Anova A Series User manual

Anova Industries
Houston TX USA
TEL: [phone]
FAX: [phone]
www.waterbaths.com
[e-mail]
Operating Manual
Refrigerated and Heating Circulators – A Series

2
Thank you for choosing Anova Temperature Control Instruments!
This manual covers basic operational usage of our circulators. For optimal utilization of all functions, we
recommend that you thoroughly study this manual prior to beginning operation. Anova does not directly support
OEM systems or system branded for other companies. OEM systems may contain different specifications and
features that are not covered in this manual. This manual also does not include usage instructions for OEM /
custom designed systems because they typically run custom software designed by other companies.
Intellectual Property
All Intellectual Properties, as defined below, owned by or which is otherwise the property of Versa Inc. or its suppliers relating to Versa
products, including but not limited to, accessories, parts or software relating thereto (Versa Instruments), are proprietary to federal and state
laws, and international treaty provisions. Intellectual Property includes but is not limited to, inventions (patentable or unpatentable), patents,
trade secrets, copyrights, software, firmware, computer programs, and related documentation and other works of authorship. Moreover, you
agree that you will not, and will not attempt to, modify, prepare derivative works of, reverse engineer, disassemble the Versa instruments,
decompile or otherwise attempt to create source code from the related software/firmware. No title to or ownership in Intellectual Property is
transferred to you. All applicable rights of the Intellectual Property shall remain with versa and its suppliers.

3
Unpack the circulator and accessories and inspect them for
possible transport damage.
Wait 24 hours before Power On for Max Cooling Capacity on
Refrigerated Systems
Immediately report damage to Anova and the responsible carrier.
Failures to report transport damage will not allow us to support your claim for insurance.

4
TABLE OF CONTENTS
Introduction 5
Safety 6
Application safety 7
Installation 7
Safe Bath fluids 7-8
Filling procedures 8
Disposal 9
Technical specifications 10
Operating controls and functional elements 11-12
Computer control (RS232 Operation) 13-14
Maintenance 15
Warranty 16

5
Introduction
Anova circulators control the temperature of specific fluids in a bath tank. The system features a pump
connection for temperature control of external systems in a closed loop circuit.
Anova circulators are not for direct temperature control. Direct temperature control means direct contact
of the object with the bath fluid. This includes food, tobacco, pharmaceutical and other consumed organic
products.
Do not use Anova circulators to directly cook food – at no time should food products come in contact with
bath fluid. Food must by vacuum-sealed before use with circulator.

6
Safety
Anova products ensure safe operation when installed, operated, and maintained according to
Safety recommendations in this manual. This section explains the potential dangers that may
arise when operating Anova circulator and notes many important safety precautions.
FIRE HAZARD
Be careful when filling the bath with flammable fluids
Observe fluid flash points and adjust safety dial
Observe all warnings for bath fluids and the respective safety datasheets
Only use the system in well-ventilated areas when using flammable fluids
Insufficient ventilation may result in the formation of explosive mixtures
DO NOT OPERATE WITH SUSPECTED FAILURES
Do not run circulation fluids above their boiling point
Do not crimped circulation lines.
Do not circulate cold fluid into hot glassware
Do not set safety temperature limiter above fluid flash points.
Anova is not responsible for any damage that might result from examples similar to above
BURN HAZARD
Do not touch connectors and bath cover or fluids when bath is under high temperature
OBSERVE ALL WARNING LABELS ON PRODUCT
Read all labels on product to ensure proper usage.
GROUND PRODUCT
Proper grounding is required.
Operational Safety
Follow the safety instructions to avoid personal injury and property damage.
Fluids Safety:
●Set the temperature safety dial to at least 25 °C below the flash point of the bath fluid.
●Never operate the system without bath fluid in the bath.
●Do not introduce water into hot oil.
●Pay attention to the thermal expansion of bath oil during heating to avoid overflows.
●Do not drain the bath fluid while it is hot!
Circulation Safety:
●Note the temperature range of plastic bath tanks and tubing – they melt!!!
●Avoid bent and crimped tubing in the tubing, and maintain a sufficient distance from
surrounding walls.
●Regularly check the tubing for material defects (e.g., for cracks and leaks).
Installation and transport safety:
●Place the system on an even surface to prevent spills and tip over.
●Do not operate damaged or leaking units.
●Disconnect power before cleaning the unit.
●Sudden jolts or drops may cause damage in the interior of the unit.
●Do not remove warning labels.

7
Application Safety:
Temperature controlling the contents of a reactor constitutes normal circulator practice.
However, we do not know what substances are contained within reactor vessels and cannot help
with determining the safety of your applications.
Many chemicals are:
●Flammable or explosive
●Hazardous to health
●environmentally unsafe
Many materials and reaction processes are unstable at room temperature.
The user alone is responsible for the handling of these substances and determining the safety of his or
her individual applications.
Installation
•Wait at least an hour to setup the system after transportation. This will allow any compressor oil to drain
back into the compressor. Failure to do so will compromise the cooling performance of the system.
• The installation location should be large enough and provide sufficient air ventilation.
• Keep at least 1 foot of open space on the front and rear vents.
• Do not set up the unit in the immediate vicinity of heat sources.
• Do not install in outdoors and do not expose to sun light.
• Make sure that the power supply has low impedance.
• Ambient temperature range: 40 °C, min. 5 °C.
• Relative humidity: 50% (40 °C).
Safe Bath fluids
Caution:
Carefully read the safety data sheet of the bath fluid, pay attention to the fluid flash point!
Use only non-acidic and non-corrosive bath fluids.
If user chooses to use non-approved fluids make sure they are non-corroding.
If using hazardous materials or materials that could become hazardous, the operator must affix safety
labels to the front of the unit so they are highly visible.
Recommended Bath Fluids:

8
Fluid recommendations for cold temps:
Temperature ranges 1°C -20°C: Ethanol or water/glycol mixture 1:1
Temperature ranges -20°C to -40°C: Dynalene
Fluid recommendations for hot temps:
Temperature ranges 1°C to 80C: Soft/decalcified water or distilled water only. Tap water quality is highly
variable based on local conditions.
Temperature ranges 80 °C to 200 °C: Mineral/silicone oils
Warning:
• Hard water leads to calcification in the bath.
• Ferrous water can cause corrosion.
• Chloric water can cause pitting corrosion.
• Lab distilled and deionized water can cause corrosion if used long term, even in stainless steel.
Fire or other dangers when using bath fluids that are not recommended:
Please contact Anova before using other than recommended bath fluids. Anova assumes no liability for
damage caused by the selection of an unsuitable bath liquid.
Unsuitable bath fluids are fluids which:
• are highly viscous
• have creep characteristics
• have corrosive characteristics
Filling
Take care that no liquid enters the interior of the circulator.
Recommended maximum filling level of 1.5 Inches below the rim.
Pay attention to overflow of liquid.
Do not drain the bath fluid while it is hot!

9
Disposal
This product uses bath fluids that might partially consist of mineral oil or synthetic oil. For disposal,
observe the instructions in the safety data sheets. Some systems contains common refrigerants found in
household products please contact your local waste management company to determine disposal
requirements.

10
Technical specifications
System
C
6
C
14
C22
A
15
A
25
A
30
A
40
Temperature
Min
°C
-
-
-
-
20
-
25
-
30
-
40
Temperature Max
°C
150
200
200
150
200
200
200
Stability
± .01ºC ± .01ºC ± .01ºC ± .01ºC ± .01ºC ± .01ºC ± .01ºC
Heater Power
1KW
1KW
1KW
1
KW
1KW
1KW
1KW
Circulation Pump
15LPM
15LPM
15LPM
15LPM
15LPM
15LPM
15LPM
Input power
120V
120V
120V
120V
120V
120V
120V

11
Operating controls and functional elements
1) LCD with touchpad
2) Control Keypad
3) Indication LEDS
4) Temperature Display
5) Safety Dial Temperature Limiter
6) Bath Opening
7) Power Switch
8) Power Connector
9) Fuse
10) RS232 Port
11) Circulation Inlet/outlet

12
Operating controls and functional elements (cooling systems)
1) LCD with touchpad
2) Control Keypad
3) Indication LEDS
4) Bath opening
5) Drain port (on back in some models)
6) Air Filter for condenser
7) Start/Stop
8) Temperature LED Indicator / Safety Dial
9) Power Switch
10) Power Plug – Please used use Anova supplied heavy duty power cord
11) Fuse – (location may vary)
12) RS232 Port – for PC control
13) Circulation Inlet/outlet

13
Computer Control (RS232 Operation)
Cable Requirements
In order to interface to a PC you need the following hardware cable pictured below:
DB9 Serial Cable Male to Female – Strait though configuration. Do not purchase a “Null Modem,” “crossover,” or
“Crossed over” cables.
Before interfacing with a PC, make sure a RS232 port exists on your PC. RS232 ports will be in parentheses and
named “COM1-100” like the one above named COM1
RS232 Port Settings (continued)
Baud Rate - 9600, Data Bits - 8, Parity - none, Stop bits - 1, Flow control – none.

14
Most programming packages like LabView, LabWindows and Visual Studio will allow you to program comport
settings dynamically in program.
RS232 Commands
Note: All Rs232 commands are not case sensitive.
Do not include quotation marks when entering in commands.
Commands are "initiated" by a carriage return.
Status Commands
“help” – returns list of end user commands
“version” – returns software version information
“status” – returns status of system
“default” – sets ramp rate and pump speed to “auto” settings.
“temp” – returns bath temperature
Control Commands
“start” – starts system
“stop” – stops system
“clear” – clears stops from errors
Settings Commands
“set temp xxx.xx” - sets temperature max 5 significant digits
“set highlimit xxx.xx” – sets high temperature warning
“set lowlimit xxx.xx” – sets low temperature warning
“set pump speed” – sets pump speed from 20-100
“get temp setting” – returns temperature settings
“get highlimit setting” – returns high temperature warning
“get lowlimit setting” – returns low temperature warning

15
System Maintenance
Caution:
General Information
• Always turn off the unit when not in operation.
• Electrical connections and any other work must be performed by Anova certified personnel only.
Maintaining Cooling Performance
Coolant Maintenance
1. Power off chiller and open chiller reservoir drain port.
2. Drain reservoir into drip pan. Tip chiller to remove all fluid from the reservoir.
3. Flush chiller. If it is a water-soluble coolant, use water to flush out. If it is an oil-based coolant, use
surfactant and water to flush out. For cleaning the bath tank and the immersed parts of the circulator,
use a mild surfactant like dish soap and a soft brush. Do not use steel wool or bleach - this will cause
corrosion and pitting of the bath.
4. Turn chiller on.
Cleaning the Exhaust Vent
1. Wipe the rear exhaust vent with a wet towel.
2. Remove any excess restrictions with compressed air.
Cleaning the Air Filter
1. Remove front panel.
2. Remove the air filter.
3. Clean under running water. This may require surfactants or detergents based on air contents.
Chiller Maintenance Schedule
1. Replace coolant when visibly dirty. Although it is possible to run the instrument, using old coolant
will significantly decrease instrument usability and life by clogging the pump and restricting
system performance.
Repairs
Please contact an Anova representative for a return authorization (RA) number.
• During transport, the unit must stand upright. Mark the packaging with the RA number.
• When returning a unit, take care of careful and adequate packing.
• Anova is not responsible for damages that might occur from insufficient packing.
• Must be shipped by freight when returning the entire unit.

16
WARRANTY PROVISIONS
1. Do not restrict airflow from the back and front of the system.
2. Use appropriate coolant – no acid/base solutions or salts.
Failure to comply with aforementioned requirements will result in voidance of manufacturer’s warranty.
The following Warranty Provisions shall apply to products sold in North America by Anova (“Seller”) to the entity shown as
buyer (“Buyer”) on Seller’s invoice.
1. Warranty. Seller warrants to the Buyer that the products manufactured by the Seller are free from defects in material and
workmanship for a period not to exceed one year or five thousand (5,000) hours of operation, whichever comes first, from the
date the product is shipped by Seller to Buyer (the “Warranty”).
2. Exclusions. The Warranty does not include damage to the product resulting from accident, misuse, improper installation or
operation, unauthorized or improper repair, replacement or alteration(including but not limited to repairs, replacements, or
alterations made or performed by persons other than Seller’s employees or authorized representatives), failure to provide or
use of improper maintenance, unreasonable use or abuse of the product, or failure to follow written installation or operating
instructions. Buyer must return the product’s record of purchase to the Seller or one of Seller’s authorized representatives
within thirty (30) days of the date the product is shipped by Seller to Buyer in order to make a claim under the Warranty.
Notwithstanding anything contained herein to the contrary, all glassware, including but not limited to reference thermometers,
are expressly excluded from the Initial Warranty.
3. Governing Law. The Warranty Provisions and all questions relating to their validity, interpretation, performance, and
enforcement shall be construed in accordance with, and shall be governed by, the substantive laws of the State of Texas.
4. Shipping. Buyer will arrange and pay for shipping and handling charges for the unit to be returned to the Seller. Seller will
arrange and pay for shipping and handling for the return of the unit to the Buyer.
