Aosom 370-130V80 User manual

ASSEMBLY INSTRUCTION
370-130V80
INfac011_US_CA
CHILDREN'S ELECTRONIC TOY QUAD
1.Suitable age for 18-36 Months.
2.Maximum user weight: 20KGS.
3.Adult assembly required
OWNER'S MANUAL
with Assembly Instructions
Read and understand this entire manual before using!
Please keep this manual for future reference as it contains important information.
Before first time use, charge the battery for at least 8-12 hours.

Specification
ltem
Battery
Motor
Maximum weight
Size
Speed
Using time
Available ages
Charger
1.body 2. Windshield 3.handlerbar 4.Trunk
Our products are suitable for ASTM F963; CPSIA; EN71 and EN62115 standard.
Parts Diagram
1.Your sealed lead-acid battery must be recycled or disposed of in an envi-
ronmentally sound manner.
2. Do not dispose of your lead-acid battery in a fire. The battery may explode or
leak
380#
20KGS
78.5X40.5X46CM
3.Do not dispose of a lead-acid battery in your regular, household trash. The
incineration, land filling or mixing of sealed lead-acid batteries with house-hold
trash is prohibited by law.
DC6V500mA
Disposal Of Battery
About Your New Vehicle
Specifications
6V4.5AH
3Km/h
working for 1-2 hours, once charged for 8-12 hours
Children at 18-36 months

5.Bumper 6.front wheel X3 7.A rear axle 8.motor
9.rear wheel X1 10.Steering shaft 11.Axle sleeve 12.charger
2.4X10 SCREW X10
3.M8 CHECK BACK NUT X4
4.M10 CHECK BACK NUT X1
1. insert the back axis，assemble the gear motor &
Axle sleeve，assemble back wheels，fix the
wheels(2XM8 NUT&3X10MM GASKET）
2.fix the front wheel(2XM8 NUT&4X10MM GASKET)
Attach the Side Wheels & Rear Fender
Windshield and motor in battery compartment
Number of screw packs
1 2 3 4
1.10MM GASKET X8

9.CONNECT THE MOTOR ELECTRIC LINE INTO THE
MOTOR 10.CONNECT THE BATTERY ELECTRIC LINE INTO THE BATTERY
7.Fix the trunk (3X(4X10)SCREW) 8.OPEN THE SEAT
3.Install bumper(4X(4X10)SCREW) 4.Flip the car bottom up,then insert steering shaft
5.Insert handlerbar into the axial shaft ,secure
with(1XM10 NUT) 6.Fasten the windshield to the handlebar,(2X(4X10)SCREW)
