ATS E6501S User manual

- Page 1 -
User’s Manual
for the
ATS E6501S
For use with Internet Phone service by SunRocket
Expandable DECT 6.0 Cordless Internet Phone
with Adapter and Router Built In
Specific instructions for the addition of expansion handsets
(model E6502S) may be found on page 72???.
To enjoy all the benefits of this product, please review
the information contained in this manual

- Page 2 -
Table of Contents
Important Safety Instructions.............................................................................................. 4
Safety Instructions for Handset Battery Pack ..................................................................... 5
FCC Statement .................................................................................................................... 5
Package Includes (Parts List) for E6501S (Master unit) .................................................... 6
Package Includes (Parts List) for E6502S (Handset + Charger only) ................................ 6
SPECIAL ATTENTION TO E6502S (Handset + Charger only)....................................... 6
Handset and Base Layouts.................................................................................................. 7
Handset LCD Display......................................................................................................... 9
Chapter 1: Introduction ..................................................................................................... 10
Chapter 2: Connect the E6501S........................................................................................ 11
Overview....................................................................................................................... 11
Connecting Your Hardware Together........................................................................... 13
Chapter 3: Setup the Handset............................................................................................ 14
Chapter 4: Configure your PC .......................................................................................... 15
Overview....................................................................................................................... 15
Configuring Windows 95, 98, and Millennium PCs..................................................... 15
Configuring Windows 2000 PCs .................................................................................. 18
Configuring Windows XP PCs ..................................................................................... 20
Integrated Cable Modems/Routers ............................................................................... 24
Connect E6501S behind an existing router................................................................... 25
Chapter 5: Configure E6501S router ................................................................................ 26
Chapter 6: Advanced Configuration of E6501S ............................................................... 29
Status............................................................................................................................. 29
Network – WAN Config............................................................................................... 30
Network – LAN Config ................................................................................................ 32
Chapter 7: Voice Features and Operations ....................................................................... 33
Basic Operation.................................................................................................................33
Power on operation..................................................................................................... 33
Making VoIP calls....................................................................................................... 34
Receiving external Call............................................................................................... 36
Making internal calls.................................................................................................. 37
Receiving internal Call............................................................................................... 38
Terminating a call ......................................................................................................... 38
Joining two external calls........................................................................................... 39
Mute ............................................................................................................................. 40
Handset speakerphone................................................................................................ 40
Changing Volume........................................................................................................ 41
Low battery Warning................................................................................................. 41
Out of range warning.................................................................................................. 42
Battery charging.......................................................................................................... 42
Paging function............................................................................................................ 42
Base Unit Status Indication............................................................................................... 43
Handset Status Indication ................................................................................................. 43

- Page 3 -
Audible Alerts................................................................................................................... 44
Troubleshooting ................................................................................................................ 45
Consumer Information ...................................................................................................... 46
Limited Warranty.............................................................................................................. 47

- Page 4 -
Important Safety Instructions
BEFORE USING YOUR TELEPHONE EQUIPMENT, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK AND INJURY TO PERSON, INCLUDING THE FOLLOWING
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink,
laundry tub, in a wet basement, or near a swimming pool.
5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing
serious damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation. To
protect it from overheating, these openings must not be blocked or covered. The openings
should never be blocked by placing the product on the bed, sofa, rug, or other similar surface.
This product should never be placed near or over a radiator or heat register. This product
should not be placed in a built-in installation unless proper ventilation is provided.
7. This product should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to your home, consult your dealer or local
power company.
8. Do not allow anything to rest on the power cord. Do not locate this product where the cord will
be damaged by persons walking on it.
9. Do not overload wall outlet extension cords, as this can result in the risk of fire or electric shock.
10. Never push objects of any kind into this product through cabinet slots as they may touch
dangerous voltage points or short out parts that could result in a risk of fire or electric shock.
Never spill liquid of any kind on this product.
11. To reduce the risk of electric shock, do not disassemble this product. Instead, when some repair
work is required, take the unit to a qualified technician. Opening or removing covers may
expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric shock
when the appliance is subsequently used.
12. Unplug this product from the wall outlet and refer servicing to qualified service personnel
under the following conditions:
a. When the power supply cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions because improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician to
restore the product to normal operation.
e. If the product has been dropped or cabinet has be damaged.
f. If the product exhibits a distinct change in performance.
13. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a
remote risk of electrical shock from lightning.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
15. This power unit is intended to be correctly oriented in a vertical or floor mount position.
16. Use only with Class 2 (Classe 2) power source 7VDC 1A
SAVE THESE INSTRUCTIONS

- Page 5 -
Safety Instructions for Handset Battery Pack
CAUTION:
There is a danger of explosion if the battery is incorrectly replaced. Use only an approved battery pack in
the handset of your Cordless Telephone. To reduce the risk of fire or injury, always do the following when
replacing, discarding, or charging battery, when handling the batteries, be careful not to short the battery
with conducting materials such as rings, bracelets, and keys. The Battery or conducting material may
overheat and cause burns. Use only the following type and size of battery pack:
FOR HANDSET UNIT:
GP60AAAH3BMX 3.6V 600mAh GPI INTERNATIONAL LIMITED
CONTAINS NICKEL-METAL HYDRIDE BATTERY. BATTERY
MUST BE RECYCLED OR DISPOSED OF PROPERLY
1. Do not dispose of the battery in a fire. The cell may explode. Check with local codes for possible
special disposal instructions.
2. Do not open or mutilate the battery. Released electrolyte is corrosive and may cause damage to
the eyes or skin. It may be toxic if swallowed.
3. Exercise care in handling batteries in order not to short the battery with conducting materials
such as rings, bracelets and keys. The battery or conductor may overheat and cause burns.
4. Charge the batteries provided with or identified for use with this product only in accordance
with the instructions and limitations specified in this manual.
5. Observe proper polarity orientation between the battery(ies) and battery charger.
6. Do not mix old and new batteries in this product.
7. Do not mix batteries of different sizes or from different manufacturers in this product.
SAVE THESE INSTRUCTIONS
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

- Page 6 -
Package Includes (Parts List) for E6501S (Master unit)
• Master Base
• Handset
• Ethernet cable
• Battery pack
• 7V Switching Power adapter
Package Includes (Parts List) for E6502S (Handset +
Charger only)
• Handset
• Battery pack
• Charger
• 9VDC Power adaptor
SPECIAL ATTENTION TO E6502S (Handset + Charger
only)
• The handset works ONLY if you have purchased an ATS master unit (model
E6501S)
• To register the new handset to the master base, please refer to the section
“Registration of Expansion Handset with the Base” found on page 72???.

- Page 7 -
Handset and Base Layouts
1 Keypad (0-9; *; #) 9 Redial/Pause
2 Program 10 End Call (Onhook)
3 Handsfree (Speakerphone) 11 Cancel
4 Delete/Clear 12 Start Call (Offhook)
5 Navigation Keys 13 Intercom
6LCD 14VoiceMail
7 Receiver 15 Microphone
8 Message Waiting Indicator 16 Flash

- Page 8 -
17 Charge Cradle 19 In Use Indicator
18 Page Key 20 Message Waiting Indicator

- Page 9 -
Handset LCD Display
1. In Service icon (displayed when Handset is ‘in range’ of the Base)
2. Off Hook icon (displayed when Handset is on an external or intercom call)
3. Caller ID Time
4. Caller ID Date
5. Key lock icon (displayed when user locks the keypad)
6. Battery icon (battery level is shown)
7. Ringer OFF icon (displayed when user turns the ringer off)
8. Microphone Mute icon (displayed when microphone is set to mute)
9. Speakerphone icon (displayed when speakerphone is on)
10. Left / Right arrow icons (displayed to indicate the contents on LCD left / right)

- Page 10 -
Chapter 1: Introduction
Your E6501S package should include these items:
• E6501S base unit
• One Cordless handset
• One 3-meter Ethernet cable
• 7V switching Adapter
• User Guide and Safety Instructions
• SunRocket install steps
• SunRocket service plan and features
• SunRocket subscriber agreement
• American Telecom warranty card
• SunRocket 911 information
This user guide explains the basic steps for setting up, configuring, and operating the
telephone features of the E6501S:
• Chapter 2: Connect the E6501S – this chapter covers how to connect the
E6501S to your cable or DSL modem and your PC(s).
• Chapter 3: Setup the Handset – this chapter covers how to setup your handset
for use with the E6501S.
• Chapter 4: Configure your PC – this chapter covers how to configure your PC
to properly connect to the E6501S.
• Chapter 5: Configure your E6501S – this chapter covers how to configure the
E6501S’s basic router using a web-based utility.
• Chapter 6: Advanced Configuration of E6501S – this chapter covers the many
advanced router features that are available on your E6501S.
• Chapter 7: Voice Telephone Features and Operations – this chapter covers the
many voice features that are available on your E6501S.
Be sure to follow the instructions in Chapters 2 through 5 to insure that you are ready to
connect to the internet and establish both voice and data service on your new E6501S.

- Page 11 -
Chapter 2: Connect the E6501S
Overview
The rear panel of the E6501S base is where both power adaptor and Ethernet cables are
connected:
LAN The LAN (Local Area Network) port is where you
connect the cable to your PC.
WAN The WAN (Wide Area Network) port is where you
connect the cable to your cable or DSL modem.
7V DC The 7V DC port is where you connect the cable from
your 7V switching adapter.
The best way to connect the E6501S depends upon your pre-existing network
configuration. If you don’t already own a router, or if your cable/DSL modem has an
integrated router, you should use the configuration shown below for connecting your
E6501S.

- Page 12 -
If you already own a router and you would like to continue using it, it is possible to put
E6501S in a series connection with the existing router as shown in below diagram.

- Page 13 -
Connecting Your Hardware Together
1. Before you begin, make sure all of the hardware you will be connecting is
powered off.
2. Connect an Ethernet cable from the DSL or Cable modem (which may have an
integrated router) to the WAN port on the back of the E6501S.
3. If you have a PC to connect to the E6501S, connect an Ethernet cable to the LAN
port on the back of the E6501S and the other end of the cable to the LAN port on
your PC’s Ethernet adapter.
4. If you have an existing Router you would like to continue to use, connect one end
of an Ethernet cable to the WAN port on the back of the E6501S and the other
end of the cable to one of the LAN ports on the router.
5. Make sure all devices are properly connected. Connect the power connector from
your 7V switching adapter to the port labeled “7V DC” on the back of the E6501S.
Plug the adapter into a wall outlet.
6. Power on the other devices that you have connected.
Your E6501S is now ready for configuration (Chapter 4), but first you will need to setup
and begin charging the handset.

- Page 14 -
Chapter 3: Setup the Handset
Follow these steps to install your battery and attach the optional belt clip:
1. Open the battery compartment by sliding the cover down.
2. Plug the Battery Pack connector into the Handset socket, then place the battery
pack and wires in the compartment.
3. Slide the battery cover back into place.
4. Place the handset in the base unit to begin charging. The unit should charge for
12 hours before first use. Note that it is normal for the battery compartment area
to become warm during charging.

- Page 15 -
Chapter 4: Configure your PC
Overview
The instructions in this chapter will help you configure each of your computers to be able
to communicate with the E6501S. If you are re-using an existing router, please skip ahead
to the section, “Connect E6501S behind an existing router” later in this chapter.
To communicate with the router in the E6501S, your PCs must be configured to obtain an
IP address automatically from the E6501S. This IP address helps the computer
communicate across the Internet. It is quite likely that your computers are already
configured that way, but the following instructions will help you make sure that is true.
Find out what operating system your computers are using and skip ahead to the
appropriate section of this chapter that applies to you. You can find out what operating
system you are running, such as Windows 95, 98, Millennium, 2000, or XP by:
• Windows XP: Click on the Start button, then Control Panel then click on
System.
• All other Windows Operating Systems: Click on the Start button and then
Settings and then click on Control Panel. Finally double click on System.
• All other Operating Systems (Including Mac): Please see your system manual
for instructions on enabling DHCP on your Ethernet interface.
For the Windows OS, click cancel after you have identified your operating system.
Configuring Windows 95, 98, and Millennium PCs
1. Go to the Network page by clicking on Start and then Settings. Click on
Control Panel and then double-click on the Network icon to open the window
below:

- Page 16 -
2. Select the TCP/IP line in the list that is associated with your Ethernet Adapter
and click on the Properties button to open the window below:

- Page 17 -
3. Now click on the Gateway tab to open the window below:

- Page 18 -
4. Remove any Installed gateways by clicking on the Remove button and then click
on OK.
5. Click the OK button again. Windows may ask you to take additional steps at this
point.
6. Finally, restart your PC if you have not already done so.
Configuring Windows 2000 PCs
These instructions assume you are running windows XP with the default interface. If you
are using the Classic Interface, please follow the instructions for Windows 2000.
1. Find the Local Area Connection Status screen by clicking the Start button and
then click on Settings and then Control Panel. From there, double click the
Network and Dial-up Connections Icon, and finally the Local Area
Connection item in the window that opens to see the window below (you may
have several local area connection choices- choose the one that has your Ethernet
adapter in the Device Name field):

- Page 19 -
2. Click the properties icon to see the window below and then select the item
“Internet Protocol (TCP/IP)” from the list.
3. Click on the
Properties button to see the window below:

- Page 20 -
4. Select the items “Obtain an IP address automatically” and “Obtain DNS
server address automatically” and then click OK. Click OK or Close button
again to complete the setup.
Configuring Windows XP PCs
These instructions assume you are running windows XP with the default interface. If you
are using the Classic Interface, please follow the instructions for Windows 2000.
5. Find the Local Area Connection Status screen by clicking the Start button and
then click on Control Panel. From there, click the Network Connections Icon,
and finally the Local Area Connection item in the window that opens to see the
window below:
