Aviator MIG-29 CHRONO User manual

1
english UseR MAnUAl
MIG-29 CHRONO
MOVeMenT
ROnDA 5130.D
SWISS MADE WATCHES
Mig FAMilY

2
We would like to thank you for choosing an exclusive AVIATOR watch. Your timepiece was
made and tested using meticulous techniques and premium materials of which we assure the
authenticity.
We certify that your AVIATOR watch is guaranteed against material and manufacturing defects
for 24 months starting from the date of purchase from an ofcial authorised dealer.During this
period of time, the repairs and exchange of defective parts under warranty will be carried free
of charge. This excludes failures due to accidents or careless use.
To full this requirement with any of our international distributors and service centres, your
watch must be accompanied by the international guarantee certicate/card signed by the au-
thorised dealer where the watch was purchased.
The shipping and insurance expenses will be charged to the owner of the watch. AVIATOR/
BURAN SA and the authorised distributors reserve all rights for repair, in accordance with this
warranty.
IMPORTANT:
This warranty does not cover the following parts:
-Damages and or failure in working due to wrong repairing or tampering, to careless use, to
negligence, to changes made to the original structure of the case or band or to intervention
made by people who are not authorised by AVIATOR/BURAN SA;
-Damages to the lens, breaking or scratching on the case, on the ban, on the buckle or on
the plating due to wearing or to bad use of the watch;
-Life of the battery in watches with quartz movement;
-Wearing of leather, textile, rubber or stainless steel band.
SWISS MADE WATCHES
English User Manual

3
MIG-29 CHRONO RONDA 5130.D
English User Manual
Push-button A
Crown
Push-button B
Minute hand
Hour hand
Hour and
minute counter
Center stop-second
Alarm and reference time
Second hand
Date 5130.D
DESCRIPION OF THE DISPLAY AND CONTROL BUTTONS
MULTIFUNCTION MOVEMENT
The alarm and chronograph are combined in Cal. 5130.0 and 5130.B.All funions can be
operated with the 2 push-buons and crown.
INITIAL STATUS (chronograph hands at zero position)
- art the chronograph with push-buon A
- switch the a larm on and o with push-buon B
CHRONOGRAPH ACTIVE
Push-buon B is also operative for the chronograph as soon as timing isarted with
push-buon A
At the end of timing and when the chronograph hands are reset to the zero positions the
push-buon fun ions once again assume their “initial atus”.
The alarm cannot be adjued when the chronograph is aive.

4
MIG-29 CHRONO RONDA 5130.D
English User Manual
SETTING THE DATE (QUICK MODE)
Pull out the crown to position II (the watch continues to run).
Turn the crown until the correct date 01 appears.
Push the crown back into position I.
Please note:
The date of the following day must be set in the calendar changing phase between 9
PM and midnight.
Setting the date too quickly in quick mode can result in the incorrect date being dis-
played. Switching the date between 01 and 31 (position II) restores the synchronisation.
Data 5130.B
Data 5130.B
1
2
3

5
Hour counter Push-button A
Push-button B
Minute counter
MIG-29 CHRONO RONDA 5130.D
English User Manual
CHRONOGRAPH: BASIC FUNCTION
Hour counter
Minute counter
Push-button B
Push-button A
(Start / Stop / Reset)
Example:
Start: Press push-button A.
Stop: to stop the t iming, press pushbutton A once
more and read the 3 chronograph counters:
4h / 20 min / 38 sec
Zero positioning:
Press push-button B.
(The 3 chronograph hands will be reset to their
zero positions)
Note:
The alarm cannot be used as long as the chro-
nograph is in operation.
1
2
3
CHRONOGRAPH:
ACCUMULATED TIMING
Example:
Start: (start timing)
Stop: (e.g. 15 m in 5 sec following )
Restart: (timing is resumed)
*Stop: (e.g. 10 min 5 sec following )
= 25 min 10 sec
(Tile accumulated measured time is shown)
Reset:
The three chronograph hands are returned to their
zero positions.
Please note:
*Following , the accumulation of the timing can
be continued by pressing push-button A
(Restart / Stop, Restart / Stop, ...)
1
2
3
4
4
5
1
3

6
MIG-29 CHRONO RONDA 5130.D
English User Manual
Push-button A
Push-button B
Minute counter
Push-button B
CHRONOGRAPH:INTERMEDIATE OR
INTERVAL TIMING
Example:
Start: (start timing)
Display interval:
e.g. 10 minutes 10 seconds (timing continues
in the background)
Making up the measured time:
(the 3 chronograph hands are quickly
advanced to the ongoing measured time)
Stop: (Final time is displayed)
Reset:
The 3 chronograph hands are
returned to their zero position
Please note:
*Following . further intervals or intermediates can be
displayed by pressing push-button B (display interval I
make up measured time, ...)
1
2
3
4
5
3
*
Adjusting the center stop-second
Single step A 1 x short
Continuous A long
Adjusting the next hand B
Adjusting the minute counter hand and the
hour counter hand
(mechanical coupled)
Single step A 1 x short
Continuous A long
Returning the crown to position I
Termination of the chronograph hands adjust-
ment (can be carried out at any time The display
changes from reference to alarm time.)
3

7
MIG-29 CHRONO RONDA 5130.D
English User Manual
Date 5130.DAlarm time
Date 5130.D
Reference time
Second hand
SETTING THE TIME AND DATE
Example:
-Date / time on the watch: 17 / 1:25 AM
-Present date / time: 04 / 10:39 PM
Pull out the crown to position II (watch continues
to run).
Turn the crown until yesterday’s date appears 03
Pull out the crown to position Ill (the second hand
stops. The display changes from alarm lime to ref-
erence time.)
1
2
3
Reference time
Alarm time
Turn the crown until the correct date 04 appears.
*Continue to turn the crown until the current time
10:39 PM appears.
Push the crown back into position I (the display
changes from reference to alarm time)
4
5
6
Please note:
Resetting the time also requires the identical correction of
the reference time.
Please refer to “setting the reference time”.
*Please observe the AM / PM clock rhythm.

8
MIG-29 CHRONO RONDA 5130.D
English User Manual
Alarm time Push-buttion
SETTING THE ALARM TIME
Activate the setting mode
Press the push-button for at least 2 seconds. As
soon as the small minute hand jumps forward one
minute, this mode is active.
Setting
Short pressing (less than 1 second):
the alarm time is moved forward by the minute
Long pressing (longer than 2 seconds):
the alarm time is moved forward until the push-but-
ton is released.
Please note:
If the push-button is not activated for 10
seconds, the setting mode of the alarm time de-
activates itself. At the same time, two beeps are
emitted to indicate that the a larm is switched on.
Note:
The alarm cannot be used as
long as the chronograph is in
operation.
1
2
Alarm time Push-buttion
SWITCHING THE ALARM ON / OFF
The alarm is switched on/off by briey pressing the
push-button:
2 beeps alann switched on
1 beep alann switched off
Please note:
The alarm can be set maximum 12 hours before the desired alarm time.
Once the set alarm time has been reached, a signal is emitted for 20 seconds. This
sognal is repeated after two minutes. Following brief pressing of the push-button, the signal is
immediately switched off.

9
MIG-29 CHRONO RONDA 5130.D
English User Manual
Reference time
Reference time
Small minute hand
SETTING THE REFERENCE TIME
*Pull out the crown to position Ill (second hand stops
The display changes from alarm time to reference
time.)
Activating the setting mode
Press the push-button for at least 2 seconds. As soon
as the small minute hand jumps forwards one minute,
this mode is active.
Short pressing (less than 1 second):
the reference time is moved forwards by the minute.
Medium pressing: (1-2 seconds):
the reference time is moved forwards by the hour.
Long pressing (longer than 2 seconds):
the reference time is moved forwards until the push-but-
ton is released.
*Push the crown back into pos ition I (the display
changes from refe rence time to alarm time). A signal
indicates that the alarm is switched off.
1
2
3
4
Alarm time
What is the reference time?
The current time is displayed by means of the
hour and minute hand.
Parallel to the current time, the reference time
runs in the background the alarm time refers
itself to this reference time Thus, resetting the
time also requires the identical correction of
the reference time.
If the reference time is not synchronised with
the current time, this results in the a larm
signal being emitted at a different time to the s
et a larm time.
Please note:
* In order to set the time to the exact
second, 0 must be pulled out when
the second hand is in position «60»
(Ill ). Once the hour and minute
hands have been s et, 0 must be
pushed back into position I at the exact second.

10
