Aswar AS-HDV-20F User manual

AS-HDV-
20m Outdoor Bullet Camera
Before providing power for the camera, please read this
user guide.
Do not attempt to disassemble the camera. If the
camera does not work, please contact us or your local
distributor.
www.aswar-g.com
www.facebook.com/aswarME
www.twitter.com/aswarME
SPECIFICATIONS
FEATURES
DISTRIBUTED BY:
NOTES:
Model Number AS-HDV-
Outdoor bullet camera
1080P Resolution Camera
20m IR distance
Thank you for using our product.
20F
Image Sensor 1/3" Aptina 3.1MP CMOS Sensor
Resolution 3MP
Signal System PAL / NTSC
Minimum Illumination 0.01Lux/F1.2
S/N Ratio More than 45dB
Synchronous System Internal
IR Distance 20 Meters
IR Power On Photodiode AUTO Control
Video Output TVI / AHD
Power/Current DC12V(+/550/(%10-mA
Lens Board Len 3.6mm
Weather Proof IP66
Dimension (mm) 220(W) x 65(H) x 55(D)
Weight (g) 550
Operating Conditions 50+~10-℃RH%95 MAX
20F

OSD MENU CONNECTIONS INTRODUCTION
TROUBLESHOOTING
SCHEMATICS
3D-NR ON/OFF
AE MODE
intelligent / global / center
center weight / black light
front / light / distinguish
WB
AWB-PRO / AWB-TEMPORAL
AWB-AI / AWB-GW
AWB-CCT
ENHANCE
sharpness / contrast /
saturation
MIRROR ON / OFF
FLIP ON / OFF
BRIGHTNESS 250 ...,20 ,10 ,0
ZOOM IN 5 ,4 ,3 ,2 ,1 ,0
DAY&NIGHT external / color / B&W / auto
ZONE
MASKING
COLOR
mosaic / white / yellow / cyan
green / magenta / red / blue /
black
AREA NO.0 - AREA NO.8
MOTION
DIRECTION
SENSITIVITY weak / low / middle / high
AREA NO.0 - AREA NO.4
VIDEO
STANDARD PAL / NTSC
LANGUAGE CHINESE / ENGLISH
LOAD DEFAULT
SOFT VERSION
SAVE&EXIT
EXIT
VIDEO
DC12V
DC12V POWER SUPPLY
AS-HDV-20F
KEYBOARD
PRESS
MENU
1. NO VIDEO OUTPUT AFTER PROVIDING POWER
Check power supply stability
Check power supply polarity
Check video cable signal from camera to DVR using a
ASWAR CCTV tester
Test camera output directly from camera to ASWAR CCTV
tester to ensure video cable and termination is correct
2. FLOWING INTERFERENCE RIPPLES ON VIDEO OUTPUT
Caused by power supply AC ripples, change power supply
Check monitor and DVR
3. CONTINUOUSLY CHANGING VIDEO BACKGROUND
COLORS
increase distance between lighting and camera
Use external synchronization on power supply
4. PICTURE SMEAR
Unstable power supply voltage, change the power supply
High impedance on cables, check cable quality and
termination
Congratulations for purchasing a ASWAR product. The AS-
HDV-20FHDV series is a feature-full product that adopts
the latest Sony sensor chip and driver. This camera enjoys
high resolution and real-time video capturing that is rich in color
and quality. It is also easy to install with a built-in -3axis bracket
making it both wall mount and ceiling mount.
“Please read this instruction manual carefully to ensure proper use of
the product.”
Please note the camera’s storage and operating temperature
Avoid using the camera in environments of very high or very
low temperatures.
The operating temperature is °30-C to °60+C
(Recommended operating temperature is °10-C to °50+C)
Never make the camera face the sun or a bright object.
Do not mount the camera near by the radiator or heater.
Do not attempt to disassemble the camera. If the camera
does not work, please contact local distributor or our
company
CAUTION: RISK OF ELECTRIC
SHOCK, DO NOT OPEN
NOTES:
DVR
POLARITY GUIDE
GND VIDEO VIDEO
POWER
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER OR BACK. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION: TO PREVENT ELECTRIC SHOCKS AND
RISK OF FIRE HAZARDS, DO NOT USE OTHER THAN
SPECIFIED POWER SOURCE.
