ALLOWAY 3130 User manual

PN : 200-5-0016 (2019)
2019
ROW CROP CULTIVATOR
OPERATOR’S MANUAL

PN : 200-5-0016 (2019)
TO THE DEALER:
Assembly and proper installation of this product is the responsibility of the Alloway dealer. Read manual
instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists in the
Operator’s Manual are completed before releasing equipment to the owner.
The dealer must complete the Warranty Registration included in this manual. Both dealer and customer
must sign the registration which certies that all Dealer Check List items have been completed. The dealer is to
return the prepaid postage portion to Alloway, give one copy to the customer and retain one copy.
Note: Warranty credit is subject to this form being completed and returned.
TO THE OWNER:
Read this manual before operating your Alloway equipment. The information presented will prepare
you to do a better and safer job. Keep this manual handy for ready reference. Require all operators to read this
manual carefully and become acquainted with all the adjustment and operating procedures before attempting to
operate. Replacement manuals can be obtained from your dealer.
The equipment you have purchased has been carefully engineered and manufactured to provide
dependable and satisfactory use. Like all mechanical products, it will require cleaning and upkeep. Lubricate the
unit as specied. Observe all safety information in this manual and safety decals on the equipment.
For service, your authorized Alloway dealer has trained mechanics, genuine Alloway service parts and
the necessary tools and equipment to handle all your needs.
Use only genuine Alloway service parts. Substitute parts will void the warranty and may not meet
standards required for safe and satisfactory operation. Record the model number and serial number of your
equipment in the spaces provided:
Model:_________________________ Date of Purchase _____________________________
Serial Number: (see Safety Decal section for location) __________________________________
Provide this information to your dealer to obtain correct repair parts.
Throughout this manual, the term IMPORTANT is used to indicate that failure to observe can cause damage
to equipment. The terms CAUTION, WARNING and DANGER are used in conjunction with the Safety-Alert Symbol,
(a triangle with an exclamation mark), to indicate the degree of hazard for items of personal safety.
This Safety-Alert Symbol indicates a hazard and means
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Indicates an imminently hazardous situation that, if not avoided,
will result in death or serious injury.
Indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury and includes hazards that are
exposed when guards are removed
Indicates a potentially hazardous situation that, if not avoided,
may result in minor or moderate injury.
IMPORTANT Indicates that failure to observe can cause damage to equipment.
NOTE Indicates helpful information.
WARNING
CAUTION

PN : 200-5-0016 (2019) 1
TABLE OF CONTENTS
INTRODUCTION ....................................................................................................................... Inside Front Cover
GENERAL INFORMATION .................................................................................................................................... 1
SAFETY RULES ............................................................................................................................................... 3 - 7
CHECK LISTS (DEALER’S RESPONSIBILITY) ................................................................................................... 8
OPERATOR SIGN-OFF RECORD ........................................................................................................................ 9
SAFETY & INSTRUCTIONAL DECALS ....................................................................................................... 10 - 13
OPERATION ................................................................................................................................................. 15 - 30
OWNER SERVICE ....................................................................................................................................... 31 - 35
TROUBLE SHOOTING ....................................................................................................................................... 36
INDEX TO PARTS LISTS .................................................................................................................................... 37
BOLT TORQUE CHART .................................................................................................................................... 101
ABBREVIATIONS .............................................................................................................................................. 102
INDEX ................................................................................................................................................................ 103
REPLACEMENT PARTS WARRANTY .............................................................................................................. 104
PRODUCT WARRANTY ............................................................................................................ Inside Back Cover
GENERAL INFORMATION
The purpose of this manual is to assist you in operating
and maintaining your Beet Defoliator. Read it carefully.
It furnishes information and instructions that will help
you achieve years of dependable performance. These
instructions have been compiled from extensive eld
experience and engineering data. Some information
may be general in nature due to unknown and varying
operating conditions. However, through experience
and these instructions, you should be able to develop
procedures suitable to your particular situation.
The illustrations and data used in this manual were
current at the time of printing, but due to possible
inline production changes, your machine may vary
slightly in detail. We reserve the right to redesign and
change the machines as may be necessary without
notication.
WARNING
Some illustrations in this manual show
the Beet Defoliator with safety shields
removed to provide a better view. The Beet
Defoliator should never be operated with
any safety shielding removed.
Throughout this manual, references are made to right
and left direction. These are determined by standing
behind the equipment facing the direction of forward
travel.

PN : 200-5-0016 (2019)
2
Number of Rows: �������������������������������������������������������������������������������������������� 8 - 12
Row Spacing: ������������������������������������������������������������������������� 20 - 30 in (51 - 76 cm)
Transport Width (Folded): �������������������������������������������������������������������� 14’ 4” (4�4 m)
Overall Width (Operation): ������������������������������������������������������������������� 25’ 6” (7�8 m)
Transport Height (Folded): ������������������������������������������������������������������� 13’ 4” (4�1 m)
Size: ����������������������������������������������������������������������������������� (Traction Tire) 11�2 X 24
Tire Pressure: ������������������������������������������������������������������������������ 20 PSI (137�9 kPa)
Weight: ������������������������������������������������������������������������������������ 14,400 lbs (6530 kg)
SPECIFICATIONS
MODEL TOOLBAR 3-PT HITCH TRANSPORT
WIDTH
WEIGHT
6 Row 22” R D 152” 1955 lbs.
6 Row 30” R D 200” 2215 lbs.
8 Row 22” R D 200” 2475 lbs.
8 Row 30” R D 252” 2875 lbs.
8 Row 30” F D 145” 3305 lbs.
12 Row 22” R D 288” 3505 lbs.
12 Row 22” F D 157” 4000 lbs.
12 Row 24” TRR D 300” 3530 lbs.
12 Row 24” F D 171” 4010 lbs.
12 Row 30” TRF D 213” 5175 lbs.
16 Row 30” TRF D 267” 6220 lbs.
18 Row 22” TRF D 246” 6405 lbs.
24 Row 22” FR E 288” 8375 lbs.
Weights are without optional equipment.
MODEL 3130 SPRING TINE SHANK CULTIVATORS
MODEL TOOLBAR 3-PT HITCH TRANSPORT
WIDTH
WEIGHT
6 Row 30” R D 200” 2215 lbs.
6 Row 36/40” R D 252” 2475 lbs.
8 Row 30” R D 252” 2875 lbs.
8 Row 30” F D 145” 3305 lbs.
8 Row 36” TRR D 328” 3305 lbs.
12 Row 30” TRF D 213” 5175 lbs.
16 Row 30” TRF D 267” 6220 lbs.
16 Row 38” TRF D 267” 6000 lbs.
8 Row 40” TRF D 267” 5000 lbs.
Weights are without optional equipment.
MODEL 3130 RIGID SHANK CULTIVATORS

PN : 200-5-0016 (2019) 3
OPTIONAL EQUIPMENT
Description Part No. Weight
Guide and Support Wheels
Adjustable guide wheel 200-1-3666 312 lbs./pair
Semi-Pneumatic guide wheels 200-1-3699 175 lbs./pair
Steel guide wheels 200-1-3668 220 lbs./pair
King guide strut 200-1-3639 777 lbs./pair
Shields
24” Rolling shields 200-1-3636 57 lbs./pair
24” Rolling end shield 200-1-3637 84 lbs./pair
Open top shields 22” row 200-1-3691 102 lbs./row
Open top shields 30” row 200-1-3642 104 lbs./row
Open top shields 36-40” row 200-1-3692 105 lbs./row
Flip-up 14” disc with knife mounts and knives 200-1-3645 78 lbs./row
Row Weeder Attachment
Row weeder disc with clamp 200-1-3655 115 lbs./row
The Alloway Row Crop Cultivator has several toolbar types and a variety of optional equipment for row crop applications.
Optional equipment may change these specications.
Cultivator weights do not include optional equipment.

PN : 200-5-0016 (2019)
4
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Safety is a primary concern in the design and
manufacture of our products. Unfortunately, our e󰀨orts
to provide safe equipment can be wiped out by a single
careless act of an operator.
In addition to the design and conguration of equipment,
hazard control and accident prevention are dependent
upon the awareness, concern, prudence and proper
training of personnel involved in the operation, transport,
maintenance and storage of equipment.
It has been said “The best safety device is an informed,
careful operator.” We ask you to be that kind of an
operator.
TRAINING
Safety instructions are important! Read
all attachment and power unit manuals; follow
all safety rules and safety decal information.
(Replacement manuals are available from dealer).
Failure to follow instructions or safety rules can
result in serious injury or death.
If you do not understand any part of this
manual and need assistance, see your dealer.
Know your controls and how to stop engine
and attachment quickly in an emergency.
Operators must be instructed in and be
capable of the safe operation of the equip-
ment, attachments and all controls. Do not allow
anyone to operate this equipment without proper
instructions.
Keep hands and body away from pressurized
lines. Use paper or cardboard, not body parts to
check for leaks. Wear safety goggles. Hydraulic
uid under pressure can easily penetrate skin
and will cause serious injury or death.
Make sure that all operating and service
personnel know that in the event hydraulic uid
penetrates skin, it must be surgically removed
as soon as possible by a doctor familiar with
this form of injury, or gangrene, serious injury
or death will result. CONTACT A PHYSICIAN
IMMEDIATELY IF FLUID ENTERS SKIN OR EYES.
DO NOT DELAY.
Never allow children or untrained persons to
operate equipment.
PREPARATION
Check that all hardware is tight and properly
installed. Always tighten to torque chart
specications unless instructed otherwise in
this manual.
Air in hydraulic systems can cause erratic
operation and allows loads or equipment
components to drop unexpectedly. Before
operating or allowing anyone to approach
the equipment, purge any air in the system by
operating all hydraulic functions several times
after connecting equipment, connecting hoses,
or doing any hydraulic maintenance.
Make sure all hydraulic hoses, ttings and
valves are in good condition and not leaking
before starting power unit or using equipment.
Check and route hoses carefully to prevent
damage. Hoses must not be twisted, bent
sharply, kinked, frayed, pinched, or come into
contact with any moving parts. Operate moveable
components through full operational range to
check clearances. Replace any damaged hoses
immediately.
Always wear relatively tight and belted
clothing to avoid entanglement in moving
parts. Wear sturdy, rough-soled work shoes
and protective equipment for eyes, hair, hands,
hearing and head; and respirator or lter mask
where appropriate.
Ensure implement is properly attached,
adjusted and in good operating condition.
Make sure spring-activated locking pin or
collar slides freely and is seated rmly in tractor
PTO spline groove.
Before starting power unit, check all equip-
ment driveline guards for damage and make sure
they rotate freely on all drivelines. Replace any
damaged guards. If guards do not rotate freely
on drivelines, repair and replace bearings before
operating.
Power unit must be equipped with ROPS or
ROPS CAB and seat belt. Keep seat belt securely
fastened. Falling o󰀨 power unit can result in
death from being run over or crushed. Keep
foldable ROPS systems in “locked up” position
at all times.
(Safety Rules continued on next page)

PN : 200-5-0016 (2019) 5
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
TRANSPORTATION
Power unit must be equipped with ROPS
or ROPS cab and seat belt. Keep seat belt
securely fastened. Falling o󰀨 power unit can
result in death from being run over or crushed.
Keep foldable ROPS systems in “locked up”
position at all times.
Always sit in power unit seat when operating
controls or starting engine. Securely fasten
seat belt, place transmission in neutral, engage
brake and ensure all other controls are
disengaged before starting power unit engine.
A minimum 20% of tractor and
equipment weight must be on tractor front
wheels when attachments are in transport
position. Weight may be attained with a loader,
front wheel weights, ballast in tires or front
tractor weights. Weigh tractor and equipment.
Do not estimate.
Always attach safety chain to tractor drawbar
when transporting unit.
Always raise unit and install transport
locks before transporting. Leak down or
failure of mechanical or hydraulic system can
cause equipment to drop.
Never exceed 20 MPH during transport.
See the Speed vs. Weight Ratio Table in "Field
Operation, Transporting the Unit" for proper tow
vehicle to machine weight ratios.
Watch for hidden hazards on the terrain.
Always comply with all state and local
lighting and marking requirements.
Never allow riders on power unit or
attachment.
Look down and to the rear and make sure
area is clear before operating in reverse.
Do not operate or transport on steep slopes.
Use extreme care and reduce ground speed
on slopes and rough terrain.
Do not operate or transport equipment
while under the inuence of alcohol or drugs.
(Safety Rules continued from previous page)
(Safety Rules continued on next page)
Remove accumulated debris from this
equipment, tractor and engine to avoid re hazard.
Ensure all safety decals are installed.
Replace if damaged. (See Safety Decals section
for location.)
Ensure shields and guards are properly
installed and in good condition. Replace if
damaged.
A minimum 20% of tractor and equipment
weight must be on tractor front wheels when
attachments are in transport position. Without
this weight, tractor could tip over, causing
personal injury or death. The weight may be
attained with a loader, front wheel weights, ballast
in tires or front tractor weights. When attaining
the minimum 20% weight on the front wheels,
you must not exceed the Roll Over Protection
Structure (ROPS) weight certication. Weigh the
tractor and equipment. Do not estimate.
Make sure hydraulic hoses and cylinders
are fully purged of air before operating. Keep
all persons away and ll the system by raising
and lowering all functions several times. Air
in the system can allow components to fall
unexpectedly.
Inspect and clear area of stones, branches or
other hard objects that might be thrown, causing
injury or damage.

PN : 200-5-0016 (2019)
6
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
(Safety Rules continued from previous page)
Operate tractor PTO at the RPM speed stated
in "Specications" section.
Do not operate PTO during transport.
Look down and to the rear and ensure area
is clear before operating in reverse.
Do not operate or transport on steep slopes.
Do not stop, start or change directions
suddenly on slopes.
Use extreme care and reduce ground speed
on slopes and rough terrain.
Watch for hidden hazards on the terrain
during operation.
Stop power unit and equipment
immediately upon striking an obstruction.
Turn off engine, remove key, inspect and repair
any damage before resuming operation.
Always connect safety chain from equipment
to towing vehicle when transporting.
OPERATION
Equipment may be pictured with covers open
for instructional purposes. Never operate equip-
ment with covers open.
Do not allow bystanders in the area when oper-
ating, attaching, removing, assembling or servic-
ing equipment.
Never walk, stand or position yourself or others
under a raised wing or in the path of a lowering wing.
Never go under equipment (lowered to the
ground or raised) unless it is properly blocked and
secured.
Never place any part of the body under
equipment or between moveable parts even when
the engine has been turned o󰀨.
Hydraulic system leak down, hydraulic system
failures, mechanical failures, or movement of control
levers can cause equipment to drop or rotate
unexpectedly and cause severe injury or death.
Follow Operator’s Manual instructions for working
under equipment and blocking requirements or have
work done by a qualied dealer.
Keep bystanders away from equipment.
Do not operate or transport equipment while
under the inuence of alcohol or drugs.
Operate only in daylight or good articial light.
Avoid contact with electrical wires.
Keep hands, feet, hair and clothing away from
equipment while engine is running. Stay clear of all
moving parts.
Always comply with all state and local lighting
and marking requirements.
Never allow riders on power unit or attachment.
Power unit must be equipped with ROPS
or ROPS cab and seat belt. Keep seat belt securely
fastened. Falling o󰀨 power unit can result in death
from being run over or crushed. Keep foldable
ROPS systems in “locked up” position at all times.
Always sit in power unit seat when operating
controls or starting engine. Securely fasten seat
belt, place transmission in neutral, engage brake
and ensure all other controls are disengaged
before starting power unit engine.
(Safety Rules continued on next page)

PN : 200-5-0016 (2019) 7
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
AVOID INJURY OR DEATH FROM
POWER LINES:
• Stay away from power lines.
• Electrocution can occur without direct
contact.
• Check clearances before raising
implement.
• Do not leave operator’s seat if any part
of tractor or implement contacts electric
lines.
Before servicing, adjusting, repairing or
unplugging, stop tractor engine, place all controls
in neutral, set park brake, remove ignition key,
and wait for all moving parts to stop.
Before working under a raised implement,
read and follow all Operator's Manual instructions
and safety rules. Implement must be attached to
tractor. Lift cylinder locks must be installed and
lift cylinders lowered against locks. Hydraulic
system leak down, hydraulic system failures, or
movement of control levers can cause equipment
to drop unexpectedly and cause severe injury or
death.
MAINTENANCE
Before servicing, adjusting, repairing, or
unplugging, stop tractor engine, place all controls
in neutral, set park brake, remove ignition key,
and wait for all moving parts to stop.
Before working underneath a raised
implement, read and follow all Operator's Manual
instructions and safety rules. Implement must
be attached to tractor. Lift cylinder locks must
be installed and lift cylinders lowered against
locks. Hydraulic system leak down, hydraulic
system failures, or movement of control levers
can cause equipment to drop unexpectedly and
cause severe injury or death.
Service and maintenance work not covered
in OWNER SERVICE must be done by a qualied
dealership. Special skills, tools, and safety proce-
dures may be required. Failure to follow these
instructions can result in serious injury or death.
Do not modify or alter or permit anyone else
to modify or alter the equipment or any of its
components in any way.
Your dealer can supply original equipment
hydraulic accessories and repair parts. Substitute
parts may not meet original equipment specica
tions and may be dangerous.
Always wear relatively tight and belted
clothing to avoid entanglement in moving
parts. Wear sturdy, rough-soled work shoes
and protective equipment for eyes, hair, hands,
hearing and head; and respirator or lter mask
where appropriate.
Do not allow other people in the area when
operating, attaching, removing, assembling or
servicing equipment.
Never go under equipment lowered to the
ground or raised unless it is properly blocked
and secured. Never place any part of the body
under equipment or between moveable parts
even when the engine has been turned o󰀨.
Hydraulic system leak down, hydraulic
system failures, mechanical failures or movement
of control levers can cause equipment to drop or
rotate unexpectedly and cause severe injury or
death.
Follow Operator’s Manual instructions for
working under and blocking requirements, or
have work done by a quali ed dealer.
Ensure implement is properly attached,
adjusted and in good operating condition.
Never perform service or maintenance with
engine running.
Make sure hydraulic hoses and cylinders
are fully purged of air before operating. Keep
all persons away and ll the system by raising
and lowering all functions several times. Air
in the system can allow components to fall
unexpectedly.
Keep all persons away from operator
control area while performing adjustments,
service or maintenance.
(Safety Rules continued from previous page)

PN : 200-5-0016 (2019)
8
SAFETY RULES
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Make certain all movement of implement
components has stopped before approaching
for service.
Do not handle blades with bare hands.
Careless or improper handling may result in
serious injury.
Tighten all bolts, nuts and screws to torque
chart specications. Check that all cotter pins are
installed securely to ensure equipment is in a safe
condition before operating.
Ensure all safety decals are installed.
Replace if damaged. (See Safety Decals section
for location.)
Ensure shields and guards are proper-
ly installed and in good condition. Replace if
damaged.
Do not disconnect hydraulic lines until
machine is securely blocked or placed in lowest
position and system pressure is released by
operating all valve control levers.
__________________________________________
(Safety Rules continued from previous page)
STORAGE
Follow manual instructions for storage.
Keep children and bystanders away from
storage area.

PN : 200-5-0016 (2019) 9
CHECK LISTS
PRE-DELIVERY CHECK LIST
(DEALER’S RESPONSIBILITY)
Inspect the equipment thoroughly after assembly to
ensure it is set up properly before delivering it to the
customer.
The following check lists are a reminder of points to
inspect. Check o󰀨 each item as it is found satisfactory
or after proper adjustment is made.
ѩCheck that all safety decals are installed and in
good condition. Replace if damaged.
ѩCheck that shields and guards are properly
installed and in good condition. Replace if
damaged.
ѩCheck that PTO shaft is properly installed.
ѩProperly attach implement to tractor and make
all necessary adjustments.
ѩCheck all bolts to be sure they are tight.
ѩCheck wheel lug nuts and adjust to proper torque.
ѩCheck that all cotter pins and safety pins are
properly installed. Replace if damaged.
ѩCheck and grease all lubrication points as
identied in “Service, lubrication information.”
ѩ Check the level of gearbox uids before delivery.
Service, if required, as specied in the “Service,
lubrication information.”
ѩCheck that tractor hydraulic reservoir has been
serviced and that hydraulic system and all
functions have been operated through full cylin-
der stroke to purge air from system.
ѩAfter pressurizing and operating all Defoliator
functions, stop tractor and make sure there are
no leaks in the hydraulic system. Follow all safety
rules when checking for leaks.
DELIVERY CHECK LIST
(DEALER’S RESPONSIBILITY)
ѩCheck that all safety decals are installed and in
good condition. Replace if damaged.
ѩShow customer how to make adjustments and
select proper PTO speed.
ѩShow customer how to make adjustments.
ѩInstruct customer how to lubricate and explain
importance of lubrication.
ѩPoint out the safety decals. Explain their meaning
and the need to keep them in place and in good
condition. Emphasize the increased safety haz-
ards when instructions are not followed.
ѩPresent Operator’s Manual and request that
customer and all operators read it before operat-
ing equipment. Point out the manual safety rules,
explain their meanings and emphasize the in-
creased safety hazards that exist when safety
rules are not followed.
ѩShow customer how to make sure driveline
is properly installed and that spring-activated
locking pin or collar slides freely and is seated in
groove on tractor PTO shaft.
ѩShow customer the safe, proper procedures to be
used when mounting, dismounting, and storing
equipment.
ѩExplain to customer that when equipment is
transported on a road or highway, safety devices
should be used to give adequate warning to
operators of other vehicles.
ѩExplain to customer that when equipment is
transported on a road or highway, a Slow Moving
Vehicle (SMV) sign should be used to provide
adequate warning to operators of other vehicles.
ѩExplain to customer that when towing on a public
road to comply with all state and local lighting/
marking laws and to use a safety tow chain.
ѩMake customer aware of optional equipment
available so that customer can make proper
choices as required.
ѩPoint out all guards and shields. Explain their
importance and the safety hazards that exist
when not kept in place and in good condition.

PN : 200-5-0016 (2019)
10

PN : 200-5-0016 (2019) 11
SAFETY & INSTRUCTIONAL DECALS
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Replace Immediately If Damaged!
B. 100-3-1367 Safety Guard
A. 500-3-0977 Caution (1-11)
D. 500-3-0980 Missing Shields Warning
N. 200-3-1366 Serial Number Tag
SHIELD MISSING
DO NOT OPERATE - PUT SHIELD ON
18869-B
DANGER
K. 506-3-0194 Shield Missing Warning
J. 200-3-4034 Orange Fluorescent Reector 9 x 2
I. 200-3-4005 Red Reector 9 x 2
H. 200-3-4004 Amber Reector 9 x 2

PN : 200-5-0016 (2019)
12

PN : 200-5-0016 (2019) 13

PN : 200-5-0016 (2019)
14
SAFETY & INSTRUCTIONAL DECALS
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Replace Immediately If Damaged!
7. 506-3-0195 Hydraulic Pressure Warning
1. 200-3-3889 Hydraulic Air Warning
10. 200-3-4028 Tipping Hazard Warning Decal
9. 200-3-3888 Raised Wing Hazard
6. 200-3-4030 Cylinder Lock Warning
2. 200-3-3893 Three Point Top Link
Warning

PN : 200-5-0016 (2019) 15

PN : 200-5-0016 (2019)
16

PN : 200-5-0016 (2019) 17

PN : 200-5-0016 (2019)
18
