Altius ATSW-SCA User manual

atSw-Sca
Smart watch
USEr manUal

2 3
We hope you enjoy your purchase!
ALTIUS products are carefully designed and produced to the
highest standards of performance and safety, backed by our
comprehensive 1 Year Warranty.
This user guide will provide all the information required for
you to setup and use your new product.
wElcomE contEntS
Welcome 2
General Safety Warnings 4
Product Overview 7
Operation 8
Troubleshooting 17
Specications 18
Compliance and Responsible Disposal 19

4 5
GEnEral SafEty warninGS
This product complies with Australian Safety
Standard AS/NZS 62368.1 to ensure the safety
of the product.
Health & Safety Information
Read these important safety instructions before using your
smart watch.
If you feel discomfort while using the device, stop using it
and remove it from your wrist. If your device becomes hot
to the touch, please remove it until it cools.
Maintaining Water and Dust Resistance
To avoid electric shock and damage to your device, do not
charge the device while it is wet or in an area where it could
get wet. Do not handle the device, charger or cords with
wet hands while it is charging.
Your device is water resistant up to 1 metre as per IP67
standard. Not intended for scuba diving. Avoid excessive,
sudden temperature changes, and high velocity activities.
Falls and shocks may breach integrity. After use in sea
water, rinse in fresh water and dry the device. Despite
this classication, your device is not impervious to
water damage in any situation. It is important that all
compartments are closed tightly.
Follow these tips carefully to prevent damage to the device:
• Whenever your device gets wet, dry it thoroughly with a
clean, soft cloth. Failure to rinse the device in fresh water
and dry it as instructed may cause the device to suer
from operability or cosmetic issues.
• Do not expose the device to water at high pressure.
• If the device is dropped or receives an impact, the
water and dust resistant features of the device may be
compromised.
Heart Rate Sensor/Blood Pressure/Blood Oxygen
When the smart watch is synced with a compatible smart
watch app (Da Fit), you can use additional features.
The information gathered from this device or the Da Fit
app is not intended for use in the diagnosis of disease or
other conditions, or in the cure, mitigation, treatment or
prevention of disease.
The accuracy of the information and data provided by this
device and its related software, including heart rate, blood
pressure and blood oxygen readings, may be aected by
factors such as environmental conditions, skin condition,
specic activity performed while using/wearing the device,
settings of the device, user conguration/user-provided
information, placement of the sensor on the body, and
other end-user interactions. Please refer to the User Manual
for more information on proper wear and use.

6 7
Charging
This product can only be charged with the provided
charging dock.
The charging dock shall not be used for any other
purpose other than charging the smart watch.
Do not place any metallic objects in the charging dock.
Device Temperature
Some functions or prolonged usage may increase
device temperature. Prolonged skin contact with a
device that is too hot to touch may produce skin
discomfort or redness, or low temperature burns. If the
device feels too hot to touch, discontinue use and close
all applications or turn o the device until it cools.
Always ensure that the device has adequate ventilation
and air ow.
Restricting Children’s Access to Your Mobile Device
Your device is not a toy. Do not allow children to play
with it because they could hurt themselves and others,
or damage the device.
Keep the device and all its parts and accessories out of
the reach of small children.
A. Smart Watch
B. Charging Dock
C. User Manual
D. Warranty Certicate
What’s in the box:
ProdUct ovErviEw
1. Touch screen
2. Charging pins
1
2
3
3. Heart rate, blood pressure
and blood oxygen sensor
d

8 9
oPEration
firSt timE USE
Charge your watch before using for the rst time, you
will need to charge it for about 3 hours.
charGinG StEPS:
1. Place the watch on top of the base with the charging
points on the back of the watch aligned with the
charging pins on the charging base. It will snap into
position once correctly aligned.
2. Plug the USB charging dock into a USB charging
adaptor (not included) or a USB port on your
computer.
3. Once fully charged, unplug the charging dock from
the charger.
To keep the charging pins clean, use a semi-wet cloth to
clean the pins weekly.
da fit aPP
Search for the Da Fit app in the app store
to download, or scan the QR code below
for installation.
For Android For iOS
Google Play and the Google Play logo are trademarks of Google
LLC.
Apple, the Apple logo, iPhone, and iPad are trademarks of
Apple Inc., registered in the U.S. and other countries and
regions. App Store is a service mark of Apple Inc.

10 11
tUrn on thE watch
Once the watch is fully charged, press and hold the
touch screen for 5 seconds to turn on the watch.
connEct to thE aPP
Open the Da Fit app on your smart phone. On the main
page, tap on the icon then “Add A Device.” On the
device list, select “ATSW-SCA” to connect to the watch.
On iOS devices, you may need to tap on “Pair” on a pop
up window.
diSconnEct from thE aPP
Open the Da Fit app on your smart phone. Tap on the
icon, then tap on “ATSW-SCA” then tap “OK” to
disconnect the watch. On iOS devices, you will also
need to open the Settings menu on your iPhone. Go to
Bluetooth settings and then tap ‘Forget This Device’ to
nish disconnecting.
fUnctionS on thE homE ScrEEn
• Swipe up to get to the main menu. From here, swipe
up/down to navigate to dierent menu screens.
• Swipe down for the quick settings menu. From here,
swipe down again to go back to the home screen.
• Press and hold the screen for the watch Mac
address.
fUnctionS in any ScrEEn
• Swipe right to return to the previous screen.
• Tap on any icon to get into the sub screen.

12 13
aPPlicationS
StEP
On the main menu, tap on the Step icon to enter the Step
app. The Step app acts as a pedometer and will track the
number of steps taken and calories burnt.
mESSaGE
On the main menu, tap on the Message icon to enter
the Message app to view text messages. To display
incoming calls and messages or notications from other
applications installed on your smart phone, you need to
turn on notications on the Da Fit app. The Message app
will store your last 3 messages, after the limit is reached,
the previously displayed message will be deleted.
ExErciSE
On the main menu, tap on the Sports icon to enter the
exercise/sports interface. There are 8 activities: walking,
running, cycling, climbing, soccer, basketball, jump
roping and badminton.
Select the desired exercise and the watch will display the
relevant data.
Please allow permission and enable the notication
settings on the respective smart phone application.
SlEEP monitorinG
On the main menu, tap on the Sleep icon to enter the
Sleep app. The Sleep app allows you to track your sleep
patterns (you must be wearing the watch throughout
your sleep). You can synchronise data between your
smart watch and the Da Fit App.
StoPwatch
On the main menu, tap on the S-Watch icon to enter
the stopwatch function. Tap the start icon to start the
stopwatch and the pause icon to pause. Press the icon
again to reset the time.
wEathEr
On the main menu, tap on the weather icon to display
the weather. You must be connected to the Da Fit app
for the weather to be available. Go to the others menu
on the app and turn weather on and select your city.
You must have Internet connection and your phone
location must be turned on.

14 15
hEart ratE mEaSUrEmEnt
On the main menu, tap on the HR icon to enter the heart
rate interface. It will vibrate once the measurement has
nished and the data will be displayed.
For accurate measurements, ensure the following:
• The smart watch has good contact with your wrist.
• Check that the sensor is clean and there is no dirt or
debris covering it.
• It may take over 30 seconds before the rst result is
shown on the screen.
Blood PrESSUrE
On the main menu, tap on the Blood Pressure (BP) icon
to enter the blood pressure interface. It will vibrate
once the measurement has nished and the data will be
displayed. Tap the measure icon on the app to start a
new measurement.
Blood oxyGEn
On the main menu, tap on the Blood Oxygen (SPO2)
icon to enter the blood oxygen interface. It will vibrate
once the measurement has nished and the data will be
displayed. Tap the measure icon on the app to start a
new measurement.
For accurate measurements for heart rate, blood pressure
and blood oxygen, ensure the following:
• The smart watch has good contact with your wrist.
• Check that the sensor is clean and there is no dirt or
debris covering it.
• It may take over 30 seconds before the rst result is
shown on the screen.
Note: The results and measurements of heart rate, blood
pressure and blood oxygen data cannot be used for
medical reference and should be used as a guide only.
camEra (rEmotE caPtUrE)
On the Da Fit app, make sure the watch is connected.
On the main menu, tap on the camera to use the watch
as a camera remote for your phone. Tap the camera icon
again (you can also tap “shutter” on the app). Tap the
icon on the watch screen to remotely take a photo.
BriGhtnESS
On the main menu, tap on the brightness icon to adjust
the screen brightness of the watch. Swipe right to exit to
the main menu and save the brightness setting.

16 17
morE
On the main menu, tap on the More icon to enter and
change the following settings:
rESEt: Reset all settings to the factory state.
PowEr off: Turn the watch o.
aBoUt: Display the watch’s Bluetooth name, hardware
address and software version.
watch facE
You can change the watch face on the Da Fit app.
Go to the watch faces menu on the app, tap on the
desired design and the watch will now display the
selected face.
SEt alarm
You can set alarms on the Da Fit app and synchronise to
the watch. On the app, turn alarm on and set the time.
You can set up to 3 alarms. The watch will vibrate during
the set alarm.
troUBlEShootinG
ProBlEm SolUtion
Weather function
is not working
• Ensure your smart watch is
connected to the Da Fit app.
• Ensure you have Wi-Fi/Mobile
data internet connection
• Ensure your smartphone’s
location/GPS setting is on.
• Manually set the city on the Da
Fit app.
Heart rate/Blood
pressure/Blood
oxygen function is
not working
• The smart watch has good
contact with your wrist.
• Check that the sensor is clean
and there is no dirt or debris
covering it.
• It may take over 30 seconds
before the rst result is shown
on the screen.

18 19
comPliancE and rESPonSiBlE diSPoSal
Packaging
The packaging of your product has been selected from
environmentally friendly materials and can usually be recycled.
Please ensure these are disposed of correctly. Plastic wrapping
can be a suffocation hazard for babies and young children, please
ensure all packaging materials are out of reach and are safely
disposed of. Please recycle these materials rather than throwing
them away.
Product
At the end of its working life, do not throw this product out with
your household rubbish. An environmentally friendly method of
disposal will ensure that valuable raw materials can be recycled.
Electrical and electronic items contain materials and substances
which, if handled or disposed of incorrectly, could potentially be
hazardous to the environment and human health.
This product complies with the Australian Safety Standard
AS/NZS 62368.1 to ensure the safety of the product.
Display 1.3”, 240 x 240 pixels
Ingress protection IP67
Charging time 3 hrs (approx.)
Charging base
input 5V 100mA
Bluetooth Range < 10m
Built-In Battery Li-ion 3.7V 170mAh
Weight 41g
Dimensions (mm) 35(W) x 40(H) x 12(D)
SPEcificationS
The Bluetooth®word mark and logos are registered trademarks
owned by Bluetooth SIG,Inc. and any use of such marks by
Hands (IP) Holdings Pty Ltd is under license. Other trademarks
and trade names are those of their respective owners.
