ANTlabs InnGate 3 M-series Use and care manual

INNGATE 3
ADMINISTRATOR’S MANUAL
DOCUMENT RELEASE 1.01

Connectivity Made Easy Page 2 of 164
InnGate 3 Administrator’s Manual
This manual provides an in-depth coverage of the setup, configuration and
administration of an InnGate 3 and is intended for system and network
administrators who will be performing these tasks.
Copyright © 2002 - 2009 Advanced Network Technology Laboratories Pte Ltd.
All rights reserved.

Connectivity Made Easy Page 3 of 164
TRADEMARKS AND ACKNOWLEDGEMENTS
The following trademarks and acknowledgments apply to the following:
The InnGate system and Tru’Connect™ technology are products and
technologies of Advanced Network Technology Laboratories Pte Ltd,
(ANT
labs ). Windows and Microsoft are registered trademarks of
Microsoft Corporation. Solaris is a registered trademark of Sun
Microsystems. All other products mentioned in this manual are
trademarks of their respective owners.
DISCLAIMER
No part of this manual may be copied, distributed, transmitted,
transcribed, stored in a retrieval system or translated into any human
or computer language, in any form or by any means, electronic or
otherwise, without the express written permission of ANT
labs .
The software and accompanying written materials (including
instructions for use and this document) are provided “as is” without
warranty of any kind.
ANT
labs does not warrant, guarantee or make any representations
regarding the use, or the results of the use, of the software or written
materials in terms of correctness, accuracy, reliability, trend or
otherwise. ANT
labs reserves the right to make changes without further
notice to any products described herein to improve reliability, function
or design. This documentation is copyrighted and may not be altered
without written consent from ANT
labs .
ANT
labs reserves the right to prosecute companies or individuals who
make, distribute or use illegal copies of this software system and its
accompanying documentation.
Release Date: 10 July 2009
Document Reference No: IG3-ADM

Connectivity Made Easy Page 4 of 164
CONTENTS
Chapter 1................................................................................................ 9
GETTING STARTED............................................................................. 9
1.1Overview ............................................................................... 9
1.1.1Hardware.........................................................................10
1.1.2Network Operation............................................................11
1.2Recommended Setting...........................................................12
1.3System Setup........................................................................12
1.3.1Accessing the Web-based Admin GUI.................................13
1.3.2Configuring the WAN Interface ..........................................15
1.3.3Configuring the Domain Name Server.................................17
1.3.4Configuring the Web Proxy................................................18
1.3.5Creating a Plan.................................................................20
1.3.6Firewall Rules...................................................................22
1.3.7Creating a Location...........................................................24
1.3.8Creating VLANs ................................................................32
1.3.9Importing and Exporting VLAN Definitions ..........................34
1.4Network Installation...............................................................35
1.4.1VLAN-enabled Networks....................................................36
1.5Testing the Configuration.......................................................36
Chapter 2...............................................................................................38
Authentication ...................................................................................38
2.1Overview ..............................................................................38
2.2Local Accounts ......................................................................38
2.2.1Local Accounts Maintenance..............................................40
2.3PMS......................................................................................40
2.4Account Printers....................................................................43
2.5Credit Card ...........................................................................47
2.6MAC Filter.............................................................................47
2.7Global Settings......................................................................48
Chapter 3...............................................................................................50
LAN NETWORK SETTINGS..................................................................50
3.1Overview ..............................................................................50
3.2DHCP Setup..........................................................................51
3.2.1Configuring DHCP Server Mode..........................................51
3.2.1.1Setting up the Default Scope ........................................53
3.2.1.2Setting up the User Provision Routed Scope...................55
3.2.2Configuring DHCP Relay Mode ...........................................60
3.2.2.1Relay Agent Mappings..................................................61
3.3Routed Network Setup...........................................................62
3.4Walled Garden Setup .............................................................64
3.4.1Define HTTP URLs ............................................................65
3.4.2Define HTTPS Domains .....................................................67
3.4.3Define IP Addresses..........................................................69
3.5Network Devices Setup ..........................................................71
3.5.1Port Binding.....................................................................72

Connectivity Made Easy Page 5 of 164
3.6Device Detection Setup..........................................................75
3.7ARP Setup.............................................................................76
Chapter 4...............................................................................................78
WAN NETWORK SETTINGS.................................................................78
4.1Overview ..............................................................................78
4.2WAN Setup ...........................................................................78
4.2.1Defining a Static Route......................................................78
Chapter 5...............................................................................................80
NETWORK SERVICES SETTINGS .........................................................80
5.1Overview ..............................................................................80
5.2Web Server...........................................................................80
5.3Web Proxy............................................................................81
5.4Email Server..........................................................................81
5.5Remote Access......................................................................84
5.5.1Accessing the InnGate via Telnet and FTP ..........................86
Chapter 6...............................................................................................87
SYSTEM MAINTENANCE AND DIAGNOSTICS........................................87
6.1Overview ..............................................................................87
6.2Local Accounts Maintenance...................................................87
6.3Reports Maintenance .............................................................88
6.4PMS Diagnostics....................................................................90
Chapter 7...............................................................................................92
SYSTEM MONITORING AND REPORTING.............................................92
7.1Overview ..............................................................................92
7.2Monitors ...............................................................................92
7.2.1Status Monitor..................................................................92
7.2.2Device Monitor .................................................................94
7.2.3Session Monitor................................................................96
7.2.4Account Monitor ...............................................................97
7.2.5Cookies Monitor................................................................99
7.2.6Email Monitor.................................................................100
7.3Logs...................................................................................101
7.3.1Device Logs....................................................................101
7.3.2Session Logs ..................................................................102
7.3.3PMS Logs.......................................................................103
7.3.4Account Printer Logs.......................................................105
7.3.5Credit Card Logs.............................................................106
7.4Maintenance .......................................................................106
Chapter 8.............................................................................................107
SYSTEM ADMINISTRATION ..............................................................107
8.1Overview ............................................................................107
8.2Setting up Administrator Accounts.........................................107
8.2.1Creating an Administrator Group......................................108
8.2.2Defining Admin Group Permissions...................................109
8.2.3Creating an Administrator Account ...................................110
8.2.4Viewing Audit Log...........................................................112
8.2.5Assigning Admin Access ..................................................112
8.2.6Viewing Sessions ............................................................113

Connectivity Made Easy Page 6 of 164
8.3Powering up and shutting down the system...........................113
8.4System Configuration Backup or Restore ...............................114
8.5Applying System Patches......................................................115
8.6Setting the Date and Time....................................................116
8.7Syslog Configuration............................................................117
8.8SNMP Setup........................................................................118
8.8.1Traps Generated.............................................................120
8.8.2Supported MIBs..............................................................124
8.9View API Information...........................................................124
8.9.1HTTP Setting..................................................................125
8.9.2Browser Setting..............................................................126
8.10High Availability...................................................................128
8.11View License Information.....................................................128
8.12Console Access via Serial Connection.....................................128
8.13Securing the System for Deployment.....................................129
8.13.1Securing Access to the Admin GUI ...................................129
8.13.2Change the Default Admin User Account...........................130
8.13.3Change the FTP Account Password...................................131
8.13.4Change the Telnet and Console Password.........................131
Chapter 9.............................................................................................133
HIGH AVAILABILITY (E-Series) .........................................................133
9.1Overview ............................................................................133
9.2Network Configuration .........................................................133
9.3System Configuration...........................................................134
9.3.1HA Identifier ..................................................................136
9.4HA Leader Election ..............................................................137
9.5HA Failover Behavior............................................................137
9.6HA Synchronization..............................................................138
9.6.1Manual Synchronization...................................................139
Chapter 10...........................................................................................141
HIGH AVAILABILITY (M-Series).........................................................141
10.1Overview ............................................................................141
10.2Network Configuration .........................................................141
10.3System Configuration...........................................................142
10.4Billing Configuration.............................................................144
10.5Failover Behavior.................................................................145
Chapter 11...........................................................................................146
System Save & Restoration...............................................................146
11.1Overview ............................................................................146
11.2Save Snapshot ....................................................................146
11.3Restore Firmware ................................................................147
11.4Restore Snapshot ................................................................149
Appendix A...........................................................................................151
REDIRECT LOG................................................................................151
Appendix B...........................................................................................154
PERL REGULAR EXPRESSIONS..........................................................154
Appendix C...........................................................................................155
CSV FILE RESTRICTIONS .................................................................155

Connectivity Made Easy Page 7 of 164
Appendix D ..........................................................................................156
UPLOADING CUSTOM WEBPAGES .....................................................156
Appendix E...........................................................................................157
CUSTOM SSL LOGIN PAGES..............................................................157
Appendix F...........................................................................................161
ERROR PAGES.................................................................................161
Appendix G ..........................................................................................163
CREDIT CARD..................................................................................163

Connectivity Made Easy Page 8 of 164
PREFACE
AUDIENCE
This manual is intended for administrators who will be responsible for the
installation and configuration of the InnGate 3.
This manual will explain how first-time installation and configuration should
be done as well as the tasks involved in performing regular maintenance and
configuration.
Administrators are expected to have a good working knowledge of networks
and TCP/IP. Knowledge of the operating environment and characteristics of
the systems used in the deployed networks are also useful. Basic knowledge
of HTML and HTTP will also allow the administrator to customize the user-
facing web pages.
RELATED DOCUMENTATION
You may refer to the ANT
labs homepage at http://www.antlabs.com/ for
other related materials and documents released by ANT
labs .
FEEDBACK AND COMMENTS
ANT
labs welcomes all comments and suggestions on the quality and
usefulness of this document. Our users’ feedback is an important component
of the information used for improvement of this document.
Please include in your feedback:
Name
Title
Company
Department
E-Mail
Postal Address
Telephone Number
Document Title & Release No
Document Reference No.

Comments/Feedback
Also, please include the chapter, section and/or page number when referring
to specific portions of the document.
Send your comments via email to [email protected]

Connectivity Made Easy Page 9 of 164
Chapter 1
GETTING STARTED
1.1 Overview
This chapter will illustrate a simple network deployment of the InnGate 3
involving the following 3 steps:
1. System Setup – Configuring the InnGate to operate in the network.
2. Network Installation – Connecting the InnGate to the network.
3. Testing the Configuration – Ensuring that the InnGate operates as
expected.
Figure 1-1 shows a simple network setup which will be used to illustrate the
deployment steps in this chapter.
Figure 1-1 Example Network Diagram

Connectivity Made Easy Page 10 of 164
Although your own network will likely differ from this, the general principles
for installing and configuring the InnGate are still applicable.
The setup covered in this chapter is suitable for quick demonstrations and
small-scale setups. Later chapters will cover details for more complex
deployment scenarios.
1.1.1 Hardware
Front Panel
Back Panel
Figure 1-2 InnGate E Series Front & Back Panels
Front Panel
Back Panel
Figure 1-3 InnGate M Series Front & Back Panels
Some of the switches and connectors shown in Figure 1-2 and Figure 1-3 are
described here:

Connectivity Made Easy Page 11 of 164
1. USB Serial Console – The left USB port allows direct console access
to the InnGate. Use the provided USB-to-serial converter to connect a
PC with a terminal program to access the console (see Section 8.12).
2. Serial Console – The M-series serial console allows direct console
access to the InnGate.
3. LAN – All clients to be managed by the InnGate are placed on the
network which is connected to this port.
4. WAN – This port connects the InnGate to the rest of the network for
client traffic to pass through.
5. OPT1 – Used to connect two InnGates in a High Availability (HA)
setup. Both OPT1 have to be connected to the same HA VLAN. This will
be used for the HA heartbeat signals between the gateways.
6. Power button (for E Series only) – The power button is located to
the left of the front panel, behind the faceplate. The behaviour of the
button depends on the power state:
a. InnGate is powered up – Pressing will shut down the
InnGate.
b. InnGate was shutdown normally – Press to power up.
In the event of a power failure, the InnGate will automatically
power up when the supply from the electrical mains is restored. The
power button does not need to be pressed.
The hardware serial number is usually found on the rear panel of the InnGate
and the licensing serial number is accessible via the Admin GUI (see Section
8.11).
1.1.2 Network Operation
As shown in Figure 1-1, the InnGate separates the network into the
upstream and downstream networks:
1. Downstream Network – The InnGate manages the Authentication,
Authorization and Accounting (AAA) functions and enables the
Tru’Connect Zero-Configuration for client devices on the downstream.
2. Upstream Network – Only successfully authenticated downstream
clients may be authorized to access the upstream network. This is
where the server farm, DMZ and also the gateway to the Internet
normally reside.

Connectivity Made Easy Page 12 of 164
When in operation, the InnGate performs Network Address and Port
Translation (NAPT) on the WAN interface for downstream clients (routing can
also be done and is discussed in Section 3.2 and Section 3.3). Thus when a
downstream client wants to send packets to the upstream, the InnGate will
do so using its WAN IP address.
1.2 Recommended Setting
The recommended settings for InnGate 3 are shown in table below:
M-Series E-Series EX-Series
Recommended Recommended Recommended
User Accounts 1,000 10,000 20,000Total number of accounts* + MAC
filter entries
Log Entries 5,000 50,000 50,000
Total number of log entries in
database
User Licenses 300 1,000 1,000
Total number of detected devices
VLANs 300 1,000 2,000
Total number of configured VLANs
Network Devices 30 100 200
Total number of Network devices
Port Binding Rules 30 100 200
Total number of Port Binding rules
Undelivered Mails 1,000 10,000 20,000
Total number of undelivered mails
Locations 5 15 25
Total number of defined Locations
Plans 10 30 50
Total number of defined Plans
1.3 System Setup
This section explains the basic configuration for a new InnGate to operate in
our network example. These configuration tasks are performed through the
web-based admin GUI (see Section 1.3.1):
1. Configuring the WAN Interface – See Section 1.3.2.
2. Configuring the Domain Name Server – See Section 1.3.3.
3. Configuring the Web Proxy (optional) – See Section 1.3.4.
4. Configuring the Plans – See Section 1.3.5.
5. Configuring the Locations – See Section 1.3.7.
6. Configuring the VLANs – See Section 1.3.8.

Connectivity Made Easy Page 13 of 164
Some of these tasks can also be performed through the Command Line
Interface (CLI) and is discussed separately in the InnGate Command Line
Reference.
1.3.1 Accessing the Web-based Admin GUI
This section explains how to access1the Web-based Admin GUI to configure
the system settings.
Power up the InnGate and connect to either the WAN or LAN port using a
cross-cable. Then follow the instructions to access the Admin GUI:
If ever you are unable to access the InnGate from one of the
interfaces due to possible incorrect configuration settings, you can
always attempt to reconnect via the other interface. In addition, the
Admin GUI can only be accessed via secure-HTTP (HTTPS) and the
forward slash (‘/’) after “admin” should be included.
1. Connecting from the WAN Interface:
The URL to access the Admin GUI is:
https://<WAN IP Address>/admin/
The factory default WAN IP address is 192.168.0.1, with a
subnet mask of 255.255.255.0. When connecting directly,
ensure that the subnet mask setting on your client device
matches the default value. The URL of the Admin GUI for a new
InnGate will therefore be: https://192.168.0.1/admin/
2. Connecting from the LAN Interface:
The URL to access the Admin GUI is:
https://ezxcess.antlabs.com/admin/
The “ezxcess.antlabs.com” domain is only valid on the LAN
network (assuming that LAN access to the Admin GUI is not
blocked) and is not a valid domain on the public Internet.
Figure 1-4 shows the SSL warning message you will see when connecting via
HTTPS. Click the Yes button to continue.
1You will need a version 4.0 or better MS IE/Netscape web browser to access the Admin GUI.
The web browser should also have cookies and Javascript enabled and must support frames.

Connectivity Made Easy Page 14 of 164
Figure 1-4 SSL Warning Message
The administrator’s login page is presented next (see Figure 1-5).
Figure 1-5 Login Prompt
Login with the default User ID “ root ” and default password “ admin ”.
It is recommended that you change the default password (see Section
8.3.2) to prevent unauthorized access.
Upon successful login, the main Admin Page will be displayed (Figure 1-6
shows a portion of the actual page), which is a status summary.
Figure 1-6 Admin Page

Connectivity Made Easy Page 15 of 164
The various menu options are displayed on the left side of the page and you
may return to the main Admin page at any time by clicking on the “InnGate”
logo at the top-left corner of the browser window.
1.3.2 Configuring the WAN Interface
The WAN interface has to be properly configured with a routable IP address,
valid subnet mask and gateway in order for the InnGate to function correctly
in your network.
To configure the WAN Interface:
1. Click on WAN.
A list of WAN profiles will be displayed (see Figure 1-7).
Figure 1-7 WAN Profiles
The InnGate comes preconfigured with a single default WAN profile. In our
example, we will go ahead and modify this profile by clicking on the entry.
The settings of the selected WAN Profile will be displayed (see Figure 1-8).

Connectivity Made Easy Page 16 of 164
Figure 1-8 Modify WAN Profile
The various fields are described as follows:
1. IP Address – The host IP address for the InnGate on the upstream
network.
The factory default IP address setting is 192.168.0.1 . Change this to
a valid routable IP address on your upstream network.
2. Subnet Mask – The subnet mask of the upstream network that the
InnGate is connected to.
The factory default subnet mask setting is 255.255.255.0 . Change
this to the mask used on your upstream network segment.
3. Gateway – The address of the router or gateway for the InnGate to
send network traffic to for the next-hop.
4. Bandwidth – Bandwidth options are available with an optional module
which may be purchased separately.
a. Download Limit – The maximum bandwidth allocated for the
WAN Interface for incoming packets.
b. Upload Limit – The maximum bandwidth allocated for the
WAN Interface for outgoing packets.

Connectivity Made Easy Page 17 of 164
5. Source NAT Address Range – The InnGate will use the pool of IP
addresses defined here when performing network address and port
translation (NAPT) on the WAN interface for its downstream clients.
The WAN IP address must be in the same subnet as the source
NAT address range
6. Description – A description of this profile.
Click to confirm the changes. The system will then display a summary of
the WAN profile.
If you are accessing the Admin GUI via the WAN interface and your web
browser appears to have stalled, it is because the browser is trying to access
the InnGate using the previous IP address. If that happens, close ALL
currently opened browser sessions, start a new browser session and login to
the admin page again.
1.3.3 Configuring the Domain Name Server
A DNS is required by the InnGate to resolve domain names. If you do not
configure this parameter, hosts will only be addressable via their IP
addresses.
If you have your own DNS within your network for name resolutions, you
can likewise configure the InnGate to use it. This DNS should be able to
resolve both internal and external domains. Alternatively, you can configure
the InnGate to use your ISP’s DNS for name resolutions. The InnGate also
allows more than one DNS entry to be specified.
To configure the DNS settings:
1. Click on WAN.
2. Click on DNS.
A list of DNS entries will be displayed (see Figure 1-9), sorted in order of
priority.
Figure 1-9 DNS Settings

Connectivity Made Easy Page 18 of 164
The InnGate comes with a default entry which we will modify according to
your network DNS defined. Click on the entry to proceed.
The DNS configuration page will be displayed (see Figure 1-10).
Figure 1-10 DNS Configuration Page
The fields are described here:
1. Parent DNS Server – IP address of the Domain Name Server that
can be contacted for name resolution. Click to add more entries.
Click to confirm the changes.
The InnGate will switch to another DNS server in the list for subsequent
name resolution attempts if a previous attempt was unanswered.
1.3.4 Configuring the Web Proxy
The InnGate can be configured to forward HTTP requests to a web proxy
server if necessary. This is optional, depending on whether your network
allows direct connections to the Internet or requires the use of a proxy.
To configure the Web Proxy settings:
1. Click on Services.
2. Click on Web Proxy.
The Web Proxy configuration page will be displayed (see Figure 1-11).

Connectivity Made Easy Page 19 of 164
Figure 1-11 Web Proxy Configuration
The various fields are described as follows:
1. Direct Connection – Select this if your network allows direct
connections to the Internet.
2. Use Proxy – Select this if your network requires the use of a web
proxy for browsing.
3. IP Address / Name – A proxy server entry that the InnGate can use
for downstream web traffic.
4. Port – The port number for accessing the proxy server.
5. Display Email – This is the email address that is displayed in error
pages generated when users attempt to access an invalid or
inaccessible URL.
You may add and remove proxy server entries by clicking or .
Click to confirm the entries.
Configuring the web proxy for the InnGate does not mean that the
downstream clients have to set their browser’s proxy setting. Downstream
clients will continue to enjoy Zero-Configuration. However, it is important to
note that a downstream client that has an existing browser proxy setting (e.g.
company laptop with corporate web proxy setting) should not change it after
logging in.

Connectivity Made Easy Page 20 of 164
1.3.5 Creating a Plan
Next you need to create the different types of service plans required. This
depends on your business needs.
To configure the Plans:
1. Click on Policies.
2. Click on Plans.
Any existing plans will be shown. Select an existing plan or create a new one.
Figure 1-12 Plans
Figure 1-13 shows the plan creation page. These are the fields:
1. Plan Name – Name of the plan. Best to give a meaningful name.
2. Price – The units to charge for usage. The definition of a unit depends
on what is defined in your PMS system.
3. Duration & Volume Limit – Select if you want to charge by duration
or data volume usage. The user will need to repurchase once the plan
is used up. The 4 different types of duration and volume plans
supported are:
a. Unlimited duration and volume
b. Fixed Duration / Single Duration – single fixed usage period
valid from the first time of use for the duration specified
c. Stored Duration – multiple usage period valid as long as there
is balanced time left
