ASROCK 890GMH/USB3 User manual

AMD 890GX + SB710 Chipsets
890GMH/USB3
www.asrock.com
Detail Specification
Product Brief
CPU
Memory
Expansion Slot
Graphics
Audio
LAN
USB 3.0
Rear Panel I/O
Connector
BIOS Feature
Support CD
Accessories
Hardware Monitor
OS
Certifications
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Chipset
Platform
- ASRock DuraCap (2.5 x longer life time),
100% Japan-made high-quality Conductive
Polymer Capacitors
- Supports ASRock Turbo UCC
- Supports Dual Channel DDR3 1800(OC)
- Supports ATITM Hybrid CrossFireXTM
- Integrated AMD Radeon HD 4290 graphics,
DX10.1 Class iGPU, Shader Model 4.1, Max.
shared memory 512MB
- Multi VGA Output options: D-Sub, DVI-D and
HDMI
- 5 x SATA2 connectors, 1 x eSATA2 Connector,
1 x USB 3.0 port, PCIE Gigabit LAN
- Supports ASRock Instant Boot, Instant Flash,
OC Tuner, IES, OC DNA, AIWI, APP Charger
- 7.1 CH HD Audio with Content Protection
(Realtek ALC892 Audio Codec), Premium
Blu-ray audio support
- ErP/EuP Ready
- Free Software : CyberLink DVD Suite - OEM
and Trial; Creative Sound Blaster X-Fi MB - Trial
- Micro ATX Form Factor: 9.6-in x 9.0-in, 24.4 cm x 22.9 cm
- All Solid Capacitor design (100% Japan-made high-quality Conductive
Polymer Capacitors)
- Support for Socket AM3 processors: AMD PhenomTM II X6 / X4 / X3 / X2
(except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron processors
- Six-Core CPU Ready
- Supports ASRock UCC - Unlock CPU Core
- Supports AMD's Cool 'n' Quiet Technology
- FSB 2600 MHz (5.2 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport 3.0 (HT 3.0) Technology
- Northbridge: AMD 890GX
- Southbridge: AMD SB710
- Dual Channel DDR3 memory technology
- 4 x DDR3 DIMM slots
- Supports DDR3 1800(OC)/1600(OC)/1333/1066/800 non-ECC,
un-buffered memory
- Max. capacity of system memory: 16GB
- 1 x PCI Express 2.0 x16 slots (blue @ x16 mode)
- 1 x PCI Express 2.0 x1 slot
- 2 x PCI slots
- Supports ATITM Hybrid CrossFireXTM
- Integrated AMD Radeon HD 4290 graphics
- DX10.1 class iGPU, Shader Model 4.1
- Max. shared memory 512MB
- Multi VGA Output options: D-Sub, DVI-D and HDMI
- Supports HDMI Technology with max. resolution up to 1920x1200 (1080P)
- Supports Dual-link DVI with max. resolution up to 2560x1600 @ 75Hz
- Supports D-Sub with max. resolution up to 2048x1536 @ 85Hz
- Supports HDCP function with DVI and HDMI ports
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with DVI and
HDMI ports
- 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec)
- Premium Blu-ray audio support
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
- 1 x USB 3.0 port by Fresco FL1000G, supports USB 3.0 up to 5Gb/s
I/O Panel
- 1 x PS/2 Keyboard Port
- 1 x VGA/D-Sub Port
- 1 x VGA/DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 5 x Ready-to-Use USB 2.0 Ports
- 1 x eSATAII Connector
- 1 x Ready-to-Use USB 3.0 Port
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front Speaker /
Microphone
- 5 x Serial ATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1,
RAID 10 and JBOD), NCQ, AHCI and "Hot Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- 1 x COM port header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 3 x USB 2.0 headers (support 6 USB 2.0 ports)
- 8Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- VCCM, NB, SB Voltage Multi-adjustment
- Drivers, Utilities, AntiVirus Software (Trial Version), AMD OverDriveTM
Utility, AMD Live! Explorer, AMD Fusion, ASRock Software Suite
(CyberLink DVD Suite - OEM and Trial; Creative Sound Blaster X-Fi
MB - Trial)
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore
- Microsoft®Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP / XP Media
Center / XP 64-bit compliant
- FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
- Quick Installation Guide, Support CD, I/O Shield
- ATA 133 Cable
- 2 x SATA Data Cables (Optional)
Unique Feature
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- ASRock AIWI
- ASRock APP Charger
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- Turbo 25 / Turbo 30 GPU Overclocking

AMD 890GX + SB710 Chipsets
890GMH/USB3
www.asrock.com
USB3.0, the world's best-known computer
peripheral interface once again receives a
major revamp to stay current with today’s
most demands for connectivity bandwidth.
Delivering data transfer rates up to ten times
faster than USB 2.0 with the optimized power
efficiency, USB 3.0 promises a major leap
forward in transfer speeds and capability.
Turbo UCC technology provides you an all-in-one solution to unlock the hidden cpu cores in the CPU, get the amazing system
performance boost by auto-overclocking, and running the system in a certainly lower power consumption level as well. When you press
"X" when switch on the computer, the system will automatically reboot itself, after that, the system will execute the Turbo UCC function.
Enabling Turbo UCC, it will automatically help you to unlock the extra CPU core to enjoy an instant performance boost, and the system
performance will boost up by overclocking CPU frequency, memory frequency and all related voltage settings! Different from normal
high-energy consumption for overclocking or system upgrading process, ASRock Turbo UCC can allow an energy-saving overclocking or
system upgrade computing operation!
Phenom II X6
6-Core CPU Ready
ASRock DuraCap
100% All Solid Capacitor
design
890GMH/USB3
AMD 890GX + SB710
Phenom II X2 555
Kingston 1333 1Gx2
onboard VGA
WD 500G
Motherboard
5674
11130
61.3
153.42
97%
97% 121%121%
ASRock DuraCap (2.5x longer life time), 100% Japan-made
high-quality Conductive Polymer Capacitors

AMD 890GX + SB710 Chipsets
890GMH/USB3
www.asrock.com
ATI Radeon®HD4290
DirectX 10.1 Onboard Graphics
Features DirectX®10 DirectX®10.1
Shader Model 4 4.1
Separate per-MRT
blend modes
Pixel Coverage
Masks
Sample Pattern
Selection
Cube Map Arrays
Gather4
VS Inputs 16 32
Blending INT8, FP16/32 INT8/16, FP16/32
Filtering FP16 FP32
No Yes
No Yes
No Yes
No Yes
No Yes
Key features of DirectX 10.1 include an updated shader model, improved anti-aliasing support,
more flexible data access, and tighter specifications for better applicationcompatibility.
DirectX 10.1 Anti-Aliasing
DirectX 10 –Standard
MSAA:Foliage edges do
not get anti-aliased
–causes shimmering and
crawling when they move
DirectX 10.1 –Alpha Test
MSAA:Foliage edges are
smoothed and anti-aliased
–offers significant image
quality improvement
Blu-ray video + Blu-ray audioBlu-ray video + Blu-ray audio
True Blu-rayTrue Blu-ray
Supporting Blu-ray Full HD 1080p
playback and Premium Blu-ray audio
with 24-bit / 192KHz sampling rate in
7.1 channel
(Integrated AMD Radeon HD 4290
graphics, supports DX10.1)
Premium Blu-ray Audio
Premium Blu-ray Audio, an outstanding technology developed on ASRock motherboard, provides the excellent
audio output of 24-bit/192 kHz with its respective Blu-ray DRM compatible driver/software. With Content
Protection-Support and High SNR DAC, the Blu-ray entertainments can be played in a high quality of
24-bit/192KHz. In other words, if you are using a device without the Blu-ray Audio support, the audio quality will
be downgraded to 16-bit/48kHz like a regular CD quality. To deliver the best possible sound solution for today’s
most demanding users, ASRock Premium Blu-ray Audio motherboard is the best choice for users who are
particularly desired to enjoy the pure HD audio. ASRock users are able to take full advantages of our Blu-ray
Audio motherboards. Choose ASRock, choose Pure HD audio!
Why ASRock?
* SNR: Signal-to-Noise Ratio.

AMD 890GX + SB710 Chipsets
890GMH/USB3
www.asrock.com
ASRock AIWI Quick Start Guide
Playing Games by Holding Your iPhone or iPod touchPlaying Games by Holding Your iPhone or iPod touch
ASRock AIWI -
Turn Your iPhone Into Game Joystick
ASRock AIWI -
Turn Your iPhone Into Game Joystick
ASRock AIWI software introduces a new way of PC gaming operation. ASRock AIWI is the world's first software to turn your iPhone/iPod
touch as a game joystick to control your PC games. Just to install the ASRock AIWI software on your ASRock motherboard, connect your
PC and apple devices via Bluetooth or WiFi networks, then you can start experiencing the exciting motion controlled games.

AMD 890GX + SB710 Chipsets
890GMH/USB3
www.asrock.com
OC DNA
Save your OC settings as a profile and share with
friends. Try OC DNA now!
OC DNA Instruction
Step 1 Step 2
Step 3 Step 4
Save your BIOS OC settings as User Default in BIOS OC
Tweaker menu. (For example: we name this User Default setting
as “CPU_OC3.8GHz”)
Press “Save” button to save the “CPU_OC3.8GHz” OC settings as
a profile.
Execute ASRock OC DNA under OS, you will find
“CPU_OC3.8GHz” as User Profile 1.
Send the “CPU_OC3.8GHz” profile to other friends.
Step 5 Step 6
When the friend receives your “CPU_OC3.8GHz” profile, he can
press “Load” to load the “CPU_OC3.8GHz” profile in OC DNA.
After that, the friend can enter into BIOS OC Tweaker menu to
load the “CPU_OC3.8GHz” profile as his BIOS OC settings.
Now, you have successfully share your OC setting profile with your friends.
890GMH/USB3
890GMH/USB3
890GMH/USB3
*The OC DNA works only when users use the same motherboard and BIOS version.

AMD 890GX + SB710 Chipsets
890GMH/USB3
www.asrock.com
ASRock Instant Flash is an exclusive and the most user-friendly BIOS flash utility
developed by ASRock. It is embedded in Flash ROM which is used to update the
system BIOS without having to enter operating systems like MS-DOS or Windows.
Once executing ASRock Instant Flash, the utility will automatically detect all devices such as USB, hard disk or even floppy drive to
find the exact BIOS for your system. Instead of giving you all BIOS in your devices, the Instant Flash just list BIOS versions that
apply to your motherboard model only. For example, if you have many different BIOS of different motherboards saved in your
devices, but you just need to flash your P45 motherboard, the Instant Flash will just list the P45 BIOS versions for you. This unique
function allows you to easily select the suitable BIOS version instead of browsing through all data.
Features
ASRock Instant Flash
Instant Flash just list
BIOS versions that
apply to your
motherboard model.
Click and start
Flashing!
Simple!Simple! Quick!Quick!
ASRock Instant Boot
10 Times Faster, Only 4 Secs to Boot Up to Windows!
ASRock YouTube
http://tw.youtube.com/watch?v=BucIjXZVxXo
ASRock Instant Boot is a new feature invented exclusively by ASRock.
It can boot up system in an amazing speed,
which is 10 times faster than traditional boot up. For home users or office
PC users, ASRock Instant Boot can also
guarantee a clean Windows OS, and consumed less power! For details:
http://www.asrock.com/feature/InstantBoot/index.asp
* This function is applicable ONLY to single user that does not secure ID and Password to their
systems.
* The boot up time depends on the hardware configuration.
ErP/EuP Ready Motherboard ErP/EuP Ready Power Supply ErP/EuP System
What is ErP/EuP?
ErP/EuP, stands for Energy Using Product, was a provision regulated by European Union to define the power consumption for
the completed system. With the great quantity and the popularly using of the electrical products nowadays and the continuously
increasing of the electrical products categories in the following 20 to 30 years, European Union decided to establish an effective
strategy to solve the energy consumption problem. That is, according to ErP/EuP, the total AC power of the completed system
shall be under 1.00W in off mode condition.

AMD 890GX + SB710 Chipsets
890GMH/USB3
www.asrock.com
CyberLink Power2Go 6.1 LE OEM
Power2Go 6 lets you burn and backup videos, photos, music and data onto Blu-ray
Discs and DVDs.
CyberLink MediaShow 4.1 SE OEM
Photo and video management software MediaShow edits videos and photos
instantly, creates slideshow, and allows publishing directly to YouTube and Flickr.
CyberLink PowerDVD 8.0 DTS Trial
World-renowned PowerDVD 8 DTS delivers outstanding DVD movie playback quality
on your PC.
CyberLink PowerDirector 8.0 Trial
PowerDirector - Video Editing software – edits high-definition videos including
AVCHD, allows output to PSP iPod and Blu-ray Disc.
CyberLink PowerBackup 2.5 Trial
PowerBackup backups valuable data on your PC.
Creative Sound Blaster X-Fi MB Trial
The Sound Blaster X-Fi MB solution provides premium audio quality, effects and
features for PC systems equipped with onboard audio.
For gamers, the EAX®ADVANCED HD 4.0, with its state-of-the-art Multi-Environment
rendering and reverb modelling, delivers a much more realistic and immersive 3D
gaming experience than your motherboard audio ever will.
