U-Line Echelon 2175RC Configuration guide

2175RC features flexible
storage with in-door
bins and crisper drawer.
FEATURES
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
2175RC
REFRIGERATORS
2175RC 2000 Se rie S
Overlay
Black
White
Stainless
INTEGRATION INTERIOR / EXTERIOR PERFORMANCE
Single Zone
Convection Cooling
System featured in
2175RC .
• 5.2 cubic feet overall capacity maximizes storage
• Touch glass digital control featuring easy view command center manages key
functions and provides user alerts such as an audible door open alarm
• Digital controlled single-zone convection cooling system provides a stable and
consistent environment for optimum food and beverage storage
• Temperature setting from 34 to 45˚ F
• Sabbath / Blackout mode turns off all lighting, controls display and automatically
resets after 36 hours
• Automatic defrost
• ENERGY STAR®/ CEE Tier 3 rated
• UL residential and commercial listings
• Lighted white interior optimizes easy viewing of contents
• Three 4mm tempered glass shelves with bullnose edge to maximize storage
potential
• Convenient crisper drawer for proper storage and humidity control of perishable
items
• Standard commercial stainless steel handle is interchangeable with professional
handle option on stainless model
• Two adjustable in-door storage bins allow for flexible storage
• Full wrap stainless door on stainless model and unit must be ordered right or left
hand hinged
• Black and white model doors are field reversible
• Vinyl clad textured cabinet is more resistant to scratching, peeling and flaking
• Unit can be built-in or freestanding providing a custom aesthetic
• Optional full 3/4" overlay panel on black and white models requires purchase of
overlay kit PN: U-OL2115 and can be fully integrated into all styles of cabinetry
• Black and white models will accept a 1/4" insert panel to match with surrounding
decor
• Allow a 2-1/2" clearance on hinged side for 90˚ door opening when installed
adjacent to a wall (for stainless steel model)
• Allow 1/4" width overall for proper installation (see backside for details)
• No additional clearance around sides, top or rear of unit is needed for ventilation
• Durable, factory installed level legs provide a more precise undercounter fit
• Do not obstruct front grille air flow

DIMENSIONS AND SPECIFICATIONS
Please visit www.u-line.com for installation guide.
All specifications are subject to change without notice.
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
2175RC
REFRIGERATORS
Height 34-1/8" (86.6)
Width 23-15/16" (60.8)
Depth 23-1/4" (59.0)
With stainless steel handle 25-1/8" (63.8)
Shipping weight:
Black and white models 122 lbs (55 kg)
Stainless model 116 lbs (53 kg)
Running amps 2.4
Maximum start-up amps 9.8
Amps pertain to voltage rating 110/115 volt, 60 Hz
ENERGY STAR®and CEE Tier 3
Capacities:
Defrost technology Automatic
Refrigerator volume 5.2 Cu. Ft
4"
7"
24"
24-3/16"
34-1/4"
to
35-1/8"
23-1/16"
34-1/8"
23-15/16"
23-15/16"
23-15/16"
2175R(C)(F) Black and White Models
2175R(C)(F)S(G) Stainless & Out Door Models
2175R(C)(F)S Overlay Models
34-1/8"
34-1/8"
3-13/16"
23-1/16"
23-1/4"
3-13/16"
3-13/16"
23-1/16"
34-1/8"
23-15/16"
23-15/16"
23-15/16"
2175R(C)(F) Black and White Models
2175R(C)(F)S(G) Stainless & Out Door Models
2175R(C)(F)S Overlay Models
34-1/8"
34-1/8"
3-13/16"
23-1/16"
23-1/4"
3-13/16"
3-13/16"
2175RC
Stainless Right-hand U-2175RCS-00
Stainless Left-hand U-2175RCS-01
Black U-2175RCB-00
White U-2175RCW-00
Overlay
U-2175RCB-00
with Overlay kit
U-OL2175B
2175RCB Black Model and
2115RCW White Model
2175RC Stainless Model
OVERALL DIMENSIONS
