ATO DYB-63A User manual

LIMITED 1 YEAR WARRANTY
We make every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials
and workmanship for the period of one year from the date of purchase(90 days if used by a
professional contractor or if used as rental equipment). This warranty does not apply to
damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or
alterations outside our facilities, normal wear and tear, or to lack of maintenance. We shall
in no event be liable for death, injuries to persons or property, or for incidental, contingent,
special or consequential damages arising from the use of our product. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above
limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with
transportation charges prepaid. Proof of purchase date and an explanation of the complaint
must accompany the merchandise. If our inspection verifies the defect, we will either
repair or replace the product at our election or we may elect to refund the purchase price if
we cannot readily and quickly provide you with a replacement. We will return repaired
products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning
the product.
The warranty gives you specific legal rights and you may also have other rights which
vary from place to place.
Instruction Manual
HYDRAULIC ELECTRIC PUMP
Due to continuing improvements, actual product may differ
slightly from the product described herein.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL
www.ato.com [email protected] 800-585-1519 Global Shipping

OPERATION INSTRUCTION
I. Product description
Super-high Pressure Electric Oil pump features small Volume,
high pressure.
Compact structure, light weight and easy operation and
maintenance. This product can be widely used as hydraulic
source for various hydraulic apparatus in addition to the high,
middle and low pressure testing hydraulic source. It may be
used together with these tools or machines of crane, form
pressing, pipe bending, aligning, unloading machine, pipe
cutter and punching.
II. Main technical parameters:
Rated pressure: 70Mpa
Voltage: 220VV/380V (can be customized)
Power: 750W/1500W/3000W Frequency: 50/60 Hz
Oil Storage: 7 L/10L/30L
REV: 1400r/min
Oil Type: Grade 8#/10#/15# Hydraulic Oil
Fill Oil Before Start Motor
III. Structure
1. Oil tank 7.Motor
2. High-pressure oil pipe 8.Voltmeter
3. Hydraulic apparatus cylinder 9.Meter support, pipe
nut
4. Switch handle 10.Oil filler cover
6. Motor switch 11.Oil level
www.ato.com [email protected] 800-585-1519 Global Shipping

IV Application
Keep the oil filler cover (10) open when using to ventilate the
tank, rotate the switch handle(4) on offload state, and connect
the high-pressure oil pipe(2) with matched hydraulic
apparatus(3), start-up the motor(7) for oil supply; then turn the
switch handle to pressure ousting state and the oil pump
begins to supply oil to hydraulic apparatus. The oil pressure
will be boosting as the increasing load till the work is finished.
V. Precautions:
1. The medium used in this oil pump is Grade 8 hydraulic oil.
2. The oil storage must reach above the oil level line.
3. Use 80 meshes or above filter when fill ling oil; replace the
oil and clean the tank every three months.
4. The oil in the apparatus cylinder shall be 8# machine oil and
it should be clean.
5. Please stop the pump when it’s found the motor us
overheated because of a continuous high pressure (70Mpa ).
6. The pressure of the relief safety valve (5) has been
adjusted as 70Mpa. Please do not adjust the pressure at will.
If necessary, please turn to professional technician with a
voltmeter (8) and the pressure should be kept within 70Mpa to
avoid any damage.
VI Packing list
No.
Name
Spec
Unit
Qty
1
Electric pump
DYB-63A
HHB-700AB
HHB-700A
HHB-700D3
QQ-700
DB075-D2
DB150-D3
DB150-D2B
DB150-D2
DB150-D1
DB150-S2
DB300-S2
DB300-D1
DB300-D2
High Pressure:70Mpa
0.75Kw
High Pressure Stage:0.9L/Min
Low Pressure Stage:5L/min.
1.5Kw
High Pressure Stage:1.7L/Min
Low Pressure Stage:7.9L/min.
3Kw
High Pressure Stage:2.8L/Min
Low Pressure Stage:14L/min.
Set
1
2
High pressure hose
1800mm
Set
1
3
Instructions
Set
1
4
Certificate of
inspection
Set
1
www.ato.com [email protected] 800-585-1519 Global Shipping

FAULT ANALYSIS SOLUTION
A. Motor
abnormalit
y
1. The motor does
not rotate
2. The motor
speed is very
slow
Check power supply, switch
B. Pressure
abnormalit
y
1. High pressure
relief valve out
of adjustment
2. Solenoid valve
oil leakage
3. Plunger wear
4. Leakage of
pump body
sealing bolt
1. Adjust the high pressure
relief valve Return tool to
manufacture or distributor
2. Cleaning the inside of the
valve block and the
solenoid core
3. Change plunge
4. Tighten the bolt or change
the gasket
C. Insufficient
flow
1. Some plungers
are not working
2. Hydraulic oil
concentration
is too high
3. High and low
pressure
distribution
valve oil
leakage
1. Cleaning oil pump
2. Change the hydraulic oil
3. Grinding the seat to
change the spool
TROUBLESHOOTING
www.ato.com [email protected] 800-585-1519 Global Shipping

SAVE THIS MANUAL
Keep this manual for the safety warnings and precautions, assembly, operating,
inspection,
maintenance and cleaning procedures. Write the month and year of purchase. Keep this
manual and the receipt in a safe and dry place for future reference.
IMPORTANT SAFETY INFORMATION
In this manual, on the labeling, and all other information
provided with this product:
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER indicates a hazardous situation which,
if not avoided, will result in death or serious injury.
WARNING indicates a hazardous situation which,
if not avoided, could result in death or serious injury.
CAUTION, used with the safety alert symbol,
indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
