Apltch HB03 User manual

Operation guide
Smart Life, from now!
Dear customer,
Thanks for your using HB03 smart watch!
In order to use better with this watch, pls kindly see the operation guide carefully before use!
basic configuration and function
MTK
MT2502
GSM 850/900/1800/1900MHz
1.22’’ ISP/TFT RGB240x204 pixels
G+F
4P Mini USB
4.0，GPRS
basic configuration and function
MTK Smart wearable system
MT2502 Professional smart wearable chip
GSM 850/900/1800/1900MHz
1.22” ISP/TFT Display
RGB240x204 Pixels
G+F capacitive touchscreen
4P mini USB magnetic port
(Data/Charging)
Bluetooth 4.0, GPRS
Headphone / Speaker (2in1)
Microphone，Vibration motor
Message, colorful message, music, video, sound recording
Warmly reminder:
There are many versions of it and different version with different sensor configuration
Pls according to the product configuration (functions are related to Hardware
configuration)
X1
X1
Standard accessories\

Smart watch X1
Magnetic Charging Dock X1
Operations Guide X1
Portable Star screwdriver X1
Warmly reminder:
This product has many versions and some doesn’t need the screwdriver bcz of the different
construction and configuration, pls refer to the product configuration.
Safety Notice
1.To keep this product & accessories away from children in case accidents happen.
2.Safety first, pls keep both hands on steering wheel when driving,
talk directly with the watch on the wrist or Bluetooth headset if need to answer
phone call.
Pls turn off the watch or active the flying mode.
。
4.Please strictly observe relative rules not to use this product to make phone call near gas
station, mining fields, chemical factory or explosion district.
5.Only institute or staff authorized by our company could

disassemble or repair this product. Disassembling or repairing
unauthorized may bring damage to the product and can be risky,
also, it will invalidate the warranty.
6.This watch may get a little warm when charging and this is normal.
7.The efficiency (standby time and usage time) of the internal
battery may vary due to different usage or network conditions.
8.The signal of the watch can be disturbed by infinitely strong electronic wave and the quality of
the communication will be effected shortly.
9.The images in this user guide are for reference only,
some picture may not be exactly same as the product, please
refer to the actual product as final. If you find any mismatch in the
user guide, or if you have any question/comments, feel free to
contact our after-sales service center.
10.The operation guide is protected by the patent and copy right law and it can be copied,
reprinted, translated or spread in any way.
Warmly reminder:
As the user's actual usage scenarios is hard to judge well, so the product due to water damage not
belong to our warranty. (Our company provides only paid service)
Removable bottom cover

Insert the SIM Card
Under the power off situation, pls use a screwdriver to take down the bottom cover screws to
remove the cover. (Some versions using coins to remove the bottom). And then to insert or remove
the SIM card.
Notice: Only Mini SIM card suitable or you can use the card-cutter.
Warmly reminder:
The watch only support GSM network and China Mobile and China Unicom card supported and
China Telecom card not supported.

Charging & Data transfer
This product uses magnetic port for charging & data transfer. If
you need to charge this product or transfer data, just get bottom
of this watch, close to the magnetic port, that’s all you need to do.
(if necessary, please check whether the two are connecting
properly).
Reminder：
Pls let the 4P flicking needle contact well with USB contacts.
If necessary, please wipe/clean the USB contacts on the watch to ensure good contact.

Key operation
Power on/off key
。

Power on/off key
1.Long press the button to power on or off for.
2.Under power on, pls click this button to turn on or turn off the display.
3.Try more applications in practice
Touch screen operation
In the function application or the settings menu, slide the touchscreen from right to left can
entrance the subsidiary interface, slide from left to right the screen can exit the application and
return on a menu or before windows until the clock dial interface (like the back button).
Switch watch face
This watch provides different types of watch faces. You could select & quickly switch between the
ones you like.
Method: tap & hold on the watch face interface until the interface status changes and you could
slide left/right to select from different watch faces, then click ok to store the setting.

Application menu
Under clock interface, slide the touch screen from down to enter application menu. (and setting)
Gesture control
This product supports gesture control, especially suitable for one hand operation or quick/shortcut
operation.
1.Raise up wrist to show time
To reduce power consumption, the screen will go off when standby; when you need to see time,
just raise up your wrist and let the watch facing towards you, the time will automatically show on
the screen.
2.Shake your wrist to answer phone call.

You only need to shake your wrist few times to answer incoming phone call.
3.Rotate to mute the call/alarm
If you’re not convenient to answer phone call, just rotate to let the watch screen facing down to
mute the call. （can also hang up the phone using the gesture above during communication）
.
Health Care
This watch integrates exercise testing and heart rate monitor and develop the health caring
functions below.
1.Heart rate monitor
Heart rate data can reflect most of the health problems of your body, pls check your heart rate data
constantly, scientific is more important than prevention.
2.Fatigue data
Scoring for your mental state. Pls have a good rest when you are very tired. Take a good rest and
good health is the basis of everything.
3.Sleeping monitor
Sleep is the only way to restore your energy. Concerned about your sleep is to concern about your
future
4.Sedentary reminder
No matter how busy you work, pls don’t sit too long. To have some activity, maybe work will be
more efficient.

Pedometer Monitoring
This watch is with G-sensor inbuilt, plus powerful sport calculation program, it provides scientific
data for your walking activity, it’s time for you to make a sport exercise plan.
1.Pedometer (walking or running):
To know your targeted steps or actual steps for a count period or for a day.
2.Calorie detection:
To know how much calories have been consumed during walking, running, wide awake or
sleeping.
3.Timing (Various active time)
To know how long (meters) you have walked, running, wide awake or sleeping.
4.Big Data:
This watch automatically records your physical fitness data for your big data base, and save it in
cloud to check anytime.

Phone companion andAPPdownload
Support connecting with Android & IOS phones via Bluetooth. Enjoy smart life brought by new
technology.
1.Bluetooth dial
2.Bluetooth phone call
3.Bluetooth answer call
4.Bluetooth Sync phone book
5.Bluetooth Sync call history
6.Bluetooth music control
7.Bluetooth Remote Camera control
8.Phone anti-lost
9.Find Phone / Find Watch
10.SMS Push message
11.We chat Push message
12. QQ push message
13.Newsletter push message
14.Other online chat push message

Scan the QR code to downloadAPP ,choose the Fendong Android or IOS version
