Install the Dash or Vent Mount
You canuse either the Dash Mount or the Vent Mount for your onyX, depending upon your vehicle and the
location where you want to place your radio.
CAUTION! Make sure yourradio isn’t in a place where it could interfere with driver visibility or safe deployment
of the airbags.
IMPORTANT! Whenyou install the chosen mount, do not yet attach the PowerConnect VehicleDock to the
mount. The cables must be attached prior toconnecting the dock to the mount.
Option 1
jump
FM
menu
234567890
direct
1
Option 2
234567890
direct
jump
FM
menu
1
Option 3
234567890
direct
jump
FM
menu
1
Dash
Mount
Installing the Dash Mount:
CAUTION: Theadhesive usedon the Dash Mountmay be difficultto remove.
Do not install thismount on leathersurfaces (contactyour vehicledealer if you
are unsure aboutyour dash surface), andmake sure theair temperature is at
least60ûF (15ûC) duringinstallation.If it’snot at least 60ûF, turnon the heater
in yourvehicle to bringthe temperature up to60ûF.
1 Locate a flat surface forthe Dash Mount. (Options 1, 2, or 3.) Make
sure there is ample room for the dock and radiowhen installed.
2 Set the orientation of the mount before adhering it. Loosen the
knob and adjust the adhesive foot for the location youselected:
•Option 1 & Option 3
should be oriented
as I.
•Option 2 should be
oriented as II.
3 The dock mounting plate can be tilted in different directions.
Adjust as necessary for your particular vehicle. When the
orientation is correct, tighten the knob.
4 Clean the surface with the alcohol preparation
pad, and let it dry thoroughly.
5 Peel off the adhesive liner. Position, press, and
hold the Dash Mount in place for 30 seconds.
IMPORTANT! Allow theDash Mount adhesive to cure(dry) for a minimum of
2-4 hoursbefore using the mount.The best adhesion occursafter 24 hours.
Dock Mounting Plate
Knob Adhesive Foot
I II
234567890
direct
jump
FM
menu
1
Option 5
jump
FM
menu
234567890
direct
1
Option 4
Extended Vent Clamps
Short Vent
Clamps
Vent Mount
Installing the Vent Mount:
1 Locate a suitable vent in yourvehicle which is strong enough to
hold the onyX andthe PowerConnect Vehicle Dock. (Options 4
or 5.)
2 If the vent louvers are recessed, you’ll have to use the
extended vent hooks. The Vent Mount is assembled with the
short vent clamps, so you will have to remove the short clamps
and install the extended clamps as shown below.
3 Push the Vent Mount onto the vehiclevent as shown (1) until
hooked on the rear of the vent louver (2).
4 Rest the foot against the bottom ofthe vent (2). If necessary,
adjust the tilt of the Vent Mount byrepositioning the foot to a
different tilt adjustment hole (3).
Slide Short Vent Clamps Out
Remove End Cap
Slide Extended Vent Clamps In Replace End Cap
PUSH
Dash
Vent
Louver
Foot
Vent Vent
Dash Dash
HOOKED
TILT
ADJUSTMENT
HOLES
1 2 3
1 Pick a Spot for Your Radio Pick a Spot for Your Radio (continued) 2 Install the Magnetic Mount Antenna
Mount the Magnetic Mount Antenna
Choose the best location for the antenna considering your vehicle type. Refer to the antenna
placement tips and cautions in the User Guide beginning on page 22 .
•Sedan or Coupe: We recommend mounting theantenna just above eitherthe front windshield
or the back window.
•Pickup Truck: We recommend mounting the antenna just abovethe front windshield.
•Convertible: We recommend mounting the antenna at the leading edge of the trunk.
•SUV: We recommend mounting the antenna at the rear of the roof.
CAUTION! STOP and read the more specificinstructions in the User Guide for all
types of vehicles — or get someone who knowsvehicles to help — if you don’t
understand what to do. You might accidentally do damage to your vehicle.
Feed the antenna wire under the rubber molding around the front or rear
windshield, and into the seal around the trunk or door. For a convertible, the cable
can be routed directly into the trunk.
TIP! Use a tool like a blunt plastic putty knife,a credit card, a plastic knife, or a
similar blunt tool to help hide wires along the windshield trim.
Hide the Magnetic Mount Antenna Cable Inside the Vehicle
The best place to hide your antenna cabledepends on your type of vehicle.
When the antenna is mounted at the rear of the vehicle, it’s usually easiest to run
the cable from the rear to the front toward the radio by routingthe cable along
the interior trim where it meets the carpet, gently pushing it behind the edges of
the trim. Bring the cable out from the trim and route it under the carpet toward
the dashboard.
When the antenna is mounted at the front of the vehicle, bring the cable into the
rubber weather stripping around the door to the bottom ofthe door opening.
Bring the cable out of the weather stripping and route it under the carpettoward
the dashboard.
Coil any excess cablein a hidden location, such as under the carpet, keeping it
away from any vehiclepedals or controls. Secure the excess cable with wire ties.
Plug the antenna into the silver ANT connection on the rear ofthe dock.
TIP! Avoid damaging or compromisingthe window, door, and trunk seals.
TIP! For morehelp, refer to the detailed antenna cable routing instructions for
your type of vehicle, in the UserGuide beginning on page 25 .
AUDIO ANT PWR FM
3 Connect the Audio to Your Vehicle’s Stereo
Decide How to Connect
You will listen to onyX through your vehicle’s stereo systemor FM radio. First, onyX must be receiving the XM signal.
Ensure your vehicle is outside with the antenna having a clear viewof the sky. Your audio connectionoptions are:
• Best: Use theAux In Cableif your vehicle’sstereosystem has
an auxiliary input connection.Plug one end ofthe cable intothe
greenAUDIO connectoron the PowerConnectVehicleDock and
the other end intothe vehiclestereosystem’s auxiliary input jack.
Set thestereosystem toplay from theauxiliaryinput source.
• Better: Use a CassetteAdapter if your vehiclehas a built-in
cassette player. Cassette Adaptersare sold separately. Plug
the CassetteAdapter intothe green AUDIOconnector onthe
PowerConnect VehicleDock. Insert theCassetteAdapter into
the vehicle’scassettedeck. Set the stereo system toplay from
the cassettesource.
• Good: Usethe PowerConnect feature in the onyX. PowerConnectplays the audio through yourvehicle’sFM radio.
When youhave finishedstep 4 (below), you’llfirst need to findan available FMchannel in your area, and thenyou
need toensure that the onyXand your vehicle’s FMradio are tunedto the same available FM channel. (Step 5)
• Best: Usean FM Direct Adapter (FMDA) if none of theabove three audio connection options worksin your
vehicle.The FMDA needs to be installed by a professional installer and directly connects the onyX toyour
vehicle’s FM radio.
TIP! Refer to your vehicle’s owners manual to find the location of the auxiliary input jack, or consultthe vehicle
dealer.To learn more about purchasing a CassetteAdapter or FMDA, check with the retailer where you bought your
onyX or go to xmradio.com/accessories.
Audio Quality GOOD BETTER BEST
PowerConnect
CassetteAdapter
Aux In Cable
FMDirect Adapter (FMDA)
AUDIO ANT PWR FM
AUDIO ANT PWR FM
4 Finish the Installation and Power On
Connect the PowerConnect Power Adapter
Insertthe PowerConnect Power Adapter intoyour vehicle’s cigarettelighter or power
adapter socket. Then plugit into the red PWRconnectoron the rear of thedock.
Attach the Dock to the Mount
and the Radio to the Dock
Attach the PowerConnectVehicle Dock
to the mount that you selected. Utilize
the wire guide at the rear of the dock to
help organize the wire and cables, and
make your installation neater.
Place the onyX into the dock. Press the
Power button to turn it On.
Wire Guide
234567890
direct
jump
FM
menu
1
AUDIO ANT PWR FM
5 PowerConnect
If you have connected the audio in step 3 using the Aux In Cable or Cassette Adapter, continue with step 6.
Tune the onyX and Vehicle FM Radio to the Same FM Channel
1 Find an Available FM Channel in Your Area
An available FM channel is one that’s not being used by an FM radio station in your area. When you
tune your FM radio to an availablechannel, you should only hear static or silence – not talk or music.
We recommend one of the followingmethods to find an available FM channel:
a. Use the SIRIUS | XM FM Channel Finder at www.xmradio.com/fmchannel. Go to the website and
enter your zip code. The Channel Finder will suggest a listof available FM channels in your area.
For convenience, write down or print out the list.
OR
b. Manuallytune throughyour localFM channelson your vehicle’sFM radio.Locateand createa list of
channels thataren’t beingused by anyFM radio station.Write downthe list. Once you have created
yourlist of availableFM channels,you will needto find the onethat provides thebest match for onyX.
TIP! You’ll need to use the‘Manual’ tune function on your vehicle’s FM radioto tune through everyFM channel
one-by-one.Turn on yourvehicle’s FM radio. Start at 88.1 and use the‘Manual’ tune function on your vehicle’s FM
radio totune through each FM channel one-by-one (88.1followed by 88.3 etc.)to locate channels that aren’tbeing
used by a localFM radio station. Writedown each FM channel that hasonly static or silence on it, untilyou reach 107.9.
2 Tune your Vehicle’s FM Radio
a Pick the first FM channel on your list.
b Turn on your vehicle’s FM radio (if you have not already done so) and tune it to this FM channel.
3 Set Your onyX to Transmit on the Same FM Channel
a Press menu.
b Press to scroll to and highlight FM Settings and press the Select button.
c FM Channels will be highlighted. If it is not highlighted, press to scrollto
and highlight FM Channels. Press theSelect button.
d Press to scroll to and highlight the storage location FM 2 and press the
Select button.
e Tune to the available FM channel you found in step 1. Press and to tune
in steps of .2, i.e., 99.3 to 99.5. Press and to tune in steps of 1, i.e.,
99.3 to 100.3. Pressthe Select button to select the FM channel.
f Start Using will be highlighted. P ress the Select button.
g The FM channel you selected will be confirmed on the display screen and
the onyX will tune to that FM channel.
h You should hear XM through your vehicle’s radiowhen onyX is tuned to
channel 1. If you are satisfied with the sound quality, you’re done.
FM Channels
current
FM 1
FM 2
FM 3
FM 4
FM 5
97.9
_ _ _
_ _ _
_ _ _
_ _ _
Edit FM Channel 2
99.3 FM
and Select to confirm
Press arrow keys to tune
FM Channel 2
Start Using
Edit Channel
PowerConnect (continued)
6 Activate
Activate Your Service
Before you can enjoy Commercial-Free Music, plus Sports, News, Talk& Entertainment, you need to activate
your onyX.
1 Make sure your onyX is properly installed, turned on, and receiving the XM signal so that you can
hear the audio on channel 1.
2 Make a note of your XM Radio ID. You can findit on channel 0, on a label on the bottom of the gift
box, and on the label on the back of your onyX.
NOTE! The XM Radio ID does not use the letters I, O, S, or F.
3 Activate your service:
•Online: Go to www.xmradio.com and click on “ACTIVATE
RADIO” in the top right corner
OR
•By phone: Call1-800-XM-RADIO (1-800-967-2346)
TIP! Youcan follow the built in activation
wizard in your onyX. If yourradio has not
been activated, press menu and the firstitem
in the list will be Activate Radio.Press the
Select button. A series of screenswill guide
you through the activation process.Follow the
instructions on each screen. Press the Select
button to advance tothe next screen, or
menu to cancel the activation process.
4 When your service is activated, youronyX will receive all channels to which you have subscribed. At
this time, if you press or , you can scroll and tune other channels. Activation usually takes 10
to 15 minutes, but may take up toan hour. We recommend that your radioremain on until activated.
Welcome
The next few screens will help
you activate your satellite radio.
Please press Select to continue
with the activationof your radio,
or press menu to cancel
activation at this time.
Press Select to continue
TIP! If the signal reception is
low, check to seeif the
antenna’s view ofthe sky is
blocked by a tree, a building, a
bridge, or by anything on the
vehicle roof such as a roof rack
or luggage container,etc. Adjust
until you are receiving a good
signal.
Tocheck the signal, press menu.
Press to scroll toand
highlight Signal Indicatorand
press theSelect button.
4 You May Need to Try Other FM Channels on Your List
If the chosen FM channel doesn’t work well for you,work down the list of FM channels until you find
one that allows you to hear XM clearly. Each time, you will need to tune yourvehicle’s FM radio and
onyX to the same FM channel.
TIP! Youmay find an FM channel with static or silence that does not work with onyX. It is possible that some type
of inaudible interference is presentthat prevents reception of the onyX broadcast.Your only options are to use
another FM channel or a different audio connection method.
NOTE! If you are using the VehicleDock from the Universal Xpress Car Kit instead of the
PowerConnect VehicleDock which came with your onyX, you will have to complete some
additional instructions before you can setonyX to transmit on an FM channel. Refer to
“Using the Vehicle Dock From the Universal Xpress Car Kit” on page96 of the User
Guide, and complete the instructions. The audio connectionwill be through your
vehicle’s FM radio,but it is not PowerConnect.
23 4 5 6 7 8 9 0 direct
jump
FM
menu
1
99.3
MATCH FM CHANNELS
Signal Indicator
S
ATELLIT
E
TERRESTRIA
L

What’s in the Box? onyX Button Functions
Direct Button
Press first before
entering the channel
number,to directly
tune to a channel.
23 4 5 6 7 8 9 0 direct
jump
FM
menu
1
Power Button
Turn radioon and off.
Left and Right Arrows
Search for channels by
category.
Up and Down Arrows
Scroll through lists and
preview channels; also
highlight menu options.
Menu Button
Access advancedfeatures
and configuration options;
also press and hold to
return to main display
screen.
Select Button
Press to confirm
selection for channel and
menu items.
FM Button
Access and cyclethrough
FM presets.
Jump
Directly access traffic
and weather of the 20
most congested cities;
or use it to go back to
the previous channel to
which you were listening.
Number Buttons
Select your favorite
channels; also enter a
channel number.
Trim Ring
Changeable
decorative
Trim Ring.
xmradio.com
SIRIUS XM Radio Inc.
1221 Avenue of the Americas
New York, NY 10020
1.800.967.2346
© 2009 SIRIUS XM Radio Inc.
XDNX1QSG 092909a
onyX Radio
PowerConnect Vehicle Dock
Magnetic Mount
Antenna
Vent Mount
and Extended
Vent Clamps
Antenna & Adhesive Mount
Alcohol Preparation Pads
PowerConnect
Power Adapter
Aux In Cable
Trim Rings
Trim Ring
Removal Tool
Dash Mount
23 4 5 6 7 8 9 0 direct
jump
FM
menu
1
Quick Start Guide
