ASROCK H67M-ITX User manual

Detail Specification
Product Brief
CPU
Memory
Expansion Slot
Graphics*
Audio
LAN
SATA3
USB 3.0
Rear Panel I/O
Connector
BIOS Feature
Support CD
Accessories
Hardware Monitor
OS
Certifications
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Chipset
Platform
- ASRock DuraCap (2.5 x longer life time, 100%
Japan-made high-quality Conductive Polymer
Capacitors)
- Supports Intel®K-Series unlocked CPU
- Supports Dual Channel DDR3 1333
- Intel®HD Graphics 2000/3000 and new Visual
Features, DX10.1, Pixel Shader 4.1
- Supports Blu-ray Stereoscopic 3D with HDMI 1.4a
- Multi VGA Output options: D-Sub, DVI-D, HDMI
- 2 x SATA3, 2 x USB 3.0, 8 x USB 2.0 , 1 x
eSATA2
- Supports AXTU, UEFI, XFast USB, Instant Boot,
Instant Flash, APP Charger, Good Night LED,
SmartView
- 7.1 CH HD Audio with Content Protection (Realtek
ALC892 Audio Codec)
- Free Bundle : 1 x 3D Red/Cyan Anaglyph Glasses
- Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
- All Solid Capacitor design (100% Japan-made high-quality
Conductive Polymer Capacitors)
- Supports 2nd Generation Intel®CoreTM i7 / i5 / i3 in LGA1155
Package
- Supports Intel®Turbo Boost 2.0 Technology
- Supports Intel®K-Series unlocked CPU
- Supports Hyper-Threading Technology
- Intel®H67
- Dual Channel DDR3 memory technology
- 2 x DDR3 DIMM slots
- Supports DDR3 1333/1066 non-ECC, un-buffered memory
- Max. capacity of system memory: 16GB
- 1 x PCI Express 2.0 x16 slot (blue @ x16 mode)
* Requires Processor with Intel®Graphics Technology
- Intel®HD Graphics 2000/3000 and new Visual Features
- Pixel Shader 4.1, DirectX 10.1
- Max. shared memory 1759MB
- Multi VGA Output options: D-Sub, DVI-D and HDMI
- Supports HDMI 1.4a Technology with max. resolution up to 1920x
1200 @ 60Hz
- Supports DVI with max. resolution up to 1920x1200 @ 60Hz
- Supports D-Sub with max. resolution up to 2048x1536 @ 75Hz
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR
(High Bit RateAudio) with HDMI
(Compliant HDMI monitor is required)
- Supports Blu-ray Stereoscopic 3D with HDMI 1.4a
- Supports HDCP function with DVI and HDMI ports
- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with DVI
and HDMI ports
- 7.1 CH HD Audio with Content Protection (RealtekALC892 Audio
Codec)
- Premium Blu-ray audio support
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
- Supports LAN Cable Detection
- Supports Energy Efficient Ethernet 802.3az
I/O Panel
- 1 x PS/2 Keyboard Port
- 1 x VGA/D-Sub Port
- 1 x VGA/DVI-D Port
- 1 x HDMI Port
- 1 x Optical SPDIF Out Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x eSATA2 Connector
- 2 x Ready-to-Use USB 3.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front Speaker
/ Microphone
- 2 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID
10, RAID 5 and Intel Rapid Storage),NCQ, AHCI and Hot Plug functions
- 2 x SATA3 6.0 Gb/s connectors
- 1 x CIR header
- 1 x COM port header
- 1 x Power LED header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 64Mb AMI UEFI Legal BIOS with GUI support
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- IGPU, DRAM, PCH, CPU PLL, VTT, VCCSA Voltage
Multi-adjustment
- Drivers, Utilities, AntiVirus Software (Trial Version),
- ASRock Software Suite (CyberLink DVD Suite - OEM andTrial;
Creative Sound Blaster X-Fi MB - Trial)
- 2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0, RAID 1,
RAID 10, RAID 5 and Intel Rapid Storage), NCQ,AHCI and "Hot
Plug" functions
- 2 x USB 3.0 ports by Etron EJ168A, support USB 1.0/2.0/3.0 up to
5Gb/s
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis Fan Tachometer
- CPU/Chassis Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU or MB Temperature)
- CPU/Chassis Fan Multi-Speed Control
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP /
XP 64-bit compliant
- FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (Optional)
- 1 x 3D Red/Cyan Anaglyph Glasses (Optional)
Intel®H67 Chipset
Unique Feature
- ASRock ExtremeTuning Utility (AXTU)
- Instant Boot
- ASRock Instant Flash
- ASRock AIWI
- ASRock APP Charger
- SmartView
- ASRock XFast USB
- Hybrid Booster:
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- Good Night LED
H67M-ITX
www.asrock.com

Intel®H67 Chipset
H67M-ITX
www.asrock.com
ASRock XFast USB Technology -
Faster Than Your Imagination!
ASRock XFast USB Technology -
Faster Than Your Imagination!
ATTO Disk Benchmark - 8M Write
151231 KB/s
76477 KB/s 97.7%
Faster
Other Motherboard with NEC USB 3.0 Chipset
ASRock XFast USB Motherboard with Etron USB 3.0 Chipset
CrystalDiskMark 3.0 - Read 512K
Other Motherboard with NEC USB 3.0 Chipset
ASRock XFast USB Motherboard with Etron USB 3.0 Chipset
264.5 MB/s
194.4 MB/s 36.1%
Faster
ATTO Disk Benchmark - 512K Write
148523 KB/s
76315 KB/s 94.6%
Faster
Other Motherboard with NEC USB 3.0 Chipset
ASRock XFast USB Motherboard with Etron USB 3.0 Chipset
CrystalDiskMark 3.0 - Read Seq
Other Motherboard with NEC USB 3.0 Chipset
ASRock XFast USB Motherboard with Etron USB 3.0 Chipset
276.6 MB/s
202.3 MB/s 36.7%
Faster
ASRock XFast USB Technology redefines the new standard in high performance computing. Proving once
again to be the pioneer in motherboard industry, ASRock XFast USB Series Motherboards integrate with
the latest XFast USB Technology which delivers the world's fastest USB data transfer speed. According to
the below graph, it shows that the ASRock XFast USB technology can even boost USB 3.0 performance up
to 97.7%!
(The rear I/O photo is example only)

Intel®H67 Chipset
H67M-ITX
www.asrock.com
Support Intel®
K-Series unlocked CPU DuraCap
100% Japan-made high-quality
Conductive Polymer Capacitors

Free Gift
3D Red/Cyan Anaglyph Glasses
Intel®H67 Chipset
H67M-ITX
www.asrock.com
Free Gift
3D Red/Cyan Anaglyph Glasses
Undoubtedly, "jump-out-of -the-screen" stereoscopic 3D technology is a rising trend in entertainment.
In order to let our users experience 3D display in a simple way, ASRock specially provides a set of 3D
Red/Cyan anaglyph glasses in our package.
3D video systems are designed to duplicate this real-world experience by providing each eye a unique
version of the video. The 3D image is created by displaying a separate image for each eye. Objects in
a 3D video might appear to be in front of or behind the screen. To view 3D video, the display technol-
ogy and the corresponding 3D glasses insure that the left eye sees only the video meant for the left
eye, and so on for the right eye.
Mention 3D video, many people are of course familiar with 3D
glasses, one red and one blue, cyan or green lens. The
red/blue system is mainly used for traditional television and
computer 3-D effects, and was used in older 3-D movies.
These glasses use the anaglyphic method of displaying a 3D
image.
Anaglyph images are created by using color filters to remove a
portion of the visible color spectrum from the image meant for
each eye. When viewed through the color filters in the 3D
glasses, each eye only sees the image that contains the
portion of the color spectrum not filtered out by the lens. The
disadvantage of Anaglyphic 3D is obvious; the overall image
quality suffers as a large portion of the color spectrum is filtered
out of the image for each eye.
3D Video Systems and 3D Viewing
Anaglyphic 3D
INTEL®INTRU™ 3D
Stereoscopic 3D Blu-ray playback experience in
full HD 1080p resolution over HDMI 1.4a
Free Gift
3D Red/Cyan
Anaglyph Glasses
Enjoy 3D Display Now!
What You Need?
ASRock H67 MB Normal Monitor 3D Red/Cyan
Anaglyph Glasses
3D Red/Cyan Content Video
+ Normal Player
or
Blu-ray 3D Content Video
+ PowerDVD 10 Blu-ray 3D

Intel®H67 Chipset
H67M-ITX
www.asrock.com
UEFI – The Revolutionary BIOS Interface
AXTU – The All-in-1 Tuning Software
AXTU – The All-in-1 Tuning Software
UEFI – The Revolutionary BIOS Interface
ASRock Extreme Tuning Utility (AXTU) is an all-in-one software to fine-tune different features in an user-
friendly interface, which includes Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In
Hardware Monitor, it shows the major readings of your system. In Fan Control, it shows the fan speed and
temperature for you to adjust. In Overclocking, you are allowed to overclock the GT frequency which helps
to boost up the graphics performance and some voltage settings for optimal system performance.
In OC DNA, you can save your OC settings as a profile and share with your friends. Your friends then can
load the OC profile to their own system to get the same OC settings. In IES (Intelligent Energy Saver), the
voltage regulator can reduce the number of output phases to improve efficiency when the CPU cores are
idle without sacrificing computing performance.
Unified Extensible Firmware Interface (UEFI) is a
revolutionary BIOS utility which offers tweak-
friendly options in an advanced viewing interface.
Compared with traditional BIOS design, the latest
UEFI utility provides lots improved functions. The
major features of UEFI include:
1. Graphical Visual Experience – UEFI provides an
improved visual interface with colorful icons and
makes your computing environment more versatile
to replace the traditional dull BIOS page.
2. Mouse Enabling – Besides keyboard control,
you can freely use mouse to select your ideal
settings in UEFI as well.
3. Supports 3TB bootable HDD - UEFI breaks the
limitation of 2TB bootable HDD on traditional
BIOS. With UEFI, you can enjoy 3TB bootable
HDD size.
*Windows Vista-64bit or Windows 7-64bit OS is required

Intel®H67 Chipset
H67M-ITX
www.asrock.com
The Major Features of SmartView
Visual thumbnail images which categorize
and rank your frequently visited websites, as
well as provide a chronological view of your
browser history.
A persistent, real-time Facebook newsfeed
located within the Internet Explorer sidebar.
A "Friend Wall" that conveniently alphabet-
izes your Facebook friends by profile photo,
allowing immediate access to your friends'
profile pages.
Two mode options that allow you to choose your favored view style.
A "share this" button which allows you to
instantly and immediately share webpage posts
and links to your friends' Facebook pages.
A persistent search box from best-in-class search engines
such as Google, Yahoo, Baidu (China only) and Yandex
(Russia only).
Flow Mode Flow Mode
Experience the Brand New Browser Now
SmartView is the smart start page for IE that combines your most visited web sites, your history, your
Facebook friends and your real-time newsfeed into an enhanced view for a more personal Internet
experience. ASRock motherboards are exclusively equipped with the SmartView utility that helps you keep
in touch with friends on-the-go.
System Requirements
OS version: Win7 32/64 bit, Vista 32/64
bit�Browser version: IE8

Intel®H67 Chipset
H67M-ITX
www.asrock.com
CyberLink Power2Go 6.1 LE OEM
Power2Go 6 lets you burn and backup videos, photos, music and data onto Blu-ray
Discs and DVDs.
CyberLink MediaShow 4.1 SE OEM
Photo and video management software MediaShow edits videos and photos
instantly, creates slideshow, and allows publishing directly to YouTube and Flickr.
CyberLink PowerDVD 8.0 DTS Trial
World-renowned PowerDVD 8 DTS delivers outstanding DVD movie playback quality
on your PC.
CyberLink PowerDirector 8.0 Trial
PowerDirector - Video Editing software – edits high-definition videos including
AVCHD, allows output to PSP iPod and Blu-ray Disc.
CyberLink PowerBackup 2.5 Trial
PowerBackup backups valuable data on your PC.
Creative Sound Blaster X-Fi MB Trial
The Sound Blaster X-Fi MB solution provides premium audio quality, effects and
features for PC systems equipped with onboard audio.
For gamers, the EAX®ADVANCED HD 4.0, with its state-of-the-art Multi-Environment
rendering and reverb modelling, delivers a much more realistic and immersive 3D
gaming experience than your motherboard audio ever will.
