ASROCK X470D4U User manual

X470D4U
User Manual
Version 1.0
Published December 2018
Copyright©2018 ASRock Rack INC. All rights reserved.

Version 1.0
Published December 2018
Copyright©2018 ASRock Rack Inc. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or translated
in any language, in any form or by any means, except duplication of documentation by the
purchaser for backup purpose, without written consent of ASRock Rack Inc.
Products and corporate names appearing in this documentation may or may not be
registered trademarks or copyrights of their respective companies, and are used only for
identication or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock Rack. ASRock Rack assumes no responsibility
for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock Rack does not provide
warranty of any kind, either expressed or implied, including but not limited to the implied
warranties or conditions of merchantability or tness for a particular purpose.
In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for loss of
prots, loss of business, loss of data, interruption of business and the like), even if ASRock
Rack has been advised of the possibility of such damages arising from any defect or error
in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRock Rack’s Website: www.ASRockRack.com

Contact Information
If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re
welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you may contact
your dealer for further information.
ASRock Rack Incorporation
6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,
Taipei City 112, Taiwan (R.O.C.)

Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Unique Features 5
1.4 Motherboard Layout 6
1.5 Onboard LED Indicators 9
1.6 I/O Panel 11
1.7 Block Diagram 13
Chapter 2 Installation 14
2.1 Screw Holes 14
2.2 Pre-installation Precautions 14
2.3 Installing the CPU 15
2.4 Installing the CPU Fan and Heatsink 17
2.5 Installing Memory Modules (DIMM) 19
2.6 Expansion Slots (PCI Express Slots) 21
2.7 Jumpers Setup 22
2.8 Onboard Headers and Connectors 24
2.9 Dr. Debug 29
2.10 Unit Identication purpose LED/Switch 30
2.11 Driver Installation Guide 30
2.12 M.2_SSD (NGFF) Module Installation Guide 31
Chapter 3 UEFI Setup Utility 33
3.1 Introduction 33

3.1.1 UEFI Menu Bar 33
3.1.2 Navigation Keys 34
3.2 Main Screen 35
3.3 Advanced Screen 36
3.3.1 CPU Conguration 37
3.3.2 Chipset Conguration 38
3.3.3 Storage Conguration 39
3.3.4 ACPI Conguration 40
3.3.5 USB Conguration 41
3.3.6 Super IO Conguration 42
3.3.7 H/W Monitor 43
3.3.8 AMD CBS 45
3.3.9 AMD PBS 46
3.3.10 Instant Flash 49
3.4 Server Mgmt 50
3.4.1 System Event Log 51
3.4.2 BMC Network Conguration 52
3.5 Security 54
3.5.1 Key Management 55
3.6 Boot Screen 58
3.6.1 CSM Parameters 60
3.7 Exit Screen 62
Chapter 4 Software Support 63
4.1 Install Operating System 63

4.2 Support CD Information 63
4.2.1 Running The Support CD 63
4.2.2 Drivers Menu 63
4.2.3 Utilities Menu 63
4.2.4 Contact Information 63
Chapter 5 Troubleshooting 64
5.1 Troubleshooting Procedures 64
5.2 Technical Support Procedures 66
5.3 Returning Merchandise for Service 66

X470D4U
PB 1
English
Chapter 1 Introduction
ank you for purchasing ASRock Rack X470D4U motherboard, a reliable
motherboard produced under ASRock Rack’s consistently stringent quality control.
It delivers excellent performance with robust design conforming to ASRock Rack’s
commitment to quality and endurance.
In this manual, chapter 1 and 2 contains introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration
guide to BIOS setup and information of the Support CD.
1.1 Package Contents
• ASRock Rack X470D4U Motherboard
(micro-ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm)
• Quick Installation Guide
• 1 x I/O Shield
• 1 x SATA3 Cable (60cm)
• 2 x Screws for M.2 Sockets
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/

2 3
English
1.2 Specications
X470D4U
MB Physical Status
Form Factor micro-ATX
Dimension 9.6'' x 9.6'' (24.4 cm x 24.4 cm)
Processor System
CPU AMD AM4 Socket Ryzen Series CPUs (Raven Ridge and
Pinnacle Ridge) and Ryzen 7nm CPUs
Socket AM4 PGA 1331
Chipset AMD X470
System Memory
Capacity - 4 x 288-pin DDR4 DIMM slots
- Support up to 64GB DDR4 ECC/UDIMM
- One DIMM: 1R DIMM @2667MT/s; 2R/2DR DIMM
@2400MT/s
- Two DIMMs: (2) 1R DIMM @2133 MT/s; (2) 2R/2DR DIMM
@1866MT/s; 1R and 2R/2DR DIMM each @1866MT/s
Type - Dual Channel DDR4 memory technology
- Support DDR4 ECC/UDIMM
DIMM Size Per
DIMM
- ECC/UDIMM: 64GB, 32GB, 16GB, 8GB
DIMM Frequency - ECC/UDIMM: 2666/2400/2133 MHz
Voltage 1.2V
Expansion Slot
PCIe 3.0 x 16 PCIE6: Gen3 x16 link (splittable in x4/4/4/4); auto switch to x8
link when PCIE4 is occupied.
PCIE4: Gen3 x8 link
PCIe 3.0 x 8 PCIE5: Gen3 x4 link
Storage
SATA Controller 6 x SATA3 6.0 Gb/s (1x SATA DOM port)
Additional SATA
Controller
Asmedia 1061: 2 x SATA3 6.0 Gb/s
M.2 Slot 2 (2242/2260/2280/22110, supports SATA3 and PCIe 3.0 x2 or
supports PCIe 2.0 x4 only)
Ethernet
Interface 1000 /100 /10 Mbps by Intel i210

X470D4U
2 3
English
LAN Controller - 2 x RJ45 GLAN by Intel® i210
- 1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller ASPEED AST2500
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features Watch Dog
Graphics
Controller ASPEED AST2500
VRAM DDR4 256MB
Rear Panel I/O
VGA Port 1 x D-Sub
Serial port 1 x COM port
USB 3.0 Port 2
LAN Port - 2 x RJ45 Gigabit Ethernet LAN ports
- 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID 1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, and front
LAN LED)
TPM Header 1
IPMB Header 1
Fan Header 6 Fans x 4-pin (FAN1(CPU)/FAN2~FAN6(5Front))
ATX Power 1 x (24-pin) + 1 x (8-pin)
USB 3.1 Gen1
Header
1 (supports 2 USB 3.1 Gen1 ports)
M.2 2(M2_1: 2242/2260/2280/22110, PCIE(X4);
M2_2:2242/2260/2280/22110, SATA/PCIE(X2))
SATA DOM 1
BMC_SMB1 1
PSU_SMB1 1
80 debug port LED 1
Buzzer 1
Clear CMOS 1 (short pad)
OH/FanFail LED 6 (only Fan Fail LED)
System BIOS
BIOS Type 16MB AMI UEFI Legal BIOS

4 5
English
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU/DDR temperature sensing
- MB/Card side temperature sensing
Fan - Fan Tachometer
- Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU
Temperature)
- Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows®:
Windows 10 (64 bit)
Linux®:
- UBuntu 16.04.4 (64 bit)
- RedHat Enterprise Linux Server 7.3 (64bit) / 7.4 (64bit)
* Please refer to our website for the latest OS support list.
*e Linux system doesn’t support Raid mode.
*Supports UEFI BOOT only.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
NOTE: Please refer to our website for the latest specications.
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.

X470D4U
4 5
English
1.3 Unique Features
ASRock Rack Instant Flash is a BIOS ash utility embedded in Flash ROM. is con-
venient BIOS update tool allows you to update system BIOS without entering operat-
ing systems rst like MS-DOS or Windows®. With this utility, you can press the <F6>
key during the POST or the <F2> key to enter into the BIOS setup menu to access
ASRock Rack Instant Flash. Just launch this tool and save the new BIOS le to your
USB ash drive, oppy disk or hard drive, then you can update your BIOS only in a
few clicks without preparing an additional oppy diskette or other complicated ash
utility. Please be noted that the USB ash drive or hard drive must use FAT32/16/12
le system.

6 7
English
1.4 Motherboard Layout
24.4cm (9.6 in)
24.4cm (9.6 in)
ATXPWR1
VGA1 COM1
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin moule)
ATX12V1
USB 3.1
Gen1
T: USB2
B: USB1
IPMI_LAN
LAN1
LAN2
UID1
USB3_3_4
PCIE5
PCIE6
PCIE4
M2_2 M2_1
NUT42_2
NUT60_2
NUT80_2
1
SATAPWR1
SATA3_1
ASPEED
2500
X470D4U
BMC
F/W
Socket
AM4 PGA 1331
1
PSU_SMB1
NUT110_2
FAN4
FAN3
FAN2
FAN1
NUT42_1
NUT60_1
NUT80_1
NUT110_1
SATA3_0
SATA3_3
SATA3_2
SATA3_5
SATA3_4
SATA3_9
SATA3_8
CLRMOS1
1
AUX_PANEL1
HDLED RESET
PLED PWRBTN
PANEL1
1
Dr.
Debug
BAT1
1
TPMS1
FAN5
FAN6
1
CHASSIS_ID1
1
CHASSIS_ID2
1
CHASSIS_ID3
1
1
IPMB_1
BMC_SMB_1
BUZZER1
1
PWM_CFG1
RoHS
23 1 4
8
7
9
10
11
12
13
14
16
17
18
19
20
21
22
23
15
242526272829303132
5
6
34
33

X470D4U
6 7
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1, Blue)*
3 PSU SMBus Header (PSU_SMB1)
4 ATX Power Connector (ATXPWR1)
5 Front Fan Connector (FAN3)
6 Front Fan Connector (FAN4)
7 Front Fan Connector (FAN2)
8 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2, White)*
9 CPU Fan Connector (FAN1)
10 AM4 PGA 1331 Socket
11 M.2 Socket (M2_2) (Type 2242 / 2260 / 2280 / 22110)
12 M.2 Socket (M2_1) (Type 2242 / 2260 / 2280 / 22110)
13 SATA3 Connector (SATA3_1)
14 SATA3 DOM Connector (SATA3_0), Red*
15 SATA DOM Power Jumper (SATAPWR1)
16 USB 3.1 Gen1 Header (USB3_3_4)
17 SATA3 Connector (SATA3_2)
18 SATA3 Connector (SATA3_3)
19 SATA3 Connector (SATA3_5)
20 SATA3 Connector (SATA3_4)
21 SATA3 Connector (SATA3_8)
22 SATA3 Connector (SATA3_9)
23 Clear CMOS Pad (CLRMOS1)
24 System Panel Header (PANEL1)
25 Auxiliary Panel Header (AUX_PANEL1)
26 TPM Header (TPMS1)
27 Front Fan Connector (FAN5)
28 Front Fan Connector (FAN6)
29 Chassis ID3 Jumper (CHASSIS_ID3)
30 Chassis ID1 Jumper (CHASSIS_ID1)
31 Chassis ID2 Jumper (CHASSIS_ID2)
32 BMC SMBus Header (BMC_SMB_1)
33 Intelligent Platform Management Bus header (IPMB1)

8 9
English
No. Description
34 PWM Conguration Header (PWM_CFG1)
*For DIMM installation and conguration instructions, please see p.20 (Installation of Memory Modules
(DIMM)) for more details.

X470D4U
8 9
English
1.5 Onboard LED Indicators
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin moule)
ATX12V1
USB3_3_4
M2_2 M2_1
NUT42_2
NUT60_2
NUT80_2
1
SATAPWR1
SATA3_1
ASPEED
2500
X470D4U
BMC
F/W
1
PSU_SMB1
NUT110_2
FAN4
FAN3
FAN2
FAN1
NUT42_1
NUT60_1
NUT80_1
NUT110_1
SATA3_0
1
AUX_PANEL1
HDLED RESET
PLED PWRBTN
PANEL1
1
Dr.
Debug
BAT1
1
TPMS1
FAN5
FAN6
1
CHASSIS_ID1
1
CHASSIS_ID2
1
CHASSIS_ID3
1
1
IPMB_1
BMC_SMB_1
1
PWM_CFG1
RoHS
2
3
1
4
5
67
8
SATA3_3
SATA3_2
SATA3_5
SATA3_4
SATA3_9
SATA3_8
CLRMOS1

10 11
English
No. Item Status Description
1 SB_PWR1 Green STB PWR ready
2FAN_LED4 Amber FAN4 failed
3FAN_LED3 Amber FAN3 failed
4FAN_LED2 Amber FAN2 failed
5FAN_LED1 Amber FAN1(CPU) failed
6FAN_LED5 Amber FAN5 failed
7FAN_LED6 Amber FAN6 failed
8BMC_LED1 Green BMC heartbeat LED

X470D4U
10 11
English
1.6 I/O Panel
2
3
16
7
45
No. Description No. Description
1 UID Switch (UID1) 5 GLAN RJ-45 Port (LAN2)**
2VGA Port (VGA1) 6 USB 3.1 Gen1 Ports (USB3_1_2)
3 Serial Port (COM1) 7 LAN RJ-45 Port (IPMI_LAN1)*
4 GLAN RJ-45 Port (LAN1)**
*ere are two LED next to the LAN port. Please refer to the table below for the LAN port
LED indications.
Dedicated IPMI LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10M bps connection or no
link
Blinking Yellow Data Activity Yellow 100M bps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

12 13
English
**ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
LAN Port (LAN1, LAN2) LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection or
no link
Blinking Green Data Activity O 100Mbps connection
On Link Yel low 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

X470D4U
12 13
English
1.7 Block Diagram
IPMI
ASPEED
AST2500
4x SATAIII
PCIeUSB
MAC
U AR T
RTL
8211E
MAC
VGA
RGMII
USB2.0 PCIe2.0 x1
LPC/eSPI
SPI
D-Sub
AMD
X470
BIOS
Switch
2xUSB3.0, 2xUSB2.0
2xUSB3.0, 2xUSB2.0
PCIe2.0x1
NCT6779D-R
PCIe2.0x1
PCIe2.0x1
DDR4 DDR4
A
B
AMD Ryzen™
2nd Generation
Processor
AMD AM4 Socket
PGA 1331
TDP: max. 105W
PCIe3.0x8
NCSI
i210 i210
SLOT6 x16
PCIe3.0x8
PCIe
MUX
8
SLOT4 x8
ASM
1061
LPC
2x SATAIII
PCIe2.0 x4
PCIe3.0 x2/SATAIII
COM port
2x SATAIII
SLOT5 x4 PCIe3.0x4
SLOT4 x8

14 15
English
Chapter 2 Installation
This is a micro-ATX form factor (9.6” x 9.6”, 24.4 cm x 24.4 cm) motherboard. Before
you install the motherboard, study the conguration of your chassis to ensure that the
motherboard ts into it.
2.1 Screw Holes
Place screws into the holes indicated by circles to secure the motherboard to the chassis.
Attention! Before installing this motherboard, be sure to unscrew and remove the standos
at the marked location, under the motherboard, from the chassis, in order to avoid electri-
cal short circuit and damage to your motherboard.
Make sure to unplug the power cord before installing or removing the motherboard. Failure
to do so may cause physical injuries to you and damages to motherboard components.
Do not over-tighten the screws! Doing so may damage the motherboard.
2.2 Pre-installation Precautions
Take note of the following precautions before you install motherboard components or
change any motherboard settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the motherboard’s components due to static electricity, NEVER
place your motherboard directly on the carpet or the like. Also remember to use a
grounded wrist strap or touch a safety grounded object before you handle the compo-
nents.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in
the bag that comes with the component.
5. When placing screws into the screw holes to secure the motherboard to the chassis,
please do not over-tighten the screws! Doing so may damage the motherboard.
Before you install or remove any component, ensure that the power is switched o or the
power cord is detached from the power supply. Failure to do so may cause severe damage to
the motherboard, peripherals, and/or components.
