Ancor PM 13- 2778 User manual

INSTALLATION
Fix pump to engine in accordance with request fixing.
TECHNICAL FEATURES
• Pump body: bronze-aluminium
• Impeller: neophrene
• Deliveries: see scheme A
DESCRIPTION
This pump must be use for engine cooling only.
It is perfectly self-priming.
Use with salt or fresh water only.
Pump does not run dry.
Attention : these instructions are addressed to specialized technicians, prepared to correct use of manual and motorized
utensils and of all security precautions (eyes protection including). Before to use product, insure to read carefully this
instruction guide. For any work on the pump we recommend the use of protective gloves. Disposal of obsolete product must
be in accordance with the rules and regulations applied in te Country of destination. Product guarantee: 1 year.
We thank you a lot for purchase of our cooling pump.
ENGINE COOLING PUMPS
PM MODEL
INSTRUCTION USER GUIDE
After made pump installation in according with Par. “Installation”, connect pipe to
inlet connections.
The section of both suction and delivery pipes must respect the pump inlet original
sections.
Dip pipe into liquid and then turn on pump.
After 15 seconds about, pump starts to deliver liquid.
WARNING
• Do not use Ancor pumps for petrol, gasoline, petroleum products or any product with flash point
below 37°C (98°F)
• Keep product away from children
• Verify that pump is locked strongly before use
• Use pump for described applications only
• Do not vacuum solid part with pump
MAINTENANCE
We suggest regularly maintenance of cooling circuit in order to avoid damages caused by
overheat.
It’s also important to preserve cooling circuit during outhousing period to avoid damages
caused by cold and corrosion.
N.B. It’s better to have maintenance adrift, else can be enter water onboard.
Pump does not run dry.
In case of water filter is mounted on, verify that it is clear and integral.
Impeller: The impeller is very important to safety.
It’s necessary to replace it every 500 operating hours at least.
A damaged impeller must be replaced IMMEDIATELY.
We suggest to keep a new impeller with gasket onboard always.
MALFUNCTIONING
• Pump does not start: check if pump connection with engine is correct
• Pump does not vacuum: check liquid level and position of pipe into liquid
• Pump does not much vacuum:
- Check if impeller is damaged or if there are residual inside or if impeller is
unsticked from its insert.
- Check if there are air leakages inside circuit. In order to verify this, check if
outflow from pump has lacteal form, caused by nebulised air inside circuit.
- Verify that inside seal below impeller , is integral and soundness.
In case malfunction keep on , please do not hesitate to contact our customer
assistance office at phone nr [phone].
For any further information you can contact our customer service at telephone
no. [phone], or by mail writing to [e-mail]
In case malfunction keep on, please do not hesitate to contact our customer assistance office at phone nr +39
029657321.
For any further information you can contact our customer service at telephone no. [phone], or by
mail writing to [e-mail]
DECLARATION OF CONFORMITY CE (According to
the Machinery Directive 2006/42/EC, Annex II)
With this documentation the ANCOR srl declares that the equipment together with this document
and shown on the cover are produced and marketed in accordance with the Machinery Directive
2006/42/EC, as amended. All of the product documentation, including drawings and statements of
suppliers for components and processes of the product are kept at the premises of the company and
managed under the Quality Management System in accordance with UNI EN ISO 9001:2008.
Therefore, the ANCOR srl complies with the rule stated above the development of “technical
documentation” of this product.
Caronno Pertusella 01/04/10
Andrea Melgrati
(Legal Representative authorized to compile the technical file)
(address as at Ancor srl)

KITS LIST DELIVERIES LITERS - MIN
Pompa Pump
Kit
Portata
Range
Bocche
Connections
PM 13- 2778
2501
1
3/8” gas
PM 15-273
4456
2
3/8” gas
PM 15/T-5037
5988
2
3/8” GAS
PM 16-2018
2502
3
½” gas
PM 37-2770
2807
4
3/8” gas
PM 38-2520
2504
5
3/8” gas
PM 35-4257
2503
6
¾” gas
PM 36-2020
2800
7
1” gas
PM 40-2021
2506
8
1 ½” gas
PMF 40-3985
9
1 ½” gas
Range
900 r.p.m.
1400 r.p.m.
2000 r.p.m.
0 Bar
0,6
Bar
0 Bar
0,6
Bar
0 Bar
0,6
Bar
1
18
10
20
14
26
20
2
18
10
20
14
26
20
3
22,5
21
36
34,5
50
47
4
17
13
22
18
32
26
5
17
13
22
18
32
26
6
23
20
35
32
44
39,5
7
53
45
80
78
96
93
8
121
107
195
181
293
270
9
121
107
195
181
293
270
Range =Legenda (vedere tabella Kit – SEE KITS SCHEME)
