Akura MB18 IDTV User manual

-1-
Contents
No-Signal Detection (TV)....................24
Volume Bar.........................................24
AVModes............................................24
Teletext .................................................. 24
To Operate Teletext.............................24
To SelectAPage Of Teletext ...............25
To Select Index Page..........................25
ToSelectTeletextWithATVProgramme.25
To Select Double Height Text .............25
To Reveal “Concealed” Information ...25
To Stop Automatic Page Change........25
To Select A Subcode Page .................25
To Exit Teletext ....................................25
To Display The Time ..........................25
Fastext................................................26
Connect Peripheral Equipment ............26
Via The Euroconnector.......................26
ViaAntInput ........................................26
Decoder..............................................26
TVAnd Video Recorder.......................27
Playback NTSC ..................................27
Search For And Store The Test
Signal Of The Video Recorder............27
Camera And Camcorder ....................27
To Connect to S-Video Input...............27
Connect The Decoder To The Video
Recorder.............................................27
Connecting Headphones...................27
Tips ........................................................28
Peripheral Equipment Connections .....29
Specifications .......................................32
Important Instruction ............................33
Safety Precautions .................................2
Remote Control Batteries ....................2
Features ...............................................3
Control Panel Buttons ............................ 4
Remote Control Buttons .........................5
Before Switching On Your TV ................. 6
Power Connection................................6
Connections To The RF Input Socket ..6
How To Connect Other Devices ...........6
Switching The TV ON/OFF ....................... 6
To switch the TV on:..............................6
To switch the TV off:..............................6
Initial Settings .........................................6
Basic Operations .................................... 8
Everyday Operation ................................ 8
Information Banner ..............................8
Electronic Programme Guide (EPG)....9
Displaying The Subtitles ....................10
Digital Teletext ....................................10
Over Air Download ..............................10
Widescreen ........................................10
IDTV Menu System................................ 11
Channel List ....................................... 11
Installation ..........................................13
Configuration......................................14
Timers ................................................16
Language ...........................................17
TVSetup .............................................17
Common Interface .............................17
Analogue TV Menu System ..................18
Picture Menu.......................................18
Audio Menu........................................18
Window menu ....................................20
options menu .....................................20
settings menu ....................................21
Other Features ...................................... 23
TVStatus.............................................23
Programme Swap (P<P) ....................23
Personal Preferences (PP) ................23
Sound Indicator ..................................23
Picture Mode.......................................24
Mute Indicator .....................................24
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:361

-2-
Safety Precautions
1. Power Source
The TV set is designed to operate on 12V DC.
The adaptor should be operated from a 230-
240V AC, 50 Hz. outlet. Ensure you select the
correctvoltage setting for your convenience.
2. Power Cord
The power supply cord should be placed so
that it is not likely to be walked on or pinched
by items placed upon them or against it. Pay
particular attention to cord where it enters
the plug, power outlet, and the point where it
exits from the receiver.
3. Moisture and Water
Do not use this equipment in a humid and
damp place (avoid the bathroom, the sink in
the kitchen, and near the washing machine).
Do not expose this equipment to rain or wa-
ter, as this may be dangerous and do not
place objects filled with liquids on top. Avoid
from dripping or splashing.
4. Cleaning
Before cleaning, disconnect the mains sup-
ply. Do not use chemical cleaning agents.
Use a dry duster. For sticky stains, use a
damp cloth with a mild detergent.
5. Ventilation
The slots and openings on the receiver are
intended for ventilation and to ensure reli-
able operation. To prevent overheating,
these openings must not be blocked or cov-
ered in anyway.
6. Lightning
In the case of a Thunderstorm, or when leav-
ing the Tv for long periods, disconnect the
Aerial lead (if outdoor) and the mains supply
to prevent power surges damaging the Tv.
7. Replacement Part
When replacement parts are required, be sure
the service technician has used replacement
parts which are specified by the manufacturer
or have the same specifications as the origi-
nal one. Unauthorised substitutions may re-
sult in fire, electrical shock, or other hazards.
8. Servicing
Please refer all servicing to qualified per-
sonnel. Do not remove cover as this may re-
sult in electric shock.
9. Naked Flame Sources
Do not place naked flame sources on the
apparatus.
WARNING: When the device is not in use
for a long time, disconnect from power.
Instructions for waste disposal:
• Packaging and packaging aids are recy-
clable and should principally be recycled.
Packaging materials, such as foil bag, must
be kept away from children.
Remote Control Batteries
When batteries are exhausted do not throw in
the domestic waste. Contact the local waste
authority.
Do NOT break open or throw on a fire, they
may cause injury or damage.
“DO NOT LEAVE YOUR TV AT STAND-BY OR
OPERATINGWHENYOU LEAVEYOURHOUSE”
"The LCD panel is very high technology
product with about a million thin film tran-
sistors, giving you fine picture details. Oc-
casionally, a few non-active pixels may ap-
pear on the screen as a fixed point of blue,
green or red. Please note that this does not
affect the performance of your product."
" The mains plug of the power supply is
used as disconnect device and therefore
shall remain readily operable. "
“DO use the power cord given/supplied by
the manufacturer for the AC adaptor of the
product”.
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:362

-3-
• Programme swapping between the last two
programmes.
• Forward or backward automatic tuning.
• Sleep timer.
• Child Lock
• Automatic sound mute when no transmis-
sion.
•Auto, Fill all and Wide picture modes.
• NTSC Playback.
• BAV in is available.
• SVHS is available.
• AVL (Automatic Volume Limiting)
• When no valid signal is detected, after 5
minutes the TV switches itself automatically
to stand-by mode.
• PLL (Frequency Search)
• High resolution, 20” TFT LCD display.
Correct disposal of this Product
(Waste Electrical & Electronic Equipment (WEEE)
The crossed out “Wheelie bin” is intended to show that this appliance must
not be placed with ordinary household waste at the end of its useful life. To
prevent possible harm to the environment or human health from uncon-
trolled waste disposal, please keep separate from other household waste
and recycle it responsibly to promote the sustainable reuse of material re-
sources.
Household users should contact either the retailer where you purchased the product, or
their local government office for details of where and how you can take this item for envi-
ronmentally safe re-cycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product must not be mixed with other commercial wastes for dis-
posal. The lightning flash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of un-insulated “dangerous
voltage” within the products enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to the persons.
The exclamation point within an equilateral triangle is intend to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Features
• Remote controlled color television.
• 100 programmes from VHF, UHF bands or
cable channels can be preset.
• It can tune to cable channels.
• Controlling the TV is very easy by its menu
driven system.
• It has an Euroconnector socket for an exter-
nal device (such as video, video games, au-
dio set, etc.)
• Stereo sound system (German+Nicam).
• Full function Teletext.
Fastext .
• Headphone connection.
• Direct channel access.
•A.P.S. (Automatic Programming System).
• All programmes can be named.
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:363

-4-
Control Panel Buttons
TV/AV
MENUP/C HVOLUME
- P/CH +
MENU
LED
TV/AV
- VOLUME + POWER
ON/OFF
INFRARED RECEIVER
SPEAKER
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:374

-5-
Remote Control Buttons
= Stand By
= Cursor Up
= Cursor Right
OK / SELECT = Okay(Store)
INFO= Info (In Digital Broadcast)
0 - 9 = Digit buttons
-/-- / EXIT = Double Digit
P<P =Previous Programme
P/CH + = Programme Up
+= Volume +
DTV / TV =TV / DTV mode (To change between
Analogue-Digital Broadcast)
AV = External Source
(AV-1, RGB1,AV-2,SVHS, IDTV)
Yellow*
Blue *
= Hold
= Update, = No function
/GUIDE = IndexPage
= Reveal, PC = No function
= Expand, WIDE =Aspect ratio
= No Function
= Teletext
= Time
Red* /
Green */
= Mute
I-II =Mono/Stereo - Dual I-II
-= Volume -
- P/CH = Programme Down
PP = Colour Temperature
M= Menu
31
= Cursor Down
32
= Cursor Left
Coloured buttons are used in ELECTRONIC
PROGRAMME GUIDE (7 Day) menu navigation
and in digital teletext.
M
OK
21 3
54 6
87 9
0
5
6
7
8
9
10
11
12
13
14
15
16
22
24
25
26
27
28
29
30
31
32
23
1
2
4
17
18
19
20
3
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:375

-6-
Before Switching On Your TV
Power Connection
AC adapter
To POWER
INPUT DC 12 V
terminal
IMPORTANT: The TV set is designed to op-
erate on 12V DC. For this, an adaptor is
used which gives 12V DC voltage. Connect
this adaptor to a system that supplies 230-
240V AC, 50 Hz.
•After unpacking, allowthe TV set to reach the
ambient room temperature before you con-
nect the set to the mains.
Connections To The RF Input
Socket
VHF/UHF
75

REAR OF THE TV
CABLE TV
Connect the aerial or cable connection to the
RF input socket at the back of the Tv. You
may also connect RF outputs from a VCR to
this socket.
How To Connect Other Devices
IMPORTANT: Switch off the TV before con-
necting any external device.
Sockets for external connections are at the
rear side of the TV. For connection of other
devices via Euroconnector refer to the manu-
als of the related devices.
Switching The TV ON/OFF
To switch the TV on:
Your TV will switch on in two steps:
1- Connect the power supply cord to the sys-
tem. Press On/Off switch at the rear of the
TV. Then the TV switches itself to stand-
by mode and the LED becomes RED lo-
cated onthe front of the TV.
2- To switch on the TV from stand-by mode
either:
Press a digit button on the remote control so
that a programme number is selected,
or,
Press “ ”, "-P/CH" or "P/CH+" button on the
top of the TV or press “-P/CH” or “P/CH+”
button on the remote control, so that last
switched off programme is selected.
By either ways the TV will switch on and the
LED will turn off.
To switch the TV off:
• Press the “stand-by” button on the remote
control, so the TV will switch to stand-by
mode and the LED will become RED,
or,
Press the “ ” button located on the top of
the TV, so the TV will switch off and the LED
will become RED.
To power down the TV completely, press
On/Off switch,
or
unplug the power cord from the mains
socket.
Initial Settings
When the TV is turned on for the first time, it
is in the digital mode.
Because this is the first time the TV is used, there
are no channels stored in the memory and the
following message appears on the screen.
Please ensure aerial is plugged in. Do you
want to start first time installation?
Yes No
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:376

-7-
A.P.S. WARNING
all prestored programs
will be deleted
<M> to exit <OK> to start
Press OK to start and wait for finalized APS.
After APS is finalized, a programme list will
appear on the screen. In the programme list
you will see the programme numbers and
names assigned to the programmes.
down to adjust channel order
program table
1
5
6
7
8
9
10
11
12
2
3
417
18
19
20
21
22
23
24
29
30
31
32
33
34
35
36
16
28
ZDF
ITV
C 5
BB C1
C 6
C 8
C 21
13
14
15
25
26
27
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
-----
If you do not accept the locations and / or the
programme names of programmes, you
can change them in Program menu. For de-
tails see Program menu on page 23.
To display channel list in IDTV, switch to the
IDTV via pressing the “TV/DTV” button.
Then press the “M” button to enter main
menu, Channel List will be highlighted.
Press the “SELECT” button to enter the
menu. For detailed information see page
11.
• To start installation process, select “Yes”,
to cancel select “No”.
• To select an option “Yes or No”, highlight
the item by using or buttons and press
the “OK”button.
The IDTV will automatically tune to the UHF
transmision channels 21 to 68 looking for
digital terrestrial TV broadcasts and display-
ing the names of channels found. This pro-
cess will take about five minutes. To cancel
searching, you can press the “M” button at
any time during the process.
MENU
BBC ONE
BBC TWO
BBC CHOICE
Searching UHF channels 30. Please wait. This will take a few minutes
Cancel searching
AUTOMATIC SEARCH
Channels:
12 %
After Automatic Search process is com-
pleted, the following message asking for
analogue channel search appears on the
screen. TV switches to the analogue TV
mode.
Yes
Do you want to search for
analogue channels?
No
To seach for analogue channels, select
“Yes”. The menu below is displayed to
search for analogue channels.
down for A.P.S.
A.P.S.
country
A.P.S.
UK
By pressing or button, adjust the
“Country” item.
Press button to select “Continue” item and
/ or OK buttonstostartAPSoperation.
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:377

-8-
Basic Operations
You can operate your TV using both the
remote control and onset buttons.
Operation with the buttons on the TV
Volume Setting
• Press “ -” button to decrease volume or
“+” button to increase volume, so a vol-
ume level scale (slider) will be displayed at
the middle of the bottom on the screen.
Programme Selection
• Press “P/CH +” button to select the next pro-
gramme or “P/CH -” button to select the pre-
vious programme.
Entering Main Menu
• Press the “MENU” button to enter Main
menu. In the Main menu select sub-menu
using “ +” or “ -” buttons and enter
the sub-menu using “P/CH +” or “P/CH -”
buttons. To learn the usage of the menus,
refer to the Menu System sections.
AV Mode
Press the “TV / AV” button at the control
panel on the right side of the TV to switch
your TV to AV modes.
Operation with Remote Control
The remote control of your TV is designed to
control all the functions of the model you se-
lected. The functions will be described in ac-
cordance with the menu system of your TV.
Functions of the menu system are de-
scribed in the following sections.
Volume Setting
Press “ +” button to increase volume.
Press “ -” button to decrease volume. A
volume level scale (slider) will be displayed
in the middle at the bottom of the screen.
Programme Selection (Previous or next
programme)
• Press “P/CH -” button to select the previous
programme.
• Press “P/CH +” button to select the next pro-
gramme.
Programme Selection (direct access):
Press digit buttons on the remote control to
select programmes between 0 and 9. TV
will switch to the selected programme. To
select programmes between 10 - 999 (for
IDTV) or 10-99 (for analogue), press the digit
buttons consecutively which programme you
want to select (eg. for programme 27, first
press 2 and then 7). When it is late to press
second digit button only the first digit pro-
gramme will be displayed. The limit of the
delay time is 3 seconds.
Press directly the programme number to
reselect single digit programmes.
Everyday Operation
Pressing the “TV/DTV” button at any time
while watching television programmes will
switch the TV set between displaying the
digital terrestrial television broadcasting and
its normal analogue broadcasting.
Information Banner
Whenever you change channel, using the
“P/CH +” /“- P/CH” button or the digit but-
tons, TV displays the channel picture along
with an information banner at the bottom of
the screen. This will remain on the screen
for approximately three seconds. The infor-
mation banner can also be displayed at any
time while watching TV by pressing the
“INFO” button on the remote control.
Now: 50/50
Next:Ace Lighting
1. BBC ONE Signal Level: 13:15
09:25 - 11:00
11:00 - 11:25
The information banner gives a number of
facts on the channel selected and the
programmes on it. The name of the channel
is displayed, along with its channel list num-
ber and an indication of the strength of the
signal received on this tuning channel.
Hint
N o t a l l c h a n n e l s b r o a d c a s t t h e
programme data. If the name and times of
the programme is not available then “No
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:378

-9-
Information Available” are displayed in the
information banner.
Icons are also displayed in the information
banner and if this channel is a favourite
channel:
Favourite channel icon .
If the selected channel is locked, you must
enter the correct four digit code to view the
channel.
Enter Lock Key
Electronic Programme Guide (EPG)
Some, but not all, channels send informa-
tion about the current and next events.
Please note that event information is up-
dated automatically. If there is no event infor-
mation data available in channels, only
channel names with “No Information Avail-
able” banner is displayed.
• Press “GUIDE” button to view the EPG
menu.
• In EPG Menu, you can easily see the ex-
tended help information by pressing “INFO”
button and by pressing this button again you
can close this window.
ELECTRONIC PROGRAMME GUIDE (Now/Next) Wed 23/3 13:25
ITV News 14:00-15:00
Rolling national and international news
including breaking news as it happens,
business updates, sports results and
weather summaries.
Channels
Current Programme
Next Programme
30. CBBC Channel
40. BBC NEWS 24
41. ITV News
50. FourText
51. BBCi
ChuckleVision
BBC NEWS
ITV News
No Information
BBCi
Tracy Beaker
BBC NEWS
ITV News
No Information
BBCi
i
MENU
Navigate Current
Reminder
7 Day EPG
More
SELECT
• In the EPG Menu all channels are dis-
played. Current channel is highlighted. Use
or buttons to change channels. Also
press or buttons to make page up/
down scroll for the channels.
• If you highlight an event, short event de-
scription, extended event description, start
and finish times of event are displayed on
the screen.
• When the current programme is high-
lighted, the box is switched to the highlighted
channel by pressing the “SELECT” button.
• If you press the “SELECT” button when a
next event is highlighted, a reminder is set
for the highlighted programme and a clock
appears across the highlighted channel
line.
Programme reminders can be set to signal
that a programme is about to start when you
are watching another channel. If you set re-
minder to a programme, then you will be
asked for switching to that channel when the
reminder time is reached.
• Press the “M” button to view the 7 day
EPG.
• Press or button to navigate in Chan-
nels or Programmes.
• Press or button to navigate through
the channel and programme list.
ELECTRONIC PROGRAMME GUIDE (7 Day) Wed 23/3 13:25
ChuckleVision 13:00-14:00
Triple bill. In the Ring/Romany Days/On the Radio: Paul and Barry
grapple with the world of wrestling: hunt for a mysterious Emperor’s
underpants: and record their first pop song.
Channels Programmes on Wed 23/3, 13:00 - 15:00
30. CBBC Channel
40. BBC NEWS 24
41. ITV News
50. FourText
51. BBCi
800. BLUE/LEFT 1k...
801. CCIR17/1kHz...
13:00 ChuckleVision
14:00 Tracy Beaker
14:55 Newsround
Navigate
Change Time Change Day
i
More
• With “RED/GREEN” buttons you can
change schedule time. By pressing “YEL-
LOW/BLUE” you can advance the schedule
backward / forward of a day.
• If you press “INFO” button you can see the
detailed help information easily. And by
pressing “INFO” button again you can exit
Help menu.
• The starting time for EPG is the current
time.You can see the event information for
the next two hours. By pressing or but-
ton, you can go to the next/previous hours
while Programmes list is highlighted.
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:379

- 10 -
• lf you press the “SELECT” button when a
next event is highlighted, a reminder is set
for the highlighted programme and a clock
appears on the screen. Programme remind-
ers can be set to signal that a programme is
about to start when you are watching an-
other channel. If you set reminder to a
programme, then you will be asked for
switching to that channel when the reminder
time is reached.
CBBC joins the Newsround team, keeping you up to date on the latest
stories and events happening at home and abroad.
Channels Programmes on Wed 23/3, 15:00 - 17:00
30. CBBC Channel
40. BBC NEWS 24
41. ITV News
50. FourText
51. BBCi
800. BLUE/LEFT 1k...
801. CCIR17/1kHz...
15:00 Even Stevens
15:50 Newsround Showbiz
16:00 Basil Brush
16:55 Newsround
Navigate
Change Time Change Day
i
More
ELECTRONIC PROGRAMME GUIDE (7 Day)
Wed 23/3 13:25
Newsround 16:55-17:00
Displaying The Subtitles
With Digital terrestrial broadcasting (DVB-T),
some programmes are broadcast with sub-
titles. Subtitles can be displayed when
watching these programmes.
Press the “M” button to display the Main
menu, highlight the Configuration line using
or button and press the “SELECT” but-
ton to display the Configuration menu.
Highlight the “Subtitle” item in Configura-
tion menu and use or button to set
Subtitle to off or a language.
If “Subtitle” is on via selecting one language
option, pressing the button causes the
following warning message display on the
screen.
Interactive services cannot be used
while subtitles are on. Would you like
to turn subtitles off now?
Yes No
Digital Teletext
With Digital terrestrial broadcasting (DVB-T),
in addition to pictures and sound, you can
also watch digital teletext.
Digital teletext is sometimes broadcast at
the same time as normal broadcasting.
1. Press the button.
The digital teletext information appears.
2. Operate it with the coloured buttons, /
buttons and OK button.
The operation method may differ depending
on the contents of the digital teletext.
Follow the instructions displayed on digital
teletext screen.
• When “Press SELECT” button or similar
message appears on the screen, press the
“SELECT” button.
• When the (Text) button is pressed, the
TV returns to television broadcasting.
• With Digital terrestrial broadcasting (DVB-
T), in addition to digital teletext broadcasting
at the same time as normal broadcasting,
there are also channels with just digital tele-
text broadcasting.
• The aspect ratio when watching a channel
with just digital teletext broadcasting is the
same as the aspect ratio of the picture
watched previously.
• When you press the (Text) button
again, the digital teletext screen is dis-
played.
Over Air Download
To ensure that your IDTV always has the
most up-to-date information, please ensure
that after use it is set to its standby mode. At
3AM each day, the IDTV automatically
searches for any new information which
may be broadcast and will download this to
your IDTV automatically. This operation will
normally take approximately 30 seconds.
If you want to do this, you need to set Auto-
matic Download to “Enabled” in Receiver
Upgrade setting. For details see page 16.
Widescreen
Depending on the type of broadcast being
transmitted, programmes can be viewed in
a number of formats. Press the “WIDE” but-
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3710

- 11 -
ton repeatedly to select between Auto,fill all
or wide.
When Auto is selected, the format being dis-
played is determined by the picture being
broadcast.
Please Note: Menu size changes depending
on the chosen image size.
IDTVMenu System
The IDTV menu can only be shown when
watching Digital terrestrial broadcasting.
Press the “TV/DTV” button to turn IDTV on
while TV is in analogue mode.
Press the “M” button. The menu below
appears on the screen:
Main Menu
Channel List
Installation
Configuration
Timers
Language
TV Setup
Common Interface
Channel List
Using the or button on the remote con-
trol in Main menu, make sure that the first
item, Channel List, is highlighted and press
the “SELECT” button to display the Channel
List.
The following operations can be performed
in this menu:
1. Navigating the whole list of channels
2. Deleting channels
3. Renaming channels
4. Adding locks to channels
5. Setting favourites
Channel List is the place where the chan-
nels are managed.
SELECT
i
SELECT
CHANNEL LIST 1 BBC ONE
1. BBC ONE
2. BBC TWO
3. ITV 8
4. Channel 4
5. BBC THREE
6. Teletext
7. BBC FOUR
8. Sky Travel
9. UKHistory
10. RTL
Select Delete Edit Name Lock Favourites
Function Select Channel Watch More
Navigating the whole channel list
Press or button for selecting the previ-
ous or next channel. You can press or
button to move page up or page down.
To watch a specific channel, highlight it us-
ing or button and then press “SELECT”
button, while the “Select” item on Channel
List menu is highlighted by using or
button.
Then the name and number of the selected
channel will be displayed in the top-left and
top-right of the channel display at the top-
right of the screen, respectively.
Deleting the channels in the channel list
Press or button to select the channel
that will be deleted.
Press or button to select the ‘’Delete’’
item on Channel List menu. As seen on
Channel List menu, SELECT is written next
to Delete item at the bottom of the screen to
indicate that press the “SELECT” button to
delete the highlighted channel in the chan-
nel list.
SELECT
i
SELECT
CHANNEL LIST 1 BBC ONE
1. BBC ONE
2. BBC TWO
3. ITV 8
4. Channel 4
5. BBC THREE
6. Teletext
7. BBC FOUR
8. Sky Travel
9. UKHistory
10. RTL
Select Delete Edit Name Lock Favourites
Function Select Channel Delete More
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3711

- 12 -
Press the “SELECT’’ button to delete the
highlighted channel in the channel list. Then
the message below appears on the screen.
The selected service will be permanently
deleted. Are you sure?
Yes No
Press or button to highlight the desired
option. If “SELECT’’ button is pressed while
“Yes” is highlighted, the highlighted channel
is deleted. Selecting “No” cancels the delete
operation.
Renaming channels
To rename a specific channel, the channel
must be highlighted via pressing or
button and then highlight the Edit Name item
by pressing or button. Press the “SE-
LECT” to activate rename feature.
SELECT
i
SELECT
CHANNEL LIST 1 BBC ONE
1. BBC ONE
2. BBC TWO
3. ITV 8
4. Channel 4
5. BBC THREE
6. Teletext
7. BBC FOUR
8. Sky Travel
9. UKHistory
10. RTL
Select Delete Edit Name Lock Favourites
Function Select Channel Edit Name More
Now pressing or button moves to the
previous/next character. Pressing or
button toggles the current character, i.e., ‘b’
character becomes ‘a’ by and ‘c’ by .
Pressing the numeric buttons ‘0...9’ re-
places the highlighted character with the
characters printed above the button one by
one as the button is pressed.
Press the “M” button to cancel the editing or
“SELECT” button to save the new name.
Adding locks to channels
Channel Locking provides a password-pro-
tected access to channels selected by parents.
In order to lock a channel you should know the
Parental Lock password (default value is set to
0000 in the factory and can only be changed
fromthe Configuration Menu).
Select the channel to be locked by highlight-
ing it and select the “Lock” option by press-
ing or button. When the “SELECT” but-
ton is pressed, a password box is dis-
played.
SELECT
i
SELECT
CHANNEL LIST 1 BBC ONE
1. BBC ONE
2. BBC TWO
3. ITV 8
4. Channel 4
5. BBC THREE
6. Teletext
7. BBC FOUR
8. Sky Travel
9. UKHistory
10. RTL
Select Delete Edit Name Lock Favourites
Function Select Channel Lock/Unlock More
Enter Lock Key
Enter the password using the digit buttons
on the remote control. The Lock icon will
now be displayed next to the selected chan-
nel. Repeat the same operation to cancel
the Lock.
Setting Favourites
You can set various channels as favourites
so that only the favourite channels are navi-
gated. To set a favourite you should highlight
the “Favourites” item at bottom of the Chan-
nel List menu.
Use the or button to highlight the
“Favourites” item at the base of the screen
and then, in turn, highlight each channel you
want to add to the favourites list, using the
and buttons (or / buttons), and
press the “SELECT” button.
A channel selected as a favourite appears
in the main channel list with a favourites
icon ( ) against the channel name.
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3712

- 13 -
SELECT
i
SELECT
CHANNEL LIST 1 BBC ONE
1. BBC ONE
2. BBC TWO
3. ITV 8
4. Channel 4
5. BBC THREE
6. Teletext
7. BBC FOUR
8. Sky Travel
9. UKHistory
10. RTL
Select Delete Edit Name Lock Favourites
Function Select Channel Add/Remove... More
On Screen Help Pressing INFO Button
For all menus press the “INFO” button to
display the help information about the menu
functions. For Channel List menu the follow-
ing message is displayed on the screen.
Press the SELECT button on your remote control to tune to the
highlighted channel.
Press MENU to exit this screen.
Installation
The Installation menu mainly intends to help
you for building a Channel Table in most effi-
cient way.
Main Menu
Channel List
Installation
Configuration
Timers
Language
TV Setup
Common Interface
This menu includes the following items:
1. Add New Channels
2. First Time Installation.
ADD NEW CHANNELS:
This tuning menu consists of two parts:
Automatic Search
Manual Search
Installation
Add New Channels
First Time Installation Automatic Search Manual Search
Automatic Search:
Automatic search is started by pressing the
“SELECT” button in the auto-search pop up
menu. All the services are searched and a
channel table is created automatically.
All channels found are stored in a sorted
form with respect to their channel numbers.
Some services may not appear with the cor-
rect channel number. At the time of printing,
not all broadcasters are sending their chan-
nel number information.
Manual Search:
In manual search, the number of the multi-
plex is entered manually and only that multi-
plex is searched for the channels. For every
valid channel number, signal level, signal
quality and network name are shown at the
bottom of the screen.
In both manual and auto search any existing
channel in the database is not re-stored to
avoid redundant duplicates of that channel.
FIRST TIME INSTALLATION
The user can use this item to load default
settings, which had been loaded to the re-
ceiver at the factory.
To install factory settings, highlight “First
Time Installation” menu and press the “SE-
LECT” button, then you will be asked to con-
firm for deleting all channels and settings.
Installation
Add New Channels
First Time Installation
Yes
Your previous digital channel list will be destroyed.
Are you sure you want to delete all digital channels
and settings for first time installation?
No
By selecting YES and pressing the “SE-
LECT” button, the existing channel table will
be deleted.
After factory settings is loaded, “First Time
Installation” menu will be displayed.
Please ensure aerial is plugged in. Do you
want to start first time installation?
Yes No
Press the “SELECT” button to start installa-
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3713

- 14 -
tion. After search is completed for digital
channels, a message asking search for
analogue channels appears on the screen.
Yes
Do you want to search for
analogue channels?
No
Press the “SELECT” button to search for
analogue channels.The following menu ap-
pears on the screen for analogue channel
search.
down for A.P.S.
A.P.S.
country
A.P.S.
UK
By pressing or button, adjust the
“Country” item.
Press button to select “A.P.S” item and
/ or OK buttons to start APS operation.
A.P.S WARNING
All prestored programs
will be deleted
<M> to cancel <OK> to start
After APS is finalized, the programme table
will appear on the screen. In the programme
table you will see the programme numbers
and names assigned to the programmes.
If you do not accept the locations and / or the
programme names, you can change them
in the Program menu. (See page 22 for Pro-
gram table explanation.)
Configuration
Press the “M” button to display the Main
Menu and the button twice to highlight
Configuration, then press the “SELECT” but-
ton to display the Configuration menu. Press
the “M” button to leave the menu.
Main Menu
Channel List
Installation
Configuration
Timers
Language
TV Setup
Common Interface
The various configuration functions are dis-
played in a list, along with a quarter-screen
image of the currently selected channel. You
can select a function by highlighting the cor-
responding menu line using the or but-
ton.
i
CONFIGURATION
Audio Language
Subtitle
Favourite Mode
EPG Preference
Receiver Upgrade
Parental Settings
English
Off
Off
Now&Next
V.1.5
Change Default Audio Language
More
Audio Language
Digital terrestrial television channels can
broadcast simultaneous soundtracks in
more than one language. This function se-
lects which language soundtrack you will
hear when switching to a channel broad-
casting with the multiple soundtracks.
Highlight the Audio Language line in the
Configuration menu and use the or but-
ton to cycle through the language options.
Subtitle
Digital terrestrial television channels can
broadcast subtitles displayed on-screen for
the hard-of-hearing. This function selects
the desired subtitle language and enables
the automatic display of subtitles whenever
subtitle information is broadcast.
Highlight the Subtitle line in the Configura-
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3714

- 15 -
tion menu and use the or button to
cycle through “Off” and language options.
Favourite Mode
This function enables or disables the
favourite channel list mode. See Channel
List menu Favourites on page13.
Use or button to turn on/off favourite
mode. If the “Favourite Mode” is on, in nor-
mal operating mode pressing “P/CH+” and “-
P/CH” buttons will only navigate through the
channels that were previously defined as
favourites in Channel List.
EPG Preference
Digital terrestrial television channels can
broadcast simultaneous Next&Now and 7-
Day electronic programme.
Highlight the EPG Preference line in the
Configuration menu and use the or but-
ton to selectNext&Now or 7-Day.
Receiver Upgrade
The IDTV can be upgraded via the configura-
tion menu, entered from the main menu.
In the Configuration menu, highlight the
“Receiver Upgrade” item by pressing or
button and press the “SELECT” button to
start upgrade process.
There are two possibilities for Receiver soft-
ware to be upgraded: automatic and
manual.
i
CONFIGURATION
Audio Language
Subtitle
Favourite Mode
EPG Preference
Receiver Upgrade
Parental Settings
English
Off
Off
Now&Next
V.1.5
Exit More
Automatic Download
Search for New Version Enabled
MENU
Automatic Download (Automatic upgrade)
Automatic Download can be enabled or
disabled by pressing or button. If it is
enabled, then there are two ways for auto-
matic upgrade. The first one is checking the
existence of a new software every time the
IDTV goes to standby. The second one is
waking up at 03:00 a.m. every night, pro-
vided that the IDTV is left in standby mode.
Both automatic upgrade methods result in
standby mode either upgraded or not.
If the automatic upgrade is set to “Disabled”
then this function will not work.
Search For New Version (Manual upgrade)
Manual upgrade starts if the “Search for
New Version” item is highlighted by using
or button and activated via pressing
the “SELECT” button.
After “Search for New Version” is acti-
vated, the IDTV tunes to each frequency that
have been stored in its database and looks
for the new software.
Software Upgrade
Searching for upgrade. Please wait, or
press MENU to cancel.
Search Progress:
Parental Settings
Some channels broadcast material which
you do not want younger members of the
family to watch. Any channel can be ‘locked’
so that it cannot be selected for viewing with-
out first a four-digit PIN code being entered.
In this way any channel not suitable for
younger viewers can be protected.
This function enables or disables the menu
protection system and allows the PIN code
to be changed.
Use or button to go to Parental Set-
tings option. Press the “SELECT” button to
enter Parental Settings Menu. A box asking
for the lock key is displayed.
Enter Lock Key
There is only one key which is set to “0000”
initially. Enter lock key. If wrong Lock key is
entered, the following message is displayed
on the screen and it is returned back.
Wrong Lock Key
If it is correct, the Parental Settings Menu in-
cluding following items is displayed:
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3715

- 16 -
Menu Lock Installation
Set Lock Key
There you can set/reset locking for the Main
Menu, or the Installation Menu to restrict ac-
cess. If the menu lock is disabled, there will
be free access to the menu system. Also in
this menu you can change the lock key and
set/change parental lock mode.
Disabled: All menus are unlocked.
Main Menu: Main menu is accessible only
with the correct lock key. So the user cannot
add, delete, rename, move channels, cannot
set timers.
Installation: Installation menu is locked, so
the user cannot add channels.
Changes will be updated after exiting Con-
figuration Menu.
Timers
You can set a timer to switch the TV to any
channel without your intervention. This is
also for making video recordings of
programmes when you are out.
Display the Main Menu by pressing the “M”
button. Highlight the Timers line by pressing
or button and press the “SELECT” but-
ton to display the Timer menu.
Main Menu
Channel List
Installation
Configuration
Timers
Language
TV Setup
Common Interface
Up to five separate timer events can be set
and each is displayed in the Timer screen,
showing the event number, the channel to
be selected, the start time, end time, date
and the mode - whether that event is active
(and will be acted on) or not.
SELECT
i
MENU
TIMER MENU
No Channel Name Start End Date Mode
1. ITV 1 20:00 21:00 12/05/2005 Active
2. BBC ONE 00:00 00:00 01/01/2005 Inactive
3. BBC ONE 00:00 00:00 01/01/2005 Inactive
4. BBC ONE 00:00 00:00 01/01/2005 Inactive
5. BBC ONE 00:00 00:00 01/01/2005 Inactive
6. BBC ONE 00:00 00:00 01/01/2005 Inactive
Toggle Mode Exit Edit Timer More
• To set an event, highlight its mode button
using the or button and press the “SE-
LECT” button to display the timer entry win-
dow.
Name:
Start:
End:
Date:
Mode:
3. ITV 1
00:00
00:00
03/06/2005
Once
• Here the five settings of channel name,
start time, end time, date and frequency
mode can be set. You can move freely be-
tween each setting using the or but-
tons.
• The channel name is set using the or
button to display the channel which broad-
casts the programme.
• The start time, end time and date are each
set with the digit buttons on the remote con-
trol in 24-hour format.
• The frequency mode determines how of-
ten the receiver operates this event and is
set with the or button to be either Once,
Daily, or Weekly.
If an invalid number for the start or end times
or the date is entered, “Entered time is not
valid” message appears on the menu.
If timer action occurs while the DigitalTV is
watched, the TV switches to the selected
channel. When timer expires, the TV switches
to the channel which it is switched from.
Selected digital channel will be output via
Scart-1 when in DTV source or if AV1 Output
has been selected as DTV. In Analogue TV
mode, scart output cannot be selected as
DTV, if you switch the Analogue TV, a warn-
ing is displayed.
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3716

- 17 -
WARNING
DTV Timer is active
Your action will cancel timer
<M> to cancel <OK> to accept
If you accept and select OK, DTV timer is
canceled, TV switches Analogue TV mode,
scart-1 output becomes Analogue TV. You
should connect your VCR to Scart-1 for re-
cording digital broadcast.
Language
Some programmes are broadcast in two or
more languages simultaneously. The lan-
guage heard can be selected from the Lan-
guage Menu.
• Press the “M” button to display the Main
Menu and use or button to highlight the
Language line and press the “SELECT” but-
ton.
Main Menu
Channel List
Installation
Configuration
Timers
Language
TV Setup
Common Interface
• Use the or button to highlight the
soundtrack language required and press
the “SELECT” button. Normal viewing, with
the required language soundtrack, can be
resumed by pressing the “M” button.
Languages
English
TV Setup
To be able to go through TV functions, you
can use this item.
The digital TV Setup menu screen is ac-
cessed from the main menu. Press the “M”
button to display the main menu and use
or button to highlight “TV Setup”, press
the “SELECT” button to display TV Setup
menu screen.
Main Menu
Channel List
Installation
Configuration
Timers
Language
TV Setup
Common Interface
Detailed information about Sound, Picture
and Feature menus are in AnalogueTV
Menu System section on page 19.
Common Interface
• Press the “M” button to display the Main
Menu and use the or button to highlight
the “Common Interface” line and press the
“SELECT” button.
Main Menu
Channel List
Installation
Configuration
Timers
Language
TV Setup
Common Interface
It is required to subscribe to a pay channel
company to view the pay channels of the
Digital Terrestrial broadcasting.
Obtain the Conditional Access Module
(CAM) and the Viewing card by subscribing
to a pay channel company, then insert those
to the Television using the following proce-
dure.
1. Switch off the TV and unplug from the
mains.
2. Insert the CAM, then Viewing Card to the
slot that is located in the terminal cover at
the left-hand side of the TV (from front view).
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3717

- 18 -
• The CAM should be correctly inserted, it is
impossible to insert fully if reversed. The
CAM or the TV terminal may be damaged if
the CAM is forcefully inserted.
3. Connect the TV to the mains supply,
switch on and then wait for few moments
until the card is activated.
• Some CAMs may require the following set
up. Please set the CAM by entering the IDTV
menu, Common Interface then pressing the
“SELECT” button. (CAM set up menu is not
displayed when it is not required.)
• To see the viewing contract information:
Enter IDTV; press the “M” button, then high-
light Common Interface and press the “SE-
LECT” button.
• When no module is inserted, “No Common
Interface module detected” message ap-
pears on the screen.
• Refer to the module instruction manual for
details of the settings.
Analogue TV Menu System
Your TV has been designed with a menu
system to provide easy manipulation of a
multifunction system. Press the “M”(MENU)
button to enter the main menu.
To select a sub-menu use or button,
and press / or “OK” button.
Picture Menu
• Press the “M” button, now you are in main
menu. In the Main menu, select “Picture”
using / button, then enter the Picture
menu by pressing or button.
down for picture settings
brightness
contrast
sharpness
color
61
filter
sharp
36
50
43
Brightness
• As you enter the picture menu, Brightness
will be the first item.
• Press button to increase brightness.
• Press button to decrease brightness.
Contrast
• Using or button select Contrast.
• Press button to increase contrast level.
• Press button to decrease contrast level.
filter
•Using or button, select filter.
•Press button to change filter setting to nor-
mal, sharp or sharpest. This function allows
user to choose the level of image sharpness
that changes the details of picture display.
Setting Sharpness
• Using or button select Sharpness.
• Press button to increase sharpness level.
• Press button to decrease sharpness
level.
Setting Colour
• Using or button select Colour..
• Press button to increase colour level.
• Press button to decrease colour level.
Audio Menu
• As you enter the main menu, audio will be
the second item. In the main menu, select
Audio using / button, then enter the
audio menu by pressing / button.
down for audio settings
volume
balance
extended audio features
audio
AVL on
off
20
51
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3718

- 19 -
Setting Volume:
As you enter the audio menu, Volume will be
the first selected option.
•Press button to increase volume.
• Press button to decrease volume.
Or you can directly change the volume set-
tings using “ +” (to increase) or “-” (to
decrease) button.
Setting Balance
Balance allows adjustment of volume distri-
bution between the left and right speakers.
• Using or button select Balance.
• Press button to change balance to the
right.
• Press button to change balance to the left.
AVL
Automatic Volume Level or AVL normalises
the audio output level. This is required to com-
pensate variations in sound level during a
transmission (e.g. Commercials are normally
louder than the rest of the transmission).
Press or button to select AVL. By
pressing / buttons, set AVL on to acti-
vate it or off to deactivate it.
Extended audio features
By pressing button, select extended au-
dio features. Press button to enter sub-
menus. Extended audio features menu has
the following sub-menus:
feature menu
By pressing button, select the first icon.
Feature menu appears on the screen.
down for feature settings
sound style
feature
effect
user
normal
effect
This feature turns on or off the surround ef-
fect.
By pressing or button, select effect.
Press button to select Normal or Ex-
tended.
Extended effect mode is used to get deep
sound impression from loudspeakers.
sound style
By pressing or button, select sound
style. Press button to change sound style
setting. The available styles are: Theatre,
Music, Voice and User.
A sound style consists of equalizer settings.
equalizer menu
By pressing button, select the second
icon. Equalizer menu appears on the
screen.
down for equalizer settings
equalizer
100
300
1K 3K 8K
+12db-
-12db-
+0db-
Press button to select the first frequency
band. Press / button to select the other
frequency bands. Selected band can be ad-
justed by pressing or button.
Press button on the first band to exit the
equalizer menu.
headphone menu
By pressing button, select the third icon.
Headphone menu appears on the screen.
down for headphone settings
volume
balance
headphone
20
51
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3719

- 20 -
volume
By pressing or button, select volume.
Press button to increase volume level.
Press button to decrease volume level.
Volume level can be adjusted between 0
and 50.
balance
By pressing or button, select balance.
Press button to increase balance to the
right. Press button to decrease balance to
the left. Balance level can be adjusted be-
tween 0 and 100.
Window menu
By pressing / buttons, select the third
icon. Window menu appears on the screen.
down for window settings
image size
color temperature
window
dynamic skin tone
auto
normal
onoff
image size
Press or button to select image size.
By pressing / button, you can change
image size to Auto,fill all or wide.
You can enter image size directly by press-
ing the “ WIDE” button.
color temperature
You can enter color temperature directly by
pressing "PP" button.
This feature is used to change the color
temperature.
Press or button, to select color tem-
perature. By pressing / button, you can
select one of these options: Normal,Warm
andCool.
dynamic skin tone
Dynamic skin tone effect corrects the hue of
colours that matches to skin tones.
Press or button to select dynamic skin
tone. By pressing / button, turn skin tone
on / off.
options menu
By pressing / button, select the fourth
icon. Options menu appears on the screen.
Options menu in AV modes ( AV1, RGB1,
AV2, SVHS ) has just an additional “ AV1
Output” feature which has been explained in
page 26. The rest of the features in options
menu are as in the TV mode explained be-
low.
down for option settings
menu background
language
sleep timer
options
room lighting
opaque
English
bright
0
child lock onoff
menu background
By pressing or button, select menu
background. You can change menu back-
ground to translucent or opaque by press-
ing / button.
Language
By pressing or button, select language.
Press / button to select the menu lan-
guage you want.
room lighting
Press or button to select room lighting.
By pressing / button, you can select
one of these options: Normal,Bright and
Movie.
ENG-20700-20 INCH TFT-BACK AV-1549UK-MB18 IDTV-(WO PIP-WO PC)-50093041.p65 06.09.2006, 17:3720
