Alpha Image AMD2x-E Series User manual

AMD2x-E Series IR Dome camera
“Alpha Image” Metal Dome 2x-E
2 = Series “2” for 1000 T lines
x = color of the camera housing:
x = G (Grey) - x = B (Black) - x = W (White)
Specifications
Packing List
No
Name Model Number
2.
User Guide AMD2x-E
1
1.
Vandalproof IR Dome Camera AMD2x-E 1
Franchiser：
Put your information and notes here:
Notes:
::
: Before providing power to the
camera, please read this User Guide in
detail !
Do not attempt to disassemble the camera.
If the camera does not work, please contact
your local supplier.
Model
AMD2x-E(*)
Pick up Element 1/3” Sony 1,3 Megapixel CMOS Exmor sensor
Effective Picture Elements
(H×V) PAL: 1305 (H) x 1049 (V)
Horizontal Resolution 1000 TV Lines
Minimum Illumination 0.01 Lux (F1.2) - 0 lux with IR on
S/N Ratio > 50 dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter PAL: 1/50 sec ~ 1/100,000 sec
Gama Characteristic 0.45
Video Output 1,0 Vpp, 75 Ω
Auto Gain Control Auto
Power/
//
/Current 12 VDC (+/-10%)/ 450mA
Lens 2.8—12 mm Manual Zoom Lens
Dimensions & Weight ￠131 x 93 (H) mm - 800 gr.
(*) Housing color x = G (Grey), x = B (Black), x = W (White)
Storage Temperature -30 ~ +60 ℃ RH95% MAX
Operating Temperature -10 ~ +50℃ RH95% MAX
IR Distance 25 Meters (with￠5 x 36 pcs Infrared LED—850 nm)

INTRODUCTION
Congratulations on your purchase of this product.
This User Guide suits AMD2x-E product. We use the lat-
est SONY sensor and driver in this product. This camera
is very small and robust, so it can be used in almost any
condition. In addition, it has a very high quality and stabil-
ity, strong anti-jamming, and produces rich and real colors.
Also the installation is very easy, you don’t have to open
the camera to mount it and set it up, the setup is all done
externally.
Please read this instruction manual carefully to en-
sure proper use of the product.
CONNECTING
PRODUCT BRIEF
*
* *
* Sensor (
((
(CMOS)
))
)
SONY 1/3"CMOS Exmor sensor (1.3 Mpix).
*
* *
* Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. This camera
produces a high definition picture in low Lux condition.
*
* *
* Scanning Mode
PAL
*
**
*Supports UTC-function: OSD menu can be set with
optional UTC (Up-The-Coax) controller ref. AMD1-UTC
*
* *
* OSD SETTING
12 VDC Power Supply
Monitor
AMD2x-E
TROUBLESHOOTING
Link wire rule：
Power
Video
Note:
: :
:
● Please note the camera’s operating temperature and its envi-
ronment requirement. Avoid using the camera at too high or too
low temperatures. The operating temperature is -30 ~ +60 C.
(Recommendatory operating temperature is -10 ~ +50 C.)
● Never make the camera face the sun or a very bright object. It
might damage the CMOS sensor.
● Don’t mount the camera near any heating source (eg. radiator).
1. No Picture after providing power
. Maybe your power supply is not a 12 VDC Device. Maybe the polarity +/- is
incorrect according to the schematic above.
. Please check if all the connections are made in a proper manner like in the
schematic above. Monitor, power supply and connectors with the appro-
priate cabling according to the industry standard.
2. The picture level direction have flowing interference ripples
. May be caused by power supply AC ripples, it needs filtering of the waves of
the power supply. May be caused by ground loops.
. Check the monitor and peripheral equipments used.
3. The picture background color changes continuously
. Fluorescent lamp’s electromagnetic field causes color roll. This is a proper
phenomenon of cameras in general.
. Reduce the number of fluorescent lamps or increase the distance between
the camera and the fluorescent lamps.
. Use power supply external synchronisation.
4. Too much picture smear is seen in the image
. The power supply’s voltage is unstable.
. Please check the connecting cables, maybe they are not well fitted.
To prevent fire or shock hazards do not expose the unit
If you don’t want to use this product or it is faulty, do not
This symbol is intended to alert the user to the presence of
to rain or moisture.
throw it away. Please return it to your original supplier for
proper recycling or disposal. Think of the environment!
uninsulated ‘dangerous voltage’ within the product’s
enclosure that may be of sufficient power to cause a risk
or electric shock to persons.
Video
12 VDC
CAUTION:
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE THE COVER OR BACK. THERE ARE NO
USER SERVICEABLE PARTS INSIDE. PLEASE REFER TO QUALI-
FIED PERSONAL IF THERE IS A PROBLEM WITH THE CAMERA.
RISK OF ELECTRIC SCHOCK DO NOT OPEN
CAUTION: TO PREVENT ELECTRIC SHOCKS AND RISK OF
FIRE HAZARDS, DO NOT USE AN OTHER THAN THE
SPECIFIED POWER SOURCE.
Notes：
：：
：
●The power supply must have a legal safety attestation. Its output
voltage, current, voltage polarity and operating temperature must
match the camera’s requirement.
●When using the camera in bad wheather conditions (eg. lightning),pls
note to use a surge protection device or put out the PSU plug & cable.
●In order to produce high quality pictures, the power supply’s cable and
video output cable should not be too long.
MENU
UP
DOWN
RIGHT
LEFT
PRESS
KEY BOARD
OSD
SET
3D-NR ON/OFF
AE MODE
GLOBAL/CENTER/
CENTERWEIGHT/BACK
LIGHT/FRONT LIGHT/
DISTINGUISH
IMAGE ENHANCE SHARPNESS/CONTRAST/
SATURATION
MIRROR ON/OFF
FLIP ON/OFF
BRIGHTNESS 0. 10. 20….. 250
ZOOM IN 50. 0. 70. 80. 90. 100
DAY &
NIGHT
AUTO
IR-CUT
WB
AWB-PRO
AWB-TEMPORAL
AWB-AI
AWB-SZ
AWB-GW
AWB-CCT
PRIVACY
MASKING
COLOR
MOSAIC/WHITE/YELLOW/
CYAAN/GREEN/MAGENTA/
RED/BLEU/BLACK
AREA NO. 0-7
MOTION
DETECT. AREA NO. 0-4
LANGUA-
GE
ENGLISH
CHINESE
LOAD DEFAULT
SOFT VERSION
SAVE & EXIT
