Avanti MO1108SST User manual

Art. Name Count Art. Name Count Art. Name Count
P01 door (with inlaids) 1C02 h.v .diode 1B01 upper foam cushion 2
P02 door window 1C03 h.v. capacitor 1B02 turntable cushion 1
P04 capacitor holder 1C04 wave filter 1B03 plastic bag 1
P05 fan shroud 1C05 fan motor 1B04 manual 1
P06 fan blade 1C06 lamp 1B05 protection film 1
P07 door frame 1C07 thermostat 1 1B06 plastic bag 1
P08 choke cover 1C08 magnetron 1B07 lower cushion 2
P10
shaft (turn table hub)
1C09 microswitch 1B08 carton 1
P11 roller ring 1C10 microswitch 1B09 paper card 1
P12 glass tray 1C11 microswitch 1
P13 splash shield 1C12 transformer 1
P14 upper hinge 1C13 wiring harness 1
P16 cavity 1C14 power cord 1
P17 label 1C15 turntable motor 1
P18 outer enclosure 1C17
p.c. board
1
P21 lamp socket 1C18 thin film swith 1
P22 air duct 1C19 thermostat 1
P23 microswitch mounting 1
P26 foot 2
P27 base plate 1
P28 lower hinge 1
P29 keyboard (with inlaids) 1
P34 handle 1
P46
handle decoration
2
P109
lower door flake
1
P114 flake(in door frame) 1
P117 door hook 1
P118
door hook spring
1
P120
lower panel flake
1
P124 clamp holder 1
P126 mica flake 1
P170
glass clip
1
P288 magnetron bracket 1
MO1108SST Parts and Components List
