.4 Battery charger: fault report ......................................................................................................................................................53
7.4.5 Battery replacement..................................................................................................................................................................53
8. MARKS AND CERTIFICATIONS..........................................................................................................................................................54
9. PLATES AND STICKERS.....................................................................................................................................................................55
10. CHECK REGISTER...............................................................................................................................................................................57
11. WIRING DIAGRAM - STANDARD MACHINES....................................................................................................................................71
12. HYDRAULIC DIAGRAM - STANDARD MACHINES ............................................................................................................................73
13. DECLARATION OF CONFORMITY EC FACSIMILE. ..........................................................................................................................75

Use and Maintenance Manual - XP - XLP Series
Page 5
1. INTRODUCTION
This Use and Maintenance Manual provides general instructions concerning the complete range of machines indicated on the
cover. Therefore the description of their components, as well as control and safety systems, may include parts not present on Your
machine since supplied on request or not available. In order to keep pace with the technical development AIRO-Tigieffe s.r.l.
reserves the right to modify the product and/or the use and maintenance manual at any time without updating the units already
delivered.
1.1 Legal aspects
1.1.1 Delivery of the machine
Within EU (European Union) member countries the machine is delivered complete with:
Use and Maintenance manual in your language
CE mark applied on the machine
Original EC Declaration of conformity
Guarantee certificate
Only for Italy:
Declaration of commissioning to INAIL
List of local INAIL departments
Declaration of internal testing
It is to be noted that the Use and Maintenance Manual is an integral part of the machine and a copy of this, together with copies of
the documents certifying that the periodical checks have been carried out, must be kept on board in its suitable container. In the
event of a transfer of ownership the machine must always be provided with its use and maintenance manual.
1.1.2 Declaration of commissioning, first check, further periodical checks and transfers of ownership
The legal obligations of the owner of the machine vary according to the country of commissioning. It is therefore recommended to
inquiry about the procedures in force in your country from the boards responsible for industrial safety. This manual contains a final
section called "Check register" for a better filing of documents and recording of any modifications.
1.1.2.1 Declaration of commissioning and first check
In ITALY the owner of the Aerial Platform must notify the use of the machine to the local competent INAIL and submit it to
periodical compulsory checks. The first of such checks is performed by the INAIL within sixty days from a request being made. In
the event of such time passing without the inspection being made, the employer can call in the ASL (Local Health Unit) or qualified
public or private services. Subsequent checks are made by the already-mentioned parties within thirty days from a request being
made. In the event of such time passing without these checks being made, the employer can call in qualified public or private
services. The checks are on a payment basis and the employer (machine owner) will be charged for them. For these checks, the
territorial inspection boards (ASL/USL or ARPA) and INAIL can be supported by qualified public or private services. The qualified
private institutes acquire the qualification of responsibles of the public service and refer directly to the public structure that controls
this function.
To declare the commissioning of the machine in Italy, send the form that is supplied together with other documents upon machine
delivery, by registered letter with advice of receipt.
The INAIL will assign a serial number when the First Check is performed before completing the “technical identification sheet” on
which it indicates only the details obtained from the already-operating machine or obtainable from the instruction manual. Such
document shall form an integral part of the machine documentation.

Use and Maintenance Manual - XP - XLP Series
Page 6
1.1.2.2 Further periodical checks
Yearly checks are compulsory. In Italy the owner of the Aerial Platform must apply for a periodical check by sending a registered
letter to the local competent inspection board (ASL/USL or other qualified public or private services) at least twenty days before the
expiry of the year from the last check.
NB: If a machine without a valid control document should be moved in an area outside the competence of the usual inspection
board, the owner of the machine must ask the inspection board, competent for the new territory where the machine is to be used,
for the annual check.
1.1.2.3 Transfers of ownership
In case of transfer of ownership (in Italy) the new owner of the Aerial Platform must notify the ownership of the machine to the local
competent inspection board (ASL/USL or ARPA or other qualified public or private services) by enclosing a copy of:
Declaration of conformity issued by the manufacturer.
Declaration of commissioning carried out by the first owner.
1.1.3 Operator training and information
The employer must ensure that the workers appointed to use the equipment are adequately and specifically trained so they are
able to use the Mobile Elevating Work Platform in a proper and safe way and also avoid the risks caused by other people.
1.2 Tests performed before delivery
Before being placed on the market, each MEWP undergoes the following tests:
Braking test
Overload test
Operating test
1.3 Intended use
The machine described in this use and maintenance manual is a manual drive aerial platform (moving is not power-driven)
intended for lifting persons and materials (equipment and work materials) in order to carry out maintenance, installation, cleaning,
painting, de-painting, sand-blasting, welding operations, etc.
The max. capacity allowed (which varies according to the model –see paragraph “Technical features”) is divided as follows:
-80 Kg for each person on board.
-40 Kg for equipment.
-Any remaining load is represented by the work materials.
In any case NEVER exceed the maximum capacity allowed as indicated in paragraph "Technical features”. Persons, tools and work
materials can be loaded on the platform only from the access position (platform lowered). It is absolutely forbidden to load persons,
tools and work materials on the platform when it is not in access position.
All loads must be positioned inside the platform. Do not lift loads (even if complying with the maximum capacity allowed) hanging
from the platform or lifting structure.
Do not carry large-sized panels since they increase the resistance to wind force thus causing the machine to overturn.
It is forbidden to move the machine with platform raised. To move the machine it is necessary that the work platform is in the
access position (fully lowered). No operator must be on board the platform during the displacement of the machine.
The machine is not equipped with an overload controller as in the design phase we considered stability and overload criteria
increased as reported by the EN280 in paragraphs 5.4.1.5 and 5.4.1.6 .
The machine cannot be used in areas where road vehicles operate. Always surround the working area by means of suitable signs
when the machine is used in public areas.
All types of machine use other than those for which it was designed must be approved in writing by the machine manufacturer
following a specific request on the part of the user.

Use and Maintenance Manual - XP - XLP Series
Page 7
Do not use the machine for purposes other than those for which it was designed, except after making a
request and having obtained written permission in this sense from the manufacturer
1.3.1 Leaving at height
The work elevating platforms are not designed by taking into account the risks of the “leaving at height” because the only access
position considered is when the platform is completely lowered. For this reason this activity is formally forbidden.
However, there are exceptional conditions in which the operator needs to access or leave the work platform not in the access
position. This activity is normally defined as “leaving at height”.
The risks connected to the “leaving at height” do not depend exclusively on the PLE (work elevating platform) characteristics; a
specific risk analysis carried out by the employer can authorize this specific use by taking into account:
The working environment characteristics;
The absolute prohibition to consider the work platform as an anchoring point for people working outdoors;
The use of the machine at xx% of its performances to avoid that additional forces created by a specific operation or
bending of the structure move away the access zone from the unloading zone. Provide for some tests in order to define
these limitations;
Provide for a specific evacuation procedure in case of emergency (for example: an operator always on the platform, one at
the ground control panel while a third operator leaves the lifted platform );
Provide for a specific training of the staff both as operator and transported staff;
Equip the unloading zone with all the devices that are necessary to avoid the risk of fall of the staff that accesses/leaves
the platform.
What said above is not a formal authorization of the manufacturer for the “leaving at height”, but it wants to supply information to
the employer - who is fully responsible for that - which can be useful for the planning of this exceptional activity.
1.4 Description of the machine
The machine described in this use and maintenance manual is a Manual Drive Elevating Work Platform equipped with:
-Chassis equipped with wheels.
-Vertical scissor lifting structure operated by one or more hydraulic cylinders (the number of cylinders varies according to
machine model).
-Work platform (the max. capacity varies according to the model - see chapter "Technical features”).
The chassis is equipped with four idle wheels of which two rear pivoting and two front fixed (non steering). The rear wheels are
equipped with pedal parking brake; on front wheels there is a device for automatic braking which intervenes when the work platform
is in a position other than the access one.
The hydraulic cylinder moving the extensible structure is provided with a solenoid safety valve directly flanged on the same. These
devices allow the booms to remain in position even if one of the supply tubes accidentally breaks.
The platform is equipped with rails and toe-boards of a prescribed height (the height of the rails is 1100 mm; the height of the
toe-boards is 150 mm). For basic models XP4 E –XP5 E –XLP5 E the platform perimeter corresponds to the rails perimeter,
while for DUAL models it is possible to adjust the maximum platform size by adjusting the rails on two fixed positions. In the "open"
position, the rails make the whole platform floor available to the operator; in the "closed" position the rails reduce its perimeter
dimensions allowing the operator on board to fit the platform into confined spaces such as the panels of false ceilings.
To access the platform the following access systems are available:
-Entrance area with one-door reclosing gate and automatic lock in the closed position (standard for basic models XP4 E –XP5
E –XLP5 E);
-Entrance area with gravity rod (standard for "DUAL” models);
-Entrance area with two-door gate ("saloon” type) with automatic reclosing and locking system in closed position (optional for
"DUAL” models).
When no motive power is available, the manual emergency lowering can be controlled enabling the knob manually from the ground
(see instructions plates).

Use and Maintenance Manual - XP - XLP Series
Page 8
1.5 Control panels
The machine is provided with a single control panel on the platform for the normal use of the machine.
On the ground there is an emergency stop device and the device for manual emergency lowering.
1.6 Drive power
The machines are powered by an electro-hydraulic system consisting of rechargeable accumulators and electric pump.
Both the hydraulic and the electric systems are equipped with all necessary protections (see electric and hydraulic circuit diagrams
annexed to this manual).
1.7 Machine life, demolition and decommissioning
The machine has been designed to last for 10 years in normal operating environments, if properly used and serviced. Within this
period, the manufacturer must carry out a complete inspection/overhaul.
If disposal of the unit is necessary, comply with current local regulations.
In Italy, the demolition/decommissioning must be notified to the local ASL / USL or ARPA.
The machine consists mainly of metal parts which are easy to be identified (steel for the most parts, and aluminium for the
hydraulic blocks); thus, we can state that the machine can be recycled at 90%.
European standards and those transposed by the member countries relating to respect for the environment
and the disposal of wastes envisage heavy administrative and penal fines in case of infringement.
In case of demolition/decommissioning, carefully keep to the provisions of applicable regulations,
especially as regards materials such as hydraulic oil and batteries.

Use and Maintenance Manual - XP - XLP Series
Page 9
1.8 Identification
In order to identify the machine, when spare parts and service are required, always mention the information given in the serial
number plate. Should this plate (as well as the various stickers applied on the machine) be lost or illegible, it is to be replaced as
soon as possible. In order to identify the machine when no plate is available the serial number is also stamped on the chassis. To
locate the plate and the stamp of the serial number, see the following picture. It is recommended to copy such data in the following
boxes.
Model.................................…………..
Chassis:..................................………...
Year:...................................…………...
FIG.1
SFXX.XX.XXX

Use and Maintenance Manual - XP - XLP Series
Page 10
1.9 Location of main components
Alongside is a diagram showing the machine and its
components.
1) Platform control push-button panel
2) Box components
3) Control panel
4) Hydraulic control unit
5) Steering wheels with pedal parking brake
6) Fixed wheels with automatic parking brakes
7) 230V plug (optional)
8) Spirit level for visual check of machine levelling
(optional)
9) Lifting cylinders
10) Lowering control valves
11) Battery
12) Battery charger
13) Inclinometer
14) Manual device for emergency lowering
15) Platform height control M1 microswitch
16) Stopping levers of the lifting structure
17) Document box
18) Battery charger power cable location
19) Wheel chocks for forklift truck
20) Transport fixing holes.
FIG.2
1
2
3,4,11
5
6
7.8
9
10
12
13
14
15
16
17
18
19
19
20
20

Use and Maintenance Manual - XP - XLP Series
Page 11
2. TECHNICAL FEATURES OF STANDARD MACHINES
THE TECHNICAL FEATURES OF THE PRODUCTS IN THE FOLLOWING PAGES CAN BE MODIFIED
WITHOUT PRIOR NOTICE
2.1 Model XP4 E –XP4 E DUAL.
Dimensions:
XP4 E
XP4 E DUAL
Maximum working height
4.0
m
Max. platform height
2.0
m
Ground clearance
50
mm
Maximum capacity (m)
250
kg
Max. number of people on the platform (n) –indoors
1
Tool and material weight (me) * –indoors
170
kg
Max. pressure of lifting circuit
150
bar
Tyre dimensions
Ø200 x 50
mm
Type of tyres
Non-marking
polyurethane
Platform dimensions
0.57 x 1.05
m
Rails height
1.10
m
Toe board height
0.15
m
Transport dimensions with removable rails installed
0.70 x 1.20 x 1.74
m
Transport dimensions with removable rails not installed
0.70 x 1.20 x 0.78
m
Machine weight (unloaded) (1)
325
kg
Stability limit:
Longitudinal inclination
1.5
°
Transversal inclination
1.5
°
Maximum wind speed
0
m/s
Maximum manual force:
200
N
Max. load per wheel
300
Kg
Performance:
Battery capacity and voltage
12 / 85-102
V/Ah (c5-c20)
Standard battery type
Gel
Total electrolyte quantity
(7)
Lt.
Battery weight
32
kg
Single-phase battery charger
12 / 10 HF
V/A
Max. current absorbed by the battery charger
4
A
Electric pump power
0.8
kW
Max. absorbed current
150
A
Lowering/lifting time (unloaded)
20 / 27
Sec.
Oil tank capacity
2
Lt.
Max. operating temperature
+50
°C
Min. operating temperature
-15
°C
( * ) me = m –(n x 80)
(1) In some cases different limits can be fixed. It is recommended to comply with the data shown on the machine plate.

Use and Maintenance Manual - XP - XLP Series
Page 12
FIG.3

Use and Maintenance Manual - XP - XLP Series
Page 13
2.2 Model XP5 E –XP5 E DUAL.
Dimensions:
XP5 E
XP5 E DUAL
Maximum working height
4.6
m
Max. platform height
2.6
m
Ground clearance
50
mm
Maximum capacity (m)
250
kg
Max. number of people on the platform (n) –indoors
1
Tool and material weight (me) * –indoors
170
kg
Max. pressure of lifting circuit
250
bar
Tyre dimensions
Ø200 x 50
mm
Type of tyres
Non-marking
polyurethane
Platform dimensions
0.57 x 1.05
m
Rails height
1.10
m
Toe board height
0.15
m
Transport dimensions with removable rails installed
0.70 x 1.20 x 1.84
m
Transport dimensions with removable rails not installed
0.70 x 1.20 x 0.89
m
Machine weight (unloaded) (1)
360
kg
Stability limit:
Longitudinal inclination
1.5
°
Transversal inclination
1.5
°
Maximum wind speed
0
m/s
Maximum manual force:
200
N
Max. load per wheel
310
Kg
Performance:
Battery capacity and voltage
12 / 85-102
V/Ah (c5-c20)
Standard battery type
Gel
Total electrolyte quantity
(7)
Lt.
Battery weight
32
kg
Single-phase battery charger
12 / 10 HF
V/A
Max. current absorbed by the battery charger
4
A
Electric pump power
0.8
kW
Max. absorbed current
150
A
Lowering/lifting time (unloaded)
20 / 27
Sec.
Oil tank capacity
2
Lt.
Max. operating temperature
+50
°C
Min. operating temperature
-15
°C
( * ) me = m –(n x 80)
(1) In some cases different limits can be fixed. It is recommended to comply with the data shown on the machine plate.

Use and Maintenance Manual - XP - XLP Series
Page 14
FIG.4

Use and Maintenance Manual - XP - XLP Series
Page 15
2.3 Model XLP5 E –XLP5 E DUAL.
Dimensions:
XLP5 E
XLP5 E DUAL
Maximum working height
5.35
m
Max. platform height
3.35
m
Ground clearance
50
mm
Maximum capacity (m)
250
kg
Max. number of people on the platform (n) –indoors
1
Tool and material weight (me) * –indoors
170
kg
Max. pressure of lifting circuit
150
bar
Tyre dimensions
Ø200 x 50
mm
Type of tyres
Non-marking
polyurethane
Platform dimensions
0.57 x 1.05
m
Rails height
1.10
m
Toe board height
0.15
m
Transport dimensions with removable rails installed
0.70 x 1.20 x 1.96
m
Transport dimensions with removable rails not installed
0.70 x 1.20 x 1.00
m
Machine weight (unloaded) (1)
430
kg
Stability limit:
Longitudinal inclination
1.5
°
Transversal inclination
1
°
Maximum wind speed
0
m/s
Maximum manual force:
200
N
Max. load per wheel
330
Kg
Performance:
Battery capacity and voltage
12 / 85-102
V/Ah (c5-c20)
Standard battery type
Gel
Total electrolyte quantity
(7)
Lt.
Battery weight
32
kg
Single-phase battery charger
12 / 10 HF
V/A
Max. current absorbed by the battery charger
4
A
Electric pump power
0.8
kW
Max. absorbed current
150
A
Lowering/lifting time (unloaded)
20 / 27
Sec.
Oil tank capacity
2
Lt.
Max. operating temperature
+50
°C
Min. operating temperature
-15
°C
( * ) me = m –(n x 80)
(1) In some cases different limits can be fixed. It is recommended to comply with the data shown on the machine plate.

Use and Maintenance Manual - XP - XLP Series
Page 16
FIG.5

Use and Maintenance Manual - XP - XLP Series
Page 17
2.4 Vibrations and noise
Noise tests have been carried out under the most unfavourable conditions to study the effects on the operator.
The level of acoustic pressure weighed (A) at work places does not exceed 70dB (A) for each model to which this Use and
Maintenance manual refers.
As to vibrations in ordinary working conditions:
The average weighted quadratic value in frequency of the acceleration which the upper members have to withstand is
below 2.5 m/sec² for each of the models to which this Use and Maintenance manual refers.
The average weighted quadratic value in frequency of the acceleration which the body has to withstand is below 0.5
m/sec² for each of the models to which this Use and Maintenance manual refers.

Use and Maintenance Manual - XP - XLP Series
Page 18
3. SAFETY PRECAUTIONS
3.1 Personal protective equipment (PPE)
Always wear personal protective equipment according to
current regulations concerning industrial health and safety (in
particular, hard hat and safety shoes are COMPULSORY).
It is the operator or safety manager’s responsibility to choose
the personal protective equipment (PPE) depending on the
activity to be carried out. For their correct use and
maintenance, refer to the equipment manuals themselves.
The use of safety harness is not compulsory except in certain
countries with specific regulations. In Italy, the consolidation act
on safety, Law Decree 81/08, has made the use of a safety
harness mandatory.
FIG.6
3.2 General safety norms
Only adults (18 years old), after carefully reading this manual, are allowed to use the machine. The employer is
responsible for training.
The platform is intended for people carriage; therefore, it is necessary to comply with the current local
regulations relevant to this class of machines (see paragraphs 1).
At least two users must operate the machine, one of them on the ground, able to carry out the emergency
operations described in this handbook.
Always keep the machine at a safety distance from power lines as indicated in the next chapters.
Use the machine according to the capacity values indicated in the technical features section. The identification
plate shows the maximum number of people allowed on the platform at any one time, the maximum capacity
and the tool and material weight. Never exceed the indicated figures.
Do NOT use the framework of the platform or any of its elements for grounding connection while welding on
platform.
It is absolutely forbidden to load and/or unload persons and/or material with platform not in the access position.
It is the machine owner and/or safety manager’s responsibility to check that the maintenance and repair
operations are carried out by skilled personnel.
Harness
attachment
Safety

Use and Maintenance Manual - XP - XLP Series
Page 19
3.3 Use instructions
3.3.1 General
The electric and hydraulic circuits are provided with safety devices, calibrated and sealed by the manufacturer:
DO NOT TAMPER WITH AND MODIFY THE CALIBRATION OF ANY COMPONENT OF THE ELECTRIC AND
HYDRAULIC SYSTEMS.
The machine must be used only in areas well lit up, checking that the ground is flat and firm. The machine may
not be used if the lighting conditions are not sufficient. The machine is not equipped with any lightening system.
Before using the machine check its integrity and conservation state.
During maintenance operations do not dispose of any waste materials in the environment, but comply with
current regulations.
Do not carry out any service or maintenance operations when the machine is connected to the mains supply.
Follow the instructions given in the following paragraphs.
Do not approach the electric and hydraulic system components with sources of heat or flames.
Do not increase the max. allowed height by means of scaffolds, ladders or other.
With the machine lifted, do not fasten the platform to any structure (beams, pillars or wall).
Do not use the machine as a crane, hoist or lift.
Protect the unit (in particular the platform control panel) and the operator when working in adverse
environmental conditions (painting, de-painting, sand-blasting, washing, etc.).
Using the machine in bad weather conditions is forbidden; in particular, wind speeds must not exceed the limits
indicated in the technical specifications (to measure speeds, see following chapters).
Machines with a wind speed limit of 0 m/s are to be used indoors only.
The machine must be parked / stored in closed environments, not exposed to weather conditions, within the
temperature limits indicated in table "Technical features" and with both parking brakes on. It cannot be parked /
stored outdoors.
Do not use the machine in areas where risks of fire or explosion exist.
Do not use pressurized water jets (high-pressure cleaners) to wash the machine.
Overloading the work platform is forbidden.
Avoid knocks and/or contacts with other vehicles and fixed structures.
Leaving or accessing the work platform is forbidden unless this is in the position required for access or leaving
(see the “Accessing the platform” chapter).
3.3.2 Handling
Before handling the machine check that the connection plugs are disconnected from the power supply source.
Move the machine into working position by pushing it with both hands on the handles placed on the entry rail.
Pay attention during this procedure to avoid any hands or feet crushing.
While operating on slopes ask for colleague’s help to avoid risks.
In order to avoid any instability, use the machine on regular and firm grounds. To prevent the machine from
overturning, comply with the max. gradeability values indicated in the Technical data section under paragraph
"Stability limits". However, movements on inclined grounds are to be carried out with the utmost caution.
It is forbidden to move the machine with platform raised. To move the machine it is necessary that the work
platform is in the access position (fully lowered). No operator and/or material must be on board the platform
during the displacement of the machine.
The machine must not be used directly for road transport. Do not use it for material transport (see chapter
“Intended use”).
Do not operate the machine if components boxes are not properly closed.
Check that in the operating area there are not obstacles or other dangerous elements.
Pay particular attention to the area above the machine during lifting to avoid any crushing and collisions.
During operation keep your hands in safety position, the driver has to place them as shown in picture A or B
while the transported operator has to keep them as shown in picture C.

Use and Maintenance Manual - XP - XLP Series
Page 20
FIG.7
3.3.3 Operating procedures
The machine is equipped with an inclination control system disabling lifting in case of unstable positioning.
Working operations can be resumed only after placing the machine in a steady position. Should the tilt alarm
turn on, the machine is not correctly positioned (see paragraphs “Use instructions”) and the platform must
be brought back to safety rest position before resuming operations.
The machine is not equipped with an overload controller as in the design phase we considered stability and
overload criteria increased as reported by the EN280 in paragraphs 5.4.1.5 and 5.4.1.6 .
The machine is equipped with a device to avoid the risk of shearing and crushing in the lifting structure in
compliance with EN280:2001: the lowering movement is automatically stopped in a position where the
vertical distance between the scissor ends is over 100 mm. The operator on the platform should check that
no people are nearby the area with crushing risk, only then the lowering control can be resumed (see
chapter "Lifting and lowering").
The machine features a device for checking the state of battery charge (battery protection device): when
battery charge is at 20% this condition is signalled by a red flashing light on the voltmeter. In this condition
lifting is disabled, battery should be immediately charged.
Do not lean over the platform guard rails.
Make sure that no people, apart from the operator, are in the area where the machine is operating. While
lowering the platform, the operator on board should pay particular attention to avoid any contact with the
personnel on the ground.
During operations in public areas, in order to prevent people other than the personnel from approaching the
machine and being endangered, surround the working area by means of barriers or other suitable signs.
Lift the platform only if the machine rests on solid and horizontal surfaces (see the next chapters) and only
when all four wheels are in contact with the ground.
After each work session, always take the keys out of the control panels and keep them in a safe place to
prevent unauthorized people from using the machine.
Always place working tools in a steady position to prevent them from falling and hurting the operators on the
ground.
When choosing the positioning point of the chassis, to prevent unexpected possible contacts with obstacles, always observe the
figures carefully as these make it possible to identify the range of action of the platform ( chap. 2).
