Aqara Camera Hub G2H User manual
Camera Hub G2H User Manual
Camera Hub G2H User Manual
$BNFSB)VC()⢪欽铝僈剅
Camera Hub G2H Bedienungsanleitung
Camera Hub G2H Manuel d’utilisation
Camera Hub G2H Manual de uso
Camera Hub G2H Manuale di istruzioni
ΚϟϠϓϲΑϓϟϘϣϓΗϦϝϡϕϡϗϤϥϕϡϢϡΤϝϤϢϞϦϓϥϓϩϛϛ
$BNFSB)VC()⺅䪒鞃僻剹
$BNFSB)VC()칺푷컲졓컪
· 01
· 10
· 16
· 25
· 33
· 41
· 49
· 57
· 64
Indicator light
Micro SD card slot
Lens
Microphone pickup hole
Reset button
Long press the button for 5s:
restore to factory settings
Product introduction
Aqara Camera Hub G2H is an intelligent hardware product that integrates dual functions
of camera and hub. It has functions such as video intercom, motion detection, sound
detection, and Micro SD card recording. It can also be used as a Zigbee hub in collabora-
tion with other sensors, controllers and other child-devices to realize the functions such
as home guard, data reporting and smart control. It also supports for HomeKit Secure
Video, activity detected by supported cameras is privately analyzed by your home hub
using on device intelligence to determine if people, pets, or cars are present.
01
Camera Hub G2H User Manual
Speaker hole
Micro USB slot
Function button
Long press the button for 5s:
Leave a video message
Warnings
* This product is NOT a toy. Please keep children away from this product.
* This product is designed for indoor use only. Do NOT use in humid environments or
outdoors.
* Beware of moisture, do NOT spill water or other liquids onto the product.
* Do NOT place this product near a heat source. Do NOT place it in an enclosure unless
there is normal ventilation.
* Do NOT attempt to repair this product by yourself. All repairs should be performed by
an authorized professional.
* This product is only suitable for improving the entertainment, convenience of your
home life and reminding you about the device status. If a user violates the product
use instructions, the manufacturer will NOT be liable for any risks and property losses.
* This product is only suitable for improving the convenience of your home life and
reminding you of the status of your devices. It should NOT be used as security
,0$+( )/!*-#*( я*Ȃ$ я2- #*0. *-)4*/# -+' .ю!0. -1$*'/ ./#
02
Quick Setup
1. Download the Aqara Home app
Scan the QR code, or search for "Aqara Home" on the
App Store. Download and install the Aqara Home app.
2. Power on and start up
Find the power jack on the back of the product and connect the USB power cable. Then,
+*2 -*)/# +*2 -+/ -юȅ -/# ( -./-/.0+.0 ..!0''4я/# - $)$/*-
light of the camera will flash.
* If the red indicator light does not flash, please long press the reset button and try again.
03
product use instructions, Aqara will NOT be liable for any risks or property losses.
* The magnetic base of this product has been strictly designed with strong adsorption
+$/4я2#$#) ).0- /#//# +-*0/2$'')*/!''*Ȃ2# )$/$.$)./'' *)/#
2''ю)*- -/*+- 1 )/*/# -# 14*% /.!-*((&$)"/# +-*0/!''*Ȃ/*0.
personal injury, we recommend that the installation height of the device should be
less than 2 meters.
3. Add camera
Connect to Aqara Home
Open the Aqara Home app, and click “+” on the upper corner of the homepage. Select
ћ( - 0 Фќя )*+ -/ $/ ./# +++-*(+/.ю ȅ - /# 1$ $.*)) /
successfully, the blue indicator light will be always on.
Connect to Apple HomeKit
Open Apple Home app, click “+” on the upper right corner, and then enter the “Add
Accessory” page. Scan or manually enter the HomeKit Setup Code at the bottom of the
camera to bind the camera to HomeKit.
If the device failed to be added, please check the following steps:
Failed to add to HomeKit guide:
* “Failed to add accessory”. Due to multiple adding failures, the error information of iOS cache cannot be
removed. Please restart the iOS device and reset the camera;
Ѻћ ..*-4'- 4 ќюȅ -- ./-/$)"/# $ 1$ )- . //# ( -я4*0)()0''4
* Please make sure the camera is connected with the 2.4GHz Wi-Fi network.
* Wi-Fi name or password may contain special characters. Please replace them with ordinary characters
and try again.
* The camera does not support the WAP/WAP2 Wi-Fi network.
* The camera cannot recognize the QR code generated by the phone. Please make sure the screen of the
phone is not less than 4 inches, and cannot scan the QR code under back-lighting.
* Please check whether the router turns on the Wi-Fi connection watcher function, which causes the
network connection failures.
* Please check whether the router turns on the AP isolation function, which causes the phone cannot
search the camera within LAN.
* It is recommended not to connect it to a bridge network.
04
4. Add child-device
ȅ -/# ( -$. .0 ..!0''4я+' . /# *+ ),-*( ++)/#
child-devices as shown in the user manual.
5. Product installation
Please make sure the camera is added successfully, and then install it onto the wall.
You can place the camera on a horizontal surface, such as desk, table, bookcase
and so on.
The base of the camera contains a magnet, which can be attached to the surface of
ferrous material, such as refrigerator, iron door and so on. Do not place it near the
main unit of the computer or hard disc.
Can use 3M double-side tape to attach the magnet to the surface of smooth materials,
such as glass, tile, latex wall and so on, and then attach the camera to the magnet.
05
enter the HomeKit setup code and add it again;
Ѻћ ..*-4)*/!*0)ќю' . 2$/!*-Х($)0/ .ȅ -- . //$)"/# ( -ю*0)()0''4 )/ -/#
HomeKit setup code and add it again.
* Use of the Works with Apple badge means that an accessory has been designed to work specifically with
the technology identified in the badge and has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the operation of this device or its compliance with
safety and regulatory standards.
* A 10-day recording history from your Camera Hub G2H is securely stored in iCloud and available to view
in the Apple Home app on your iPhone, iPad, or Mac. You can add one camera to your 200GB plan or up
to five cameras to your 2TB plan at no additional cost. Camera recordings don’t count against your
iCloud storage limit.
* Communication between iPhone, iPad, Apple Watch, HomePod, or Mac and the HomeKit- enabled
Camera Hub G2H is secured by HomeKit technology.
Indicator Light Status
* Please make sure the installation position is within the coverage range of the Wi-Fi.
* Do not place it near strong electromagnetic interference sources
* The product is only limited to be used indoors. Please do not use it in humid environment or outdoors.
* Please make sure there is no obstacle around the device.
Indicator Light Status
Blue light is always on
Blue light flashes
Red light is always on
Red light flashes
OȂ
Status Description
Connected successfully / works normally
Connecting to network / network is abnormal
Live streaming / recording
Waiting for connection
Sleep mode / the indicator light is oȂ
06
Specifications
Basic Parameters
Model: CH-H01 Video Code: H.264
Resolution: 1080p Input Power: 5V 1A
Lens: 140° wide angle Power Consumption: 5W(MAX)
Wireless Protocol: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz, Zigbee
Local Storage: Micro SD card (CLASS 4 or above is supported, up to 32GB storage)
Supported device: Android 4.0 or iOS13.2 and above
Operating Temperature: -10℃～40℃(14°F~104°F)
07
Hereby, [Lumi United Technology Co., Ltd] declares that the radio equipment
type [Camera Hub G2H, CH-H01] is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://www.aqara.com/DoC/
Under normal use of condition, this equipment should be kept a separation distance of at
least 20cm between the antenna and the body of the user.
Wi-Fi Operation Frequency 2412-2472 MHz
ڱФТ(
2405-2480 MHz
ڱУХ(
Wi-Fi Maximum Output Power
Zigbee Operation Frequency
Zigbee Maximum Output Power
08
FCC ID: 2AKIT-G2H
Federal Communications Commission (FCC) compliance statement: 1. This device
complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation. 2. Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment. Note: This
equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
/ ' 1$.$*)- +/$*)я2#$#) / -($) 4/0-)$)"/# ,0$+( )/*Ȃ)*)я/#
user is encouraged to try to correct the interference by one or more of the following
measures: -Reorient or relocate the receiving antenna. -Increase the separation between
/# ,0$+( )/)- $1 -юѣ*)) //# ,0$+( )/$)/*)*0/' /*)$-0$/$Ȃ - )/
All products bearing this symbol are waste electrical and electronic equipment
(WEEE as in directive 2012/19/EU) which should not be mixed with unsorted
household waste. Instead, you should protect human health and the environment
by handing over your waste equipment to a designated collection point for the recycling of
waste electrical and electronic equipment, Appointed by the government or local authorities.
Correct disposal and recycling will help prevent potential negative consequences to the
environment and human health. Please contact the installer or local authorities for more
information about the location as well as terms and conditions of such collection points.
IC: 22635-G2H
IC NOTICE TO CANADIAN USERS
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES‐003.
This device complies with RSS‐247 of Industry Canada. Operation is subject to the
condition that this device does not cause harmful interference.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
of 20 cm between the radiator and your body. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
Online Customer Service: www.aqara.com/support
Manufacturer: Lumi United Technology Co., Ltd.
Address: 8th Floor, JinQi Wisdom Valley, No.1 Tangling Road, Liuxian Ave, Taoyuan
Residential District, Nanshan District, Shenzhen, China.
09
from that to which the receiver is connected. -Consult the dealer or an experienced
radio/TV technician for help. RF Exposure statement: This equipment complies with FCC
radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance of 20 cm between the radiator
and your body. This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
