Avocent LongView Wireless Installation and maintenance instructions

Longview®Wireless
Installer/User Guide
Avocent, the Avocent logo, The Power of Being There and Longview are
registered trademarks of Avocent Corporation or its affiliates. All other
marks are the property of their respective owners.
©2004 Avocent Corporation. All rights reserved.

USA Notification
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment is a residential
area is likely to cause harmful interference, in which case the user will be required to correct the interference at
his/her own expense.
Canadian Notification
This digital apparatus does not exceed Class A limits for radio noise emissions from digital apparatus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de la classe A prescrites dans le Réglement su le brouillage radioélectrique édicté par le
Minstére des Communications du Canada.
Safety and EMC Standards
UL, FCC class A, cUL

iii
Chapter 1: Product Overview.......................................................................................... 1
Features and Benefits.................................................................................................................1
Compatibility with Peripherals ..................................................................................................3
Safety Precautions......................................................................................................................3
Chapter 2: Installation ..................................................................................................... 5
Getting Started............................................................................................................................5
Installing a LongView Wireless Extender...................................................................................5
Chapter 3: Operations ..................................................................................................... 9
Powering the LongView Wireless Extender ...............................................................................9
Informational Messages..............................................................................................................9
LEDs.........................................................................................................................................10
Image Adjustment Using the LongView Wireless Extender OSD.............................................11
Appendices..................................................................................................................... 13
Appendix A: Technical Specifications......................................................................................13
Appendix B: Technical Support................................................................................................15
Appendix C: Troubleshooting...................................................................................................16
CONTENTS

iv Longview®Wireless Installer/User Guide

1
Product Overview
Features and Benefits
The Avocent LongView®Wireless extender connects Keyboard, Video, Mouse (KVM) and audio
peripherals wirelessly to your computer, from up to 100 feet away. The LongView Wireless
extender is a digital system that processes analog video, inbound and outbound, utilizing a unique,
proprietary compression engine. At the heart of the compression engine is a multimedia DSP and
an FPGA that are coupled to an IEEE 802.11a radio board.
Its industry standard design makes the LongView Wireless extender compatible with virtually any
PC, display technology and operating system. Installation is essentially Plug and Play requiring no
new drivers or software.
Figure 1.1: LongView Wireless Extender Model
CHAPTER
1

2Longview®Wireless Installer/User Guide
The LongView Wireless extender On-Screen Display (OSD)
The LongView Wireless extender OSD makes it simple to set up and adjust your video parameters.
Accessed from the receiver side, the OSD makes tuning your video fast and convenient.
Figure 1.2: Example LongView Wireless Extender Configuration
Secure connectivity and 802.11a standards-based design
Advanced Encryption Standard (AES) provides secure connections through a proprietary design
based on the 802.11a standard.
The LongView Wireless transmitter
The LongView Wireless transmitter connects directly to your computer and serves as the radio
interface device enabling the computer to transmit audio and video data. It also acts as the receiver
for keyboard and mouse signals from extended devices. The LongView Wireless transmitter
contains five chassis-mounted connectors for local video, keyboard and mouse peripherals, in
addition to power and audio in from the computer. It includes a 3.5 foot cable with video and PS/2
keyboard and mouse connectors. Power is supplied to the transmitter from a universal input 12þV
DC switching power supply (included).
Server
Longview Wireless
Transmitter
Longview Wireless
Receiver
Extended Access
User

Chapter 1: Product Overview 3
The LongView Wireless receiver
The LongView Wireless receiver connects directly to your user interface devices (keyboard, video
monitor and mouse) and serves as the radio interface device for these components. It receives audio
and video data from the source computer and sends keyboard and mouse data from the user
interface devices to the source computer. The LongView Wireless receiver has five chassis-
mounted connectors for video, keyboard, mouse and audio peripherals and power. Power is
supplied to the transmitter from a universal input 12 V DC switching power supply (included).
Compatibility with Peripherals
The LongView Wireless extender is compatible with the following peripherals:
• Keyboard - The LongView Wireless transmitter and receiver support virtually any standard
PS/2 keyboard.
• Mouse - The LongView Wireless transmitter and receiver support 2-button PS/2 mice. Mice
that have more than two buttons work with the reduced functionality of a 2-button mouse.
• Video - The LongView Wireless extender supports VGA, SVGA and XGA resolutions up to
60 Hz refresh rate. Both CRT and LCD monitors with standard 15-pin high density connectors
are supported.
• Audio - Speakers and headphones with 3.5 mm audio plugs are supported on the receiver side
of your LongView Wireless extender, provided the transmitter has been connected to the sound
card of your PC with the provided audio cable.
Safety Precautions
To avoid potential video and/or keyboard problems when using Avocent products:
• If the building has 3-phase AC power, ensure that the computer and monitor are on the same
phase. For best results, they should be on the same circuit.
• Use only Avocent-supplied cable to connect computers and KVM switches. Avocent
warranties do not apply to damage resulting from user-supplied cable.
To avoid potentially fatal shock hazard and possible damage to equipment, please observe the
following precautions:
• Do not use a 2-wire extension cord in any Avocent product configuration.
• Test AC outlets at the computer and monitor for proper polarity
and grounding.
• Use only with grounded outlets at both the computer and monitor. When using a backup
Uniterruptible Power Supply (UPS), power the computer and the LongView Wireless
transmitter unit off the supply.
NOTE: The AC inlet is the main disconnect.

4Longview®Wireless Installer/User Guide

5
Installation
Getting Started
Before installing your LongView Wireless extender, refer to the list below to ensure that you have
all the items that shipped with the product.
Supplied with the LongView Wireless extender
• LongView Wireless transmitter
• LongView Wireless receiver
• Two local country power supplies
• Audio cable
• LongView Wireless Installer/User Guide
• LongView Wireless Quick Installation Guide
Installing a LongView Wireless Extender
Follow the procedures To install a LongView Wireless transmitter and To install a LongView
Wireless receiver to properly install your new KVM extension system.
WARNING: To reduce the risk of electric shock or damage to your equipment -
Disconnect the power from the unit by unplugging the power supply from the electrical outlet.
To install a LongView Wireless transmitter:
1. Ensure that the video setting of your computer is 1024 x 768, 800 x 600, or 640 x 480 at 60 Hz
refresh rate. Best performance will be achieved if the color resolution is set to 24 bit color
or higher.
2. Power down the computer that will be connected to your LongView Wireless extender.
3. Unplug the peripherals (keyboard, mouse, monitor and speakers with built-in amplifiers, if
applicable) from your computer.
CHAPTER
2

6Longview®Wireless Installer/User Guide
Figure 2.1: LongView Wireless Transmitter Installation Example
4. Prepare locations for your LongView Wireless extender equipment, computer and peripherals.
Place the transmitter near your computer. Best performance is achieved when the antennas are
clearly visible and free from obstructions.
5. Connect the LongView Wireless transmitter cables into the computer’s PS/2 keyboard (purple
connector), PS/2 mouse (green connector) and monitor connections (blue connector).
6. Using the supplied audio cable, connect one end to the LongView Wireless transmitter’s audio
input connection (lime green connector) and the other end to the computer’s audio output con-
nection (lime green connector).
7. Connect your LongView Wireless transmitter to an AC power source with one of the power
supplies included with your LongView Wireless extender.
NOTE: The transmitter must be powered up before the computer.
NOTE: Use only an Avocent-supplied power supply.
8. Power up your computer.
Power
Supply
Transmitter
Cables
Peripheral Cables
Audio Cable

Chapter 2: Installation 7
Connecting the LongView Wireless receiver
Virtually any industry-standard display device can be attached to the LongView Wireless receiver,
as long as it has a 15-pin D shell connector for video input and can accept VGA (640 x 480),
SVGA (800 x 600) and XGA (1024 x 768) resolution video.
To install a LongView Wireless receiver:
1. Select a location for your LongView Wireless receiver. Find a convenient position for locating
the LongView Wireless receiver, such as a desktop that is near your extended display. Best
performance is achieved when the antennas are clearly visible and free from obstructions.
2. Connect the extended display’s video input into the LongView Wireless receiver’s video input
(blue connector).
NOTE: The extended display must have a standard 15-pin D-shell RGB analog interface.
3. Connect the extended display’s PS/2 keyboard and mouse (if applicable) into the LongView
Wireless receiver’s keyboard connection (purple connector) and mouse connection
(green connector).

8Longview®Wireless Installer/User Guide
Figure 2.2: LongView Wireless Receiver Installation Example
4. Connect your speakers into the LongView Wireless receiver’s audio output connection (lime
green connector).
5. Connect the LongView Wireless extender power supply into the LongView Wireless receiver
and into the AC power source.
NOTE: Use only an Avocent-supplied power supply.
6. Connect your monitor’s power supply to appropriate electrical outlets.
Power
Supply
Peripheral Cables
Audio Cable

9
Operations
Powering the LongView Wireless Extender
The LongView Wireless extender units (transmitter and receiver) have been factory configured to
operate as a companion pair. The initial radio link between the two units is established by the
receiver, although all other aspects of the link are controlled by the transmitter. Once the radio link
is established, mouse, keyboard, video and audio data is free to flow between the two units.
To power up the LongView Wireless extender:
1. Complete all of the installation steps. See Chapter 2.
2. Power up the LongView Wireless transmitter and wait for the middle LED labeled S2 to illu-
minate.
3. Power up the monitor attached to the LongView Wireless receiver.
4. Power up the LongView Wireless receiver.
5. Power up your computer.
NOTE: Always power up the LongView Wireless transmitter and wait for the middle LED labeled S2 to illuminate
before powering up your computer.
Informational Messages
When the LongView Wireless receiver is powered up, it will display a message on the computer
monitor to which it is attached:
Searching for CLT_000c4116bc7b
The 000c4116bc7b is replaced by the MAC ID of the radio board in your transmitter unit. This
message indicates that your receiver unit is actively searching for its companion transmitter. When
it finds the companion transmitter, it will display a second message beneath the first:
Connecting to CLT_000c4116bc7b
The 000c4116bc7b is replaced by the MAC ID of the radio board in your transmitter unit. This
message indicates that your receiver unit is establishing the radio link with your transmitter unit.
When this link is established, both messages will be removed and the monitor will display video
information from your computer.
CHAPTER
3

10 Longview®Wireless Installer/User Guide
LEDs
Both the LongView Wireless transmitter and receiver contain three LEDs visible from the front of
each unit. The LEDs are labeled on the unit.
Figure 3.1: Transmitter LEDs
Fine-Tuning the Image Settings
Once the radio link has been established, and the monitor attached to the receiver is displaying
computer generated video, some fine-tuning of the video settings may be desired. This fine-tuning
should only be necessary the first time that a LongView Wireless transmitter is used with a
particular computer; settings, once adjusted, are saved in the transmitter unit.
A mouse or keyboard driven menu, called the On-Screen Display (OSD), enables you to perform
these adjustments. The LongView extender OSD allows you to use an Auto Setup feature to adjust
the image settings, or enables you to manually adjust any of the individual image settings. New
settings may be temporarily or permanently saved.
Main menu options
The LongView Wireless extender Main menu has two options- Auto Setup and Link Status. The
Auto Setup checks the video parameters for your source computer and then automatically
optimizes the video quality portrayed on your monitors. The Link Status indicates the signal
strength of the wireless connection between your LongView Wireless transmitter and receiver.
Advanced menu options
The LongView Wireless extender OSD Advanced menu allows you to fine-tune the video settings
that were established with the Auto Setup function. You may tune the horizontal and vertical
position of the video monitor window, as well as adjust the brightness and contrast of the video
Table 3.1: LED Conditions
S1 S2 PWR Condition
OFF OFF ON No Activity, Power is On
OFF OFF OFF No Activity, Power is Off
OFF ON ON Establish Link
ON ON ON Connected

Chapter 3: Operations 11
image. You may also adjust the video clock phase in the LongView Wireless transmitter relative to
the video clock at your source computer to assure the cleanest, sharpest video image.
Image Adjustment Using the LongView Wireless Extender OSD
When configuring the OSD, you may use the Auto Setup function to automatically optimize the
video of your LongView Wireless extender, or you may choose to optimize it manually. When
optimizing video, best results can be obtained by displaying a fixed image on screen during the
optimization process.
To optimize video automatically:
1. Activate the OSD Main menu on the receiver unit by pressing and holding the left Shift key
followed by the right Shift key and then releasing both. You may also activate the OSD via the
mouse by right-clicking twice and left-clicking once in rapid succession.
2. Optimize the video setup of your LongView Wireless extender by selecting Auto Setup - Run.
This will automatically optimize your video setup parameters. Select Finish at the bottom to
save your OSD, keyboard and Auto Setup parameters.
-or-
Select Cancel to exit without saving changes.
To optimize video manually:
If your monitor image requires further adjustment after running the Auto Setup, you may use the
Advanced Setup options from the LongView Wireless extender OSD menu.
1. Activate the OSD Main menu on the receiver unit by pressing and holding the left Shift key
followed by the right Shift key and then releasing both. You may also activate the OSD via the
mouse by right-clicking twice and left-clicking once in rapid succession.
2. Select the Advanced tab from the OSD Main menu.
3. On the OSD Advanced menu, use the fine-tuning options to make further adjustments to your
video image, as needed.
Press the Left or Right arrow keys to make adjustments for:
• Horizontal Position
• Vertical Position
• Brightness
• Contrast
• Clock Phase
4. Select Finish at the bottom of the Main OSD menu to save the parameters.
-or-
If you wish to exit without saving changes, select the Cancel button.

12 Longview®Wireless Installer/User Guide

13
APPENDICES
Appendix A: Technical Specifications
Table A.1: LongView Wireless Extender Product Specifications
Physical Attributes
Height 1.75" (4.45 cm)
Width 6.25" (15.88 cm)
Depth 5.25" (13.34 cm)
Antenna extension 4.75” (12.07 cm) above lower surface of housing
Weight 1.0 lb (0.45 kg)
Ambient Atmospheric Condition Ratings
Operating Temperature 32°F - 104°F (0°C - 40°C)
Storage Temperature -4°F - 120°F (-20°C - 50°C)
Power Supply
DC-input 12 VDC @ 1 Amp
Transformer AC-input 100 - 240 VAC
AC Frequency 50 - 60 Hz
Multimedia
Video Link Resolution 640 x 480, 800 x 600, 1024 x 768
Video Link Compatibility VGA, SVGA, XGA
Video Interface VGA compatible with analog RGB (15-Pin D-shell), non-
interlaced 60 Hz refresh rate
Audio Support Analog audio
Supported Hardware
Computer Most standard computers with the exception of those
manufactured by Apple
Peripherals PS/2 keyboard, PS/2 mouse, speakers

14 Longview®Wireless Installer/User Guide
Radio
Radio Protocol IEEE 802.11a
Radio Frequency 5150-5250; 5250-5350; 5725-5825 MHz
Radio Modulation Orthogonal Frequency Division Multiplexing (OFDM)
Nominal Output Power 17 dBm
Range XGA video resolution to 100 feet
Security AES encryption with 802.1x authentication
Regulatory Compliance
Standards
FCC Class A, UL, cUL
Table A.1: LongView Wireless Extender Product Specifications (Continued)

Appendices 15
Appendix B: Technical Support
Our Technical Support staff is ready to assist you with any installation or operating issues you
encounter with your Avocent product. If an issue should develop, follow the steps below for the
fastest possible service:
1. Check the Troubleshooting section of this manual to see if the issue can be resolved by
following the procedures outlined. See Appendix C.
2. Check our web site at www.avocent.com/support to search the knowledge base or use the on-
line service request.
3. Call Avocent Technical Support for assistance at [phone]. Visit the Avocent web site at
http://www.avocent.com/support and select Support Phone Numbers for current phone support
hours.

16 Longview®Wireless Installer/User Guide
Appendix C: Troubleshooting
No power status light on transmitter or receiver
Verify that the green LED on the separate Avocent-supplied power supply is
illuminated, indicating that the power supply is plugged in correctly.
Ensure that the power cable from the Avocent-supplied power supply is securely
plugged into the LongView Wireless transmitter or LongView Wireless receiver
unit.
No video on monitor attached to transmitter
Verify that the monitor has power.
Ensure that the video cable from the LongView Wireless transmitter is securely
plugged in to the correct connector on the computer.
Ensure that the video cable from the monitor is securely plugged in to the correct
connector on the LongView Wireless transmitter.
Verify that the computer is powered.
As a last check, plug the video cable from the monitor directly into the computer to
verify that the monitor is working and that the computer is generating active video.
If this is functioning, check that the display settings for your computer are set no
higher than a resolution of 1024þxþ768 at 60þHz refresh rate. If the monitor does
not function correctly, replace it.
No mouse and/or keyboard operation from peripherals attached to transmitter
Verify that the mouse and keyboard are connected to the correct PS/2 ports on the
computer. Match the connector color codes (green is mouse and purple is
keyboard).
If the LongView Wireless transmitter was powered up after the computer, turn
off the computer and transmitter. Power up the LongView Wireless transmitter
unit, wait for the middle LED to illuminate, then power up the computer.
Retest the mouse and keyboard by connecting them directly to the computer and
rebooting the computer. If one does not function correctly, replace the
nonfunctioning peripheral.
No video on monitor attached to receiver
Verify that the monitor attached to the LongView Wireless receiver has power.
Ensure that the video cable from the monitor is securely plugged in to the correct
connector on the LongView Wireless receiver.
Ensure that the video cable from the LongView Wireless transmitter is securely
plugged in to the correct connector on the computer.
