ARTRAY ARTCAM-130SWIR-CL User manual

- 1 -
April 9, 2019
Ver1.00
Camera Link output
Near infrared (InGaAs) camera
ARTCAM-130SWIR-CL
INSTRUCTION BOOKLET
ARTRAY CO., LTD.

- 2 -
Contents
1. Attention.......................................................................................................................................................................... - 3 -
2. Introduction..................................................................................................................................................................... - 6 -
3. Main Features ................................................................................................................................................................ - 6 -
4. The Product.................................................................................................................................................................... - 6 -
5. Setup............................................................................................................................................................................... - 7 -
5.1. Camera connection method (connection example)........................................................................................... - 7 -
5.1.1. When using on a desktop PC...................................................................................................................... - 7 -
5.1.2. When using on a notebook PC ................................................................................................................... - 7 -
6. Specifications ................................................................................................................................................................. - 8 -
6.1. Camera Specification............................................................................................................................................ - 8 -
6.1.1. Camera specification list .............................................................................................................................. - 8 -
6.1.2. External Dimensions .................................................................................................................................... - 9 -
6.1.3. Sensor Surface Perimeter Dimension........................................................................................................ - 9 -
6.2. Sensor specification (based on sensor manufacturer's data) ......................................................................... - 10 -
6.2.1. List of sensor specifications ....................................................................................................................... - 10 -
6.2.2. Spectral sensitivity characteristics............................................................................................................. - 10 -
6.3. Camera function.................................................................................................................................................. - 11 -
6.3.1. Camera function list.................................................................................................................................... - 11 -
6.3.2. Camera function block diagram ................................................................................................................ - 11 -
6.4. Required PC spec............................................................................................................................................... - 12 -

- 3 -
1. Attention
■ About this manual
1．Before using the camera, please read this manual thoroughly.
2．Please keep this manual reachable and always refer to the contents when needed.
3．Please contact us if the manual is lost or damaged. We will provide a replacement.
4．We cannot guarantee the safety of improper uses of the camera.
5．For your safety, please follow the directions of this manual.
6．All contents are subject to change.
7．Images in this manual may have been simplified to be easier comprehended.
8．Please contact us if you find any unclear points or mistakes in this manual.
9. Quoting, copying or altering some or all parts of the manual without our permission is prohibited.
10．We are not responsible for any lost or damages on your profits due to the use of our products.
11．Please understand that our oversea branches do not provide maintenance or repair services.
■ About the Icons
To keep the safety of the user, other people and their properties, please pay attention to the following icons.
Warning
If the user fails to follow the instruction, serious injury or death may occur.
Caution
If the user fails to follow the instruction, physical injury on human or damages on hardware may occur.

- 4 -
■For Safe Use
Warning
●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires
and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not
disassemble, modify or repair the camera on your own.
Please stop using the product and turn off the power immediately when:
・The product becomes smoky or gets extremely hot on the surface, or makes unusual smells or sounds.
・Foreign material or water gets into the product.
・The product falls and becomes damaged.
●Do not place the product on unstable surfaces. The product may be fallen and people may get hurt.
Caution
●Do not expose the product to steam or fumes to avoid electric shocks and fires.
●Do not leave the product in high temperature places such as inside of vehicles or under direct sunlight.
High temperature may cause damages to the camera, or even cause fires.
●Do not cover the product with cloth or other materials. The product may get extremely hot and the heat may cause
deformations on the parts or even cause fires.
●Please avoid dropping or shocking the product as the product may be damaged.
●Do not touch the cable with a wet hand. Such action may cause electric shocks.
●Please avoid continuously contacting the surface of the camera to your skin when the camera is being used. The
surface temperature of the camera may cause burns.
■Other Notices
●Please do not use the camera under strong lights such as sun light for a long period. Also please do not expose the
camera under strong lights even when the product is not being used because the sensor might be damaged.
Maintenance
● Wipe the dirt on surface with soft cloth or tissue paper. Do not use alcohol, thinner or benzene to avoid damaging the
surface paints.
Electro Magnetic Interference
●The camera may interference with electronic devices such as TV and radio. Please do not place the camera next to
such equipment.

- 5 -
■Export Control
This product is a List Control item subject to the Foreign Exchange and Foreign Trade Act and its relevant legislations
No.1 10 (2) and (4). To export this product from Japan, obtaining export licenses from the Ministry of Economy, Trade
and Industry is required. It is also necessary for our company to manage the information of users and the purposes of
use. If the end users or purposes of use change after the purchase and thus cause the need to apply export licenses
from Ministry of Economy, Trade and Industry, please contact the sales representative in advance.
■Guarantee
To save the environment, we do not issue warranty in printed format. Instead, all records of the warranty periods, delivery
dates and the customer information are well kept in our system.
For more details, please refer to the sites below:
Hardware Warranty: http: //www.artray.us/download/artray_warranty.pdf
■Dispose
To dispose this product, please return the camera to us. If you decide to dispose the camera without returning it us,
please follow related regulations and have the camera disposed as an industrial waste. Please always keep records of
the dispose, and make sure the disposed camera cannot be accessed or used by any 3rd party.
■Limited Responsibility
We do not guarantee the functions of this product or the descriptions on this manual to be completely adapted to the
users’ end applications or marketing purposes. We are also not held responsible for any direct or indirect damages
caused by our products under any circumstances.
Please do not use this product on applications that require high reliability. This product is not manufactured to be used
as medical, nuclear, aerospace, transportation equipment or equipment that is highly related to human safety. We are
not held responsible for any damages on the users’ property, equipment or personal safety caused by this product.

- 6 -
2. Introduction
This manual is to identify the specification of ARTCAM-130SWIR-CL, NIR camera adopts InGaAs (Indium gallium
arsenide) sensor with Camera Link interface.
3. Main Features
NIR Detection with High Sensitivity
The InGaAs sensor can detect radiation invisible to human eyes and CCD/CMOS cameras in the wavelength range
between 400 nm to 1700 nm bond.
Otherwise, in spite of InGaAs sensor, it has 35% of quantum efficiency between 600 nm to 900 nm, so it can be applied
to detection a wide range of wavelength.
High Resolution, High Frame Rate
1280 x 1024 pixel and delivers image at 30 frame/second.
CameraLink interface
We adopt high reliability Cameralink interface as industial application.
4. The Product
1) Camera
2) AC adapter (AC100-240V -> DC12V)
3) Software CD
<Options>
1) Grabber board (PIXCI-EB1, manufactured by EPIX, Inc., is recommended.)
2) CameraLink Cable (1m, 3m, 5m, 10m)
3) CameraLink SDK (XCLIB manufactured by EPIX, etc.)

- 7 -
5. Setup
5.1. Camera connection method (connection example)
5.1.1. When using on a desktop PC
5.1.2. When using on a notebook PC
*There is an unique port of CameraLink channel used since this camera operates with
CameraLink - Base Configuration.
For the connector of this camera is SDR-26pin, please use the supported cable.

- 8 -
6. Specifications
6.1. Camera Specification
6.1.1. Camera specification list
Item
Sensor Type 1.3 M pixels InGaAs Image Sensor
Interface Camera Link (Base Configuration)
Number of output bits 8 bits / 12 bits / 14 bits (valid 13 bits)
Frame Rate 30 fps (8 bits / 12 bits / 14 bits common)
Shutter Speed 1/1000000～1.04857sec
Synchronization System Internal Synchronization
Lens Mount C Mount
Power DC12V External input
Power Consumption Approx.3W (During normal operation)
External Dimensions
61.5(W)×71.6(H)×59.0(D)mm
*Lens, tripod and cables not included
Weight Approx. 360g
*Lens, tripod and cables not included

- 9 -
6.1.2. External Dimensions
6.1.3. Sensor Surface Perimeter Dimension

- 10 -
6.2. Sensor specification (based on sensor manufacturer's data)
6.2.1. List of sensor specifications
Item
Image pickup device SCD InGaAs sensor Cardinal1280
Number of effective pixels 1280(W) x 1024(H)
Number of output pixels 1280(W) x 1024(H)
Pixel Size 10[μm] x 10[μm]
Imaging area 12.8[mm] x 10.24[mm]
(Diagonal 17.173 mm, equivalent to approximately 1 inch)
Detection frequency band
400 to 1700 nm (whole)
800 to 1600 nm (quantum efficiency 35% or more)
Peak wavelength: 1550 nm (quantum efficiency 80% or more)
Saturation capacity /
readout noise
High Gain: 10Ke / 35e
Mid Gain: 500Ke / 170e
Low Gain: 1Me / 350e
A/D Resolution 13bit
6.2.2. Spectral sensitivity characteristics
