Arris SURFboard SBG6700-AC User manual

User Guide
SURFboard® SBG6700-AC
Wireless Cable Modem Gateway
Firmware: SBG6X82-8.6.0.0-GA-08-046-NOSH

© 2014 ARRIS Enterprises, Inc. All rights reserved.
No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation,
transformation, or adaptation) without written permission from ARRIS Enterprises, Inc. (“ARRIS”). ARRIS reserves the right to revise this
publication and to make changes in content from time to time without obligation on the part of ARRIS to provide notification of such
revision or change.
ARRIS and the ARRIS logo are all trademarks of ARRIS Enterprises, Inc. Other trademarks and trade names may be used in this document to
refer to either the entities claiming the marks and the names of their products. ARRIS disclaims proprietary interest in the marks and names
of others.
Wi-Fi Alliance®, Wi-Fi®, the Wi-Fi logo, the Wi-Fi CERTIFIED logo, Wi-Fi Protected Access®(WPA), the Wi-Fi Protected Setup logo, and WMM®are
registered trademarks of Wi-Fi Alliance. Wi-Fi Protected Setup™, Wi-Fi Multimedia™, and WPA2™ are trademarks of Wi-Fi Alliance.
ARRIS provides this guide without warranty of any kind, implied or expressed, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. ARRIS may make improvements or changes in the product(s) described in this manual at
any time.
The capabilities, system requirements and/or compatibility with third-party products described herein are subject to change without notice.

Safety and Regulatory Information
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide i
365-095-25781 x.1
Safety and Regulatory
Information
IMPORTANT SAFETY INSTRUCTIONS
Read This Before You Begin — When using your equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to
persons, including the following:
•Read all of the instructions listed here and/or in the user manual before you operate this device. Give particular attention to all safety precautions.
Retain the instructions for future reference.
•This device must be installed and used in strict accordance with manufacturer’s instructions, as described in the user documentation that is included
with the device.
•Comply with all warning and caution statements in the instructions. Observe all warning and caution symbols that are affixed to this device.
•To prevent fire or shock hazard, do not expose this device to rain or moisture. The device must not be exposed to dripping or splashing. Do not place
objects filled with liquids, such as vases, on the device.
•This device was qualified under test conditions that included the use of the supplied cables between system components. To ensure regulatory and
safety compliance, use only the provided power and interface cables and install them properly.
•Different types of cord sets may be used for connections to the main POWER supply circuit. Use only a main line cord that complies with all applicable
device safety requirements of the country of use.
•Installation of this device must be in accordance with national wiring codes and conform to local regulations.
•Operate this device only from the type of power source indicated on the device’s marking label. If you are not sure of the type of power supplied to
your home, consult your dealer or local power company.
•Do not overload outlets or extension cords, as this can result in a risk of fire or electric shock. Overloaded AC outlets, extension cords, frayed power
cords, damaged or cracked wire insulation, and broken plugs are dangerous. They may result in a shock or fire hazard.
•Route power supply cords so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to
cords where they are attached to plugs and convenience receptacles, and examine the point where they exit from the device.
•Place this device in a location that is close enough to an electrical outlet to accommodate the length of the power cord.
•Place the device to allow for easy access when disconnecting the power cord of the device from the AC wall outlet.
•Do not connect the plug into an extension cord, receptacle, or other outlet unless the plug can be fully inserted with no part of the blades exposed.
•Place this device on a stable surface.
•Avoid damaging the device with static by touching the coaxial cable when it is attached to the earth-grounded coaxial cable-TV wall outlet.
•Always first touch the coaxial cable connector on the device when disconnecting or reconnecting the Ethernet cable from the device or user’s PC.
•It is recommended that the customer install an AC surge protector in the AC outlet to which this device is connected. This is to avoid damaging the
device by local lightning strikes and other electrical surges.
•Postpone installation until there is no risk of thunderstorm or lightning activity in the area.
•Do not use this product near water: for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool.
•Do not cover the device or block the airflow to the device with any other objects. Keep the device away from excessive heat and humidity and keep the
device free from vibration and dust.
•Wipe the device with a clean, dry cloth. Never use cleaning fluid or similar chemicals. Do not spray cleaners directly on the device or use forced air to
remove dust.
•For added protection, unplug the device from the wall outlet and disconnect the cables to avoid damage to this device due to lightning and power
surges.
i

Safety and Regulatory Information
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
ii
365-095-25781 x.1
•Upon completion of any service or repairs to this device, ask the service technician to perform safety checks to determine that the device is in safe
operating condition.
•Do not open the device. Do not perform any servicing other than that contained in the installation and troubleshooting instructions. Refer all servicing
to qualified service personnel.
•This device should not be used in an environment that exceeds 104º F (40º C).
SAVE THE ABOVE INSTRUCTIONS
Note to CATV System Installer— This reminder is provided to call the CATV system installer’s attention to Articles 820.93 and 820.100 of the
National Electric Code, which provides guidelines for proper grounding and, in particular, specifies that the Coaxial cable shield shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.
FCC STATEMENTS
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the device and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
FCC CAUTION: Any changes or modifications not expressly approved by ARRIS for compliance could void the user’s authority to operate the equipment.
FCC RADIATION EXPOSURE STATEMENT
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To comply with the FCC RF exposure compliance
requirements, the separation distance between the antenna and any person’s body (including hands, wrists, feet and ankles) must be at least 20 cm (8
inches).
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter except those already approved in this filing.
The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to
match the intended destinations. The firmware setting is not accessible by the end user.
INDUSTRY CANADA (IC) STATEMENT
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions:
•This device may not cause interference, and
•This device must accept any interference, including interference that may cause undesired operation of the device.
CAN ICES-3 (B)/NMB-3 (B)
In Canada, RLAN devices are restricted from using the 5600-5650 MHz frequency band.
CAUTION: To reduce the potential for harmful interference to co-channel mobile satellite systems, use of the 5150-5250 MHz frequency band is
restricted to indoor use only.

Safety and Regulatory Information
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
iii
365-095-25781 x.1
High power radars are allocated as primary users (meaning they have priority) of 5250-5350 MHz and 5650-5850 MHz frequency bands. These radars
could cause interference and/or damage to License Exempt–Local Area Network (LE-LAN) devices.
IC RADIATION EXPOSURE STATEMENT
IMPORTANT NOTE: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20 cm between the radiator and your body.
AVIS D'INDUSTRIE CANADA (IC)
Cet appareil est conforme à la réglementation RSS-210 d'Industrie Canada. Son utilisation est assujettie aux deux conditions suivantes :
•Cet appareil ne doit pas causer d'interférences et
•Cet appareil doit accepter toute interférence reçue, y compris les interférences causant un fonctionnement non désiré.
CAN ICES-3 (B)/NMB-3 (B)
Au Canada, les appareils de réseau local sans fil ne sont pas autorisés à utiliser les bandes de fréquence 5600-5650 MHz.
AVERTISSEMENT: afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux, les dispositifs
fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l'intérieur
Les radars à haute puissance sont définis en tant qu'utilisateurs principaux (c.-à-d. prioritaires) des bandes de fréquences 5250-5350 MHz et 5650-5850
MHz. Ces radars peuvent causer de l'interférence ou des dommages susceptibles de nuire aux appareils exempts de licence–réseau local (LAN-EL).
DÉCLARATION DE IC SUR L'EXPOSITION AUX RAYONNEMENTS
NOTE IMPORTANTE : cet équipement est conforme aux limites d'exposition aux rayonnements établies par IC pour un environnement non contrôlé. Cet
équipement doit être installé et utilisé de manière à maintenir une distance d'au moins 20 cm entre la source de rayonnement et votre corps.
WIRELESS LAN INFORMATION
This device is a wireless network product that uses Direct Sequence Spread Spectrum (DSSS) and Orthogonal Frequency-Division Multiple Access (OFDMA)
radio technologies. The device is designed to be interoperable with any other wireless DSSS and OFDMA products that comply with:
•The IEEE 802.11 Standard on Wireless LANs (Revision B, Revision G, and Revision N), as defined and approved by the Institute of Electrical Electronics
Engineers
•The Wireless Fidelity (Wi-Fi) certification as defined by the Wireless Ethernet Compatibility Alliance (WECA).
RESTRICTIONS ON THE USE OF WIRELESS DEVICES
In some situations or environments, the use of wireless devices may be restricted by the proprietor of the building or responsible representatives of the
organization. For example, using wireless equipment in any environment where the risk of interference to other devices or services is perceived or
identified as harmful.
If you are uncertain of the applicable policy for the use of wireless equipment in a specific organization or environment, you are encouraged to ask for
authorization to use the device prior to turning on the equipment.
The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of the devices included with this
product, or the substitution or attachment of connecting cables and equipment other than specified by the manufacturer. Correction of the interference
caused by such unauthorized modification, substitution, or attachment is the responsibility of the user.
The manufacturer and its authorized resellers or distributors are not liable for any damage or violation of government regulations that may arise from
failing to comply with these guidelines.
Note: The use of the 5150-5250 MHz frequency band is restricted to Indoor Use Only.

Safety and Regulatory Information
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
iv
365-095-25781 x.1
SECURITY WARNING: This device allows you to create a wireless network. Wireless network connections may be accessible by unauthorized users. For
more information on how to protect your network, see the Change the Default User Name and Password for instructions or visit the ARRIS Support
website: www.arrisi.com/consumer.
CARING FOR THE ENVIRONMENT BY RECYCLING
When you see this symbol on a ARRIS product, do not dispose of the product with residential or commercial waste.
Recycling your ARRIS Equipment
Please do not dispose of this product with your residential or commercial waste. Some countries or regions, such as the
European Union, have set up systems to collect and recycle electrical and electronic waste items. Contact your local authorities
for information about practices established for your region.

Contents
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
v
365-095-25781 x.1
Contents
Safety and Regulatory Information.....................................................................................................................i
Getting Started ....................................................................................................................................................1
In The Box ............................................................................................................................................................................................................ 1
Additional Items You May Need (Not Included)................................................................................................................................... 2
System Requirements..................................................................................................................................................................................... 2
Contact Information........................................................................................................................................................................................ 2
Product Overview ................................................................................................................................................3
Front Panel.......................................................................................................................................................................................................... 3
Wi-Fi Protected Setup™ (WPS)............................................................................................................................................................ 4
Rear Panel............................................................................................................................................................................................................ 5
Gateway Label ................................................................................................................................................................................................... 6
Installing the Gateway ........................................................................................................................................7
Connect the SBG6700-AC to Your Computer........................................................................................................................................ 7
Establish an Internet Connection............................................................................................................................................................... 8
Setting Up a Wireless Network Connection .......................................................................................................9
Launch the SBG6700-AC Quick Start Wizard ......................................................................................................................................... 9
Set Up a Wireless Network Using Your Computer.............................................................................................................................14
Quick Connect Using the Windows Taskbar...............................................................................................................................14
Connect Using the Windows Control Panel................................................................................................................................17
Use the SBG6700-AC WPS Pairing Button ............................................................................................................................................19
Test Your Wireless Network Connection...............................................................................................................................................20
Managing Your Gateway and Connected Networks .......................................................................................21
Start the Gateway Web Manager .............................................................................................................................................................21
Gateway Web Manager Menu Options.........................................................................................................................................22
Get Help .............................................................................................................................................................................................................24
Overview Help ........................................................................................................................................................................................24
Help Links .................................................................................................................................................................................................25
Field Level Help......................................................................................................................................................................................25
View the Gateway Product Information................................................................................................................................................26
View the Gateway Status.............................................................................................................................................................................26
Back Up Your Gateway Configuration....................................................................................................................................................27
Restore Your Gateway Settings ................................................................................................................................................................28
Reset Your Gateway Settings.....................................................................................................................................................................28
Exit the SBG6700-AC Web Manager........................................................................................................................................................30
Protecting & Monitoring Your Wireless Network ............................................................................................31
Prevent Unauthorized Access....................................................................................................................................................................31
Change the Default User Name and Password...................................................................................................................................31

Contents
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
vi
365-095-25781 x.1
Set Up Firewall Protection ..........................................................................................................................................................................33
Set Up Parental Controls .............................................................................................................................................................................34
Set Up Port Triggers ......................................................................................................................................................................................36
Set Up Port Forwarding................................................................................................................................................................................37
Set Up the DMZ Host ....................................................................................................................................................................................39
Store Remote Firewall Logs........................................................................................................................................................................39
Creating Wi-Fi Networks ...................................................................................................................................41
Set Up Your Wireless Primary Network..................................................................................................................................................41
Enable or Disable WPS on Your Wireless Network ...................................................................................................................43
Set Up a Wireless Guest Network.............................................................................................................................................................44
Change Your Wireless Network Name (SSID)......................................................................................................................................46
Change the Wireless Channel....................................................................................................................................................................48
Troubleshooting Tips ........................................................................................................................................50
Solutions ............................................................................................................................................................................................................50
Front Panel LED Icons and Error Conditions........................................................................................................................................51
Gateway Configuration Screen Definitions .....................................................................................................52
Basic Screens ....................................................................................................................................................................................................52
Setup ..........................................................................................................................................................................................................52
DHCP ..........................................................................................................................................................................................................53
DDNS ..........................................................................................................................................................................................................55
Backup and Restore ..............................................................................................................................................................................56
Advanced Screens..........................................................................................................................................................................................57
Options ......................................................................................................................................................................................................57
IP Filtering.................................................................................................................................................................................................59
MAC Filtering...........................................................................................................................................................................................60
Port Filtering............................................................................................................................................................................................61
Port Triggers ............................................................................................................................................................................................62
Port Forwarding .....................................................................................................................................................................................63
DMZ Host ..................................................................................................................................................................................................65
Firewall Screens...............................................................................................................................................................................................66
Protection Level .....................................................................................................................................................................................66
Parental Control .....................................................................................................................................................................................68
Local Log...................................................................................................................................................................................................70
Remote Log..............................................................................................................................................................................................71
Warranty Information .......................................................................................................................................73

Contents
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
vii
365-095-25781 x.1
Tables
Table 1: SBG6700-AC Package Contents ................................................................................................................................................. 1
Table 2: SBG6700-AC Front Panel LED Icons.......................................................................................................................................... 3
Table 3: SBG6700-AC Rear Panel Ports & Connectors ........................................................................................................................ 5
Table 4: SBG6700-AC Web Manager Main Menu Options..............................................................................................................23
Table 5: Troubleshooting Solutions ........................................................................................................................................................50
Table 6: Front Panel LED Icons and Error Conditions.......................................................................................................................51
Table 7: Basic Setup Screen-Field Descriptions ..................................................................................................................................53
Table 8: Basic DHCP Screen-Field Descriptions ..................................................................................................................................54
Table 9: Basic DDNS Screen-Field Descriptions..................................................................................................................................55
Table 10: Basic Backup & Restore -Field Descriptions ......................................................................................................................56
Table 11: Advanced Options-Field Descriptions ................................................................................................................................58
Table 12: Advanced IP Filtering -Field Descriptions .........................................................................................................................59
Table 13: Advanced MAC Filtering -Field Descriptions ...................................................................................................................60
Table 14: Advanced Port Filtering -Field Descriptions.....................................................................................................................61
Table 15: Advanced Port Triggers -Field Descriptions.....................................................................................................................62
Table 16: Advanced Port Forwarding-Field Descriptions...............................................................................................................64
Table 17: Advanced DMZ Host-Field Descriptions............................................................................................................................65
Table 18: Firewall Protection Level -Field Descriptions...................................................................................................................67
Table 19: Firewall Parental Control-Set Time Zone-Field Descriptions.....................................................................................68
Table 20: Firewall Parental Control -Field Descriptions...................................................................................................................69
Table 21: Firewall Local Log -Field Descriptions ................................................................................................................................70
Table 22: Firewall Remote Log -Field Descriptions ...........................................................................................................................72
Figures
Figure 1 – SBG6700-AC Front View ........................................................................................................................................................... 3
Figure 2 – SBG6700-AC Rear View ............................................................................................................................................................. 5
Figure 3 – Sample SBG6700-AC Gateway Label ................................................................................................................................... 6
Figure 4 – SBG6700-AC Connection Diagram ....................................................................................................................................... 7
Figure 5 – SBG6700-AC Quick Start Wizard Opening Screen ........................................................................................................10
Figure 6 – SBG6700-AC Quick Start Wizard Welcome Screen.......................................................................................................10
Figure 7 – SBG6700-AC Quick Start Wizard-Step 2 of 6 Screen....................................................................................................11
Figure 8 – SBG6700-AC Quick Start Wizard-Step 3 of 6 Screen....................................................................................................12
Figure 9 – SBG6700-AC Quick Start Wizard-Step 4 of 6 Screen....................................................................................................12
Figure 10 – SBG6700-AC Quick Start Wizard-Step 5 of 6 Screen .................................................................................................13
Figure 11 – SBG6700-AC Quick Start Wizard-Saving Settings Screen........................................................................................13
Figure 12 – SBG6700-AC Quick Start Wizard-Step 6 of 6 Screen .................................................................................................14

Contents
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
viii
365-095-25781 x.1
Figure 13 – Windows Taskbar Icons........................................................................................................................................................14
Figure 14 – Sample Available Wireless Networks Screen ...............................................................................................................15
Figure 15 –Network Connection Window ............................................................................................................................................16
Figure 16 –Network Connection-Create Network Password Window ......................................................................................16
Figure 17 – Control Panel-Network and Sharing Center Window ..............................................................................................17
Figure 18 – Manually Connect to a Wireless Network Window ...................................................................................................18
Figure 19 – Manually Connect to a Wireless Network Window ...................................................................................................18
Figure 20 – SBG6700-AC Main Screen....................................................................................................................................................22
Figure 21 – SBG6700-AC Web Manager Main Menu Buttons .......................................................................................................22
Figure 22 – SBG6700-AC Web Manager Main Menu Links.............................................................................................................23
Figure 23 – Help Overview Screen...........................................................................................................................................................24
Figure 24 – Help Links Screen....................................................................................................................................................................25
Figure 25 – SBG6700-AC Status – Product Information Screen ...................................................................................................26
Figure 26 – SBG6700-AC Status Connection Screen.........................................................................................................................27
Figure 27 – SBG6700-AC Backup and Restore Screen......................................................................................................................28
Figure 28 – Restore Factory Defaults Screen .......................................................................................................................................29
Figure 29 – Change User Name Screen..................................................................................................................................................32
Figure 30 – Change User Password Screen ..........................................................................................................................................32
Figure 31 – Firewall Protection Level Screen.......................................................................................................................................33
Figure 32 – Parental Control-Change Time Zone Screen ...............................................................................................................34
Figure 33 – Firewall Parental Control Screen.......................................................................................................................................35
Figure 34 – Advanced Port Triggers Screen.........................................................................................................................................36
Figure 35 – Create Port Triggers Screen ................................................................................................................................................36
Figure 36 – Advanced Port Forwarding Screen..................................................................................................................................37
Figure 37 – Commonly Used Forwarded Ports List...........................................................................................................................38
Figure 38 – Advanced DMZ Host Screen...............................................................................................................................................39
Figure 39 – Firewall Remote Log Screen...............................................................................................................................................40
Figure 40 – 2.4 GHz & 5 GHz Wireless Primary Network Screens.................................................................................................42
Figure 41 – WPS Setup Screen...................................................................................................................................................................43
Figure 42 – 2.4 GHz & 5 GHz Wireless Guest Network Screens.....................................................................................................45
Figure 43 – Change Your 2.4 GHz & 5 GHz Network Name (SSID) and Password Screens ................................................47
Figure 44 – 2.4 GHz & 5 GHz Wireless 802.11 Radio Screens.........................................................................................................48
Figure 45 – Basic Setup Screen .................................................................................................................................................................52
Figure 46 – Basic DHCP Screen .................................................................................................................................................................54
Figure 47 – Basic DDNS Screen .................................................................................................................................................................55
Figure 48 – Basic Backup & Restore Screen..........................................................................................................................................56
Figure 49 – Advanced Options Screen...................................................................................................................................................57
Figure 50 – Advanced IP Filtering Screen .............................................................................................................................................59
Figure 51 – Advanced MAC Filtering Screen .......................................................................................................................................60
Figure 52 – Advanced Port Filtering Screen.........................................................................................................................................61

Contents
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
ix
365-095-25781 x.1
Figure 53 – Advanced Create Port Triggers Screen ..........................................................................................................................62
Figure 54 – Advanced Port Triggers Screen.........................................................................................................................................62
Figure 55 – Commonly Used Port Forwarding Port Numbers List..............................................................................................63
Figure 56 – Advanced Port Forwarding Screen..................................................................................................................................64
Figure 57 – Advanced DMZ Host Screen...............................................................................................................................................65
Figure 58 – Firewall Protection Level Screen.......................................................................................................................................67
Figure 59 – Firewall Parental Control-Set Time Zone Screen........................................................................................................68
Figure 60 – Firewall Parental Control Screen.......................................................................................................................................69
Figure 61 – Firewall Local Log Screen ....................................................................................................................................................70
Figure 62 – Firewall Remote Log Screen...............................................................................................................................................71

Getting Started
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
1
365-095-25781 x.1
Getting Started
The ARRIS Motorola SURFboard® SBG6700-AC Wireless Cable Modem Gateway is an all in one wireless
DOCSIS 3.0® cable modem and two-port Ethernet router device. It provides secure ultra high-speed
wired and wireless broadband connections for your computer and other wireless network devices on
your home or small business network. The SBG6700-AC also includes a Wi-Fi® Pairing button option for
quick and easy connections for your wireless devices.
This guide provides instructions for installing and configuring the SBG6700-AC, setting up secure
wireless network connections, and managing your gateway and network configurations.
In The Box
Before installing the SBG6700-AC, check that the following items are also included in the box. If any
items are missing, please call ARRIS Technical Support at 1-877-466-8646 for assistance.
Table 1: SBG6700-AC Package Contents
Item
Description
SBG6700-AC Wireless
Cable Modem Gateway
High-speed DOCSIS 3.0 cable modem, wireless
access point, and 2-port Ethernet router
Power Supply
Power adapter and cord for an electrical wall
outlet connection
Ethernet Cable
Standard Category 5 (CAT5) or higher network
cable
Software License &
Regulatory Card
Safety and regulatory information, software
license, and warranty for the gateway
1

Getting Started
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
2
365-095-25781 x.1
Item
Description
SBG6700-AC Quick Start
Guide
Provides basic information for installing the
gateway and setting up a secure wireless
connection on your home network.
Additional Items You May Need
•Coaxial (coax) cable, if one is not already connected to a cable wall outlet
•RF splitter (for additional coaxial cable connections, such as a set-top box or Smart TV)
System Requirements
•High-speed Internet access account
•Web browser access – Internet Explorer, Google Chrome, Firefox, or Safari
•Compatible operating systems:
οWindows® 8
οWindows 7 Service Pack 1 (SP1)
οWindows Vista™ SP2 or later
οWindows XP SP3
Note: Microsoft no longer supports Windows XP. The SBG6700-AC should still function without any
problems.
οMac® 10.4 or higher
οUNIX®
οLinux®
Contact Information
For technical support and additional ARRIS product information:
•Visit the ARRIS Support website: www.arrisi.com/consumer
•Call ARRIS Technical Support: 1-877-466-8646

Product Overview
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
3
365-095-25781 x.1
Product Overview
Front Panel
Figure 1 – SBG6700-AC Front View
Table 2: SBG6700-AC Front Panel LED Icons
LED Icon
Blinking
On (Solid)
Not applicable – no LED on
button.
Note: The Wireless LED will blink
Amber to indicate the WPS
Pairing process is in progress.
Not applicable – no LED on button.
Not applicable – icon does not
blink.
Green: Power is properly connected.
Scanning for a downstream
(receive) channel connection.
Green: Non-bonded downstream channel
is connected.
Blue*: High-speed Internet connection
with bonded downstream channels.
2

Product Overview
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
4
365-095-25781 x.1
LED Icon
Blinking
On (Solid)
Scanning for an upstream (send)
channel connection.
Green: Non-bonded upstream channel is
connected.
Blue*: High-speed Internet connection
with bonded upstream channels.
Scanning for an Internet
connection.
Green: Startup process completed.
Green: Wi-Fi enabled with
encrypted wireless data activity.
Amber: WPS Pairing process is
underway between the
SBG6700-AC and a WPS-enabled
wireless device.
Green: Any of the following applies:
•2.4 GHz wireless connection is made
between the SBG6700-AC and another
Wi-Fi enabled device on your home
network; for example, Wi-Fi telephone,
tablet, or laptop.
•The WPS Pairing process between the
SBG6700-AC and WPS-enabled wireless
device was successful.
•The WPS Pairing process either failed or
did not complete after two minutes.
Green: Wi-Fi enabled with
encrypted wireless data activity.
Amber: WPS Pairing process is
underway between the
SBG6700-AC and a WPS-enabled
wireless device.
Green: Any of the following applies:
•5 GHz wireless connection is made
between the SBG6700-AC and another
Wi-Fi enabled device on your home
network; for example, Wi-Fi telephone,
tablet, or laptop.
•The WPS Pairing process between the
SBG6700-AC and WPS-enabled wireless
device was successful.
•The WPS Pairing process either failed or
did not complete after two minutes.
*Indicates DOCSIS 3.0 operation (high-speed Internet access) which may not be available in all
locations. Check with your service provider for availability in your area.
Wi-Fi Protected Setup™ (WPS)
Wi-Fi Protected Setup (WPS) is a wireless network setup option that provides a quick and easy solution
for setting up a secure wireless network connection for any WPS-enabled wireless device; such as a
computer, tablet, gaming device, or printer. WPS automatically configures your wireless network
connections and sets up wireless security. See Use the SBG6700-AC WPS Pairing Button for more
information.

Product Overview
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
5
365-095-25781 x.1
Rear Panel
Figure 2 – SBG6700-AC Rear View
Table 3: SBG6700-AC Rear Panel Ports & Connectors
Port Name
Description
1
Two one-gigabit Ethernet ports for RJ-45 cable connections:
•Green - LED is ON - Indicates a device connection is detected
•Green- LED is Blinking - Indicates data traffic is in progress
•Amber - LED is ON – Indicates 10/100 Base-T connection(s)
•Amber - LED is OFF – Indicates GigE connection(s)
2 Reset button Recessed button can be used to reboot the gateway or reset the gateway settings.
•To reboot (or restart) the gateway, press the indented Reset button once using
the end of a paper clip or other small object with a narrow tip, and then release.
•To reset the gateway configuration back to the factory default settings, press
and hold the indented Reset button for 15 seconds using the end of a paper clip
or other small object with a narrow tip, and then release. See Reset Your
Gateway Settings for more information on an alternative method to reset the
gateway settings using the SBG6700-AC Web Manager.
WARNING! Reset will also delete any custom gateway configurations, including
your user passwords and other security settings. You should back up the
gateway configuration files before resetting the gateway. See Back Up Your
Gateway Configuration for more information.

Product Overview
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
6
365-095-25781 x.1
Port Name
Description
3
Coaxial cable connector
4
100 - 240VAC Power connector
WARNING! To avoid any damage to your SBG6700-AC Gateway, only
use the power adapter and cord provided in the box.
Gateway Label
Figure 3 – Sample SBG6700-AC Gateway Label
The gateway label is located on the bottom of the SBG6700-AC. It contains specific gateway ID
information that you may need when contacting your service provider or ARRIS Technical Support.
To receive Internet service, you will have to contact your service provider for assistance. You may need
to provide the following information listed on the gateway label:
οGateway model name (SBG6700-AC)
οGateway MAC address (HFC MAC ID)
οGateway serial number (S/N)

Installing the Gateway
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
7
365-095-25781 x.1
Installing the Gateway
This product is for indoor use only. Do not route the Ethernet cable(s) outside
of the building. Exposure of the cables to lightning could create a safety
hazard and damage the product.
Connect the SBG6700-AC to Your Computer
Before installing the SBG6700-AC:
•Check with your service provider to ensure broadband cable service is available in your area.
To set up a wireless network, you will need a high-speed Internet connection provided by an
Internet service provider.
Note: When contacting your service provider, you may need your gateway information listed on the
gateway label located on the bottom of your SBG6700-AC (see Gateway Label).
•Choose a location in your home where your computer and gateway are preferably near existing
cable and electrical wall outlets.
For the best Wi-Fi coverage, a central location in your home or building is recommended.
Note: The following installation procedure covers the wired Ethernet connection process so that you can
confirm that the SBG6700-AC was properly installed and can connect to the Internet.
Figure 4 – SBG6700-AC Connection Diagram
3

Installing the Gateway
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
8
365-095-25781 x.1
1. Check that a coaxial cable is already connected to a cable wall outlet or RF splitter (optional).
2. Connect the other end of the coaxial cable to the Cable connector on the SBG6700-AC.
Use your hand to tighten the connectors to avoid damaging them.
3. Connect the Ethernet cable to an available Ethernet port on the SBG6700-AC.
4. Connect the other end of the Ethernet cable to the Ethernet port on your computer.
Optional: Repeat steps 3 and 4 for an additional computer or other network device that you want
to install as a wired connection on your home network.
5. Connect the power cord to the Power port on the SBG6700-AC.
6. Plug the other end of the power cord into an electrical wall outlet.
Note: This automatically powers ON the SBG6700-AC.
Establish an Internet Connection
Although your computer may already be configured to automatically access the Internet, you should
still perform the following gateway connectivity test to verify that the devices were connected properly.
1. Power ON the computer connected to the SBG6700-AC if it is turned off, and then log in.
2. Contact your service provider to activate (provision) the SBG6700-AC. You may have to provide the
HFC MAC ID listed on the gateway label.
Note: Your service provider may allow for automatic activation which will automatically launch its own
special website when you open a web browser.
3. After the SBG6700-AC is activated, open a web browser (Internet Explorer, Google Chrome, Firefox,
or Safari) on your computer.
If the special website did not open, continue with step 4. If it did open, proceed to step 5.
4. Type a valid URL (www.arrisi.com) in the address bar and then click or press Enter.
The ARRIS website should open. If it did not open, please contact your service provider for
assistance.
5. Check that the Power, Receive, Send, and Online front panel LEDs on the SBG6700-AC light up in
sequential order. See Front Panel for additional LED status information.
οIf all four LEDs did not light up solid and you also do not have an Internet connection, you may
have to contact your service provider to reactivate the SBG6700-AC or check for signal issues.
οIf you still cannot connect to the Internet, your SBG6700-AC may be defective. Please call ARRIS
Technical Support at 1-877-466-8646 for assistance.

Setting Up a Wireless Network Connection
SURFboard® SBG6700-AC Wireless Cable Modem Gateway •User Guide
9
365-095-25781 x.1
Setting Up a Wireless Network
Connection
It is highly recommended that you first verify that your computer can connect to the Internet using an
Ethernet connection before configuring your wireless network.
You must already have access to an Internet service in your home before setting up a wireless network
connection. Also, make sure your computer and the SBG6700-AC are connected through an Ethernet
connection.
Choose one of the following options to set up your wireless network connection:
•Launch the SBG6700-AC Quick Start Wizard
•Set Up a Wireless Network Using Your Computer
•Use the SBG6700-AC WPS Pairing Button
After setting up your wireless network connection, check that your wireless network connection was set
up properly. See Test Your Wireless Network Connection for more information.
Launch the SBG6700-AC Quick Start Wizard
The SBG6700-AC Quick Start Wizard is a six-step application to help you quickly configure the default
wireless network settings on your SBG6700-AC. It configures your wireless network name (SSID), Wi-Fi
Security key (network password), and Wi-Fi Security code.
IMPORTANT NOTE: The quick start wizard uses the default settings already configured for your SBG6700-AC
to help you quickly set up your wireless home network. However, the wizard will only let you change the
wireless network name (SSID) and Wi-Fi Security key (network password). After completing the wizard and
getting your SBG6700-AC connected to the Internet, you will be able to make additional network
configuration changes to further customize your wireless home network and connect your wireless devices.
See Creating Wi-Fi Networks for more information.
1. Open a web browser (Internet Explorer, Google Chrome, Firefox, or Safari) on the computer
connected to the SBG6700-AC.
2. Type the default LAN IP address, http://192.168.0.1,in the Address bar and then press
Enter. The gateway Login screen displays.
3. Type the default username and password. Both entries are case-sensitive.
Username: admin
Password: password
4. Click Login to open the SBG6700-AC Web Manager. The Launch Quick Start Wizard screen displays
(see Figure 5).
Note: If the default user name and password are not working, your service provider may have to set up
alternate login credentials. Please contact your service provider or ARRIS Technical Support for
assistance.
5. Click Launch Quick Start Wizard to start the wizard. The Welcome screen displays (see Figure 6).
4
