ArtFox Matrix 360 User manual

Matrix 360
Please read this manual before using the detailed

1． Graphic section：
A．Function keys
B．Plus keys
C．Minus key
D．enter keys
E ．LED Display
window
A B C D
Instructions: Press the function key A will cycle out of eight different functional effects, digital tube in
which the first two digits represent the current function (see Menu). After two figures represent the kinds
of functions are located. Address code. Or speed parameters. Press B or C keys to modify its parameters.
Press D to confirm.
2. LED Display window function table, (all functions according to
the selected then press the D key to confirm)
No. display Function Instruction
1 DMX-16 MODE
channel D: 001 14 Channel address code，（001—512）
B、C Key subtraction address code value
2 DMX37 MODE
channel D: 001 35 Channel address code，（001—512）
B、C Key subtraction address code value
3 DMX112 MODE
channel D: 001 110 Channel address code，（001—512）
B、C Key subtraction address code value
4 Color Cycle
Speed 50 Colorful jump， （01—99）
B、C Keys to change the speed of transition
5 Gradual change
Speed 50 Colorful jump，（01—99）
B、C Key to modify the gradient speed
6 Pulse change
Speed 50 Colorful clock change， （01—99）
B、C Keys to change the speed of the pulse changed
7 Color Run
M 00 Sp 50 Running change， （01—99）
B、C Key to modify the pattern running, running
speed
8 Color Voice
Mood 00
No effect
9 Color Red
Speed 200
Red color selection, (000-255)
B, C key to modify the color values
10 Color Green
Speed 200
Green color selection, (000-255)
B, C key to modify the color values

11 Color Blue
Speed 200
Blue color selection, (000-255)
B, C key to modify the color values
12 Color White
Speed 200
White color selection, (000-255)
B, C key to modify the color values
13 Slave
25Eye Slave
Slave
14 Restore Factory
Yes ?
Restore factory settings
3．DMX512 16 Channel Description
No. fuction Instruction
Channel 1 0-255 X Motor
2nd
channel 0-255 Y motor
3 channel 0-255 X tuning (16Bit)
Channel 4 0-255 Y trimming (16Bit)
Channel 5 0-255
0--4: None;
5--130: X Story (from slow to fast);
131--255: X reversal (from fast to slow);
Channel 6 0-255
0--4: None;
5--130: Y Story (from slow to fast);
131--255: Y reversed (from fast to slow);
Channel 7 0-255 XY motor speed from fast to slow
Channel 8 Total dimming
R、G、B、W Total dimming, linear dimming, from dark to light
Channel 9 Total Strobe R、G、B、W Total strobe, from slow to fast
Channel 10
Feature
Selection 1
0--24: DMX 14 channel control;
25--30: color selection (by 512 motor control);
31--36: jump (by 512 motor control);
37--42: gradient pulse changed (by 512 motor control);
43--46: running pattern 1 (512 by motor control);
47--50: running pattern 2 (by 512 motor control);
. . . . . . . .
129--132: running pattern 23 (motor control by 512);
133--138: Voice (512 by motor control);
139--144: color selection (motor built-in program to go);
145--150: hopping (motor built-in program to go);
151--156: gradient pulse change (motor built-in program to go);
157--160: running pattern 1 (motor built-in program to go);
161--164: running pattern 2 (Built-in Motor walking program);
. . . . . . . .
244--248: running pattern 23 (motor built-in program to go);
249--255: Voice (No effect);
Channel 11
Feature
Selection 2
0--5: DMX 14 channel control;
6--130: 126 fixed pattern selection (by 512 motor control);
131--255: 125 fixed pattern selection (motor built-in program to go);
Channel 12
Feature speed1
Function speeds from slow to fast
Feature speed2
0--31: a fixed pattern direction;
32--63: Fixed pattern direction 2;
64--95: Fixed pattern direction 3;
96--126: Fixed pattern direction 4;
127--195: clockwise pattern from slow to fast;
196--255: counter-clockwise pattern from slow to fast;
Channel 13
R Dimming R dimming, linear dimming, from dark to light

Channel 14
G Dimming G Dimming, linear dimming, from dark to light
Channel 15
B Dimming B Dimming, linear dimming, from dark to light
Channel 16
W Dimming W Dimming, linear dimming, from dark to light
4．DMX512 37 Channel Description
NO. Function Instruction
Channel 1 0-255 X Motor
Channel 2 0-255 Y Motor
Channel 3 0-255 X tuning（16Bit）
Channel 4 0-255 Y trimming（16Bit）
Channel 5 0-255
0--4: None;
5--130: X Story (from slow to fast);
131--255: X reversal (from fast to slow);
Channel 6 0-255
0--4: None;
5--130: Y Story (from slow to fast);
131--255: Y reversed (from fast to slow);
Channel 7 0-255 XY motor speed from fast to slow
Channel 8 Total dimming
R、G、B、W Total dimming, linear dimming, from dark to light
Channel 9 Total Strobe R、G、B、W Total strobe, from slow to fast
Channel 10
Feature
Selection 1
0--24: DMX 35 channel control;
25--30: color selection (by 512 motor control);
31--36: jump (by 512 motor control);
37--42: gradient pulse changed (by 512 motor control);
43--46: running pattern 1 (512 by motor control);
47--50: running pattern 2 (by 512 motor control);
. . . . . . . .
129--132: running pattern 23 (motor control by 512);
133--138: Voice (512 by motor control);
139--144: color selection (motor built-in program to go);
145--150: hopping (motor built-in program to go);
151--156: gradient pulse change (motor built-in program to go);
157--160: running pattern 1 (motor built-in program to go);
161--164: running pattern 2 (Built-in Motor walking program);
. . . . . . . .
244--248: running pattern 23 (motor built-in program to go);
249--255: Voice (No effect);
Channel 11
Feature
Selection 2
0--5: DMX 35 channel control;
6--130: 126 fixed pattern selection (by 512 motor control);
131--255: 125 fixed pattern selection (motor built-in program to go);
Channel 12
Feature Speed
1
Function speeds from slow to fast
Function
Speed 2
0--31: a fixed pattern direction;
32--63: Fixed pattern direction 2;
64--95: Fixed pattern direction 3;
96--126: Fixed pattern direction 4;
127--195: clockwise pattern from slow to fast;
196--255: counter-clockwise pattern from slow to fast;
Channel 13
1 Dimming R、G、B、W Dimming
Channel 14
2 Dimming R、G、B、W Dimming
Channel 15
3 Dimming R、G、B、W Dimming
Channel 16
4 Dimming R、G、B、W Dimming
...... ....... ..........
Channel 37
25 Dimming R、G、B、W Dimming

4．DMX512 112 Channel Description
No. fuction Instruction
Channel 1 0-255 X Motor
Channel 2 0-255 Y Motor
Channel 3 0-255 X Fine tuning（16Bit）
Channel 4 0-255 Y Fine tuning（16Bit）
Channel 5 0-255
0--4: None;
5--130: X Story (from slow to fast);
131--255: X reversal (from fast to slow);
Channel 6 0-255
0--4: None;
5--130: Y Story (from slow to fast);
131--255: Y reversed (from fast to slow);
Channel 7 0-255 XY Motor speed from fast to slow
Channel 8 Total dimming
R、G、B、W Total dimming, linear dimming, from dark to light
Channel 9 Total Strobe R、G、B、W Total strobe, from slow to fast
Channel 10
Feature
Selection 1
0--24: DMX 110 control channels;
25--30: color selection (by 512 motor control);
31--36: jump (by 512 motor control);
37--42: gradient pulse changed (by 512 motor control);
43--46: running pattern 1 (512 by motor control);
47--50: running pattern 2 (by 512 motor control);
. . . . . . . .
129--132: running pattern 23 (motor control by 512);
133--138: Voice (512 by motor control);
139--144: color selection (motor built-in program to go);
145--150: hopping (motor built-in program to go);
151--156: gradient pulse change (motor built-in program to go);
157--160: running pattern 1 (motor built-in program to go);
161--164: running pattern 2 (Built-in Motor walking program);
. . . . . . . .
244--248: running pattern 23 (motor built-in program to go);
249--255: Voice (No effect);
Channel 11
Feature
Selection 2
0--5: DMX 110 control channels;
6--130: 126 fixed pattern selection (by 512 motor control);
131--255: 125 fixed pattern selection (motor built-in program to go);
Channel 12
Function
Speed 1
Function speeds from slow to fast
Function
Speed 2
0--31: a fixed pattern direction;
32--63: Fixed pattern direction 2;
64--95: Fixed pattern direction 3;
96--126: Fixed pattern direction 4;
127--195: clockwise pattern from slow to fast;
196--255: counter-clockwise pattern from slow to fast;
Channel 13
R1 Dimming R1 Dimming, linear dimming, from dark to light
Channel 14
G1 Dimming G1 Dimming, linear dimming, from dark to light
Channel 15
B1 Dimming B1 Dimming, linear dimming, from dark to light
Channel 16
W1 Dimming W1 Dimming, linear dimming, from dark to light
Channel 17
R2 Dimming R2 Dimming, linear dimming, from dark to light
Channel 18
G2 Dimming G2 Dimming, linear dimming, from dark to light
Channel 19
B2 Dimming B2 Dimming, linear dimming, from dark to light

Channel 20
W2 Dimming W2 Dimming, linear dimming, from dark to light
。。。。。。。。
。。。。。。。。 。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。。
Channel
112
W25 Dimming
W25 Dimming, linear dimming, from dark to light
5. Features:
Operation is very simple, user-friendly design, flicker-free dimming, jitter
phenomena. Can be adapted to photography, photography, television and
other demanding applications for lighting.
