Aqua La Diva User manual
La Diva
CD Transport
Owner’s Manual
Rev 2.0
IMPORTANT SAFETY NOTICES
The triangle with the lightning flash symbol displayed on the unit advises the user of
dangerous uninsulated voltage inside the product’s enclosure.
To reduce the risk of electric shock, do not remove the cover.
The triangle with the exclamation point symbol on the component suggests that the owner
refer to important operating and maintenance instructions in the owner’s manual.
Modifications and alterations not approved by the manufacturer may violate adherence to
EC regulations and make the appliance no longer suitable for use. The manufacturer
declines all responsibility for damage caused to persons or property due to the misuse or
malfunction of device subject to unauthorized change.
LASER SAFETY
This unit employs a laser. Only a qualified service person should remove the cover or
attempt to service this device, due to possible eye injury.
CAUTION : USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURE
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
In order to make changes that improve the already excellent quality of its products, Aqua -
Acoustic Quality reserves the right to modify the information or the contents of this manual
at any time and without notice.
II La Diva CD Transport Owner’s Manual
Aqua - Acoustic Quality audio products are warranted to be free from manufacturing
defects for five (5) years from the original date of purchase. The warranty includes parts
and labour. In the event of a defect or malfunction, contact your dealer or Aqua – Acoustic
Quality directly for return authorization. Aqua - Acoustic Quality will remedy the problem by
repair or replacement, as we deem necessary, to restore the product to full performance.
Products must be returned using original packaging material only. Packing material may
be purchased from Aqua - Acoustic Quality if necessary. This warranty is considered void
if the defect, malfunction or failure of the product or any component part was caused by
damage (not resulting from a defect or malfunction) or abuse while in the possession of
the customer. The warranty excludes the following components:
-Audio tubes
-NOS (New Old Stock) Components
CAUTION: Changes or modifications to this equipment not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
GENERAL SAFETY INFORMATION
The following general safety precautions must be observed during all phases of operation
of this equipment. Failure to comply with these precautions or with specific warnings
elsewhere in this manual violates safety standards of design, manufacture, and intended
use of the equipment. Aqua - Acoustic Quality assumes no liability for the customer’s
failure to comply with these requirements.
• DO NOT operate the product in an explosive atmosphere or in the presence of
flammable gases or fumes. For continued protection against fire, replace the line fuse(s)
only with fuse(s) of the same voltage and current rating and type. DO NOT use repaired
fuses or short-circuited fuse holders.
• Keep away from live circuits. Operating personnel must not remove equipment covers or
shields. Procedures involving the removal of covers or shields are for use by service-
trained personnel only. Under certain conditions, dangerous voltages may exist even with
the equipment switched off. To avoid dangerous electric shock, DO NOT perform
procedures involving cover or shield removal unless you are qualified to do so.
• DO NOT operate damaged equipment. If the built-in safety protection features have been
impaired through physical damage, excessive moisture, or any other reason, REMOVE
POWER and do not use product until safe operation is verified by service-trained
personnel. If necessary, return the product to Aqua - Acoustic Quality for service and
repair to ensure that the safety features are maintained.
• DO NOT service or adjust alone. Do not attempt any internal service or adjustment
unless a person capable of rendering first aid and resuscitation is present.
• DO NOT substitute parts or modify equipment. To avoid the occurrence of additional
hazards, do not install substitute parts or perform any unauthorized modification to the
product. Return the product to Aqua - Acoustic Quality for service or repair to ensure that
the safety features are maintained.
III
La Diva CD Transport Owner’s Manual
In This Guide…
1 Unpacking
2 Operation and Features
3 Specifications
4 Front panel
5 Back panel
IV La Diva CD Transport Owner’s Manual
1. Unpacking
To protect the top loading tray mechanism from damage in transit, it has been blocked by
spongy material.
IMPORTANT : If the CD transport subsequently needs to be transported, these
protections should be reinstalled.
PACKING MATERIAL
Please retain the original box for re-use in case your equipment ever needs to be
transported. The packing material has been especially designed to protect your valuable
equipment from mechanical shock in transit.
2. Operation and Features
Make sure the supplied voltage is the one required by the device. Please ensure the
quality of the connecting cables, paying particular attention the coaxial / AES EBU digital
cable. Often, numerous tests have revealed the importance of this cable for obtaining the
best sound quality.
Key features
• High performance proprietary ISDC (Isolated Synchronous Discrete Circuit) digital
decoding and clock manager
• Custom designed discrete circuit with high-speed photocouplers for Galvanic and
magnetic isolation between CD drive unit and digital output
• Ultra massive chassis construction and newly developed high-rigidity sub chassis
with Nextel for CD drive unit cancels internal and external acoustic and mechanical
vibrations, enabling exceptionally accurate "Red Book" RF signal
• DC disc drive motor allows to read the data accurately and minimize Jitter
• Moplen clamp to avoid flywheel masses and vibrations
• Sophisticated signal processing technology assures excellent CD Red Book
signal
• High-performance multi-stage voltage regulator (high-current stage for accurate
servo DISC drive rotation, tracking and focus)
• Jitter free digital interface AQlink (I2S protocol), uncompromising digital
connection to La Scala DAC, La Voce DAC
• etherCON RJ45 (AQlink) output connection to DAC, employs CAT6 cable can
connect both RJ45 and professional etherCON RJ45
• Separate custom-built toroidal transformers for digital and servo motors/actuators
• MODULAR DESIGN with upgradeable multi board system
• Precision Philips CD-Pro2 transport customized
• High-quality parts selected for sound quality:
- 105° long life capacitors
- low noise Metal Foil ultra-precision resistors
- metallized film pulse capacitor
- ultra-fast diodes
- halogen free cables
V
La Diva CD Transport Owner’s Manual
• Aluminium top loading tray machined from billet
• Non-magnetic low-resonance aluminium chassis with Nextel
• Field upgradeable firmware
• Fluorescent display (VFD) with user off-selectable illumination
• Designed and handmade in Italy
3. Specifications
Disc Compatibility
CD, CD-R
CD Formats
Red Book
Drive mechanism
PHILIPS CD-PRO2 Customized
Pick-Up Technology
TRIGINTA preamplifier & Laser supply
Optical
Single focault - 3 beam method
Disc Drive Motor
Precision DC Motor
Servo power supply
High-performance voltage regulator (high-current)
Digital decoder
Proprietary ISDC
Digital isolators
Custom designed discrete circuit with high-speed photocouplers
Digital Output
2 S/PDIF 75 Ω:
- 1 coaxial BNC
- 1 coaxial RCA
1 AES/EBU (XLR) 110 Ω
1 AQlink - I2S serial bus
(etherCON RJ45)
1 AT&T (ST Fiber)
Word Clock Output
1 coaxial BNC 75 Ω
AQlink (I2S bus)
CMOS level
Native Sample Rate
16 bit / 44.1 KHz
Front Panel
Standby, Display, Play, Pause, Stop, Previous, Next Switches
Display
Fluorescent display (VFD) with user off-selectable illumination
Remote Control
Infra Red (RC5)
Power Consumption
100-115V / 220-240V; 50 or 60Hz - 38VA
Disc loading
Top-Loading (Manual)
Dimensions
( W x D x H ) 450 x 370 x 100 mm
Weight
10 kg
Front finish
Satin Alu Silver or Satin Black
Case finish
Grey Nextel powder coated
VI La Diva CD Transport Owner’s Manual
4. Front panel
On the front panel, you will find:
●Power on/off switch
●Display on/off switch
●LED power indicator
●Play switch
●Pause switch
●Stop switch
●Previous switch
●Next switch
●Display
1.
Back panel
On the rear panel, you will find:
●IEC connector of the power supply (220-240V or 100-120V).
●Digital outputs :
- etherCON RJ45 - AQlink (I2S serial bus)
- XLR AES/EBU
- BNC coax (S/PDIF)
- RCA coax (S/PDIF)
- ST fiber (AT&T)
- BNC word clock
VII
La Diva CD Transport Owner’s Manual
PIN ASSIGNMENT
The pin assignments of XLR-type male outputs are as follows:
Pin 1: Signal ground
Pin 2: Signal + (non-inverting)
Pin 3: Signal - (inverting)
Connector ground lug: chassis free
VIII La Diva CD Transport Owner’s Manual
