Audiolab 6000CDT User manual

Page 1
1: Important Safety Information
IMPORTANT SAFETY INFORMATION
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR
WARNING: SHOCK HAZARD-DO NOT OPEN
This lightning with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous voltage” within the
constitute a risk of electric shock.
Warning: To reduce the risk of electric shock, do not remove
cover (or back) as there are no user-serviceable parts inside.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance instructions in the literature
accompanying the appliance.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat
that produce heat.
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding plug has two blades
and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does
-
ment of the obsolete outlet.
Protect the power cord from being walked on or pinched
particularly at the plugs, convenience receptacles, and at
the point where they exit from the apparatus.
Use only with the cart, stand, tripod, bracket,
sold with the apparatus. When a cart or rack
is used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
required when the apparatus has been damaged in any
way, such as power supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
CAUTION: These servicing instructions are for use by
electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are
such as a bookcase or similar unit, and keep well ventilated
in open space. The ventilation should not be impeded by
covering the ventilation openings with items such as
newspaper, table-cloths, curtains etc.
WARNING: or
provided by the manufacturer (such as the exclusive supply
adapter, etc).
WARNING: Please refer to the information on the exterior
panel of the enclosure for electrical and safety information
before installing or operating the apparatus.
WARNING: For the terminals marked with symbol of “ ”
shock. The external wiring connected to the terminals
requires installation by an instructed person or the used of
ready-made leads or cords.
WARNING: This product takes the power plug as the disconnecting
device, may maintain the convenient operation when using.
to a MAIN outlet with a protective earthing
Mains Supply: The mains operating voltage of Audiolab
6000 series units is shown on the rear panel. If this voltage
does not match the mains voltage in your area, consult your
Audiolab dealer about converting the unit.
The mains supply fuse on the rear panel is accessible when
the IEC mains plug has been removed. In the rare event that
it has broken, check for any obvious cause before replacing
the fuse with one of the correct rating and type.
The fuse values are:
This label tells you that the unit
contains a laser component.
Opening the unit will expose the
user to radiation from the laser
beam.
connection.
Important Safety
Information Introduction Controls and Connectors Remote Handset Connections Operation Warranty Coverage Specifications

2: Introduction
Welcome to Audiolab 6000 Series.
We hope you will enjoy its performance for many years to come.
Please read through this manual to obtain the very best performance from 6000CDT.
Inputs:
• CD disc playback
Outputs:
Features:
signal path
• Automatic equipment activation via 12V trigger output
Unpacking
Unpack the product fully. The carton should contain:
• The Audiolab 6000CDT
• One IEC power cord suitable for your area
• One remote handset
• This instruction manual
Page 2
Please note: The remote control requires 2 x AAA type batteries. Due to international
shipping and courier regulations with Lithium Ion batteries, the remote controller
battery is not included in this package.
6000CDT is a high performance CD transport that is the perfect partner for other
Audiolab components such as 6000A.
Note: The 6000CDT should be used with the DIGl or OPT outputs connected directly to a
*Compatible with 120mm (4.73-inch) CDs only.
Placement
The unit is designed to run warm during normal operation but ensure you do not block
anyventilation openings.Place the unit on a sturdy shelf or table. If you use an equipment rack,
ensure the unit hasadequate ventilation and is on its own shelf. To minimize any interference
place the powersupply in a stable location as far from sensitive analogue input as possible.En-
sure your mains voltage corresponds to the rating plate on the rear of the product’s powersup-
advice from an Audiolab appointed dealer or a competent service technician.
lf an item is missing or damaged report this to your dealer as soon as possible. Retain the
packing for safe transport of your unit. If you dispose of the packing, do so with regard to any
recycling regulation in your area.
Important Safety
Information Introduction Controls and Connectors Remote Handset Connections Operation Warranty Coverage Specifications

Page 3
3: Controls and Connectors
REPEAT
Important Safety
InformationIntroduction Controls and Connectors Remote Handset Connections Operation Warranty Coverage Specifications

4: Remote Handset
Page 4
Fitting Batteries
Handset Operation
2 Move to the next track of CD
3 Press and hold to Fast Forward
4Press and hold to Fast Reverse
6 A Press to select 6000A remote mode
7 CD Press to select 6000CDT remote mode
8 TIME Press to toggle track time remaining and elapsed
9 Press to stop CD
10 Press to eject/load the disc
11 Press to start/pause CD playback
12 Press once to replay the current track of CD
Press again to move to the previous track of CD
13 REPEAT Press to repeat whole CD playback
Press to go directly to a track by number
NOTE : the handset buttons shown crossed out are for use with other Audiolab units likeAudiolab 6000A and are
not operational when used with the 6000CDT
The remote control requires 2 x AAA type batteries. Due to
international shipping and courier regulations with Lithium
Ion batteries, the remote controller batteries are not includ-
ed in this package.
Always use AAA batteries and replace them in sets -never mix
old and new batteries.
The handset operates several Audiolab components. The
handset buttons shown crossed out are for use with other
Audiolab units and are not operational when used with the
6000CDT.
Point the handset at the remote receiver and press the
relevant key. The handset should be within 15 meters of the
player and there must be a clear line of sight between the
two units.
Important Safety
Information Introduction Controls and Connectors Remote HandsetConnections Operation Warranty Coverage Specifications

Trigger Connections
Page 5
5: Connections
Mains InputDigital Outputs
Coaxial and Optical output
P
ON OFF
IN
LINK
RE
OUT
AUX3 AUX2 AUX1
L
R
RIGHT
OUTPUT
DI
G1
DI
G2
OPT1 OPT2
6000A
330
suitable Digital coaxial (fully screened) interconnect or optical
-
Audiolab 6000CDT has a pair of trigger connections on the rear panel that can activate 6000A’s
or any other source’s trigger input. If you have an 6000 system, we advise connecting the
triggers. This will enable all 6000 units to be brought in and out of standby using the trigger
connections. To connect to your control unit, you will need a cable with one end to match the
trigger output of the control unit and other terminating in a 3.5mm jack plug. For Audiolab
6000series, this will be a 3.5mm to 3.5mm interconnect.
your system have been properly and securely made. Make sure the ON/OFF switch on the
supplied, connect the socket on the back of your 6000A to an AC supply outlet. The 6000A is
now ready for operation.
Important Safety
InformationIntroduction Controls and ConnectorsRemote HandsetConnections Operation Warranty Coverage Specifications

they are trigger enabled.
When switching on: The power LED illuminates, the display shows the welcome screen. After
a short period the unit boots up.
bring the 6000CDT out of standby, the power indicator LED becomes brighter and the display
shows “6000CDT” welcome screen while the unit is getting ready for operation.
20min, 1hour or Never.
Insert one CD into the slot. The disc information will now display. After reading the track
information the disc will stop.
6: Operation
Page 6
Switching On and Off
Standby Mode
Loading a Disc
Playing a Disc
Press to play a disc.
Press to pause a disc, press again to resume play
Press to stop the disc
Press to eject the disc
Next/Previous Track
Press to move to the next track.
Press once to replay the current track,twice to move to the previous track.
disc.
Forward and Reverse Search during play
Press and hold the / on the handset. The forward and reverse search will start.
Direct selection of the tracks from the handset
Repeat Play
Press the Repeat key on the handset to repeat all the tracks on the disc continuously.
When in PROG mode, press the Repeat key on the handset to repeat all chosen tracks.
Program Play
Program mode must be accessed when the disc has stopped.
To play the program: Press .
To stop program play: Press .
To erase a program from memory: The program is stored in the player’s memory until erased.
Press twice or eject the disc to erase stored program.
Track Time Display
Press the Time key to toggle track time remaining and elapsed
Display Setting
chosen track. If you choose a single digital track (e.g.1) in a disc which contains more than 10
player will commence from the entered single-digit track. If the choice is invalid the display
reverts to the previous state.
When the display is OFF: Pressing any key will momentarily switch the display on. After a few
Press / repeatedly to move through the tracks forward or back on track at a time.
If you exceed the number of tracks on the disc, the player will wrap round and play from track 1.
Important Safety
Information Introduction Controls and Connectors Remote Handset Connections Operation Warranty Coverage Specifications

Page 7
7: Warranty Coverage - 1
Important Safety
Information Introduction Controls and Connectors Remote Handset Connections Operation Warranty Coverage Specifications

Page 8
7: Warranty Coverage - 2
Important Safety
Information Introduction Controls and Connectors Remote Handset Connections Operation Warranty Coverage Specifications

8: Specification
Measurement made with 230V power supply
Digital Output Intensity 550±50mVpp
Frequency response
Output Impedance 75±1 ohm
44.1 KHz
Harmonic Distortion <0.005%
Max. Power Consumption 15W
<0.5W
Power Requirements 240V ~ 50 - 60Hz
230V ~ 50 - 60Hz
115V ~ 50 - 60Hz
100V ~ 50 - 60Hz
Dimensions (mm) (W x H x D) 445 x 300 x 65.5 - including feet, terminals and controls
(W x H x D) 512 x 467x 146
Weight 7.2kg (Net)
Corrent disposal of this product. This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it responsible to
promote the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling.
Page 9
Important Safety
Information Introduction Controls and Connectors Remote Handset Connections Operation Warranty Coverage Specifications

Audiolab
IAG House,
13 /14 Glebe Road,
Huntingdon,
Cambridgeshire,
PE29 7DL,
UK
Tel: [phone]
Email: [email protected]
http://www.audiolab.co.uk
CODE: AH14-MNL0004a
