C200
simply designed to be shared
User’s
Guide
InFocus Corporation
27700B SW Parkway Avenue
Wilsonville, Oregon 97070-9215
1-800-294-6400 •503-685-8888
Fax: [phone]
http://www.infocus.com
In Europe:
InFocus International B.V.
Strawinskylaan 585
1077 XX Amsterdam,The Netherlands
Phone: [phone]
Fax: [phone]
In Asia:
238A Thomson Road
#18-01/04 Novena Square
Singapore 307684
Telephone: [phone]
Fax: [phone]
Printed on
recycled
paper.
C200
C4050COVER.qxd 12/3/02 9:44 AM Page 1

Downloaded from Projector.com

Downloaded from Projector.com
2
English
Declaration of Conformity
Manufacturer: InFocus Corporation, 27500 SW Parkway Ave. Wilsonville, Oregon
97070 USA
European Office: Strawinskylaan 585, 1077 XX Amsterdam, The Netherlands
We declare under our sole responsibility that the C200 projector conforms to the fol-
lowing directives and norms:
EMC Directive 89/336/EEC, Amended by 93/68/EEC
EMC: EN 55022
EN 55024
EN 61000-3-2
EN 61000-3-3
Low Voltage Directive 73/23/EEC, Amended by 93/68/EEC
Safety: EN 60950: 2000
July, 2002
Trademarks
Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple
Computer, Inc. IBM is a trademark or registered trademark of International Business
Machines, Inc. Microsoft, PowerPoint, and Windows are trademarks or registered
trademarks of Microsoft Corporation. InFocus, and ProjectorNet, are trademarks or
registered trademarks of InFocus Corporation.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is oper-
ated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruc-
tion manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
Canada
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Safety Certifications
UL, CUL, TÜV, GOST, CCC
Remote Control Warning
Laser radiation class II product; wavelength 650nm; maximum output 1mW. Remote
control complies with applicable requirements of 21 CFR 1040.10 and 1040.11.
Remote control complies with applicable requirements of EN 60 825-1: 1994 +A11.

Downloaded from Projector.com
3
Table of Contents
Introduction 5
Connecting a computer 7
Required computer connections 7
Optional computer connections 7
Displaying a computer image 9
First-time projector use with Windows 98 10
Adjusting the image 12
Connecting a video device 13
Displaying a video image 14
Shutting down the projector 16
Troubleshooting your setup 16
Using the keypad buttons 24
Using the remote control 25
Using the audio 26
Optimizing computer images 27
Presentation features 27
Optimizing video images 28
Customizing the projector 28
Using the menus 29
Picture menu 30
Settings menu 33
Maintenance 36
Cleaning the lens 36
Replacing the projection lamp 37
Using the security lock 39
Appendix 40
Specifications 40
Accessories 40
Red LED Behavior and Projector Errors 41
Projected image size 41
If you are experienced in setting up presentation systems, use the Quick Set
Up card that was included in the carry case. For complete details on con-
necting and operating the projector, refer to this User’s Guide.
Important Operating Considerations
Do not place the projector on a tablecloth or other soft covering that may
block the vents. Vents are placed along the left and right sides of the C200,
as well as across the front of the projector. Do not use a non-approved ceil-
ing mount. In the unlikely event of the lamp rupturing, discard any edible
items placed in the surrounding area and thoroughly clean the area along
the sides and in the front of the projector.
2 ft (.6m) 2 ft (.6m)
2 ft (.6m)
Do not place objects in the areas along the side and in the front of the projector

Downloaded from Projector.com
4

Downloaded from Projector.com
5
Introduction
Your new digital projector is easy to connect, easy to use, easy to maintain
and has XGA 1024x768 resolution.
The projector comes in a carry case that offers ample room for ASK acces-
sory items such as the projector remote, color-coded cables, and documenta-
tion. The color-coded cable straps and cables they contain make your setup
experience quick and easy, while the case’s design helps you find and put
away all items without the fear of anything becoming lost.
Online Registration
Register your projector online at www.infocus.com/register to receive
product updates, announcements, and registration incentives.
Included items
Cables
computer cable
power cable
video cable
remote
audio
cable
projector
user’s guide
quick setup card
color-coded cable straps
,
and support
card *
* also holds business card
CD, and safety
card
user’s guide,
remote computer
cable
projector
lens cap
power
cable
video cable
audio cable
quick setup card, CD
safety card, support
card
computer
cable
video
cable
audio
cable
power
cable

Downloaded from Projector.com
6
Projector components and features
keypad
speakers
zoom
focus
elevator foot release
remote
control
receivers (IR)
air intake
vent
carrying
handle
remote
control
receiver (IR)
connectors
leveling
foot
heat vent
heat vent
remote control
receiver (IR)
computer 1 computer 2
video
monitor out network
serial control
audio in
audio in audio in
audio out
R
R
L
L
Y
Pr
Pb
s-video
computer in
lock
remote control
receiver (IR)
power
connector network
compu
t
er
monitor
s-video video
connector
component
video
computer
1 & 2
computer 1
& 2 audio
serial
connector
external
speakers
(audio out)
audio

Downloaded from Projector.com
7
Connecting a computer
Required computer connections
Connect the black end of the computer cable to the Computer 1 connector
on the projector. Connect the blue end to the video port on your computer. If
you are using a desktop computer, you first need to disconnect the monitor
cable from the computer’s video port.
Connect the black power cable to the connector on the back of the projector
and to your electrical outlet.
The Power LED on the projector’s keypad turns solid green.
NOTE: Always use the power cable that shipped with the projector.
Optional computer connections
To control your computer’s mouse using the projector’s remote control, con-
nect the USB connector on the computer cable to the computer. USB drivers
must be installed to use the USB feature. For more information, see page 11.
To have sound with your presentation, connect the audio cable to your com-
puter and to the computer Audio In connector on the projector.
If you are using a desktop computer and want to see the image on your
computer screen as well as on the projection screen, plug the monitor cable
to the Monitor out connector on the projector.
computer1 computer2
video
monitor network
serial control
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computerin
connect computer cable
connect power cable
computer1 computer2
video
monitor network
serial control
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computer in
connect computer cable
computer1 computer2
video
monitor network
serialcontrol
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computerin
computer1 computer2
video
monitorout network
serialcontrol
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computerin
connect audio cable
connect monitor cable
computer1 computer 2
video
monitorout network
serial control
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computerin

Downloaded from Projector.com
8
If you prefer connecting your computer to the projector with an optional
VESA cable, connect one end of the cable to the VESA port on your com-
puter, and connect the other end of the cable to the blue Computer 2 con-
nector on the projector.
You can control the projector from an LCD control panel or computer by
connecting an RS-232 cable to the projector’s Serial connector. Specific
RS-232 commands can be found in the Service and Support section of our
website at www.ask.no.
The projector can be managed by ProjectorNet networking software
through its Network connector.
Contact an authorized ASK dealer or visit the ProjectorNet website at
www.infocus.com/projectornet for information on ProjectorNet.
computer1 computer2
video
monitor network
serial control
audioin
audioin audio in
audioout
R
R
L
L
Y
Pr
Pb
s-video
computerin
connect VESA cable
connect RS-232 cable
computer1 computer2
video
monitor network
serial control
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computer in
computer1 computer 2
video
monitor network
serialcontrol
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computerin
Network
connect network cable

Downloaded from Projector.com
9
Displaying a computer image
Remove the lens cap.
Press the Power button on the top of the projector or the remote.
The LED flashes green and the fans start to run. When the lamp comes on,
the startup screen is displayed and the LED is steady green. It can take a
minute for the image to achieve full brightness.
? No startup screen? Get help on page 17.
Turn on your computer.
The computer’s image should appear on the projection screen. If it doesn’t,
press the Computer button on the projector’s keypad.
Make sure your laptop’s external video port is active.
Many laptops do not automatically turn on their external video port when a
projector is connected. Usually a key combination like FN + F5 is used to
turn the external display on and off. Refer to your computer’s documenta-
tion to learn your computer’s key combination.
? No computer image? Try pressing the Auto Image
button on the keypad. Get help on page 17.
remove lens cap
press Power
turn on computer
activate laptop’s external port

Downloaded from Projector.com
10
First-time projector use with Windows 98
The first time you connect a computer running Windows 98 to the projector,
the computer recognizes the projector as “new hardware”and the Add
New Hardware Wizard appears. Follow these instructions to use the Wiz-
ard to load the correct driver (which was installed with your Windows
operating system).
If you are running Windows 2000, Windows ME, or Window XP, skip these
steps and go to “Adjusting the image”on page 12.
aClick Next to begin searching for the driver.
bMake sure “Search for the best driver”is selected, then click Next.
cUncheck any checked boxes, then click Next. Windows automatically
locates the driver. If this driver has been removed, reload the driver using
your Windows operating system CD.
dWhen Windows finds the driver, you are ready to install it. Click Next.
a
b
c
d

Downloaded from Projector.com
11
Skip this page if you did not connect a USB mouse cable
For Windows 98:
•If you connected the USB cable, the Add New Hardware Wizard
appears again. Drivers must be installed to use the USB functionality.
•The Wizard launches three times.
The first time it detects a USB Composite Device.
The second time a USB Human Interface Device (for the keyboard).
The third time it detects a USB Human Interface Device (for the
mouse).
For Windows 2000, Windows ME, and Windows XP:
•The USB drivers are automatically installed.

Downloaded from Projector.com
12
Adjusting the image
Adjust the height of the projector, if necessary, by pressing the release but-
ton to extend the elevator foot.
Rotate the leveling foot, if necessary.
Position the projector the desired distance from the screen at a 90 degree
angle to the screen.
See page 41 for a table listing screen sizes and distances.
Adjust the zoom or focus rings by rotating them until the desired image size
and sharpness are produced.
If the image is not square, adjust the keystone by using the buttons on the
keypad.
Press the upper Keystone button to reduce the upper part of the image, and
press the lower Keystone button to reduce the lower part.
Adjust the Contrast or Brightness in the Picture menu.
See page 29 for help with the menus.
adjust height
rotate level-
ing foot
elevator foot
adjust distance
adjust zoom and focus
focus
zoom
adjust keystone
adjust Contrast or Brightness
contrast
brightness

Downloaded from Projector.com
13
Connecting a video device
Standard video connections
Plug the video cable’s yellow connector into the video-out connector on the
video device. Plug the other yellow connector into the yellow Video con-
nector on the projector.
Plug a white connector into the left audio out connector on the video device
and plug a red connector into the right audio out connector on the video
device.
Plug the remaining white connector into the left audio in connector on the
projector, and plug the red connector into the right audio in connector on
the projector.
Connect the black power cable to the connector on the back of the projector
and to your electrical outlet. The Power LED on the keypad turns solid
green.
NOTE: Always use the power cable that shipped with the projector.
Optional video connections
If the video device uses a round, four-prong S-video connector, plug an
S-video cable (sold separately) into the S-video connector on the video
device and into the S-video connector on the projector. Use the video cable’s
audio connectors as described directly above (the yellow connectors on the
video cable are not used).
If the video device uses component cable connectors (sold separately), plug
the cable’s green connectors into the green component-out connector on the
video device and into the green component connector (labeled “Y”) on the
projector. Plug the component cable’s blue connectors into the blue compo-
nent-out connector on the video device and into the blue component con-
nector (labeled “Pb”) on the projector. Plug the component cable’s red
connectors into the red component-out connector on the video device and
into the red component connector (labeled “Pr”) on the projector. Use the
video cable’s audio connectors as described directly above (the yellow con-
nectors on the video cable are not used).
connect video cable computer1 computer 2
video
monitor network
serial control
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computer in
connect power cable
computer1 computer2
video
monitor network
serial control
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computer in
connect S-video and video cables
computer1 computer2
video
monitor network
serial control
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computer in
connect component cables
computer1 computer 2
video
monitor network
serial control
audioin
audioin audioin
audioout
R
R
L
L
Y
Pr
Pb
s-video
computer in
and video cables

Downloaded from Projector.com
14
Displaying a video image
Remove the lens cap.
Press the Power button on the top of the projector.
The LED flashes green and the fans start to run. When the lamp comes on,
the startup screen is displayed and the LED is steady green. It can take a
minute for the image to achieve full brightness.
? No startup screen? Get help on page 16.
Plug in and turn on the video device.
The video device’s image should appear on the projection screen. If it
doesn’t, press the Video button on the keypad.
Adjust the height of the projector by pressing the release button to extend
the elevator foot. Rotate the leveling foot, if necessary.
Position the projector the desired distance from the screen at a 90 degree
angle to the screen. See page 41 for a table listing screen sizes and distances
to the screen.
remove lens cap
press Power
turn on video device
adjust height
rotate
leveling
foot
elevator
foot
adjust distance

Downloaded from Projector.com
15
Adjust the zoom or focus rings by rotating them until the desired image size
and sharpness are produced.
If the image is not square, adjust the keystone using the buttons on the key-
pad. Press the upper Keystone button to reduce the upper part of the
image, and press the lower Keystone button to reduce the lower part.
Adjust the volume on the keypad or remote.
Adjust the Contrast, Brightness, Color, or Tint in the Picture menu.
See page 29 for help with the menus.
adjust zoom and focus
focus
zoom
adjust keystone
adjust volume
adjust Picture menu contrast
brightness
color
tint

Downloaded from Projector.com
16
Shutting down the projector
The projector automatically displays a black screen after no active source is
detected for 30 minutes. This black screen helps preserve the life of the pro-
jector. The image returns when an active source is detected or a remote or
keypad button is pressed.
Screen Save
You can make the black screen appear after five minutes by turning on
Screen Save in the Settings>System menu. See page 34. There are six time
options for the Screen Save feature. They range from five minutes to 30 min-
utes with five minute intervals.
Power Save
The projector also has a Power Save feature that automatically turns the
lamp off after no signals are detected for 20 minutes. After 10 additional
minutes with no signal, the projector powers down. If an active signal is
received before the projector powers down, the image is displayed. You
must press the Power button to display an image after 30 minutes have
passed. When Power Save is enabled, Screen Save is disabled. See page 33.
Turning off the projector
To turn off the projector, press the power button and verify that you want to
turn the projector off by pressing the power button again within 3 seconds.
You can cancel the shutdown by not pressing the power button a second
time. The lamp turns off and the LED blinks green for 1 minute while the
fans continue to run to cool the lamp. When the lamp has cooled, the LED
lights green and the fans stop. Unplug the power cable to completely power
off the projector.
Troubleshooting your setup
If your image appears correctly on the screen, skip to the next section
(page 25). If it does not, troubleshoot the setup.
The LED on top of the projector’s keypad indicates the state of the projector
and can help you troubleshoot.
The following tables show common problems. In some cases, more than one
possible solution is provided. Try the solutions in the order they are pre-
sented. When the problem is solved, you can skip the additional solutions.
Table 1: LED behavior and meaning
LED color/behavior Meaning
solid green The projector is plugged in, or the projec-
tor has been turned on and the software
has initialized. The projector has been
turned off and the fans have stopped.
blinking green The power button has been pressed and
the software is initializing, or the projec-
tor is powering down and the fans are
running to cool the lamp.
blinking red
see page 41 for more information
A fan or lamp failure has occurred. Make
sure the vents aren’t blocked (see
page 22).Turn off the projector and wait
one minute, then turn the projector on
again. If the projector has been working
for 2000 hours or more (page 37), replace
the lamp and reset the lamp timer. Con-
tact Techincal Support if the problem per-
sists.
solid red An unidentifiable error: please contact
Technical Support.

Downloaded from Projector.com
17
Source troubleshooting
Problem Solution Result
No startup screen
Plug power cable in and remove lens cap
press power button Correct image
Only startup screen appears
Press the Computer button
Activate laptop’s external port
Computer image projected
Start Up
Logo
A
Start Up
Logo
or restart
laptop
A
A

Downloaded from Projector.com
18
No computer image, just the words “Signal out of
range”
Adjust computer refresh rate in Control
Panel>Display>Settings>Advanced>
Adapter (location varies by operating
system) Computer image projected
A
Signal out of
range
You may also need to set a different
resolution on your computer, as shown
in the following Problem, “Image fuzzy
or cropped”
A
A
