Ask C300 User manual

The Practical Network Projector
High brightness:impressive 3000ANSI lumens
Unmatched video quality:HDCP and PureProgressive™ scan
Silent (34 dB) operation to minimise audience distraction
Easily installed,with RS232 for control from any standard
control room and/or panel
Asset management through corporate network
XGA NETWORK DATA/VIDEO PROJECTOR
XGA
C300
English

WELL-CONNECTED
TheASK C300 can connect to virtually any
source.OrdinaryVGA, of course, but also BNC
connectors to easily replace already installed
projectors;fully digital DVI input to give totally
loss-free signals;wide video compatibility, withY,
Pb,Pr,and RGB component video,HDTV
NETWORK PROJECTOR
Open standard networking withTCP/IP and asset
management through Microsoft’s Management
Console and InFocus’ software.With impressive
3000ANSI lumens, vivid colours,a contrast ratio
of 800:1,whisper-quiet operation and simply
excellent video display, you get a leading edge
presentation tool that can be connected to your
LAN,WAN,VPN or to the internet.TheASK
C300 combines the latest projection technology
with network control and asset management.
ASSET MANAGEMENT
The standard network connection of the C300
allows command and control through the
corporate network.The projector can be
constantly tracked, keeping control over remaining
lamp life, set up, projector status and use.The
C300 uses open standards to make certain that
the projector can be controlled through any
network.
ASSET MANAGEMENT
TheASK C300 supports standard asset
management over the corporate network.
In this way, remaining lamp life,projector
status and service needs can be monitored
from the IT department.IT can get statistics
on the utilisation of the projectors,track
costs and keepTCO (total cost of
ownership) down,which facilitates planning
and collecting audit information.
The C300 can be configured or re-
configured over the network,which makes
it easier to support the projector.
The C300 supports standard network
connections and protocols.
• TCP/IP protocol for connection to
LANs,WANs and the internet.
• DHCP – the C300 can be automatically
assigned an IP address from the DHCP
server,or this function can be
overridden and the IP address entered
manually.
• System integrators can choose between
controlling the C300 through the
traditional RS232 serial interface, or
throughTCP/IP.
Asset management is done through a
Microsoft Management Console snap-in, the
InFocus software.This system allows control
and administration of multimedia projectors
from a remote console. It is designed as a
server-based system to ensure accurate
information regardless of whether a given
projector is on,in stand-by mode,or
completely powered off.
The Filter can easily be taken out for cleaning and
replacement.

EXCELLENTVIDEO
The advanced video processing converts existing
standard definition video from DVD, videotape,
laser disc, satellite or standard broadcast
television to a near high-definition signal,
dramatically improving the video image.
VIDEO PROCESSING FEATURES
• Motion-adaptive video deinterlacing
• Source adaptive processing
• Film mode detection with 3:2 and 2:2
pulldown
• Auto-dynamic thresholds enable reliable 3:2
pull down & 2:2 pull down detections even
with noisy sources
• SourceTransition Management provides
seamless transitions between source types
• Motion detection on per-pixel basis
• Four input fields used to determine contents
of each output frame
• Cubic interpolation for pixel calculations
• Diagonal processing reduces "jaggies"
• Low-noise, high-accuracy 10-bit video DACs
• HDCP - High bandwidth Digital Content
Protection - allows DVD and Digital video
through the DVI port for outstanding quality.
compatibility, and as one of the first projectors
in the world the C300 supports HDCP (High
bandwidth Digital Content Protection) and
digital video through DVI. USB and PS/2 mouse
control,TCP/IP protocol,a standard RJ45
network connection and RS232 control for
installations,compatible with control systems
like AMX and Crestron - well-connected indeed.
This versatile projector allows multiple
configurations of video and data sources to be
connected simultaneously, and the high
bandwidth ensures wide compatibility.
EASYTO USE, EASYTO MOVE
TheASK C300 is easy to use,with automatic
source detection and set up,an icon and text-
based menu system similar to the well-known
Windows® interface, and the award-winning
BatMouse™ IV remote control.The low weight
of 6 kg and ease of set up makes the C300 ideal
for moving between meeting rooms.
The network control features mean that an IT
department can control set up and configuration
centrally.For installations, it can be controlled
either through the RS232 connection or through
theTCP/IP protocol.
STUNNING DISPLAY
Shining brightly with 3000ANSI lumens, and with
a contrast ratio of 800:1,the ASK C300 has
great image dynamics with vivid,saturated
colours.Designed for medium to large
conference rooms,it has the clarity and
brightness needed for large images.
The high contrast and detailed graphics lets the
C300 give a cinema-like experience when
showing video, using advanced video processing
from Silicon Image for line doubling and smooth
images.The DigitalVisual Interface (DVI)
connector allows loss-free connection for both
data and video, utilising HDCP.
QUIETAND BUSINESS-LIKE
The C300 operates whisper quiet at below
34db(A),letting your audience see your
presentation without distraction.For the user’s
convenience,all functions can be controlled both
from the BatMouse IV remote and from the
projector keypad,or from a wired remote in
installation environments. Monitor loop-through
lets a presenter watch the presentation while
facing the audience.
The C300 has many features,but it is designed
to facilitate communication,without the
technology getting in the way.

www.askprojectors.com
InFocus ASA
K. G Meldahl vei 9,
Postboks 1403
N-1602 Fredrikstad
Norway
Tel.: [phone]
Fax:[phone]
E-mail: [email protected]
©2001 InFocus ASA. All rights reserved. Specifications are subject to change without further notice Article no.: 825.0020.00
10.00
4.44
5.71
1.10
0.49
0.63
2.00
0.89
1.43
4.00
1.78
2.28
6.00
2.67
3.43
8.00
3.56
4.57
Screen width
Distance to screen
Minimum Width in meters
Maximum Width in meters
10.00
5.55
7.13
1.10
0.61
0.73
2.00
1.11
1.43
4.00
2.23
2.85
6.00
3.34
4.29
8.00
4.45
5.71
Screen diagonal
Distance to screen
Minimum Diagonal in meters
Maximum Diagonal in meters
Screen Sizes:
Specifications
Compatibility
Computer Digital and analog PC, MAC,Workstation, 1400 x 1050 max resolution
RGBHV, RGBS,RGsB
Video HDCP, YPbPr, RGB, HDTV (1080i, 720p),S-Video,CompositeVideo
PAL BGHI,M,N,SECAM, NTSC 3.58/4.43
Horizontal Scan Rate 15 - 100 kHz
Vertical Scan Rate 43.5 - 130 Hz
Bandwidth,Dot Clock 165 MHz analogue, 112 MHz digital
Mouse Control USB,PS/2,MS Serial
TCP/IP, RS232, USB,Wired remote
Display
Technology 1.3" PolySilicon LCD x 3 with MLA (Micro LensArray)
Resolution 1024 x 768
Brightness 3000ANSI lumens
Contrast Ratio 800 :1 (typ)
Lamp 270W SHP / up to 1500 hrs
Colours 16.7 Mill
Optics
Lens 1.3x Manual Zoom and Focus,f = 47 - 61 mm,F/1.8 - 2.1
Image Size 0.5 - 7.8m / 27 - 300" diagonal
Throw Distance 1.1 - 11m / 4 - 36ft.
Throw Ratio 1.75 - 2.24 :1 (distance :width)
Keystone Correction, Optical 11.5 - 15.5 degrees, 9 : 1 up/down ratio
Connectivity
Computer 1,2 15-pin DSUB (VGA /VESA)
Computer 3 BNC x 5
Computer 4 DVI-D
ComputerAudio 3.5 mm Stereo mini jack x4
Mouse Control USB / 6-pin PS/2
RGB/ComponentVideo BNC x 3
Video RCA
S-Video 4-pin mini DIN
VideoAudioRCA StereoAudio
Monitor Out 15-pin DSUB (VGA /VESA) (Analog Computer in only)
Audio Line Out RCA StereoAudio
RS-232 Control 9-pin DSUB
Wired Remote Control 2.5mm mini jack
Speakers 5W Stereo speakers, integrated 20W subwoofer
Network
Protocol TCP/IP based
Connection RJ-45 10baseT standard
Features Asset management,TCP/IP control, Command and Control
Metrics
Size (W x L x H) 322x352x130mm
Weight 6.0 kg
Operating Noise < 34 dB (A)
Supplied Material
Cables CoaxialVGA cable,4m
A/V cable, 4m
Power Cord,4m
USB mouse cable, 4m
Accessories Dust Cover
Remote Control
Lens cap
Scart Adapter
Users' Guide
MS Serial mouse adapter
PS/2 Mouse adapter
General
Conformances CE, UL, cUL, IRAM, NOM, FCC Class A
Warranty Two-years parts and labour
Lamp warranty 90 days/500 hrs.
Operating temp 10 - 35 C, 50 - 95 F (ambient operating)
Power Supply 100 - 240V, 50/60 Hz
Power Consumption <400W normal operation
Distance to screen in meters
Screen Diagonal in meters
012 3456 7891011
8
7
6
5
4
3
2
1
C 300
10.70
4.75
6.11
10.70
5.88
7.63
