Alcatel-Lucent Enterprise OmniAccess Stellar AP1320 Series User manual

Alcatel-Lucent Enterprise
OmniAccess Stellar AP1320 series
Installation Guide
060455-10 Rev. B
*060455-10 Rev. B*
https://www.al-enterprise.com
The Alcatel-Lucent name and logo are trademarks of Nokia used under license by ALE. To view
other trademarks used by affiliated companies of ALE holding, visit:
https://www.al-enterprise.com/en/legal/trademarks-copyright. All other trademarks are the
property of their respective owners. The information presented is subject to ALE without notice.
Neither ALE Holding nor any of its affiliates assumes any responsibility for inaccuracies
contained herein. (2019)
Summary of Installation Steps
•WLAN Planning. Usually, a comprehensive site survey is required
before installation, such as installation location, brackets, cables,
power source, etc.
•Unpack the AP box and check all contents
•Install the AP bracket on ceiling or wall
•Installing the AP
•Connecting required cables
•Power connection
•Verifying post-installation connectivity
•AP provisioning
Access points are radio transmission devices and are subject to
governmental regulation. Network administrators who are responsible
for the configuration and operation of access points must comply with
local broadcast regulations. Specifically, access point must use channel
assignments appropriate to the location where the access point will be
deployed.
Package Contents
Item
Name
Qty
Unit
1
Access Point
1
Pcs
2
Quick Start Guide
1
Pcs
Installation Guide
1
Pcs
Regulatory Compliance and Safety
Information
1
Pcs
User Guide Info Card
1
Pcs
◆Optional Accessories（To be ordered separately）
Item
Name
Description
1
OAW-AP-MNT-B
Indoor mounting kit, Type B1(9/16") and
B2(15/16") for T shaped ceiling rail.
2
OAW-AP-MNT-C
Indoor mounting kit, Type C1(Open
Silhouette) and C2 (Flanged Interlude),
for other shaped ceiling rail mounting.
3
OAW-AP-MNT-W
Indoor mounting kit, Type W wall and
ceiling mounting with screws.
Figure1: Product Packing
Inform your ALE sales representative of incorrect, missing, or
damaged parts. If possible, retain the carton, including the
original packing materials. Use these materials to repack and
return the unit to the supplier if needed. Additional mounting
kits for use with the OmniAccess Stella AP1201 series access
points are sold separately. Contact your ALE sales representative
for details.
Hardware Overview
The following sections outline the hardware components of the
OAW-AP1320 Series access point.
Figure 2: OAW-AP1321 Front View
Figure 3: OAW-AP1322 Front View
Figure 4: OAW-AP1322 Include Antennas Front View
Figure 5: Install the external antenna on OAW-AP1322.
◆The external antennas is sold separately.
LED
The OAW-AP1320 Series access point is equipped with hidden LED
display that indicates different status with different color.
For the details of the LED status, please refer to the Quick Start Guide.

Figure 6: OAW-AP1320 Series Back View
◆OmniAccess AP1320 Stellar Connections
Table 1
External Interfaces
Item Name
Specifications
DC Power
Socket
The AP has a single 48V DC power jack socket to support
powering through an AC-to-DC power adapter, If PoE is
not available, an optional AC-DC adapter kit (sold
separately) can be used to power the AP.
2.5 Gigabit
Eth0
1x 100/1000/2.5GBASE-T autosensing (RJ-45) port, Power
over Eth0 (PoE)
1 Gigabit
Eth1
1x 10/100/1000BASE-T autosensing (RJ-45) port, Power
over Eth1 (PoE)
Console
The console port is an RJ-45 female connector and can be
used to connect to a terminal for direct local
management.
Note: Currently for use by Service & Support only.
USB
USB 2.0 host interface (Type A, output current 0.5A )
Reset
Factory reset. Press reset button for 5s, AP LEDs will
quickly flashing for 3s, then AP will restart and restore
factory configurations.
Security
Lock Slot
The AP is equipped with a security lock slot for additional
security.
Table 2
Ethernet Port Pinout
Connector
Pin
Signal Name
PoE
1
2
3
4
5
6
7
8
1
RJ45_DA+
PoE-
2
RJ45_DA–
PoE-
3
RJ45_DB+
PoE+
4
RJ45_DC+
PoE+
5
RJ45_DC–
PoE+
6
RJ45_DB–
PoE+
7
RJ45_DD+
PoE-
8
RJ45_DD–
PoE-
Table 3
Console Port Pinout
Connector
Pin
Signal Name
Function
1
2
3
4
5
6
7
8
3
TXD
Transmit
4
GND
Ground
5
GND
Ground
6
RXD
Receive
Pins not listed are not connected.
Note: The serial console port allows you to connect the AP to a
serial terminal or a laptop for direct local management. This port is
an RJ-45 female connector with the pinouts described in Table 3.
Currently for use by Service & Support only.
Power
The OAW-AP1320 series access point supports direct DC power adapter
(48V DC nominal, sold separately) and Power over Ethernet (PoE).
The DC power connector port is located on the back of the device, as
shown in Figure 6.
The PoE allows the Ethernet port to draw power from an IEEE 802.3at
compliant source.
OmniAccess Stella AP supports the power adapter provided by
ALE ONLY.
Before You Begin
Refer to the sections below before beginning the installation process.
Pre-installation Checklist
Before installing your OAW-AP1320 Stellar access point, be sure that
you have the following items:
•8-conductor, CAT5 or better UTP cable of required length.
•One of the following power sources:
◼IEEE 802.3at compliant Power over Ethernet (PoE) source
(PoE switch or PoE injector), best with 2.5GbE PoE port.
◼AC-DC adapter (sold separately)，output voltage DC 48V,
output current ≥0.5A
•A terminal or a notebook
Identifying Specific Installation Locations
You can mount the OmniAccess Stellar AP on a ceiling rail or on a wall.
You should first determine the location of the installation. The
installation position is located at the center of the required coverage
area and should be free from obstructions or obvious sources of
interference.
•Minimize the number of obstructions (such as walls) between the
AP and user terminals.
•Electronic equipment or devices (such as microwave ovens) which
may produce radio frequency noise should be away from the
installation position of the AP.
It is strictly prohibited to install around stagnant water, water seepage,
leakage or condensation. Avoid cable condensation or water seepage
along the cables connecting to the AP.
AP Installation
Refer to mounting kits installation Guide.
Verifying Post-Installation Connectivity
The LED on the AP can be used at this point to verify that the AP is
receiving power and initializing successfully.
Product Specifications
OAW-AP1320 series Dimensions/Weight
Unboxed OAW-AP1321:
•Net Weight: 1.54lbs / 0.7kg
•Dimensions (HxWxD): 7.1 inches x 7.1 inches x 1.42 inches
(18 cm x 18cm x 3.6cm)
Unboxed OAW-AP1322 (external antennas)
•Net Weight: 1.59lbs / 0.72kg
•Dimensions (HxWxD): 7.1 inches x 7.1 inches x 1.42 inches (18 cm
x 18cm x 3.6cm)
Environmental
•Operating :
▪Temperature: 0°C to +45°C (+32°F to +104°F)
▪Humidity: 10% to 90% non-condensing
•Storage and transportation :
▪Temperature: -40°C to +70°C(-40°F to +158°F)
For additional specifications on this product, please refer to the
Datasheet.
