AS MOTOR AS 530/2T MK-KAT User manual

Operating Instructions
Lawnmower
A
S 530/2T MK-Kat
From serial number:
Issued:
020610020001
16 July 2010,V11.0
EN-Translation of the Original Operating Instructions

2
Preface
Please fill in all data referring to your device.
When ordering spare parts, provide your
dealer with the device and engine number.
Serial number:
Engine number:
Date of purchase:
Address of dealer:
Dear customer:
Congratulations on your purchase. You have
acquired a reliable quality product by “AS-
Motor Germany”.
This product has been manufactured
according to modern manufacturing methods
and comprehensive quality assurance
measures. Only when you are satisfied with
your device, we have attained our goal.
Read these operating instructions carefully
and attentively so that your device operates
smoothly and you and others are safe from
any hazards. If you have questions
concerning your device, please contact your
dealer or call our customer service
(telephone [phone]). For
international AS partners, please see:
www.as-motor.de/worldwide.
“AS-Motor Germany” wishes you much joy
with your new device.
Intended use
The device is exclusively intended for
mowing well maintained grassed lawn areas.
Only use attachments and cutting tools
authorised by “AS-Motor Germany”.
Any use exceeding this purpose is
inadmissible. The manufacturer is not
responsible for any damage resulting from
this. Observe the required maintenance and
repair measures.
The user of the device is responsible for
accidents or damage to other persons or their
property!
The device must not be used:
−To cut hard objects, rocks, rubble, or
pieces of wood.
−To trim bushes, hedges, and shrubbery.
−To cut plants in flower pots or planters or
on rooftops.
−To clean (vacuum) footpaths.
−As shredder for shredding tree and
hedge cuttings.
−As drive unit for work tools and any type
of tool sets that are not authorised by
“AS-Motor Germany”.

3
Contents
Preface .........................................................2
Intended use ................................................2
Explanation of the symbols........................4
Symbols in the instructions........................4
Symbols on the device ..............................4
Safety instructions ......................................6
Get informed!.............................................6
User restrictions and hours of operation ...6
Safe handling of fuel..................................6
Check the device prior to use....................7
Use caution during operation ....................7
Prior to mowing..........................................7
Use caution when mowing ........................7
When work is completed ...........................8
Use caution during maintenance and
repair .........................................................9
Device description ....................................10
Control elements .......................................11
Assembly ...................................................12
Scope of delivery.....................................12
Unpacking................................................12
Mounting guide bar and handlebar..........12
Inserting the starter rope .........................13
Assembling the grass collection bag .......13
Mounting the grass collection bag...........13
Transport....................................................14
Information on mowing.............................14
Prior to starting .........................................14
Fuel..........................................................14
Tanking up...............................................15
Adjusting cutting height ...........................15
Starting.......................................................15
Starting the device...................................16
Engaging the blade .................................16
Driving ........................................................16
Driving .....................................................16
Turning ....................................................16
Emptying the grass collection bag..........17
Switching off and parking ........................17
Maintenance and cleaning .......................18
Preparations ............................................20
Cleaning the device.................................20
General inspection ..................................21
Maintaining the engine ............................21
Checking the spark plug..........................21
Cleaning the air filter ...............................21
Re-adjusting the drive .............................21
Checking the blade..................................22
Storage.......................................................23
Storing the device....................................23
Longer storage ........................................23
Restarting ................................................23
Spare parts ................................................23
Wear parts.................................................. 23
Accessories ...............................................23
Disposal .....................................................24
Warranty.....................................................24
Troubleshooting........................................25
Mixing ratios fuel.......................................28
Technical data ...........................................29
Declaration of conformity.........................30

4
Explanation of the symbols
Symbols in the instructions
In these operating instructions, the following
symbols are used to denote special dangers.
Warning.
These symbols denote special
dangers.
Prohibition sign.
These symbols denote
inadmissible procedures.
Directive sign.
These symbols denote required
protective measures.
Symbols on the device
The following symbols are placed on the
device to inform you must be careful and
attentive when using the device:
Working with the device
requires extreme cautiousness.
Read the operating instructions
before you use the device.
Min. 15 m.
Risk of injury!
Make sure that no one is within
the danger zone of the device.
Objects may be ejected. The
danger zone extends for at
least 15 metres.
The quickly rotating blade can
cause life threatening injuries or
immense property damage! Be
especially careful to keep your
hands and feet away from the
blade when the device is put
into operation.
Prior to any repair and
maintenance work, pull off the
spark plug connector.
Clean the ventilation grid!
The cooling air of the
motor is sucked in through
the ventilation grid of the
engine cover. Always keep
the entire surface open
and free!
Noise is causing health
problems. Use personal ear
protection to avoid hearing
damage.
Hot surface. Do not touch the
engine or the silencer. They
become very hot during
operation and you can get
burned.

5
Type plate
The type plate on the device provides you
with information on the device type and the
technical data.
AS 570 SM
Rasenm äher
7,5 kW (5,6 PS) / 3600 (1/min)
170 kg
2009
SNR: 022109070003
AS-MOTOR GERMANY GmbH & Co KG
Ellwanger Stra ße 15
D-74424 B ü hlertann
1003s
1
2
3
4
5
6
7
8 9
1
2
3
4
5
6
7
8
9
Name and address of the
manufacturer
Device designation
Type designation
Rated power output in kW / engine
speed
Weight
Year of manufacture
Serial number
CE marking
Sound level LWA

6
Safety instructions
Get informed!
For your safety, read these operating
instructions with care. Familiarize yourself
with the control elements and the proper use
of the device. Share these operating
instructions with other users of the device.
Before you use the device for the first time,
let the dealer instruct you regarding safe use.
User restrictions and hours of
operation
Never give your children or other persons
who are not familiar with the operation
instructions permission to use the device.
Persons under 18 years old may operate the
device only under supervision. Local
regulations will determine the minimum age
of the user and the hours of operation.
Unsuitable for the operation of the device are
persons
−Who are under the influence of alcohol,
drugs, or medicine that slows down
reaction time.
−With physical and mental impairments.
People fitted with pace makers are
not allowed to touch any current
carrying parts of the ignition
system.
Safe handling of fuel
Danger!
Fuel is toxic and highly
inflammable.
Danger of fire and explosion!
Keep the fuel away from ignition
sources and do not smoke while
handling the device.
Do not inhale fuel vapours; they
are dangerous to your health.
Use gloves and avoid skin contact
with the fuel.
Fuel up outdoors only when the engine is
cool and not running. Use a filler or funnel.
Do not spill any fuel and do not let the fuel
get into the canalisation or ground water.
If you spilled fuel, do not start the device until
the fuel vapours have evaporated (wipe dry).
Move the device away from the area where
the fuel was spilled.
Always close the tank cap securely and do
not open it while the engine is running or the
device is still hot.
Drain the fuel tank only when outdoors. Use a
suitable container or run the tank empty.
Keep the fuel away from children and store it
in a suitable container in a dark, cool, and dry
location.
Never park the device with fuel in the tank
inside a building where fuel vapours could
come in contact with open fire or sparks.
Immediately replace a damaged fuel tank or
tank cap (authorised dealership).
First aid
When swallowing fuel or inhaling fuel
vapours, do not force vomiting and
immediately consult a doctor.
In case of skin contact, immediately wash
with water and soap. Change your soiled
clothing as soon as you can.
Measures in case of a fire
In case of a fire, use foam, dry powder
extinguisher, or carbon dioxide (CO2). Never
douse with water!

7
Check the device prior to use
Prior to use, check by visual inspection blade,
drive and fastening parts for proper condition
and firm seating.
Never use the device if covers, impact
protection flap or grass collection bag is not
installed.
Do not remove, change or override any
safety devices or control elements.
Observe the maintenance instructions and
replace damaged or worn parts immediately.
Have an authorised service centre check
your device if the blade does not stop within
3 seconds after switching off.
Use caution during operation
Do not start the engine:
−if fuel was spilled.
−in closed or poorly ventilated rooms
(danger of poisoning!).
−if there are other persons nearby.
Only start the device when your feet are at a
safe distance to the blade.
During startup of the engine, do not tilt the
device.
Do not touch the engine or the silencer. They
become very hot during operation and you
can get burned. Resulting unintentional
movements constitute an additional injury
hazard.
Switch off the blade and wait until the blade
comes to a standstill
−before you open the impact protection
flap or remove the grass collection bag.
−before you move over surfaces other
than grass.
Switch off the engine and wait until the blade
comes to a standstill
−before you tilt or transport the device.
−if you step away from the device, even for
just a short time.
−before you adjust the cutting height.
−before you refuel.
Switch off the engine, wait until the blade
comes to a standstill, and pull off the spark
plug connector
−before you clean or check the device or
before you carry out work on the device.
−before you unblock or unclog the
discharge area.
Prior to mowing
Personal protective measures
While mowing, always wear sturdy
footwear with good grip, long
trousers, and gloves. Do not mow
in open sandals or bare feet.
Noise is causing health problems.
Use personal ear protection to
avoid hearing damage. Wear
safety glasses and headgear.
Preparing the mowing area
Prior to mowing, carefully check the
perimeter of the lawn. Remove rocks, pieces
of wood, bones, wires, and other objects that
could be picked up and thrown out by the
device.
Use caution when mowing
Risk of injury
Always stay within hearing range to other
persons who can assist you in case of an
emergency.
Danger!
Risk of injury caused by thrown out
objects.
Never mow while persons,
children, pets, or property are in
the vicinity.

8
The danger zone extends
for at least 15 metres.
The area in front of and to the right of the
device is especially dangerous.
Keep your hands and feet away from rotating
parts. Keep your distance to the discharge
area when you work with the device.
Never open the impact protection flap and
never empty the grass collection bag as long
as the blade is running. The rotating blade
can cause injuries and objects can be
ejected.
Mow only in daylight or good artificial light.
Avoid mowing wet grass -
slipping hazard.
Be extremely cautious when turning the
device round or pulling it toward you and
when moving in reverse.
Always walk slowly!
Never lift or carry the device when the engine
is running.
When using the device over a longer period
of time, vibrations can cause disturbances in
the blood supply of the hands. A generally
accepted usage time cannot be determined.
Use gloves.
Take breaks on time.
Have an authorised service centre check the
device immediately
−if the blade hit an object.
−if the device starts to vibrate unusually
severely.
Caution when mowing slopes
When mowing slopes,
there is a risk of slipping
and tilting!
−Only mow steep slopes when safe
operation assured.
−Do not mow excessively steep slopes.
−When mowing steep slopes, meet the
appropriate safety measures, e.g. use
step irons.
−Always mow in horizontal directions,
never up- or downwards.
−Sure footing is essential for your safety,
always wear skid proof safety shoes.
−Be extremely careful when changing the
direction.
−Only mow when the surface is dry and
non-slip.
The device can roll away when you mow
downhill. Put the device down on even
surfaces only and prevent inadvertent rolling.
Mowing surfaces with fire hazard
−Carry a sufficient amount of suitable
extinguishing agent.
−If side inclination is too great, fuel may
leak from the carburetor or the tank. This
poses a fire hazard!
−Observe the mowed surface also after
moving is completed to ensure that no
fire will start.
To avoid risk of fire, keep the following
components free of dirt, grass, hay, leaking
oil, grease, etc.:
−Engine
−Silencer (manifold, guard, clearances)
−Area around the fuel tank
When work is completed
After mowing, always close the fuel valve and
the tank ventilation.
Prior to leaving the device, wait until the
blade comes to a standstill and pull off the
spark plug connector.
After switching it off, let the device cool down
for at least 20 minutes before you store it in a
dry, closed, sufficiently ventilated room.

9
Never store the device when there is fuel in
the tank inside a building where fuel vapours
might come into contact with open fire or
sparks.
Use caution during maintenance
and repair
Only carry out maintenance work as
described in these operating instructions.
Have an authorised service centre carry out
all other work.
Prior to starting any maintenance work, wait
until the engine comes to a standstill and pull
off the spark plug connector.
We explicitly point out that, in accordance
with the Product Liability Act, we are not
liable for damages that were caused by our
devices if
−worn or damaged parts were not repaired
or replaced on time
−these damages were caused by improper
repair.
−when changing a part, our original parts
or parts authorised by use were not used.
−the repair work was not carried out by an
authorised service station.
The same applies for spare parts and
accessories.

10
Device description
1
2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1 Cutting height adjustment
2 Silencer
3 Grass collection bag
4 Impact protection flap
5 Tank filler spout
6 Tank ventilation
7 Handlebar with control elements
8 Lever for lateral adjustment of
handlebar
9 Clamping lever for height adjustment of
guide bar
10 Starter grip
11 Air filter
12 Bumper
13 Spark plug connector
14 Vario Bowden cable
15 Ventilation grid
16 Type plate

11
Control elements
1
2
4
3
5
6
7
Blade clutch bar (1)
The blade clutch bar is a protective device.
When you release the bar, the blade comes
to a standstill within 3 seconds.
Engaging blade: Lift the blade clutch bar (1),
engage the latch knob (6) and press the
blade clutch bar towards the handlebar.
Disengaging blade: Release the blade clutch
bar and set the accelerator lever to MIN.
0
I
0
I
M
Top:
Blade clutch bar
Bottom:
Drive bar
Drive bar (2)
With the drive bar, you switch the drive on
and off.
Drive on:
Pull the bar toward the handlebar.
Drive off:
Release the bar.
Vario lever (3)
With the vario lever, you can continuously
adjust the speed of the device while the
engine is running.
MIN: = slow
MAX: = fast
Accelerator lever(4)
MAX: Full throttle
MIN: Neutral position
Engine stop switch (5)
With the engine stop switch, you switch the
ignition on and off. If you switch off the
ignition, the engine stops.
0: OFF
I: ON
Lever for lateral adjustment (7)
1. Release the eccentric tension lever.
2. Attention: Do not crush the Bowden
cables when pivoting the handlebar.
Swivel the handlebar to the side to the
desired position.
3. Clamp the handlebar with the eccentric
tension lever.

12
Carburetor with choke and tickler
The choke (1) and the tickler (2) are required
for the cold engine start.
2
1
Opening the choke:
Turn clockwise to the
stop.
Closing the choke:
Turn anti-clockwise to the
stop.
Filling carburetor with
fuel:
Press the tickler briefly
until the fuel flow starts.
Fuel valve
1: Closed
2: Open
Assembly
Scope of delivery
The device is delivered in a carton.
The scope of delivery includes:
−The device.
−These operating instructions.
−The grass collection bag.
−Tool bag with small items.
Unpacking
1. Remove the loose parts from the box.
2. Cut open the front side of the box.
3. Push the device out of the box.
Mounting guide bar and
handlebar
12
45
6
3
7
8
1. Push the button at the clamping lever
and completely unscrew the clamping
lever (1).
2. Move the guide bar (2) backwards.
3. Attention: Do not crush the Bowden
cables (3) when moving the handlebar.
Pull the handlebar (4) rearward in a
clockwise direction and clamp it down
with the eccentric lever (5).
4. Adjust the guide bar to the desired
height and fix it with the clamping
lever (1).

13
5. Attention: During the first assembly,
remove the factory installed cable
ties (6) at the handlebar so that the
control elements can be actuated.
6. Insert the drive cable (7) into the drive
bar (8).
Inserting the starter rope
1
1. Press and continue to hold the blade
clutch bar.
2. Slowly pull the starter rope at the starter
grip (1) backwards and insert it into the
guide.
Assembling the grass collection
bag
12
3
1. Pull the grass collection bag (1) over the
frame (2).
2. Fasten the grass collection bag with the
plastic profiles to the frame.
3. On both sides of the grass collection
bag: Insert screws into the eyelets of the
grass collection bag, screw them in and
thus secure the bracket (3) to the frame
(four thread forming screws).
Mounting the grass collection
bag
2
1
1. Switch off the blade and wait until the
blade comes to a standstill.
2. Lift the impact protection flap (1).
3. Insert the grass collection bag (2) into
the recesses.
4. Lower the impact protection flap onto
the grass collection bag.

14
Transport
Switch off the engine and wait until the blade
comes to a stop before you lift the device. It
takes two persons to safely lift the device.
Prior to transport, let the device cool down for
at least 20 minutes. Close the tank ventilation
and the fuel valve.
For transport, you can fold up the handlebar
and the guide bar.
Use the eyelets marked with arrows as
suspension points.
When transporting by vehicle, secure the
device against rolling, sliding, tilting, and fuel
and oil leakage.
Information on mowing
Prior to mowing, check your device for
completeness, proper functioning, and
cleanliness. A dirty ventilation grid can
damage the engine and a dirty protective grid
at the silencer poses a fire hazard.
Frequent engagement and disengagement of
the clutch increases wear of the blade drive
belt and the blade brake. Especially in case
of high grass, clutch engagement leads to
overload.
To keep the area well maintained, mow
frequently and keep the grass short. Do not
mow your lawn too low in dry and hot
conditions because the lawn is susceptible to
sun and heat damage and will look unsightly!
Only mow with a sharp and undamaged
blade so that the blades of grass do not fray.
Have the blade sharpened and balanced
regularly (authorised service centre).
Do not mow when the grass is wet or when it
is raining. The turf may be damaged and
there is a danger of slipping!
Turn the device around only in already mown
sections. Do not leave the device unattended
while the engine is running.
For mowing, always turn the accelerator lever
to full throttle to achieve the best mowing
performance.
To collect the grass without blockage, we
recommend, for flat terrain, to proceed
according to the mowing patterns.
If the grass is extremely high, mow twice at
different cutting height settings.
Prior to starting
Fuel
Use a mixture of two stroke oil and unleaded
petrol (octane rating at least ROZ 91).
For mixing ratio, see chapter Mixing ratio fuel.
Recommendation: Two stroke oil TITAN 2T
100S, mixing ratio 1:100.
Your advantages:
−Halve oil consumption compared to 1:50
– more environmentally and cost friendly.
−Optimum protection of the engine for a
long service life.

15
You can buy Fuchs “TITAN 2T 100S” from
your AS-dealer:
Container Spare part
no.
1 litre
(resealable bottle)
100 ml
(disposable container)
40 * 100 ml
(disposable containers in box)
E06830
E10286
E10561
Notice: You can find on the market ready
mixed two stroke fuels. Based on our
experience, the ready mixed fuels “STIHL
Motomix 1:50” and “ASPEN 2-stroke” can be
used. No guarantee can be given for
operation of the device with other fuels and
oils!
Storing fuel mixture:
The fuel mixture ages and can cause engine
damages. Only mix as much fuel as you are
going to use up during the next mowing.
Tanking up
Danger!
Fuel is ignited by hot engine parts.
Prior to filling up, switch off the
engine and wait for at least
20 minutes until the engine has
cooled down. Observe the safety
instructions regarding the fuel!
Filling in the fuel:
1. For filling, use a canister with a filler
spout or use as funnel.
2. Open the canister carefully so that the
existing overpressure is discharged
slowly and no fuel spurts out.
3. Open the tank cap carefully so that the
existing overpressure is discharged
slowly and no fuel spurts out.
4. Fill the fuel tank.
5. Screw the tank cap on tightly.
Adjusting cutting height
Adjust the cutting height setting only when
the engine is switched off.
Set the cutting height so that the blade does
not touch the ground even in case of terrain
unevenness. If the cutting height is set too
high, objects can be ejected and the “clean
cut appearance” can be destroyed.
1. Switch off the engine and wait until the
blade has come to a standstill.
2. With the adjusting lever, adjust each
wheel to the same cutting height. The
cutting height can be adjusted in
1 cm increments from 3 cm to 8 cm.
Starting
Danger!
During startup, there is a risk of
injury caused by the rotating blade.
Make sure that no one is within the
danger zone of the blade. Do not
tip the device over to one side
during startup.
Danger!
If after startup the carburetor does
not close properly, fuel will
overflow and a fire hazard occurs.
Close the fuel valve and contact an
authorised service centre.

16
Starting the device
1. Place the device onto a flat surface, not
in high grass.
2. Open the fuel valve and the tank
ventilation.
3. Plug on the spark plug connector.
4. Only for cold start: Close the choke at the
carburetor (turn anti-clockwise).
5. Press the tickler at the carburetor until
the fuel is seen to drip.
6. Set the engine stop switch to "I".
7. Put the accelerator lever to lowest engine
speed position.
8. Pull the starter point slowly out until you
feel resistance then pull out quickly –
engine starts to run.
9. Let the starter rope retract slowly.
10. Put the accelerator lever to medium
engine speed position.
11. Reopen the choke (turn clockwise).
Engaging the blade
1. Move the blade clutch bar all the way up
and engage the latch knob.
2. Press the blade clutch bar downwards to
the handlebar - the blade starts up.
3. For mowing, set the accelerator lever to
the maximum speed.
For driving over paths, disengage the
blade:
1. Release the blade clutch bar.
Driving
Danger!
Risk of injury caused by tripping or
sliding while moving the mower
backwards and turning it round.
Before moving in reverse, always
switch off the blade!
Make sure that the area is clear of
objects and watch for safe footing.
Driving
In case of a hazardous situation, switch off
the drive and declutch the blade.
Drive on:
1. Switch the vario lever for the speed to
"MIN".
2. Pull the drive bar towards the handlebar -
device is running.
3. With the vario lever, adjust to the desired
speed
Drive off:
1. Release the drive bar.
Adjusting speed:
The driving speed can be continuously
adjusted with the vario lever.
Adjust the driving speed only when the
engine is running.
Turning
Turn the device round only where the grass
has been mowed already.
Turning round on an even surface:
1. Switch off the drive.
2. Turn the device to the desired side.
3. Switch the drive back on.
Turning round on a sloping area:
1. Keep the drive switched on.

17
2. Turn the device upslope.
3. Hold back the handlebar and the inner
wheel.
The drive prevents sliding and supports the
turn manoeuvre.
Emptying the grass
collection bag
3
2
1
Display of fill level: It the grass collection bag
is full, the sewn-on material goes down (1)
(dust protection).
Danger!
Risk of injury caused by rotating
blades.
When the engine is running, never
reach into the discharge channel.
Emptying the grass collection bag:
1. Switch the accelerator lever to the lowest
speed.
2. Disengage the blade and wait until it
comes to a standstill.
3. Lift the impact protection flap (2).
4. Remove the grass collection bag (3).
5. Lower the impact protection flap.
6. Empty the grass collection bag
completely.
Switching off and parking
Caution!
On a slope, the device can roll
away.
Put the device on even ground
only or secure it against rolling
away.
1. Release the drive bar.
2. Turn the accelerator lever to the lowest
engine speed.
3. Turn the engine stop switch to "0".
4. Wait until the blade comes to a standstill
before you step away from the device.
5. Close the fuel valve and the tank
ventilation.
6. Pull off the plug connector.

18
Maintenance and cleaning
Regular maintenance keeps your device
ready for use.
If you do not observe the maintenance
notices, faults may occur that are not covered
by the warranty. Operational safety is
endangered as well.
Contact your authorised service centre for
checkup if you detect problems during
maintenance.
Component Action Maintenance interval
Before
and after
each use
Annually
or every
50 h
Device Check for safe working condition. ■▲
Clean. ■
Customer service. ▲
Fuel Check fuel level. ■
Is the tank cap closed? ■
Tank, fuel valve,
and fuel line
Check parts for leaks and check for good
condition.
■▲
Carburetor Does the carburetor close again after starting? ■▲
Ventilation grid Clean. ■▲
Engine cooling Clean. ▲
Spark plug Check/adjust. ■
Replace. ■▲
Air filter Check/clean. ■▲
Replace. ■▲
Blade and
fastening
components
Check for wear and damage. See chapter
Checking the blade.
■▲
Change. ▲
Blade brake Does the blade function safely and does the blade
come to a standstill within 3 seconds?
□▲
Drive lever Does the device stop when the lever is in zero
position?
□▲
V-belt Are the V-belts tensioned correctly, without
fissures, and in good condition?
▲

19
Component Action Maintenance interval
Before
and after
each use
Annually
or every
50 h
Bowden cables Check for proper function and ease of movement. ■▲
Acceleration lever Check for proper function. □▲
Chassis and
impact protection
Check for rust and fissures and check the welding
seams.
■▲
Are all protective device fastened correctly and
properly functioning?
■▲
Label Condition of the labels. ■▲
Flammable
material
Remove easily flammable debris buildup from the
engine and the device.
■▲
Tires Check tires and tire pressure if necessary. ■▲
■
□
▲
By the user when the engine is not running.
By the user when the engine is running.
By the authorised service centre.

20
Preparations
Caution! Risk of injury. Guide
bar can snap back. To provide
secure stand, place the guide bar
onto the ground.
Prior to all maintenance and cleaning
work:
1. Let the device cool down for at least
20 minutes.
2. Pull off the spark plug connector.
3. Close the fuel valve and the tank
ventilation.
4. Remove the clamping lever from the
guide bar and flip the guide bar forward
(do not crush the Bowden cables).
5. Lift the impact protection flap all the way
and tilt the device backwards according
to the illustration.
6. Put the guide bar onto the ground.
Cleaning the device
After each use, you should clean the device
thoroughly, especially the bottom side and
the blade.
Stuck grass or dirt affect the grass discharge
and the cutting quality. For a sufficient engine
cooling, keep the engine cover, ventilation
grid, and the engine clean.
Fire hazard! Pay special attention so that
components at the silencer are clean.
For cleaning use a hand brush. Remove
stubborn soiling with a wooden or plastic
spatula. Clean the outer housing parts with a
cloth.
Do not rinse off the device with a water jet or
high pressure cleaner! Do not use aggressive
cleaning agents.
Cleaning the grass collection bag
After each mowing, clean the grass collection
bag thoroughly with water. The cloth must
remain air-permeable. Grass clippings can
clog the fabric and thus reduce the collecting
power.
