Aquafog HYDRO SS 700 User manual

HYDRO SS 700
OPERATOR’S MANUAL
Read & Understand
Retain for Future Reference
NOTICE
► DIRECT FEED

Read operator’s manual carefully and thoroughly.
Understand all safety warnings and instructions before
attempting operation of the unit.
DO NOT OPERATE THE UNIT DRY (FULL WATER SUPPLY
REQUIRED IN THE SUMP). This would cause permanent
damage to the unit’s sump pump.
Hydro 700 must be properly grounded as a precaution against possible
electric shock. Always check for the correct voltage.
Always disconnect power before inspecting or servicing machine.
Keep cord away from heat, oil, sharp edges and moving parts. Replace
damaged cords immediately. Damaged cords increase the risk of electric
shock.
If use of an extension cord is necessary, use a heavy, gauge 3 wire extension
cord with a molded three-prong plug (See installation).
Keep hands and all objects from entering the path of the blade.
Install the Hydro SS 700 at bench-top height or higher for added safety and
optimum performance.
Do not use ammable liquids, caustic materials, or corrosive materials with
the Hydro SS 700.
When servicing Hydro SS 700, use only identical replacement parts
and follow instructions in the maintenance section of this manual. Use
of unauthorized parts or failure to follow maintenance instructions may
damage equipment or cause personal injury.
1 - Drainage Line 3/8” OD
1 - Water line with Hose Connector
5 - Wire Ties
1 - Operator’s Manual
When unpacking your unit,
Locate the following items:
1 - Direct Feed Hanging Unit
1 - 20-300 cc/min Flowmeter Panel
THE HYDRO SS 700 CAN BE AUTOMATED WHEN USED
IN CONJUNCTION WITH A CONTROL. A FAN MAY NOT
APPEAR POWERED BUT COULD SUDDENLY BEGIN HIGH-SPEED ROATATION AS A
FUNCTION OF THE PRESET CONTROL.
CAUTION
GROUND FAULT RECAPTACLES ARE STRONGLY
RECOMMENDED AND MAY BE REQUIRED BY LAW.
NOTICE
GENERAL SAFETY
UNPACKING
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.

Layout Guidelines
Small structures
In applications requiring only one unit,
install the unit anywhere along one end
wall, propelling the fog up and horizontally
down the length of the structure. If there
is forced ventilation, choose the intake
end of the structure. The best location for
automated controls is behind the fan at an
easily-accessible level for monitoring.
Large structures
Equally space the units within the
structure. Lower humidity and/or
cooling requirements can allow for
greater distance between fans. Usually,
the maximum distance between fans
should be 20’ from the side and 35’
from the front. If the structure has
forced ventilation, shift the fans closer
to the intake end. The fans should
always be propelling their fog with the
direction of natural or forced air ow.
Control location area
Placement Guidelines
Mount the fan high overhead in the largest available open area. As
a general rule, the higher the better when mounting your fan. Allow
one foot above the unit and adequate room in front of and below
the fan for the unobstructed propulsion of the fog.
Mount the fan near the intake end of a ventilated structure. In struc-
tures with no ventilation, install the unit at the largest, most open
end and propel the fog towards the opposite end.
Utilize the pivoting fogging head in order to maximize the unit’s performance.
DO NOT Propel the fog into the wind (direction of airow).
DO NOT Pivot the fogging head to propel fog at a sharp downward angle.
DO NOT Cramp the fan in tight spaces or skinny aisleways.
DO NOT Mount the fan near the ground or underneath tables or benches. This
would result in a high loss of fog onto the ground, though it would not
cause mechanical harm to the unit.
PLACEMENT & LAYOUT
10’
35’
20’
Direction of air ow →
Direction of air ow →

Pull on tubing
Hose Connector
Push on retaining ring
Fig. 2
Flow
Control
Valve
Flowmeter Panel
or
Hydro SS
Optional Control Package
Garden Hose
115V
Receptacle
Horizontal Support
or
Flowmeter Panel
Wire
Ties
Supply Inlet
Fig. 3
Water
Supply In
Water Supply
Out
In Line
Strainer
Cap
Installation
Prepare the Unit for Installation: After unpacking the unit, swing
the hanger support to the top and locate a sturdy horizontal
support capable of handling well over the 14 pound weight of
the unit. The thickness of the support can be up to 1.5”. Drill a
11/32” straight vertical hole through the support where you want
to hang the unit. Using 1/2” wrenches, secure theDirect Feed unit
into position with the hardware provided. See Fig. 1
Connect the Water Supply: Hydro SS 700 DF units come
equipped with a 20-300 cc/min. (.3 - 5 GPH) Flowmeter panel.
This panel should be mounted somewhere accessible for adjusting and monitoring.
Direct Feed units also come with a 15’ of 1/4” water line tubing and a standard
garden hose connector. Cut tubing at the desired location for the owmeter. Connect
the owmeter to the tubing between the Hydro unit and the water supply. Use the
remaining tubing and hose connector to connect to an available hose bib. To shorten
tubing and remove hose connector, apply pressure to the retaining clip while pulling
on the tubing. See Fig. 2
Connect the Power Supply: Plug directly into a properly grounded receptacle. If
equipped with a Humidistat, Thermostat, or Cycle Timer Control, plug the Control into
a receptacle and then plug the fan into the female side of the control’s pre-wired
plug. See Fig. 3
INSTALLATION & OPERATION
Fig. 1
Operation
Adjusting fog output: After the unit has been
plugged in and the water turned on, you can adjust
fogging output with the owmeter’s ow control
valve, the black knob located at the bottom of the
owmeter. Turn counterclockwise to increase ow
rate.
Pivot Feature: Using the pivot knobs, loosen and
pivot the fogging head anywhere between 15°
down and 45° up from neutral. The factory’s
recommended angle is near 30° up. Retighten the
pivot knobs.

Lubricate Motor: Remove two blue plugs. Apply 4-5 drops of
light grade petroleum based oil at each bearing location 1 to 2
times a year or as needed. Replace the blue plugs. Oil ports are
located at the top of the motor. See Fig. 4
Clean Blade Assembly: After carefully removing the blade
assembly, remove the stainless steel cover and O-ring. Soak
the blades in CLR for about one hour, scrub clean and rinse
off with water. Carefully check the small holes leading into
passageways that extend the length of each blade.
See Fig. 5 When thoroughly clean, test by blowing a
small amount of air through each blade.
Clean a Clogged Solenoid:
Before replacing a clogged
solenoid, try thoughroughly
cleaning it rst. Solenoids
can be disassembled with
basic hand tools.
See Fig. 6
Clean Strainer: Periodically check for and clean out any debris
that gets caught in the in-line strainer.
Store correctly: Protect your unit from winter damage.
Expansion due to freezing can damage ttings. If storing unit
in freezing temperatures, be sure all uid is drained from all
parts of the unit. Damage due to freezing is not covered under
warranty.
Fig. 5
Blade’s Reservoir Area
Water Passageway
O-ring
Stainless Face Plate
Blade
Assy.
Clip
Plunger
Water Solenoid from optional
“DF” control packages
Water Solenoid
Coil
Brass
Body
Screws
Fig. 6
NO FOG
1. Stiff/Locked Motor Shaft
2. Bad Motor
3. Clogged Flowmeter Panel
4. Clogged In-Line Strainer
5. Clogged Water Solenoid
6. Clogged SST Feed Tube
POOR QUALITY FOG
1. Clogged Blade Assembly
2. Misaligned Water Feed Tube
3. Stiff/Locked Motor Shaft
4. Loose Blade Assembly
FAN DOES NOT SPIN
1. Stiff/Locked Motor Shaft
2. Bad Motor
3. Bad Electrical Connections
MOTOR OVERHEATING
1. Stiff/Locked Motor Shaft
2. Bad Motor
1. Lubricate motor bearings while manually rotating shaft back and forth unitl loose.
2. If motor smells, doesn’t start, or shaft will not loosen up, replace motor.
3. Remove valve and clean. If problem recurrs, clean inside the owmeter body.
4. Remove strainer cap, screen, and O ring. Flush clean iwth water.
5. Remove the top clip and disassemble the valve for cleaning with a Philips driver.
6. Remove the ream with a small wire. Clean and reinstall.
1. Remove and clean out the rear reservoir and the blades’ passageways.
2. Adjust the feed tube so its water stream ows into the the reservior area. Resecure.
3. Lubricate motor bearings, while manually rotating shaft back and forth until loose.
4. If the blade assy. can easily spin without the motor shaft spinning, replace the assy.
1. Lubricate motor bearings while manually rotating shaft back and forth until loose.
2. If motor smells, doesn’t start or shaft will not loosen-up, replace motor.
3. Check for loose connections, test motor and controls with a direct power supply.
1. Lubricate motor bearings while manually rotating shaft back and forth until loose.
2. If motor smells, doesn’t start or shaft will not loosen-up, replace motor.
Troubleshooting
Possible Cause(s) Corrective Action
3 in 1
oil
Oil ports
MAINTENANCE
Fig. 4

Fig. 8
Fig. 9
A
B
Screwdriver
Slot A
Screwdriver
Slot B Top of Flow-
meter
10-24
Nuts
Atomizing Ring/Front Guard
Assembly
Using a 3/8” nut driver or wrench,
remove four 10-24 ange nuts
located at the back of the
housing. See Fig. 7. Remove the
guard/atomizing assembly out the
front fan opening. To reinstall, it
is easiest to work the bottom legs
into position and nger tighten
their nuts rst before working the
upper two legs into position.
Fan Blade Assembly
First remove the atomizing ring/front
guard assembly. The blade assembly
is press-tted onto the motor shaft.
Position ngers behind both sides of
the hub with forearms pressed up
against the rim of the housing. Use
the housing’s rim as leverage and pull
the blade assembly outward towards
the front. See Fig. 8 Pull primarily on
the hub portion of the blade assembly;
excess force on the blades can cause
damage. To reinstall, press on using the
palm of one hand while the other hand
is supporting the unit.
Motor
Disconnect the electrical power. After
removing the atomizing ring, front guard
assembly and blade assembly, use a
3/8” nut driver or wrench to remove
the four 10-24 nuts behind the blade
assembly securing the motor to rear
guard.
See Fig. 8
Flowmeter
Using a small at screwdriver, remove
the retaining key using Slot A by sliding
the key out toward the back. See Fig. 9 Next, use the screwdriver in Slot B to pull
the retainer cap straight up. After the retainer cap is removed, be careful not to lose
the internal oat ball when handling or cleaning the owmeter.
SERVICE & REPAIR
Fig. 7
10-24
Flange Nuts
Motor
Atomizing Ring/Front
Guard Assy.

12
1
2
3
4
5
6
7
8
9
10 11
13
14
15
REPLACEMENT PART IDENTIFICATION
DESCRIPTION PART NO.
1 Atomizing Ring 400-001
2 Front Guard 400-002
3 Motor 1/20hp 115V 400-110
4 Rear Guard 400-127
5 Blade Assembly 400-128
6 Housing 400-100
7 Hanger Assembly 400-129
8 SST Water Feed Tube 400-130
9 Hydro SS Pivot Knob 400-111
10 Drain Barb Fitting 400-114
11 Drain Hose 400-089
12 Flowmeter Panel Assembly SS-FP-5
13 In-Line Strainer 71
13 1/4” Water Tubing W-14
14 Garden Hose Connect W-2

Aquafog and accessories are warranted to the original purchaser
against defects in material and workmanship under normal use for one full
year from date of purchase. Any part determined to be defective and returned
to the manufacturer, shipping cost prepaid, will be repaired or replaced at
Jaybird Manufacturing, Inc.'s discretion without charge. Proof of purchase
date and an explanation of the problem or complaint must accompany the
returned portion of the machine.
Jaybird Manufacturing, Inc. reserves the right to verify the legitimacy
of claimed defects. The provisions of this warranty do not apply to damage
resulting from direct or indirect misuse, negligence, accident, lack of main-
tenance, or unauthorized repairs or alterations which affect the machine's
performance or reliability.
LIMITATIONS OF LIABILITY. TO THE EXTENT ALLOWABLE UNDER
APPLICABLE LAW, JAYBIRD MANUFACTURING, INC.'S LIABILITY FOR DEATH,
INJURIES TO PERSONS OR PROPERTY, OR FOR CONSEQUENTIAL OR INCI-
DENTAL DAMAGES ARISING FROM THE USE OF OUR EQUIPMENT IS
EXPRESSLY DISCLAIMED. JAYBIRD MANUFACTURING, INC.'S LIABILITY IN
ALL EVENTS IS LIMITED TO, AND SHALL NOT EXCEED, THE PURCHASE PRICE
PAID. NO OTHER WARRANTY, EXPRESSED OR IMPLIED, IS AUTHORIZED,
INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PAR-
TICULAR PURPOSE.
This warranty gives you specic legal rights, and you may also have other rights,
which vary from state to state.
1
year
ONE YEAR LIMITED WARRANTY
Printed in U.S.A.
© 2015 Jaybird Mfg., Inc.
Jaybird Manufacturing, Inc.
135 Summer Lane
Centre Hall, PA 16828
Parts & Service: 1.814.364.1800
Website: www.jaybird-mfg.com
