Akai AK6520NF User manual

MODEL: AK6520NF
User Manual
65” Ultra HD
Smart TV

2
Welcome
Congratulations on your purchase!
This manual tells you all you need to know about using your new AKAI product.
Please take special note of any important safety and usage information presented with the symbol.
All products brought to you by AKAI are manufactured to the highest standards of performance and safety and, as
part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year Warranty.
We hope you will enjoy using your purchase for many years to come.

3
Contents
Networking 17
Connecting to a Wireless Network 17
Connecting to a Wired Network 17
TV Setting Menus 18
Picture 20
Audio 22
General 23
PVR Option 25
Time 27
Network 28
Lock 29
Channel 30
App Settings 32
High Dynamic Range (HDR) 33
Smart TV 34
Smart TV Applications 34
App Portals 35
Welcome 2
Contents 3
Unpack and Prepare 4
What's in the box 4
Important Tips 5
Attaching the stand 6
Wall-mounting the TV 7
Connect to power 8
Connect your antenna 8
Controls and Connections 9
Get to know your TV 9
Buttons on the TV 9
Ports on the TV 10
Remote Control 12
Setup 12
Using the Remote Control 13
Buttons on the Remote 14
On-Screen Set Up 16
TV Guide 36
Recording 37
Recording Live TV 38
Scheduled Recording 38
Playback 38
Pause Live TV (Time-shift) 39
USB Mode 40
Set up 40
Troubleshooting 42
Specications 45
Compliance and
Responsible Disposal 46

4 | UNPACK AND PREPARE
ABB
C
D
E
F
GHI J
K
See the inside flap of the
box for how to handle the
TV without damaging it!
Unpack and Prepare
What's in the box
In the box you will find:
A. 65" Ultra HD Smart TV
B. Remote Control
C. AAA Batteries
D. TV Stands
E. Screws for TV Stands
F. Warning Sheet
G. TV Toppling Safety Message
H. Quick Start Guide
I. Warranty Certificate
J. General Safety Warnings
K. User Manual
You will need:
• Phillips-head screwdriver (for stand installation)
• Someone to help you lift and install your TV
Before installing your new TV, check you have everything needed.
• Antenna cable (to watch live TV)
• Broadband internet connection (to use smart apps)

UNPACK AND PREPARE | 5
Important Tips
• Place the TV on a level surface.
• Place the TV away from any source that may generate heat or vibrations.
• Make sure there is enough space around vents for airflow.
• The remote control works up to 5 metres away from the TV.
• Unplug the TV before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Use only the power supply provided.
• It is highly recommended to use safety straps for securing the TV in place.
• Keep liquid, children and pets away from the TV at all times.

6 | UNPACK AND PREPARE
Unless you are wall-mounting the TV, you will need to
attach its stand/legs.
1. Lay the TV face-down on a soft, flat surface (like the
sofa, or a towel on a table) larger than the TV itself.
2. Match stands to the installation points on the
underside of the TV.
3. Attach the stands to the TV at the installation points
using the screws provided. (Grab a screwdriver for
this bit). Make sure the legs are facing away from
each other (not leaning inwards).
Attaching the stand
• This TV is heavy! We recommend asking
someone to help you lift it.
• Unplug the TV from the power outlet before
installing or removing the stand.
• Only touch the frame, not the screen.
• It is highly recommended to use safety straps for
securing the TV.
CAUTION!
Do not apply
excessive force as
you might damage
the screw holes.
3
1
2
3
3

UNPACK AND PREPARE | 7
400mm
Back of the TV
200mm
Wall-mounting the TV
The TV comes with holes on the back panel for use with
wall-mounting brackets (bracket not included).
Use four standard M6*10mm screws (or longer,
depending on the mounting bracket) to wall-mount this
TV (screws are not included).
• Unplug the TV from the power outlet
before wall-mounting.
• Contact a professional for assistance
with wall-mounting the TV.
Required
• VESA Mounting
Bracket
• 4 x M6*10mm
screws (or longer
as required)
The screws in the package are for securing the TV stands
only. If you are wall-mounting the TV, consult a qualified
installer for advice on bracket support and wall support.

8 | UNPACK AND PREPARE
Free-to-airTVinHD(HighDenition)
High Definition (HD) channels
provide the best viewing quality and
are available with a digital antenna
connection.
TV channels in Ultra HD resolution are
not currently available in Australia.
Therefore when you watch HD
broadcast signals on an Ultra HD TV,
the picture can appear 'soft' and lacks
the detail you see when watching the
same content on a HD TV.
Connect to power
Make sure the TV is switched off at the power outlet
until you have finished connecting your cables.
Connect your antenna
Antenna cable not included.
ABC HD
SBS ONE HD
7HD
9HD
10 HD
PRIME7 HD
WIN HD
Example
HD Channels
Don't forget to plug in the TV to the power
outlet. Leave the power switched off until
installation is finished.

CONTROLS AND CONNECTIONS | 9
See next page for more info on the connections.
Controls and Connections
Buttons on the TV
Back of TV
Get to know your TV
On/Standby light and Remote sensor
1. SOURCE : Change the input source.
2. MENU : Enter the settings menu.
3. VOL + : Increase the volume level.
4. VOL - : Decrease the volume level.
5. CH + : Select the next channel.
6. CH - : Select the previous channel.
7. : Switch the TV On or to Standby.
1
2
4
6
3
5
7

10 | CONTROLS AND CONNECTIONS
Ports on the TV
12 3 4 5 6
1Headphone Jack
SOUND
Connect to your headphones, amplifier or audio device, using an
AUX cable (not included).
2
HDMI IN
Use a high-speed
HDMI cable for
best picture and
sound quality.
SOUND SOUND
COMPUTER
All-digital connection between the TV and any HDMI device.
Supports Ultra HD resolution. Requires a high-speed HDMI cable
(not included).
3AUDIO IN
SOUND
You can use this to connect Audio to your TV for AV or Component
video inputs. Requires a RCA stereo audio cable (not included).
4AV IN CVBS/Y
You can use this to connect your DVD player. Supports Standard
Definition (SD) resolution. Requires an AV cable (not included).
5COMPONENT IN
You can use this to connect your DVD player. Supports Full High
Definition (FHD) resolution. This also requires a component cable
(not included).
6 USB
STORAGE
• PVR record and pause live TV.
• Play your stored media files (supported file codecs and
extensions may vary).
• Software updates.
HDMI IN 3
(ARC)

CONTROLS AND CONNECTIONS | 11
7 6 8 2 9 10 11
7 DIGITAL AUDIO
OUT (OPTICAL)
SOUND
Connect an external digital audio device. Use an Optical cable (not
included) to connect the unit with an amplifier, soundbar or other
audio decoding device for digital audio signal output.
8 LAN
INTERNET
Connect to your broadband modem using a network cable
(not included) for the best streaming experience. However, the TV
also has built-in Wi-Fi.
9 PC VGA
Connect to a PC or other device with a VGA cable (not included).
10 PC AUDIO
SOUND
Connect audio from your PC via a 3.5mm connector (not included).
11 ANTENNA IN
FREE-TO-AIR
TV
Connect your antenna for live TV (Antenna cable not included).
VGA AUDIO
DIGITAL
AUDIO OUT
(OPTICAL)
LAN HDMI IN 1 ANTENNA
IN
PC IN
HDMI IN 2

12 | REMOTE CONTROL
Setup
Insert two AAA size batteries according to the
polarity markings (+/-) inside the compartment. Make
sure the batteries are correctly aligned and properly
pushed into place.
Precautions When Using Batteries
• Do not use old and new batteries together.
• Do not use different types of batteries (e.g.
Manganese and Alkaline batteries) together.
• Remove the batteries from the remote if you do
not intend to use it for a long time.
• When discarding used batteries, follow any
guidelines for recycling and disposal of batteries
that apply in your local area.
• Keep batteries away from children and pets.
• Never throw batteries into a fire or expose them
to extreme heat.
Remote Control
AAA size
batteries
included

REMOTE CONTROL | 13
Using the Remote Control
To use the remote, point it towards the remote sensor
at the front of the TV. The remote will not operate if its
path is blocked.
The remote has a range of up to about 5 metres from
the TV at an angle of up to 30 degrees to either side of
the sensor, as illustrated below.
Image is an
example only.
Remote sensor
location on TV
may vary.
5m
Remote Hints and Tips
• Do not drop, step on or
otherwise impact the remote
control. This may damage the
parts or lead to malfunction.
• Do not place objects between the
remote control and the remote
sensor.
• Do not use this remote control
while simultaneously operating a
remote control for other devices.

14 | REMOTE CONTROL
Buttons on the Remote
(ON): Switch the TV to On or Standby
NUMBER BUTTONS: Key in a TV channel
number
CH.LIST: Display or exit the channel list
MENU: Access streaming apps, TV
settings
/ / / : Press the UP/DOWN/
LEFT/RIGHT buttons to navigate
RETURN: Return to the previous screen/
menu
(MUTE): Mute or restore sound
: Return to the previous viewing
channel
APPS: Direct access to YouTube, Toon
Goggles, Foxxum and Netflix app
SOURCE: Switch the input source
OK: Confirm your selection
EXIT: Exit/Quit the current screen

REMOTE CONTROL | 15
INFO: Display program information
VOL : Turn the volume up or down
GUIDE: Launch the TV Guide (DTV)
: Skip backwards
/ TIMESHIFT: Play/Pause live TV and video
playback.
: Rewind
/ / / RED/GREEN/
YELLOW/BLUE: Functions are according to
the on-screen display.
/RECORD: Record a TV program.
INDEX: Display the list of recorded programs
P.MODE: Cycle through the different picture
modes
CH : Go to the next or
previous channel
: Skip forwards
: Fast forward
/ FAV: Stop/Display your favourite
channel list
PIC SIZE: Press to select desired
screen size
S.MODE: Cycle through the different
sound modes
SUBTITLE: Enable/disable subtitles

16 | ON-SCREEN SET UP
On-Screen Set Up
Make sure equipment is properly connected (as shown on pages
10-11) before connecting the TV to power.
On/Standby light is RED
in standby mode.
On/Standby light is OFF
when the TV is on.
First Time Setup menu
When you turn the TV on for the first time, the First Time
Setup menu will appear.
Follow the prompts using the / / / / OK buttons to
select your preferences. You will be guided through:
Note: If you choose to setup Netflix or select an input source other than
DTV, the set up wizard will exit and will not let you tune TV channels.
To tune channels, go to Menu > TV Settings > Channel > Auto Scan.
2. Country 3. Environment
4. Data Collection And Firmware Update Notice
5. Connect To The Internet
6. Set Up Netix
7. Select Input Source
8. Tune TV Channels
If you make an error, you can update your preferences
in the settings menu later.
If you are using a wired network, connect an ethernet cable to the
TV and select 'wired'. The TV will automatically connect to the
Internet.
If you are using a wireless connection, select 'Wireless'. The TV will
scan for nearby wireless networks. Make sure that the TV is within
the range of your wireless modem/router, and you have your Wi-Fi
password handy.
Or, you can connect to the internet later by going to the User Menu
settings.
5. Connect To The Internet
Make sure the TV is plugged in at
the power socket and switched
on. Press the (ON) button to
turn on the TV.

NETWORKING | 17
Networking
You can set up your TV so that it can access the Internet through
your home network using a wired or wireless connection.
Connecting to a Wireless Network
• Press the MENU button on the remote to select TV
Settings > Network.
• Change network type to 'Wireless' and press OK. The TV
will automatically search nearby Wi-Fi access points. When
done, it will display a list of available networks.
• In the list of networks, press the / button to select
your home network, then press the OK button.
• When the Wi-Fi password entry screen appears, use the
on-screen keyboard. Use the / / / buttons on
the remote control to select a character and press OK to
enter it.
• Input the correct password, select ‘Connect’ and press
the OK button to connect to the network. If connection is
successful, a tick will appear next to your Wi-Fi networks's
name.
Connecting to a Wired Network
• Connect an ethernet cable to the LAN port on the back of
the TV.
• Press the MENU button on your remote to select TV
Settings > Network.
• Change the Network Type setting to 'Wired'. The TV
will automatically pick up the network setting from the
modem and connect to the network. If connection is
successful, you will see 'Connected' on-screen.
• Press the EXIT button to close the menu.
Make sure you have an
ethernet cable on hand if
you want to connect to a
wired network.
If the TV isn't connecting to the
internet check the troubleshooting
section for more info!

18 | TV SETTING MENUS
Menus Index
Picture 20
• Picture Mode
• User Mode Settings:
• Contrast, Brightness, Colour,
Sharpness, Tint
• Colour Temp
• Advanced Options:
• Backlight, Noise Reduction
• Open HDR
Audio 22
• Sound Mode
• Bass/Treble
• Balance
• Auto Volume
• Digital Audio Output
• Surround Sound
• AD Switch
TV Setting Menus
Menu Navigation Buttons
Press the MENU button and select TV Settings. See the
guide below for all the other buttons you'll need to use
to adjust and change your settings.
Function Remote Button
Display the main menu
MENU
Enter a sub menu
Select an option /
Adjust a value /
Return to the previous menu
MENU
OR RETURN
Exit a menu
EXIT
MENU
Once you have programmed
any settings, the unit will
retain them in its memory
until you change them, even
after turning the TV off.

TV SETTING MENUS | 19
General 23
• OSD Language
• Subtitle Language
• Audio Language
• Hearing Impaired
• Transparency
• Zoom Mode
• VGA Settings
• Other Settings:
• HDMI EDID, INLINK, DLC
• PVR Option
• Restore Default
• Software Update (USB)
• View End User License
Agreement
• HbbTV
• Software Update (Network)
• Software Information
PVR Option 25
• Recorded List
• Record
• Remind
• Schedule List
• PVR File System
Time 27
• Sleep Timer
• Auto Standby
• OSD Active Time
• Time Zone
• DST (Daylight Saving Time)
Network 28
• Network Type:
• Wired: (Auto Connect,
Manual Connect, Disable
Connect)
• Wireless: (Connect, Manual
Setup)
• My Network
• IP Address
Lock 29
• Change Password
• System Lock
• Channel Lock
• Parental Guidance
• Clear Lock
Channel 30
• Auto Scan
• DTV Manual Tuning
• Program Edit
• Channel List
• Favourite List
• Signal Information
App Settings 32
• Deactivate App
• Terminate App
• Netflix Version
High Dynamic Range (HDR) 33
!

20 | TV SETTING MENUS
Dynamic
Dynamic
Option Description
Contrast Adjust the contrast of the bright and dark areas of the picture. The
closer to 100, the higher the contrast.
Brightness Adjust the overall screen brightness. The closer to 100, the brighter the
picture.
Colour Adjust the saturation. The closer to 100, the deeper the colour.
Sharpness Adjust the sharpness of the picture. The closer to 100, the sharper and
clearer the image.
Tint Adjust the colour balance between red and green. (Only available with
NTSC video standard. Australia uses PAL video standard.)
User Mode settings
User
To adjust the brightness,
change the Picture Mode
to User and modify the
Brightness setting.
Picture Mode
Dynamic : Brighter and clearer picture settings for bright viewing environments.
Dynamic
:Picturesettingforgeneralviewingenvironmentsandisenergyefcient.
Movie : Settings are optimised for viewing movies.
: Adjust settings to best suit your viewing environment and content.
Standard
