arcelik 566375 Series User manual

566375*
566410*
566411*
Refrigerator
User manual
EN
5774451176/AB

1.Refrigerator
2.SAFETY INSTRUCTIONS
-Intended Use
-Safety of Children,Vulnerable
Persons and Pets
-Electrical Safety
-Handling Safety
-Installation Safety
-Operational Safety
-Food Storage Safety
-Maintenance and Cleaning Safety
-Disposal of the Old Product
3.ENVIRONMENTAL INSTRUCTIONS
-Compliance with WEEE regulations
and Waste Disposal
-Packaging Information
4.INSTALLATION
-Right Place For Installation
-Electrical Connection
-Attaching the Plastic Wedges
-Adjusting the Legs
-Hot Surface Warning
1
1
1
1
2
2
2
3
4
4
5
5
5
5
5
5
6
6
6
6
5.PREPARATION
-What To Do For Energy Saving
-First Use
-Climate Class and Definitions
6.OPERATING THE PRODUCT
7.CONTROL PANEL OF THE PRODUCT
-Indicator panel (Internal Display)
-Indicator panel (External Display)
8.USING THE PRODUCT
-Replacing the Illumination Lamp
-Door Open Alert
9.PRODUCT FEATURES
-The ice storage area
-Crisper Technologies
10.MAINTENANCE AND CLEANING
11.TROUBLESHOOTING
7
7
7
7
8
8
8
8
11
13
13
14
14
14
15
16
A
!
A
"
SUPPLIER’S NAME MODEL IDENTIFIER (*)
The model information as stored in the product data
base can be reached by entering following website and
searching for the model identifier (*) found on energy label.
https://eprel.ec.europa.eu/
Please read this user manual First!
Dear Customer
Please read this manual before using the product.
Thank you for choosing this Arçelik product. We would like you to achieve the optimal efficiency from
this high quality product which has been manufactured with state of the art technology. To do this,
carefully read this manual and any other documentation provided before using the product and keep it
as a reference. Heed all information and warnings in the user manual. This way, you will protect
yourself and your product against the dangers that may occur.
Keep the user manual. Include this manual with the unit if you hand it over to someone else.
The following symbols are used in the user manual:
Hazard that may result in death or injury.
Important information or useful tips on operation.
Read the user manual.
Combustible material, warning against fire hazard.
R600a
This symbol
denotes the
precaution on
flammable
refrigerants.
NOTICE A hazard that may cause material damage to the
product or its surroundings

This section includes the safety instructions
necessary to prevent the risk of personal injury
or material damage.
Our company shall not be held responsible for
damages that may occur if these instructions are
not observed.
1.1 Intention of Use
This product is not suitable for commercial
use and should not be used for a purpose other
than its intended use.
This product is intended for operating
interiors, such as households or similar.
For example; In the staff kitchens of the stores,
offices and other working environments, In farm
houses, In the units of hotels, motels or other
resting facilities that are used by the customers,
In hostels, or similar environments, In catering
services and similar non-retail applications.
This product shall not be used in open or
enclosed external environments such as
vessels, camper vans, balconies or terraces.
Exposing the product to rain, snow, sunlight and
wind may cause risk of fire.
2.2 Safety of Children,Vulnerable Persons
and Pets
This product may be used by children aged 8
years and older and persons with underdevel-
oped physical, sensory or mental capabilities or
lack of experience and knowledge if they are
being supervised or have been given instruction
concerning use of the appliance
in a safe way and the
hazards involved.
Children between 3 and 8 years are allowed to
put and take out food into/from the cooler
product.
Electrical products are dangerous for children
and pets. Children and pets must not play with,
climb on, or enter the product.
Cleaning and user maintenance should not be
performed by children unless there is someone
overseeing them.
Keep the packaging materials away from
children. Risk of injury and suffocation.
Before disposing of old products that shall not be
used any more:
1. Unplug the power cord from the mains socket.
2. Cut the power cable and remove it from the
appliance together with the plug.
EN 1
1. Freezer - compartment door shelf
2. Egg Section
3. Fridge door shelf
4. Fridge door shelf
5. Cosmetic Box
6. Bottle shelf
7. Fridge-compartment door shelf
8. Icebox / Ice-making compartment
9. Freezer compartment glass shelf
10. Meat zone
11. Convertible Diary compartment
12. Temperature setting button
13. Fridge compartment glass shelf
14. Crisper
15. Adjustable feet
16. Freezer compartment
17. Fridge compartment
*Selected Model
16
17
1
1
2 3
4
*5
6
7
9
*10
11
14
12 13
13
15 15
8
1.REFRIGERATOR
2.SAFETY INSTRUCTIONS
Figures that take place in this instruction manual are schematic and may not
correspond exactly withyour product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
Installation and repair operations shall always be
performed by authorized service.
Use original spare parts and accessories only.
Do not repair or replace any component of the
product unless it is clearly specified in the user
manual.
Do not perform any modifications on the product.

2 EN
2.SAFETY INSTRUCTIONS
3. Do not remove the racks and drawers from the
product to prevent children from getting inside the
appliance.
4. Remove the doors.
5. Store the product so that it shall not be tipped
over.
6. Do not allow children to play with the scrapped
product.
Do not dispose of the product by throwing it into
fire. Risk of explosion.
If there is a lock available on the product’s door,
keep the key out of children's reach.
2.3 Electrical Safety
The product shall not be plugged into the outlet
during installation, maintenance, cleaning, repair,
and transportation operations.
If the power the cable is damaged, it shall be
replaced by authorized service only to avoid any
risk that may occur.
Do not tuck the power cord under the product
or to the rear of the product. Do not put heavy
items on the power cord. The power cable should
not be bent, crushed, and come into contact with
any heat source.
Do not use an extension cord, multi-plug or
adaptor to operate your product.
Portable multi-plugs or portable power supplies
may overheat and cause fire. Thus, do not have a
multi-plug behind or in the vicinity of the product.
Do not plug the product’s power cord in a loose
or damaged power outlet. These types of
connections may overheat and cause fire.
The plug shall be easily accessible. If this is not
possible, a mechanism that meets the electrical
legislation and that disconnects all terminals from
the mains (fuse, switch, main switch, etc.) shall be
available on the electrical installation.
Do not touch the plug with wet hands.
When unplugging the appliance, don’t hold the
power cord, but the plug.
2.4 Handling Safety
This product is heavy, do not handle it by
yourself.
Do not hold the product from its door while
handling the product.
Be careful not to damage the cooling system
and the pipes while handling the product. Do
not operate the product if the pipes are damaged,
and contact an authorized service.
2.5 Installation Safety
Contact the Authorized Service for the
product's installation. To prepare the product for
use, see the information in the user manual and
make sure the electric and water utilities are as
required. If not, call a qualified electrician and
plumber to arrange the utilities as necessary.
Failure to do so may result in electric shock,
fire, problems with the product, or injury.
Check for any damage on the product before
installing it. Do not have the product installed
if it is damaged.
Place the product on a clean, level and hard
surface and balance it with the adjustable legs.
Otherwise, the refrigerator may tip over and cause
injuries.
The product shall be installed in a dry and
ventilated environment. Do not keep carpets,
rugs or similar covers under the product. This may
cause risk of fire as a result of inadequate
ventilation!
Do not block or cover ventilation holes.
Otherwise, power consumption increases and
your product may be damaged.
The product must not be connected to supply
systems such as solar power supply. Otherwise,
your product may be damaged due to sudden
voltage changes!
When positioning the appliance, ensure the
supply cord is not trapped or damaged.
The more refrigerant a refrigerator contains, the
bigger its installation room should be. In very
small rooms, a flammable gas-air mixture may
occur in case of a gas leak in the cooling system.
At least 1 m³ of volume is required for each 8
grams of refrigerant. The amount of the refrigerant
available in your product is specified in the Type
Label.
The installation place of the product shall not

EN 3
2.SAFETY INSTRUCTIONS
be exposed to direct sunlight and it shall not be in
the vicinity of a heat source such as stoves, etc. If
you cannot prevent installation of the product in the
vicinity of a heat source, use a suitable insulation
plate and make sure the minimum distance to the
heat source is as specified below:
– At least 30 cm away from heat sources such as
stoves, ovens, heating units and heaters, etc.,
– And at least 5 cm away from electrical ovens.
Your product has the protection class of I.
Plug the product in a grounded socket that
conforms with the Voltage, Current and Frequency
values specified in the type label. The socket must
have a 10A – 16A fuse. Our firm will not assume
responsibility for any damages due to usage without
earthing and without power connection in
compliance with local and national regulations.
The product’s power cable must be unplugged
during installation. Otherwise, risk of electric shock
and injury may occur!
Do not plug the product’s power cord in loose,
dislocated, broken, dirty, oily power outlets which
have a risk of water contact. These types of
connections may cause overheating and fire.
Place the power cable and hoses (if any) of the
product so that they shall not cause a risk of
tripping over.
Penetration of humidity to live parts or to the
power cord may cause short circuit. Thus, do not
use the product in humid environments or in areas
where water may splash (e.g. garage, laundry
room, etc.) If the refrigerator is wet by water,
unplug it and contact an authorized service.
Do not ever connect your refrigerator to power
saving devices. These systems are harmful for the
product
2.6 Operational Safety
Do not ever use chemical solvents on the
product. These materials contain an explosion risk.
In case of a failure of the product, unplug it and
do not operate until it is repaired by the authorized
service. There is a risk of electric shock!
Do not place a source of flame (e.g. candles,
cigarettes, etc.) on the product or in the vicinity of it.
Do not get on the product. Risk of falling and
injury!
Do not cause damage to the pipes of the
cooling system using sharp and piercing tools.
The refrigerant that sprays out in case of
puncturing the gas pipes, pipe extensions or
upper surface coatings may cause irritation of
skin and injury to the eyes.
Do not place and operate electrical appliances
inside the refrigerator/ freezer unless it is advised
by the manufacturer.
Do not jam any parts of your hands or your
body to the moving parts inside the product. Be
careful to prevent jamming of your fingers
between the refrigerator and its door. Be careful
while opening or closing the door if there are
children around.
Do not put ice cream, ice cubes or frozen food
to your mouth as soon as you take them out of
the freezer. Risk of frostbite!
Do not touch the inner walls, metal parts of the
freezer or food kept inside the freezer with wet
hands. Risk of frostbite!
Do not place soda cans or cans and bottles
that contain fluids that may be frozen to the
freezer compartment. Cans or bottles may
explode. Risk of injury and material damage!
Do not use or place materials sensitive against
temperature such as flammable sprays,
flammable objects, dry ice or other chemical
agents in the vicinity of the refrigerator. Risk
of fire and explosion!
Do not store explosive materials such as
aerosol cans with flammable materials inside the
product.
Do not place cans containing fluids over the
product an open state. Splashing of water on an
electrical part may cause the risk of an electric
shock or a fire.
This product is not intended for storage and
cooling of medicines, blood plasma, laboratory
preparations or similar materials and products
that are subject to the Medical Products
Directive.

4 EN
2.SAFETY INSTRUCTIONS
If the product is used against its intended
purpose, it may cause damage to or deterioration
of the products kept inside.
If your refrigerator is equipped with blue light, do
not look at this light with optical devices. Do not
stare directly at UV LED light for a long time.
Ultraviolet rays may cause eye strain.
Do not fill the product with more food than its
capacity. Injuries or damages may occur if the
contents of the refrigerator fall when the door is
opened. Similar problems may also occur when an
object is placed over the product.
Ensure that you have removed any ice or water
that may have fallen to the floor to prevent injuries.
Change the locations of the racks/bottle racks on
the door of your refrigerator only when the racks
are empty. Danger of injury!
Do not place objects that may fall/tip over on the
product. These objects may fall while opening or
closing the door and cause injuries and/or material
damages.
Do not hit or exert excessive pressure on glass
surfaces. Broken glass may cause injuries and/or
material damages.
The cooling system in your product contains
R600a refrigerant. The refrigerant type used in the
product is specified in the type label. This gas is
flammable. Therefore, be careful not to damage the
cooling system and the pipes while operating the
product. In case of damage to the pipes;
1. Do not touch the product or the power cable.
2. Keep the product away from potential sources of
fire that may cause the product to catch fire.
3. Ventilate the area where the product is placed.
Do not use a fan.
4. Contact Authorized Service.
5. If the product is damaged and you observe gas
leak, please stay away from the gas. Gas may
cause frostbite if it contacts your skin.
2.7 Food Storage Safety
Please pay attention to the following warnings to
avoid food spoilage:
Leaving the doors open for a long time may
cause the temperature inside the product to rise.
Regularly clean the accessible drainage systems
in contact with food.
Clean the water tanks that have not been used
for 48 hours and mains-fed water systems that
have not been used for more than 5 days.
Store raw meat and fish products in appropriate
compartments within the product. Thus, it does not
drip on or come into contact with other foods.
Two-star freezer compartments are used for
storing prefilled foods, making and storing ice and
ice cream.
One, two and three-star compartments are not
appropriate for freezing fresh food.
If the cooling product has been left empty for a
long time, turn off the product, defrost, clean,
and dry the product in order to
protect the housing of the
product.
2.8 Maintenance and Cleaning Safety
Unplug the refrigerator before cleaning it or
starting to perform maintenance.
Do not pull by the door handle if you shall move
the product for cleaning purposes. Handle may
cause injuries if it is pulled too hard.
Do not put your hands etc. under the refrigerator.
Jamming may occur or any sharp edge may cause
personal injuries.
Do not clean the product by spraying or pouring
water on the product and inside the product. Risk
of electric shock and fire.
When cleaning the product, do not use sharp
and abrasive tools or household cleaning agents,
detergent, gas, gasoline, thinner, alcohol, varnish,
and similar substances. Use only cleaning and
maintenance agents that are not harmful for food
inside the product.
Do not ever use steam or steamed cleaning
materials for cleaning the product and thawing the
ice inside it. Steam con tacts the live areas in your
refrigerator and causes short circuit or electric
shock.
Do not use any mechanical tools or any other
tools than the recommendations of the
manufacturer to speed up the defrost operation.

EN 5
2.SAFETY INSTRUCTIONS
3.ENVIRONMENTAL INSTRUCTIONS
4.INSTALLATION
Take care to keep water away from the
ventilation holes, electronic circuits or lighting of
the product.
Use a clean, dry cloth to wipe the dust or foreign
material on the tips of the plugs. Do not use a wet
or damp piece of cloth to clean the plug.
Otherwise, risk of fire or electric shock may occur.
1.9 Disposal of the Old Product
When disposing of your old product follow the
instructions below:
To prevent children from accidentally locking
themselves into the product, if there is door lock,
make it deactivated.
3.1 Compliance with WEEE regulations and
Waste Disposal
This product does not contain hazardous and
prohibited substances specified in the "Regulations
for Supervision of Waste Electrical and Electronic
Equipment" published by Turkish Ministry of
Environment and Urban Planning. 3.2 Packaging Information
Complies with WEEE Regulation.
This product was manufactured
from recyclable and reusable high
quality parts and materials.
Therefore, do not dispose of this
product with other domestic wastes at the end of its
life cycle. Take it to a collection point for electrical
The product's packaging is made of
recyclable materials, in accordance with
the National Legislation. Do not dispose
of the packaging waste with the
household waste or other wastes,
dispose it to the packaging collection
areas specified by local authorities.
Splash of coolant is harmful to the eyes. Do not
damage any part of the cooling system while
disposing of the product.
It may be fatal if the compressor oil is swallowed
or if it penetrates the respiratory tract.
Cooling system of your product includes R600a
gas as specified in the type label. This gas is
flammable. Do not dispose of the product by
throwing it into fire. Risk of explosion!
4.1 Right Place For Installation
Contact the Authorized Service for the product's
installation. To prepare the product for installation,
see the information in the user manual and make
sure the electric and water utilities are as required.
If not, call an electrician and plumber to arrange
the utilities as necessary.
Read the “Safety Instructions” section first! WARNING:The manufacturer assumes
no responsibility for any damages caused
by the work carried out by unauthorized
persons.
WARNING:The product’s power cable
must be unplugged during installation.
Failure to do so may result in death or
serious injuries!
and electronic equipment. Please ask your local
authorities regarding these collection areas.
You can help protect the environment and natural
resources by delivering the used products for
recycling.

Place the product on a flat surface to avoid
vibration.
Place the product at least 30 cm away from the
heater, stove and similar sources of heat and at
least 5 cm away from electric ovens.
Do not expose the product to direct sunlight or
keep it in damp environments.
Your product requires adequate air circulation
to function efficiently. If the product will be placed in
an alcove, remember to leave at least 5 cm
clearance between the product and the ceiling, rear
wall and the side walls.
Check if the rear wall clearance protection
component is present at its location (if provided
with the product).
If the component is not available, or if it is lost or
fallen, position the product so that at least 5 cm
clearance shall be left between the rear surface of
the product and the wall of the room. The
clearance at the rear is important for efficient
operation of the product.
4.2 Electrical Connection
4.3 Attaching the Plastic Wedges
Use the plastic wedges provided with the product
to maintain sufficient space for air circulation
between the product and the wall.
1. To attach the wedges, remove the screws on the
product and use the screws provided with the
wedges.
2. Attach 2 plastic wedges on the ventilation cover
as shown in the figure.
4.4 Adjusting the Legs
If the product is not in balanced position, adjust the
front adjustable legs by rotating them to right or
left.
4.5 Hot Surface Warning
The side walls of your product are equipped with
cooler pipes to enhance the cooling system. High
pressure fluid may flow through these surfaces,
and cause hot surfaces on the side walls. This is
normal and it does not require servicing. Be careful
when you contact these areas.
Our firm will not assume responsibility for any
damages due to usage without earthing and power
connection in compliance with national regulations.
The power cable plug must be easily accessible
after installation.
Do not use multi-group plug with or without
extension cable between the wall socket and the
refrigerator.
6 EN
4.INSTALLATION
Do not use extension or multi sockets in
power connection.
Damaged power cable must be replaced
by Authorized Service.
When placing two coolers in adjacent
position, leave at least 4 cm distance
between the two units.
WARNING:If the door span is too
narrow for the product to pass, remove the
door and turn the product sideways; if this
does not work, contact the authorized
service.
‘ B ’
50 mm
100 mm
50 mm
50 mm
‘ C ’
‘ A ’
‘ D ’
130 (’ E ‘ )
o
Model
566410*
566411*
566375*
“A”
696
“B”
1720
“C”
660
“D”
1168
“E”
130

This refrigerating appliance is not intended to
be used as a built in appliance.
Do not keep the refrigerator doors open for
long periods.
Do not place hot food or beverages into
the refrigerator.
5.1 What To Do For Energy Saving
Do not overfill the refrigerator; blocking the
internal air flow will reduce cooling capacity.
Depending on the product’s features;
defrosting frozen foods in the cooler compartment
will ensure both energy saving and preserve food
quality.
Food shall be stored using the drawers in the
cooler compartment in order to ensure energy
saving and protect food in better conditions.
Make sure the foods are not in contact with the
cooler compartment temperature sensor shown
below.
Since hot and humid air will not directly
penetrate into your product when the doors are
not opened, your product will optimize itself in
conditions sufficient to protect your food. Under
these circumstances, functions and components
such as compressor, fan, heater, defrost, lighting,
display and so on will operate according to the
needs by consuming minimum energy.
In case that multiple options are present, glass
shelves must be placed so that the air outlets at
the rear wall are not blocked and preferably, in a
way that air outlets remain below the glass shelf.
This combination may help improving air
distribution and energy efficiency.
5.2 First Use
Before using your refrigerator, make sure
the necessary preparations are made in line
with the instructions in "Safety and Environmental
Instructions" and "Installation" sections.
Keep the product running without placing any
food inside for 12 hours and do not open the door,
unless absolutely necessary.
5.3 Climate Class and Definitions
Please refer to the Climate Class on the rating
plate of your device. One of the following
information is applicable to your device
according to the Climate Class.
SN: Long Term Temperate Climate: This cooling
device is designed for use at ambient temperatures
between 10 °C and 32 °C.
N: Temperate Climate: This cooling device is
designed for use at ambient temperatures between
16°C and 32 °C.
ST: Subtropical Climate: This cooling device is
designed for use at ambient temperatures between
16°C and 38°C.
T: Tropical Climate: This cooling device is
designed for use at ambient temperatures between
16°C and 43°C.
EN 7
5.PREPARATION
Read the “Safety Instructions” section first! A sound will be heard when the
compressor is engaged. It is normal for
the product to make noise even if the
compressor is not running, as fluid and
gas may be compressed in the cooling
system.
It is normal for the front edges of the
refrigerator to be warm. These areas
are designed to warm up in order to
prevent condensation.
For some models, indicator panel turns
off automatically 1 minute after the door
closes. It will be reactivated when the
door is opened or any button is pressed.

8 EN
6.OPERATING THE PRODUCT
7.CONTROL PANEL OF THE PRODUCT
Do not use any mechanical tools or any other
tools than the recommendations of the
manufacturer to speed up the defrost operation.
Do not use parts of your refrigerator such as the
door or drawers as a support or a step. This may
cause the product to trip over or its components to
be damaged.
The product shall be used for storing food only.
Turn off the water valve if you will be away from
home (e.g. at vacation) and you will not be using
the Icematic or the water dispenser for a long
period of time. Otherwise, water leaks may occur.
Unplugging the Product
If you are not going to use the product for a long
time, unplug the product from the socket.
Remove the food to prevent odours,
Wait for the ice to melt, clean the interior and let
it dry, leave the doors open to avoid damaging the
inner body plastics.
Read the “Safety Instructions” section first!
NOTIC :Figures that take place in this instruction manual are schematic and may not correspond exactly with
your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.
Indicator panel (Internal Display)
Indicator panels may vary according to the
product model.Audio – visual functions on the
indicator panel helps you in using your product.
12 3 4
5 6 *7 8
1. Quick Freezer button
Selection button Press “Quick Freeze”.Selection
button to setting freezer compartment.
2. Error status indicator
If your refrigerator does not per form enough
cooling of in case of a sensor fault, this indicator
is activated.
3. Freezer compartment selection button
This function allows you to set the temperature
of freezer compartment.Press this button to set
the temperature of the freezer compartment to
-16 , -18, -20 and -24 respectively.
4. Freezer compartment temperature indicator
Temperature of the freezer compartment -24 ,
-20, -18, and -16.
5. Quick Fridge button
Selection button : Press “Quick Cool”.Selection
button to setting fridge compartment.
6. Fridge compartment selection button
This function allows you to set the temperature of
fridge compartment. Press this button to set the
temperature of the fridge compartment to 8, 6, 4,
and 2, respectively.
7. Vacation function indicator (optional)
When the vacation function light.It is not suitable
to keep the food in the fridge compartment when
this
function is activated.
8. Fridge compartment temperature indicator
Temperature of the fridge compartment 2, 4, 6
and 8.

EN 9
7.CONTROL PANEL OF THE PRODUCT
Indicator panel(External display)
Indicator panel allows you to set the temperature
and control the other functions related to the
product without opening the door of the product.
Just press the inscriptions on relevant buttons for
function settings.
1. Power failure/High temperature / error
warning indicator
This indicator ( ) illuminates during power
failure,high temperature failures and error
warnings. During sustained power failures, the
highest temperature that the freezer compartment
reaches will flash on the digital display. After
checking the food located in the freezer
compartment ( ) press the alarm off button to
clear the warning. Please refer to "remedies
advised for trouble shooting" section on your
manual if you observe that this indicator is
illuminated.
2.Energy saving function (display off)
If the product doors are kept closed for a long time
energy saving function is automatically activated
andenergy saving symbol is illuminated. ( )When
energy saving.function is activated, all symbols on
the display other than energy saving symbol will
turn off. When the Energy Saving function is
activated, if any button is pressed or the door is
opened, energy saving function will be canceled
and the symbols on display will return to normal.
Energy saving function is activated during delivery
from factory and cannot be canceled.
4. Fridge compartment temperature setting
button
Press this button to set the temperature of the
fridge compartment to 8, 7,6, 5,4,3, 2, 8 respective-
ly. Press this button to set the fridge compartment
temperature to the desired value. ( )
5.Vacation Function
In order to activate vacation function,press the this
button ( ) for 3 seconds, and the vacation mode
indicator ( ) will be activated. When the the
vacation function is activated, “- -” is displayed on
the fridge compartment temperature indicator and
no active cooling is performed on the fridge
compartment. It is not suitable to keep the food in
the fridge compartment when this function is
activated. Other compartments shall be continued
to be cooled as per their set temperature.To cancel
this function press Vacation function button again.
3.Quick fridge function
The button has two functions. To activate or
deactivate the quick cool function press it briefly.
Quick Cool indicator will turn off and the product
will return to its normal settings. ( )
NOTIC :Figures that take place in this instruction manual are schematic and may not correspond exactly with
your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.
1 2
3456789*1011
12
Use quick cooling function when you want
to quickly cool compartment. If you want
to the food placed in the fridge cool large
amounts of fresh Food,activate this
function before putting the food into the
product.
If you do not canel it,quick cooling will
cancel itself automatically after 1 hours
or when the fridge compartment reaches
to the required temperature.
If you press the quick cooling button
repeatedly with short intervals, the
electronic circuit protection will be
activated and the compressor will not
start up immediately.
This function is not recalled when power
restores after a power failure.

11. Quick freeze function button
Press this button to activate or deactivate the quick
freezing function.When you activate the function,
the freezer compartment will be cooled to a
temperature lower than the set value.( )
12. Economic usage indicator
Indicates that the product is running in energy-
efficient mode. ( ) This indicator will be active if
the Freezer Compartment temperature is set to -16
or the energy efficient cooling is being performed
due to Eco-Extra function.
6. Alarm off warning:
In case of power failure/high temperature alarm,
after checking the food located in the freezer
compartment press the alarm off button ( ) to
clear the warning.
7.Key lock
Press key lock button ( )simultaneously for 3
seconds. Key lock symbol ( ) will light up and
key lock mode will be activated. Buttons will not
function if the Key lock mode is active. Press key
lock button simultaneously for 3 seconds again.
Key lock symbol will turn off and the key lock mode
will be exited. Press the Key lock button if you
want to prevent changing of the temperature
setting of the refrigerator ( )
8. Eco fuzzy
Press and hold eco fuzzy button for 1 seconds to
activate eco fuzzy function. Refrigerator will start
operating in the most economic mode at least 6
hours later and the economic usage indicator will
turn on when the function is active ( ).Press and
hold eco fuzzy function button for 3 seconds to
deactivate eco fuzzy function.This indicator is
illuminated after 6 hours when eco fuzzy is
activated.
9. Freezer compartment temperature setting
button
Press this button to set the temperature of the
freezer compartmento-16,-17,-18,-19,-20,-22,
-24,-16.. respectively. Press this button to set the
freezer compartment temperature to the desired
value.( )
10. Icematic function (optional)
Indicates whether the icematic is on or off.( )If
On, then the icematic is not operating. To operate
the icematic again press and hold the On-Off
button for 3 seconds.
10 EN
7.CONTROL PANEL OF THE PRODUCT
Water frow from water tank will stop
when this function is selected.
However,ics made previously can be
taken from the icematic.
Use the quick freeze fucntion when you
want to quickly freeze the food palced in
fridge compartment. If you want to freeze
large amounts of fresh food, activate this
fuction before putting the food into the
product.
If you do not cancel it,Quick freeze will
cancel itself automatically after 24 hours
or when the fridge compartment reaches
to the required temperature.
This function is not recalled when power
restores after a power failure.
Economic usage indicator is turned off
when quick cooling or quick freeze
functions are selected.

Storing food in the freezer compartment
You can activate Quick Freezing function 4-6
hours before freezing function and perform a faster
cooling.
Bring hot meals to the room temperature before
placing them in the freezer compartment.
Foods to be frozen must be divided into portions
according to a size to be consumed, and frozen in
separate packages.
It is recommended to pack the foods before
placing them in the freezer.
In order to prevent expiration of storage time,
write the freezing date, time and name of the
product on the package according to the storage
times of different foods.
Consume the foods you have defrosted quickly.
Defrosted foods cannot be frozen again unless
they are cooked. It is not safe to consume the
refrozen fresh foods without cooking after they are
defrosted.
As you freeze fresh foods, do not bring them in
contact with already frozen foods. Otherwise,
frozen foods will be defrosted.
Storing the foods, which are sold frozen
Always follow the instructions of the producer in
relation to the time during which you are required
to store your foods. Do not excess the time
specified in these instructions!
In order to protect the quality of the food, keep
the time interval between purchasing transaction
and storing as short as possible.
Buy frozen food which are stored at –18 °C or
lower temperatures.
Avoid buying foods whose packages are
covered with ice etc. This means that the product
could be partially defrosted and refrozen.
Temperature impacts the quality of the food.
Do not excess the storing time recommended
by the food producer. Remove only the food as
much as you need from the freezer.
Except the cases where extreme circumstances
are available in the environment, if your product
(on the recommended set values table) is set to the
specified set values, the food keep their freshness
for a longer time both in the fresh product
compartment and freezer compartment.
If fresh food compartment is set to a lower
temperature, fresh fruits and vegetables may be
partially frozen.
EN 11
8.USING THE PRODUCT
Freezer
Compartment
Setting
Recommended set values table
Fridge
Compartment
Setting
-18°C
-20, -22 or -24 °C
Quick Freeze
-18 °C or colder
4°C
4°C
4°C
2°C
Remarks
This is the default, recommended setting. This setting is
recommended if ambient temperature is below 30 °C.
These settings are recommended for ambient temperatures
exceeding 30 °C.
Use when you want to freeze your food in a short time. When
the process ends, the product’s settings will return to
previous position.
Use these settings if you believe the cooler compartment is
not cold enough due to ambient temperature or frequently
opening the door.
Read the “Safety Instructions” section first!

Storing food in the cooler compartment
Compartment temperatures rise prominently if
compartment door is opened and closed frequently
and kept open for a long time, this can reduce the
life span of the food and cause the food to spoil.
In order not to cause odour and taste changes,
the food should be stored in the closed containers.
Do not store too much food in your refrigerator.
To achieve a better and homogeneous cooling,
place the food separately in a way that cold air can
wander through them.
Provide air flow by leaving a space between the
food and internal wall. If you lean the food against
the rear wall, the food may freeze.
Bring cooked hot meals to the room temperature
before placing them in the refrigerator. Then, you
can place the tepid meal in the lower shelves of
your refrigerator. Do not place the tepid meals
close to the foods which may easily spoil.
Defrost your frozen food in the fresh food
compartment. Thereby, you can cool fresh food
compartment by using frozen food and save
energy.
Storing unripe tropical fruits (mango, melon
varieties, papaya, banana, pineapple) in the
refrigerator may speed up the ripening process
This is not recommended because it will cause
shorter storage time.
You should store onions, garlics, gingers and
other root vegetables in dark and cold room
conditions, not in the refrigerator.
If you notice that a food has spoiled in the
refrigerator, throw away that food and clean the
accessories which have come into contact with it.
In order to cool the meals like soups and stews,
which are cooked in the large pots, quickly, you
can put them in the refrigerator by separating them
into their own shallow containers.
Do not place unpackaged food close to eggs.
Keep the fruits and vegetables separately and
store each variety together (for example; apples
with apples, carrots with carrots)
Quick freezing
1. After 24 hours after pressing the button, place
your food that you want to freeze on the first shelf
with higher freezing capacity.
2. The quick freezing function will be
automatically deactivated after 24 hours.
Freezer details
As per the IEC 62552 standards, the freezer must
have the capacity to freeze 4.5 kg of food items at
-18 °C or lower temperatures at 25 °C room
temperature in 24 hours for each 100 litres of
freezer compartment volume.
Food products can only be preserved forextended
periods at or below temperature of -18 °C. You can
keep the foods fresh for months (in freezer at or
below temperatures of -18 °C).
The food products to be frozen must not contact
the already-frozen food inside to avoid partial
defrosting.
Boil the vegetables and filter the water to extend
the frozen storage time. Place the food in air-tight
packages after filtering and place in the freezer.
Bananas, tomatoes, lettuce, celery, boiled eggs,
potatoes and similar food items should not be
frozen. In case these foods are frozen, only
nutritional values and eating qualities will be
negatively affected. A rotting that would threaten
human health is not in question.
Placing the food
Freezer compartment shelves: Different frozen
foods like meat, fish, ice cream, vegetables etc.
Cooler compartment shelves: Food items
inside pots, capped plate and capped cases, eggs
(in closed case)
Cooler compartment door shelves: Small and
packaged food or beverages
Crisper: Vegetables and fruits
Fresh food compartment: Delicatessen
(breakfast food, meat products to be consumed
in short time)
12 EN
8.USING THE PRODUCT

8.1 Replacing the Illumination Lamp
Call the Authorized Service when the Bulb/
LED used for lighting in your refrigerator
will be replaced.
Lamp(s) used in this appliance cannot be
used for house lighting. Intended use of
this lamp is to help the user place food into
the refrigerator / freezer safely and comfortably.
8.2 Door Open Alert
An audible alert will be heard if the
product's door remains open for 1 minute.
The audible alert will stop when you close
the cabinet door or press any button on the
display (if available).
Take green vegetables out of the plastic bag and
place them in the refrigerator after wrapping them
in a paper towel or drying cloth. If you wash this
type of food before placing them in the refrigerator,
remember to dry them.
You can both create a damp environment and
provide an air flow by keeping fruits and
vegetables, which are prone to drying, in the
perforated or unsealed plastic bags.
Except the cases where extreme circumstances
are available in the environment, if your product
(on the recommended set values table) is set to the
specified set values, the food keep their freshness
for a longer time both in the fresh product
compartment and freezer compartment.
Store different food in different places
according to their properties.
EN 13
8.USING THE PRODUCT
Eggs Door rack
If available, biofresh or
chiller compartment
Lowest shelves
Fruit and vegetable box,
crisper or EverFresh+
compartment (if
available)
If available, biofresh or
chiller compartment
Lowest shelf
Upper shelves or door
rack
Door rack
Middle shelves
Dairy products (butter,
cheese)
Fruits, vegetables and
salad
Fresh meat, poultry,
fresh fish, sausages,
cooked foods
Ready to eat foods,
packaged products,
canned foods, pickled
products
Drinks, bottles,
condiments, snacks
Leftovers
Food Location

9.1 The ice storage area
Using the ice bucket
1. Take the ice bucket out of the freezer
compartment.
2. Fill the ice bucket with water.
3. Place the ice bucket into the freezer
compartment. The ice will be ready after
approximately two hours.
4. Take the ice bucket from the freezer
compartment and bend in slightly over the holder
that you are going to serve. Ice will easily pour
into the serving holder.
9.3 Dairy Products Cold Storage
Area
Cold Storage Drawer
The Cold Storage Drawer can reach lower
temperatures in the cooler compartment. Use this
drawer for delicatessen products (salami,
sausage, etc.) and dairy products that require
colder storage conditions, or for meat, chicken or
fish to be consumed quickly. It is not suitable to
store fruits and vegetables in this drawer.
9.2 Crisper Technologies
Blue Light
Fruits and vegetables stored in the crispers that
are illuminated with a blue light continue their
photosynthesis by means of the wavelength effect
of blue light and thus preserve their vitamin
content.
VitaminZone
Fruits and vegetables stored in crispers
illuminated with theVitaminZone technology
preserve their vitamins for a longer time thanks to
the blue, green, red lights and dark cycles, which
simulate a day cycle.
When the door of your refrigerator is opened
during the dark period of theVitaminZone
technology, your refrigerator shall sense this
automatically and illuminate the crisper with one
of the blue, green or red lights respectively for
your convenience. After you have closed the door
of the refrigerator, the dark period will continue,
representing the night time in a day cycle.
14 EN
9.PRODUCT FEATURES

Do not use sharp or abrasive tools to clean the
product. Do not use materials such as household
cleaning agents, soap, detergents, gas, gasoline,
thinner, alcohol, wax, etc.
The dust shall be removed from the ventilation
grill on the rear of the product at least once a
year (without opening the cover). Clean the
product with a dry cloth.
Take care to keep water away from the lamp's
cover and other electrical parts.
Clean the door with a damp cloth. Remove all
contents to remove the door and body racks.
Remove the door racks by lifting them upwards.
Clean and dry the shelves, then attach back in
place by sliding from above.
Do not use chlorinated water or cleaning
products on the exterior surface and
chromecoated parts of the product. Chlorine will
cause rust on such metallic surfaces.
Do not use sharp and abrasive tools, soap,
house cleaning materials, detergents, gas,
gasoline, varnish and similar substances to
prevent deformation of the plastic part and
removal of prints on the part. Use warm water
and a soft cloth for cleaning, and then dry it.
On the products without a No-Frost feature,
water droplets and icing up to a thickness of a
finger may occur on the rear wall of the freezer
compartment. Do not clean, and never apply oils
or similar materials.
Use a mildly dampened micro-fibre cloth to
clean the external surface of the product.
Sponges and other types of cleaning clothes may
cause scratches.
To clean all removable components during the
cleaning of the interior surface of the product,
wash these components with a mild solution
consisting of soap, water and carbonate. Wash
and dry thoroughly.
Prevent contact of water with illumination
components and the control panel.
Stainless Steel External Surfaces
Use a non-abrasive stainless steel cleaning
agent and apply it with a soft lint-free cloth.
To polish, gently wipe the surface with a
microfibre cloth dampened with water and use
dry polishing chamois. Always follow the veins of
the stainless steel.
Preventing Odours
The product is manufactured free of any odorous
materials. However, keeping the food in
inappropriate sections and improper cleaning of
internal surfaces may lead to odours.
To avoid this, clean the inside with carbonated
water every 15 days.
Keep the foods in sealed holders, as
microorganisms arising from foods kept in
unsealed containers will cause bad odour.
Do not keep expired and spoilt foods in the
refrigerator.
Protecting Plastic Surfaces
Oil spilled on plastic surfaces may damage
the surface and must be cleaned immediately
with warm water.
This product is equipped with a lighting source of
the "G" energy class.
The lighting source in this product shall only be
replaced by professional repairers.
EN 15
10.MAINTENANCE AND CLEANING
WARNING:Read the “Safety Instructions”
section first!
WARNING:Unplug the refrigerator before
cleaning it.
CAUTION:Do not use vinegar, rubbing
alcohol or other alcohol based cleaning
agents on any interior surface.
Tea is one of the most effective odour
removers. Place the pulp of the brewed
tea in the product inside an open
container and remove it after 12 hours at
the latest. If you keep the tea pulp inside
the product for longer than 12 hours, it will
collect the organisms that cause the
odour so it can be the source of odour
itself.

Check this list before contacting the service.
Doing so will save you time and money. This list
includes frequent complaints that are not related
to faulty workmanship or materials. Certain
features mentioned herein may not apply to your
product.
The refrigerator is not working.
The power plug is not fully settled. >>> Plug it
in to settle completely into the socket.
The fuse connected to the socket powering
the product or the main fuse is blown. >>> Check
the fuse.
Condensation on the side wall of the cooler
compartment (MULTI ZONE, COOL CONTROL
and FLEXI ZONE).
The door is opened too frequently. >>> Take
care not to open the product's door too
frequently.
The environment is too humid. >>> Do not
install the product in humid environments.
Foods containing liquids are kept in unsealed
holders. >>> Keep the foods containing liquids in
sealed holders.
The product's door is left open. >>> Do not
keep the product's door open for long periods.
The thermostat is set to a very cool
temperature. >>> Set the thermostat to an
appropriate temperature.
Compressor is not working.
In case of sudden power failure or pulling the
power plug off and putting back on, the gas
pressure in the product's cooling system is not
balanced, which triggers the compressor thermic
safeguard. The product will restart after
approximately 6 minutes. If the product does not
restart after this period, contact the service.
Defrosting is active. >>> This is normal for a
fully-automatic defrosting product. The defrosting
is carried out periodically.
The product is not plugged in. >>> Make sure
the power cord is plugged in.
The temperature setting is incorrect. >>>
Select the appropriate temperature setting.
The power is out. >>> The product will
continue to operate normally once the power is
restored.
The refrigerator's operating noise is
increasing while in use.
The product's operating performance may vary
depending on the ambient temperature
variations. This is normal and not a malfunction.
The refrigerator runs too often or for too long.
The new product may be larger than the
previous one. Larger products will run for longer
periods.
The room temperature may be high. >>> The
product will normally run for long periods in
higher room temperature.
The product may have been recently plugged
in or a new food item is placed inside. >>> The
product will take longer to reach the set
temperature when recently plugged in or a new
food item is placed inside. This is normal.
Large quantities of hot food may have been
recently placed into the product. >>> Do not
place hot food into the product.
The doors were opened frequently or kept
open for long periods. >>> The warm air moving
inside will cause the product to run longer. Do not
open the doors too frequently.
The freezer or cooler door may be ajar.
>>> Check that the doors are fully closed.
The product may be set to a temperature that
is too low. >>> Set the temperature to a higher
degree and wait for the product to reach the
adjusted temperature.
The cooler or freezer door washer may be
dirty, worn out, broken or not properly settled.
>>> Clean or replace the gasket. Damaged / torn
door washer will cause the product to run for
longer periods to preserve the current
temperature.
The freezer temperature is very low, but the
cooler temperature is adequate.
The freezer compartment temperature is set to
a very low degree. >>> Set the freezer
compartment temperature to ahigher degree and
check again.
11.TROUBLESHOOTING
16 EN

The cooler temperature is very low, but the
freezer temperature is adequate.
The cooler compartment temperature is set to
a very low degree. >>> Set the cooler
compartment temperature to a higher degree and
check again.
The food items kept in cooler compartment
drawers are frozen.
The cooler compartment temperature is set to
a very low degree. >>> Set the cooler
compartment temperature to a higher degree and
check again.
The temperature in the cooler or the freezer is
too high.
The cooler compartment temperature is set to
a very high degree. >>> Temperature setting of
the cooler compartment has an effect on the
temperature in the freezer compartment. Wait
until the temperature of relevant parts reach the
sufficient level by changing the temperature
of cooler or freezer compartments.
The doors were opened frequently or kept
open for long periods. >>> Do not open the doors
too frequently.
The door may be ajar. >>>Fully close the door.
The product may have been recently plugged
in or a new food item is placed inside. >>> This is
normal. The product will take longer to reach the
set temperature when recently plugged in or a
new food item is placed inside.
Large quantities of hot food may have been
recently placed into the product. >>> Do not
place hot food into the product.
Shaking or noise.
The surface is not flat or durable >>> If the
product is shaking when moved slowly, adjust the
stands to balance the product. Also make sure
the ground is sufficiently durable to bear the
product.
Any items placed on the product may cause
noise. >>> Remove any items placed on the
product.
The product is making noise of liquid flowing,
spraying etc.
The product's operating principles involve
liquid and gas flows. >>> This is normal and not a
malfunction.
There is sound of wind blowing coming from
the product.
The product uses a fan for the cooling process.
This is normal and not a malfunction. There is
condensation on the product's internal walls.
Hot or humid weather will increase icing and
condensation. This is normal and not a
malfunction.
The doors were opened frequently or kept
open for long periods. >>> Do not open the doors
too frequently; if open, close the door.
The door may be ajar. >>> Fully close the
door.
There is condensation on the product's
exterior or between the doors.
The ambient weather may be humid, this
is quite normal in humid weather. >>> The
condensation will dissipate when the humidity is
reduced.
The interior smells bad.
The product is not cleaned regularly. >>>
Clean the interior regularly using sponge, warm
water and carbonated water.
Certain holders and packaging materials may
cause odour. >>> Use holders and packaging
materials without free of odour.
The foods were placed in unsealed holders.
>>> Keep the foods in sealed holders.
Microorganisms may spread out of unsealed food
items and cause bad odour.
Remove any expired or spoilt foods from
the product.
The door is not closing.
Food packages may be blocking the door. >>>
Relocate any items blocking the doors.
The product is not standing in full upright
position on the ground. >>> Adjust the stands to
balance the product.
The surface is not flat or durable >>> Make
sure the surface is flat and sufficiently durable to
bear the product.
11.TROUBLESHOOTING
EN 17

The crisper is jammed.
The food items may be in contact with the
upper section of the drawer. >>> Reorganize
the food items in the drawer.
Temperature on the product surface.
High temperature may be observed between
two doors, on the side panels and on the rear grill
area while your product is operated. This is
normal and it does not require servicing.
Fan continues to operate when the door is
opened.
Fan may continue to operate when the freezer
door is open.
11.TROUBLESHOOTING
18 EN
WARNING:If the problem persists after
following the instructions in this section,
contact your vendor or an Authorized
Service. Do not try to repair the product.
This is normal.
