Aquazone Home Ozone Generator 2 User manual

HOME OZONE GENERATOR 2
INFORMATION AND INSTRUCTION MANUAL
Read the instructions carefully before using the Home Ozone Generator 2
1

CONTENTS
TECHNOLOGY 3
THE CHARACTERISTIC OF OZONE 3
WHAT OZONE CAN DO 3
FACTORS WHICH AFFECT OZONE’S DISINFECTION ABILITY 4
HOW OZONE KILLS MICROORGANISMS 4
APPLICATIONS 4
WATER TREATMENT 4
FOOD INDUSTRY 4
MEDICAL 5
HOME APPLICATIONS 5
FOOD AND WATER 5
HEALTH CARE 6
OPERATING INSTRUCTIONS 6
TECHNICAL SPECIFICATIONS 7
CAUTIONS 7
SAFETY CAUTIONS 7
OPERATION CAUTIONS 7
TROUBLESHOOTING DATA 8
TERMS AND CONDITIONS OF SERVICE 8
ACCESSORIES 8
2

TECHNOLOGY
THE CHARACTERISTIC OF OZONE
Ozone, which has the scientific name O³ is created by combining three oxygen atoms. It has a
high oxidising ability, which is effective for disinfecting and sterilising. It can kill most bacteria in
the water or in the air. It is accepted as a broad-spectrum, effective disinfectant and contains
ozone. Ozone is an important component of our atmosphere. Our atmosphere confines
0.01-0.04ppm of ozone, which balances the level of bacteria and mildew in nature. Ozone is
also created electrically in nature during active thunderstorms. The electrical discharge creates
that positive sweet smell that we understand as clean fresh air.
The molecule of ozone is inherently unstable and tries to break down into the oxygen molecule
as quickly as possible. This is what makes ozone such a great air and water cleaner. The
ozone molecules need to be combined with something in order to break down so that they end
up oxidising organic compounds and turn them into harmless carbon dioxide and water. Ozone
quickly breaks down into oxygen, it’s considerably less toxic than disinfectant chemicals like
chlorine. It has been called the cleanest oxidiser and disinfector.
WHAT OZONE CAN DO
● Kill microorganisms
● Kill bacteria
● Kills most Coliform and staphylococcus in the air
● Kills coliform and staphylococcus aureus on the surface of objects
● Kills coliform and staphylococcus and salmonella in the phosphate alleviant
● Kills coliform in water
● Kills bacteria spores
● Kills Brevibacterium spores
● High ability in killing bacteria in the air but not bacteria spores
● Kills 99.999% of brevibacterium spores in the water
● Kills viruses
● Destroys 99.99% of HBsAG and 100% of HAAg
● Destroys Influenzas Virus in the air
● Destroys PV 1 and Hepatitis A virus in the water
● Destroys SA-11 in water
● When the concentration of ozone in the blood serum reaches to 4mg/l it will destroy the
HIV at 106cd50/ml
● Kills 100% of aspergillus versicolor and penicillium
● Kills 100% of Aspergillus niger, fusarium f.sp. mwlonogea and fusarium oxysporum
f.sp. lycopersici
● Kills aspergillus niger and candida bacteria
● Kills parasitic protozoa
● Kills parasitic protozoa and its egg efficiently
● Neutralise smoke and toilet smells
● Remove paint smells
3

FACTORS WHICH AFFECT OZONE’S DISINFECTION ABILITY
● The concentration of ozone
● Temperature
At a temperature of 30°C-32°C the ozone disinfection ability is best.
In killing HA V and Coliform the best temperature is 10°C
HOW OZONE KILLS MICROORGANISMS
● Ozone can combine with amino acid and breaks the protein in these bodies
● Ozone destroys viruses by diffusing through the protein coat into the nucleic acid core,
resulting in damage of the viral RN. At higher concentrations, ozone destroys the
capsid or exterior protein shell by oxidation.
● In Gram negative organisms, fatty acid alkyl chains and helical lipoproteins are present
● Ozone may also penetrate the cellular envelope, directly affecting cytoplasmic integrity,
disrupting any one of the numerous levels of its metabolic complexities
APPLICATIONS
WATER TREATMENT
● Ozone can effectively kill bacteria and viruses, and can remove the organic impurities
in the water.
● It can remove odour and be used as a bleaching agent too.
● Chlorine is widely used in water treatment practice; it generates harmful substances
such as chloroform in the process of treating water. Ozone will not generate
Chloroform. Ozone is more germicidal than chlorine. It has been widely used in water
plants in the USA and EU.
● Chemical Ozone can break the bonds of organic compounds to combine from new
compounds. It is widely used as an oxidant in the chemical, petrol, papermaking and
pharmaceutical industries.
FOOD INDUSTRY
● Because ozone is a safe, powerful disinfectant, it can be used to control biological
growth of
● unwanted organisms in products and equipment used in the food processing industries.
● Ozone is particularly suited to the food industry because of its ability to disinfect
microorganisms without adding chemical by-products to the food being treated or to the
food processing water or atmosphere in which food is stored.
● In aqueous solutions, ozone can be used to disinfect equipment, process water and
some food items and neutralise pesticides
● In gaseous form, ozone can act as a preservative for certain food products and can
also sanitize food packaging materials.
4

● Some products currently being preserved with ozone include eggs during cold storage,
fresh fruits and vegetables and fresh seafood.
MEDICAL
● Ozone has been used in hospitals and clinics as a disinfectant in China, Germany and
other developed and developing countries.
● Ozone is more germicidal than formalin, acidum peroxyacetic and potassium
permanganate.
HOME APPLICATIONS
AIR PURIFICATION
APPLICATIONS
TIME
FUNCTIONS AND EFFECTS
Airtight room
10 minutes
Removes odour, tobacco smoke and particles in
the air
Kitchen
10 minutes
Removes food preparation and cooking (onions,
garlic and fish odour and smoke in the air)
Pets
10 minutes
Removes pets' odour
Cupboard
10 minutes
Kills bacteria and mould. Removes odour from
cupboard
Carpets and
furniture
10-30 minutes
Removes harmful gases such as formaldehyde
emanating from new furniture, painting and
carpeting
FOOD AND WATER
FOOD AND WATER
APPLICATIONS
TIME
FUNCTIONS AND EFFECTS
Washing of fruits
and vegetables
10 - 20 minutes
Dissolves and eliminates pesticide on the surface of
fruits and vegetables. Kills bacteria on the surface of
fruits and vegetables
Tableware
washing
10 minutes
Kills bacteria on the surface of the tableware
5

Fish and meat
washing
5-10 minutes
Eliminates the fishy odour. Kills the bacteria on the
meat and fish
Water treatment
10 minutes (10kg)
Dissolves the organic impurities and bleaches the
water.Increases the oxygen level in the water
Food
preservation
5-10 minutes
Disinfects the food in the refrigerator. Extends fresh
fruit and vegetable storage life in refrigerators and
coolers. Keep the food fresh
Refrigerator
deodorisation
10 minutes
Eliminates any odour in the refrigerator. Prevents
odour and taste cross contamination of foods in
refrigerators and coolers
HEALTH CARE
HEALTH CARE
APPLICATIONS
TIME
FUNCTIONS AND EFFECTS
Bathing
15-30 minutes
Prevents diseases such as epiphyte from spreading
Laundry
20 minutes
Kills bacteria, eliminates any odour and bleaches the
clothes
Children's articles
10 minutes
Disinfects nursing bottles and toys etc…
Oral Hygiene
5-10 minutes
Kills bacteria in the oral cavity diseases such as
faucitis and stomatitis
Skin care
10-20 minutes
Kills harmful bacteria. Helps prevent or control many
skin conditions. Helps accelerate the metabolism
activity of the skin making skin healthier and fresher in
appearance
OPERATING INSTRUCTIONS
● Plug into an earthed socket of the appropriate rating
● Connect the tube with the outlet of the unit and the ozone diffuser / air stone (Air stone
is not required for air treatment)
● Turn the knob in a clockwise direction to indicate the working time according to the
table mentioned. (The maximum working time is 30 minutes)
6

TECHNICAL SPECIFICATIONS
● Model: Aquazone HOme Ozone Generator 2
● Power Supply: AC220V-240V/50Hz
● Power Consumption: 18W
● Ozone Output: 500mg/hour
● Max Working Time: 30 minutes
● Weight: 1 kg
● Dimensions: 27cm x 16.5cm x 5.5cm
● Purifying area: 15-20 square meters
CAUTIONS
SAFETY CAUTIONS
● The unit should be mounted in a position where it is higher than water level, to protect
from water backflow into the machine
● Do not put the unit in a smoky or damp place and avoid high temperature environments
● Handle with caution. Do not cover the air outlet
● Place the unit out of reach of children
● Keep the air tube clean and do not fold the silicon tubes
● Do not keep your eyes or nose close to the air outlet of the unit
● Keep the room well ventilated when purifying the air
● Stop using the unit if you feel dizzy after you have used it
● Do not drink ozone treated water until the process is completed for 5-10 minutes
● The safety level of ozone for people is about -ppm which is about the same as the level
of ozone in nature
● It is normal if the silicon tube becomes white or yellow after using for some time
● Make sure the diffuser air stone is at the bottom of the vessel when treating water
● In water treatment, when the water is 20cm -40cm deep, ozone has a high dissolving
ability.
● Disconnect the power cord when repairing or maintaining the unit
OPERATION CAUTIONS
Warning - the unit is operating at high voltage
Caution - handle and maintain caution
● Power requirement – AC220V/50Hz
● Operating at high voltage, do not attempt to disassemble by yourself
● Contact our service centre to change the broken cord or plug
● Unplug the unit and clean with a soft dry cloth
● Do not place the unit in a damp and high temperature environment
● Do not attempt to disassemble, repair or refit the unit by yourself
7

TROUBLESHOOTING DATA
● If ozone output is reducing, please check the following;
● The air tube is breached or folded. In the event of breaching and folding, please
change the silicon tube or unfold it.
● If the air stone is clogged, please use a new air stone
● If working normally, but has no smell of ozone, please contact Biozone Manufacturing
and a technician will assist with information or assess the unit.
TERMS AND CONDITIONS OF SERVICE
● One year / 12 months warranty for factory defects.
The following circumstances are not under warranty
● Attempt to disassemble or repair the unit by yourself
● The serial number sticker is to remain on the unit
● Damage caused by shipment or accident
● Damage caused by lack of maintenance
● Damage caused by not following the instructions
● Damage caused by improper repairing by unauthorised person
● After warranty period you will be charged for parts changed and labour
● The service, which is not included in warranty, will be charged according to stipulations
ACCESSORIES
The following items are in the box
● 1 x Aquazone Home Ozone Generator 2
● 2 x Air stones
● 2 x Silicon tubing
● 1 x Information and instruction manual
Notice: The manual is for reference only; any design or specification are subject to change
without notice.
