Ambient Recording VSLOT User manual
experience quality.
V-Mount Chassis
VSLOT
VSLOT
!
Ambient Recording GmbH
2
Battery side
Camera side
Unislot connector (25-pin sub-D)
Standard adaptor cable: VSL-2X3
experience quality.
VSLOT
www.ambient.de/en
3
Connection:
Camera: every V-Mount equipped camera
Battery: every V-Mount equipped battery supply
Radio Receiver: all receivers equipped with an Unislot connector (25-pin sub-D)
VSLOT Audio Output: TA5M receptacle
Included adaptor cable: TA5F to 2x 3-pin XLR male for stereo reception
Length: approx. 20 cm
Mechanical Specification:
Dimensions (body housing): 141 x 88 x 48 mm
Weight (unit only): approx. 400 g
Material: POM, aluminum
Electric Specification:
Battery Type: every V-Mount
equipped battery supply
max. 18V
Maximale Strombelastung: 10A
Ambient Recording GmbH
Schleissheimer Straße 181 C | D – 80797 Munich | vox +49 89 36005510-0 | fax +49 89 651855
www.ambient.de/en | info@ambient.de
MADE IN GERMANY
Approvals:
- Conformity Statement:
Manufacturer´s Name: Ambient Recording GmbH
Manufacturer´s Address: Schleissheimer Str. 181 C
DE ‒80797 Munich, Germany
declares that the product:
VSLOT, V-Mount Chassis
is conformity with:
Document No.
EN 301 489-01
EN 301 489-09
FCC-Code of Federal Regulations,
CFR47, Part 15, Sections 15.107 and 15.109 (Class B)
Industry Canada Interference-Causing Equipment Standard ICES-003 Issue 4,
Sections 5.3 and 5.5 (Digital Apparatus)
© 2014, Ambient Recording GmbH
