AWA CD2961i User manual

Service Manual
CONTENTS
Electrical Parts List ........................................................................................................................................... 5
Printed Circuit Boards ..................................................................................................................................... 12
Wiring Diagram ............................................................................................................................................... 19
Schematic Diagrams ....................................................................................................................................... 21
Voltage Chart .................................................................................................................................................. 27
IC Pins Description and IC Block Diagrams .................................................................................................... 28
Exploded Drawing Parts List ........................................................................................................................... 37
Performance Specifications .............................................................................................................................. 2
Block Diagram ................................................................................................................................................. 35
Exploded Drawing ........................................................................................................................................... 36
Pages
PRODUCT SAFETY NOTES
Many electrical and mechanical parts in this chassis have special safety characteristics.
These safety characteristics often pass unnoticed and the protection afforded by them cannot
necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.
Replacement parts that have these special safety characteristics are identified in this manual
and its supplements; electrical components having such features are identified by in the
schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully.
The use of substitute replacement parts that do not have the same safety characteristics as
specified in the parts list may create shock, fire or other hazards.
CD Mini System for iPhone or iPod
CD2961i
CAUTION:
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

2
PERFORMANCE SPECIFICATIONS
Power Supply : 230V AC 50Hz
Output Load : 6ohm Dummy Speaker Load
Reference Output : 1W
Input Signal Source : 75ohm Dummy for FM
Modulation : 40kHz for FM Mono 1kHz
Remarks : 7.5kHz Pilot Tone
67.5kHz L+R 1kHz
GENERAL TEST CONDITION
AMPLIFIER SECTION
UNIT NOMINAL LIMIT
1. Standby power AC Input: 230V, 50Hz W --- <0.5
2. Output power Ø=1kHz 10% THD (L/R) W 90 88
3. Frequency response 3dB (Ref 1kHz) Hz
4. Distortion Line IN=500mV Po=1W 1kHz % 0.5 1
20~20kHz BPF Maximum volume Line IN=500mV 1kHz % --- 15
5. Line in input sense Main PO=90W 1kHz Maximum volume mV 1000 1200
6. Audio level balance FM: Deviation=±40kHz 1kHz dB -5 ±3
CD=-6dB 1kHz dB -3 ±3
Line IN=500mV 1kHz dB 0 0
iPod=-6dB kHz dB -5 ±3
7. Channel separation Line IN=500mV Ø=1kHz dB 50 40
8. Channel unbalance Ø=1kHz Aux IN dB 0 3
9. S/N ratio Line IN=500mV 1kHz 20~20kHz BPF dB --- 55
A-Weighted dB --- 65
10. Graphic equalizer Rock 100Hz dB 6 ±2
(with Ref. to flat) 1kHz dB 0 ±3
10kHz dB 6 ±2
Classic 100Hz dB 0 ±2
1kHz dB 2 ±2
10kHz dB 4 ±2
Pop 100Hz dB -2 ±2
1kHz dB 4 ±2
10kHz dB -2 ±2
Jazz 100Hz dB 2 ±2
1kHz dB -2 ±2
10kHz dB 4 ±2
11. Muting attenuation (A Filter ON) dB 70 65
12. Hum and noise Volume=1 20~20kHz BPF mV --- 1.5
Maximum volume 20~20kHz BPF mV --- 10
Remarks:
Measurement condition:
a. AU measurement should be done at by pass mode, without EQ effects.
All Item 20k LPF-ON
40 ~ 16000
TEST ITEMS

3
PERFORMANCE SPECIFICATIONS - CONTINUED
FM SECTION
TEST ITEMS UNIT NOMINAL LIMIT
1. Tuning range MHz 87.5 - 108 ---
2. Tuning step kHz 50 ---
3. I.F frequency kHz --- ---
4. Sensitivity (at S/N=30dB) 90.1MHz dB 20 28
98.1MHz dB 20 28
106.1MHz dB 20 28
5. Limiting sensitivity -3dB Deviation=±40kHz dB 12 20
6. Stereo threshold Deviation=±40kHz dB 20 48
7. Overload I/P level THD=10% dB --- 110
8. Am Suppression MOD=30% Ø=400Hz VIN=45dBF dB 50 25
9. Selectivity 2SG DF=±400kHz
Vin=45dBF Deviation=±40kHz
10. Audio response Ref=1kHz -3dB Hz --- 60 - 4000
Channel separation Ø=1kHz dB 35 24
11. Distortion Ø=1kHz Mono Deviation=±75kHz % 0.3 4
20~20kHz BPF Stereo Deviation=±67.5kHz % 1.4 4
12. S/N ratio Mono 22.4Hz~15kHz BPF dB 50 40
Stereo 22.4Hz~15kHz BPF dB 50 40
13. Auto scan threshold dB 28 32
14. Modulation Hum 20~20kHz BPF dB 50 40
15. Oscillation fall out % --- 75
16. Minimum volume hum Volume=1 20kHz LPF mV --- 1.5
Remarks:
Measurement condition:
1. AU measurement should be done at by pass mode, without EQ effects.
2. Deviation (Mono)=±75kHz
(Stereo)=±67.5kHz / Pilot=±7.5kHz
dB 30 22
iPod SECTION
TEST ITEMS UNIT NOMINAL LIMIT
1. Frequency response (-3dB) Ref 1kHz Hz
1kHz 0dB 20Hz~20kHz BPF dB --- 60
2. S/N ratio A-Weighted dB --- 65
3. Hum and noise Volume=1 20~20kHz BPF mV --- 1.5
Maximum volume 20~20kHz BPF mV --- 10
4. Distortion -10dB 128K Bit rate % 0.5 1
5. Channel separation Ø=1kHz dB 50 40
6. Channel unbalance Ø=1kHz dB 0 3
Remarks:
Measurement condition:
1. AU measurement should be done at by pass mode, without EQ effects.
All Item 20k LPF-ON
100 ~ 16000

4
PERFORMANCE SPECIFICATIONS - CONTINUED
CD SECTION
UNIT NOMINAL LIMIT
1. Frequency response (-3dB) (Ref. 1kHz) Hz
2. S/N ratio Ref=CD 1K 0dB 20Hz~20kHz BPF dB --- 60
A-Weighted dB --- 65
3. Hum and noise Volume=1 20~20kHz BPF mV --- 1.5
Maximum volume 20~20kHz BPF mV --- 10
4. Distortion CD=-10dB Ø=1kHz % 0.5 1
5. Channel separation Ø=1kHz 0dB dB 50 40
6. Channel unbalance Ø=1kHz 0dB dB --- 3
7. Program access time Short Sec 1 3
Long Sec 4 7
8. Time to read TOC ABEX TCD-712R Sec 8 10
ABEX TCD-W012W Sec 15 20
9. Error correction SBC444A Interruption mm 1 0.6
Black dot mm 1 0.6
Fingerprint µm 75 65
ABEX TCVD-721R Scratch mm 1 0.6
10. Eccentricity Abex TCD-712R µm 210 140
11. Vertical deviation Abex TCD-731RA mm 1 0.78
12. Error correction ABEX TCD-W021W Scratch mm 1 0.6
ABEX TCD-W025W Black dot mm 1 0.6
Remarks:
Measurement condition:
1. AU measurement should be done at by pass mode, without EQ effects.
All Item 20k LPF-ON
2. Test Disc=SONY 3
40 ~ 16000
TEST ITEMS

5
ELECTRICAL PARTS LIST
Ref. No. Description Mfr's Part No. Qty.
PCB
MAIN PCB PCB CD29611-01-01 170x150x1.6mm (FR4/R29) 033-CD2961W100 1
iPod PCB PCB CD2961I-01-02 58.5x45x1.0mm (FR4/R29) 033-CD2961W101 1
KEY PCB PCB CD2961I-01-03 245x97.5x1.6mm (94HB/R01) 033-CD2961W102 1
REMOTE CONTROL SECTION
REMOTE CONTROL, MOLD BLACK, 430C PNT, 043-A72424W110 1
RUBBER: L.BLUE 2708C, w/BATTERY, NO WEEE
AMPLIFIER SECTION
RESISTORS
R888,889 CHIP RESISTOR 0 ohm +-5% 1/16W (0603/1608) 001-300052W016 2
SR65,800 CHIP RESISTOR 0 ohm +-5% 1/16W (0402/1005) 001-300056W016 2
R0420,94 CHIP RESISTOR 100 ohm +-5% 1/16W (0603/1608) 001-310152W016 2
SR49,52,55,57,62,86, R111 CHIP RESISTOR 100 ohm +-5% 1/16W (T&W) (0402/1005) 001-310156W016 7
R1,2,092,0106, SR66 CHIP RESISTOR 1 Kohm +-5% 1/16W (0402/1005) 001-310256W016 5
SR47,48,51,54,64,68,83,85, CHIP RESISTOR 10 Kohm +-5% 1/16W (T&W) (0402/1005) 001-310356W016 17
87,88,097,102,103, R401L,
431L,401R,431R
R24,148 CHIP RESISTOR 100 Kohm +-5% 1/16W (0402/1005) 001-310456W016 2
R402L,402R,116,126 CHIP RESISTOR 15 Kohm +-5% 1/16W (0402/1005) 001-315356W016 4
SR75 CHIP RESISTOR 220 ohm +-5% 1/16W (0603/1608) 001-322152W016 1
SR2,3,4,5,6,7,8,9 CHIP RESISTOR 2.2 Kohm +-5% 1/16W (0402/1005) 001-322256W016 8
SR59 CHIP RESISTOR 30 Kohm +-5% 1/16W (0402/1005) 001-330356W016 1
SR89,91,92, SC121 CHIP RESISTOR 33 Kohm +-5% 1/16W (0402/1005) 001-333356W016 4
SR93,94,95,96 CHIP RESISTOR 3.3 ohm +-5% 1/10W (0805/2012) 001-333850W010 4
SR69,70,71,72 CHIP RESISTOR 3.3 ohm +-5% 1/16W (0402/1005) 001-333856W016 4
R101,430L,430R CHIP RESISTOR 3.9 Kohm +-5% 1/16W (0402/1005) 001-339256W016 3
SR1,74, R93,106,124,125 CHIP RESISTOR 4.7 Kohm +-5% 1/16W (0402/1005) 001-347256W016 6
SR61,67 CHIP RESISTOR 47 Kohm +-5% 1/16W (0402/1005) 001-347356W016 2
R6,95,112,117,123 CHIP RESISTOR 470 Kohm +-1% 1/16W (0402/1005) 001-347416W016 5
R10,403L,403R CHIP RESISTOR 5.6 Kohm +-5% 1/16W (0402/1005) 001-356256W016 3
R8 CHIP RESISTOR 56 Kohm +-5% 1/16W (0402/1005) 001-356356W016 1
R7 CHIP RESISTOR 68 Kohm +-5% 1/16W (0402/1005) 001-368356W016 1
R251 CHIP RESISTOR 820 ohm +-5% 1/16W (0402/1005) 001-382156W016 1
R9,118,121,122 CHIP RESISTOR 820 Kohm +-5% 1/16W (0402/1005) 001-382456W016 4
CAPACITORS
SC113,135,137,139 CHIP CAP 0.001 uF/50V +-10% (0603/1608) 003-510212W050 4
(MCH185C102KK/GRM39X7R102K50PT)
C081 SC82 CHIP CAP 1000 pF/50V +-10% (0402/1005) 003-510214W050 2
SC108,109,112,120 CHIP CAP 0.01 uF/100V +-10% (0805/2012) 003-510310W100 4
C10 CHIP CAP 0.01 uF/50V +-10% (0603/1608) 003-510312W050 1
(GRM39B103K50PT)
C34,807 CHIP CAP 0.1 uF/50V +-10% (0805/2012) 003-510410W050 2
SC1,5,89,90,92,93,97,98, CHIP CAP 0.1 uF/100V +-10% (0805/2012) 003-510410W100 10
100,101
C04,94,123 CHIP CAP 0.1 uF/50V +-10% (0603/1608) 003-510412W050 3
SC79,80,103,104,107 CHIP CAP 0.1 uF/16V +-10% (0402/1005) 003-510414W016 5
C409L2,409L3 CHIP CAP 1 uF/16V +-10% (0603/1608) 003-510512W016 2
C81,83,84,86,87,90,103,104, CHIP CAP 1 uF/10V +-10% (0402/1005) 003-510514W010 17
105,125,131,402R,410R1,
410L1,411L,411R,453L
SC8,69,70,73,74,106,126, CHIP CAP 10 uF/10V +-10% (0805/2012) 003-510610W010 10
127,128,129
C31 CHIP CAP 10 uF/16V +-10% (0805/2012) 003-510610W016 1
C408R1,408R2 CHIP CAP 0.15 uF/16V +-10% (0603/1608) 003-515412W016 2
C407R1,407R2 CHIP CAP 0.22 uF/16V +80-20% (0402/1005) 003-522484W016 2
SC105 CHIP CAP 330 pF/50V +-10% (0402/1005) 003-533114W050 1

ELECTRICAL PARTS LIST - CONTINUED
6
Ref. No. Description Mfr's Part No. Qty.
SC87,94,95,102 CHIP CAP 0.033 uF/50V +-10% (0603/1608) 003-533312W050 4
C6,88,119,124,135 CHIP CAP 47 pF/50V +-10% (0402/1005) 003-547014W050 5
SC81 CHIP CAP 0.0047 uF/50V +-10% (0402/1005) 003-547214W050 1
C404R1,404R2 CHIP CAP 0.0056 uF/50V +-10% (0402/1005) 003-556214W050 2
C2 CHIP CAP 100 pF/50V +-10% NPO (0402/1005) 003-610114W050 1
C3,106,116,408,409,062,063, CHIP CAP 100 pF/50V +-5% NPO (0402/1005) 003-610154W050 19
064,065,066,067,068, SC75, (GRM36C0G101J50PT)
76,77,78,110,123,124
SC130,131,132,133 CHIP CAP 150 pF/50V +-5% NPO (0402/1005) 003-615154W050 4
C115,117,118 CHIP CAP 22 pF/50V +-5% NPO (0402/1005) 003-622054W050 3
(GRM36C0G220J50PT)
SC125,134,136,138 METALLIZED POLYESTER FILM CAP 1 uF/63V 004-110512W063 4
+-10% (MEF-105K0063DT1058) PITCH:5mm
SC91,96,99 ELECT CAP 1000 MFD/50V +-20% 85C (13x25) 006-010201W50D 3
EC1 ELECT CAP 10 MFD/50V +-20% (5x11) 006-81000AW50D 1
(TAPING PITCH:2.5mm)
C805,806 ELECT CAP 100 MFD/35V +-20% (8x11.5mm) 006-810100W35D 2
(TAPING PITCH:5mm)
C400, SC84 ELECT CAP 100 MFD/16V +-20% (5x11) 006-81010AW16D 2
(TAPING PITCH:2.5mm)
SC111 ELECT CAP 220 MFD 16V +-20% (6.3x11) 006-82210AW16F 1
(TAPING PITCH:2.5mm)
C1,071,121,515 ELECT CAP 47 MFD/16V +-20% (5x11) 006-84700AW16D 4
(TAPING PITCH:2.5mm)
C98 ELECT CAP 470 MFD/16V +-20% (10x12.5) 006-847100W16D 1
(TAPING PITCH:5mm)
C11,810 ELECT CAP 470 MFD 10V +-20% (6.3x12) 006-84710AW10F 2
(TAPING PITCH:2.5mm)
TRANSISTORS
SQ3, Q5,7,504 CHIP TRANSISTOR MMBT3904/MMBT3904LT1/ 008-A03904W000 4
3DG3904M/T3904 (T&W)
Q9 CHIP TRANSISTOR S8050LT1/C3265-EY2 008-A08050W000 1
SQ4 TRANSISTOR 3CA8550M-C/8550M-C 008-A08550W000 1
INTEGRATED CIRCUITS
U1 IC MP2451DT 36V/0.6A STEP-DOWN CONVERTER 010-232451W000 1
(SOT23-6L)
U4,5, IC9 IC D4558 (SOP8) 010-334558W001 3
IC12 IC TDA7440D (SMT):ROHS AUDIO PROCESSOR IC (S.T) 010-527440W000 1
U3 IC TAS5611PHD/TAS5611A ANALOG-INPUT 010-835611W000 1
POWER STAGE 64PIN HTQFP
DIODES
D10 CHIP ZENER DIODE RLZ 4.7V 1/2W RLZ 4.7B 011-010047W126 1
(RLZTE-114.7B) F011-010047W125
D9 CHIP ZENER DIODE 8.2V 1/2W ZMM5237BST 011-010082W126 1
D403 CHIP DIODE (SMT) LS4148(KT)/LL4148 011-044148W002 1
D11 CHIP SCHOTTKY BARRIER RECTIFIER B340A 011-050340W000 1
3A/40V DO-214AC (TAPING)
INDUCTORS
L19 POWER INDUCTOR (SMT) 22 uH +-20% 1A 018-060226W306 1
SMT73-220M/68-073220410Q =018-060226-202
SL5,6,7,8 POWER INDUCTOR 22 uH +-15% 6A PKF1313-220 018-060226W805 4
L6-B-T1-LF(B) L=3.8 +-0.5mm (ROHS) (FENFA)
L15,22,23,24 CHIP FERRITE BEAD GZ1608Y102T(f) (SUNLORD) 032-101608W015 4
STGB1608-102PT
FB20 CHIP FERRITE BEAD 30ohm @100MHz/5A 032-101608W082 1
UPZ1608E300-5R0TF

7
ELECTRICAL PARTS LIST - CONTINUED
Ref. No. Description Mfr's Part No. Qty.
MISCELLANEOUS
L29,30 BEAD COIL TOR0953-270N-B-LF 27 uH +-40% 037-000953W270 2
SP1 SPEAKER TERMINAL JACK 4 PINS DS-207x2-01 118-040207W000 1
CN602 HEADER 4 PINS #TJC6-4A PITCH:3.96mm VERTICAL 135-000TJ6W040 1
CN603 HEADER 10 PIN SPEC #2001-WS-10 PITCH:2mm 135-2001WSW100 1
VERTICAL REPLACE:135-PHS100-100
CD SECTION with NEC-N CD MECHANISM #DA11VZ--N
RESISTORS
R67, L27 CHIP RESISTOR 0 ohm +-5% 1/16W (0603/1608) 001-300052W016 2
R36,149 CHIP RESISTOR 0 ohm +-5% 1/16W (0402/1005) 001-300056W016 2
R71 CHIP RESISTOR 10 ohm +-5% 1/16W (0402/1005) 001-310056W016 1
R5R CHIP RESISTOR 100 ohm +-5% 1/16W (T&W) (0402/1005) 001-310156W016 1
R007,13,14,15,16,17,23,27, CHIP RESISTOR 1 Kohm +-5% 1/16W (0402/1005) 001-310256W016 29
41,43,49,50,51,051,52,62,
065,067,068,114,0631,039R,
042R,1R,2R,7R,8R,9R, L21
R20,39,54,55,56,57,59,66, CHIP RESISTOR 10 Kohm +-5% 1/16W (T&W) (0402/1005) 001-310356W016 18
176,178,247,012,047,048,
049,054,R040R,041R
R19,21,38,99,108,113 CHIP RESISTOR 100 Kohm +-5% 1/16W (0402/1005) 001-310456W016 6
R64 CHIP RESISTOR 12 Kohm +-5% 1/16W (0402/1005) 001-312356W016 1
R65,72 CHIP RESISTOR 2 Kohm +-5% 1/16W (0402/1005) 001-320256W016 2
R53,63 CHIP RESISTOR 20 Kohm +-5% 1/16W (0402/1005) 001-320356W016 2
R58 CHIP RESISTOR 2.2 Kohm +-5% 1/16W (0402/1005) 001-322256W016 1
R11,12,60,076 CHIP RESISTOR 22 Kohm +-5% 1/16W (0402/1005) 001-322356W016 4
R005,006 CHIP RESISTOR 2.2 ohm +-5% 1/16W (0603/1608) 001-322852W016 2
R18 CHIP RESISTOR 330 ohm +-5% 1/16W (T&W) (0402/1005) 001-333156W016 1
R9,61 CHIP RESISTOR 3.3 Kohm +-5% 1/16W (0402/1005) 001-333256W016 2
R22,70 CHIP RESISTOR 3.3 Mohm +-5% 1/16W (0402/1005) 001-333556W016 2
R109 CHIP RESISTOR 470 ohm +-5% 1/16W (0402/1005) 001-347156W016 1
R45,46,47,48,110 CHIP RESISTOR 4.7 Kohm +-5% 1/16W (0402/1005) 001-347256W016 5
R82,83 CHIP RESISTOR 47 Kohm +-5% 1/16W (0402/1005) 001-347356W016 2
R81 CHIP RESISTOR 5.6 Mohm +-5% 1/16W (0603/1608) 001-356552W016 1
R3R CHIP RESISTOR 68 ohm +-5% 1/16W (0402/1005) 001-368056W016 1
CAPACITORS
C44,59,128,133,138 CHIP CAP 1000 pF/50V +-10% (0402/1005) 003-510214W050 5
C35,96 CHIP CAP 0.1 uF/16V +-10% (0603/1608) 003-510412W016 2
(87-A10-260-08G) (C1608JB1C104K) (TDK)
C003,005,07,008,009,016, CHIP CAP 0.1 uF/16V +-10% (0402/1005) 003-510414W016 41
018,021,023,024,026,027,
032,033,034,035,036,037,
039,041,42,46,48,049,050,
52,053,60,62,71,093,97,098,
100,122,127,130, SC7,83,
85,86
C32,129,132,136,137 CHIP CAP 1 uF/10V +-10% (0402/1005) 003-510514W010 5
C006,007 CHIP CAP 2.2 uF/6.3V +-20% (0402/1005) 003-522524W006 2
C36,37,38 CHIP CAP 470 pF/50V +-10% (0402/1005) 003-547114W050 3
C015,020 CHIP CAP 15 pF/50V +-5% NPO (0402/1005) 003-615054W050 2
(GRM36C0G150J50PT)
C43 CHIP CAP 18 pF/50V +-5% NPO (0402/1005) 003-618054W050 1
(GRM36C0G180J50PT)
C4,16 CHIP CAP 22 pF/50V +-5% NPO (0603/1608) 003-622052W050 2
(GRM39C0G220J50PT)
C012,18 CHIP CAP 22 pF/50V +-5% NPO (0402/1005) 003-622054W050 2
(GRM36C0G220J50PT)

ELECTRICAL PARTS LIST - CONTINUED
8
Ref. No. Description Mfr's Part No. Qty.
C002,004 CHIP CAP 0.0047 uF/50V +-10% (0402/1005) 003-547214W050 2
C19 ELECT CAP 10 MFD/50V +-20% (5x11) 006-81000AW50D 1
(TAPING PITCH:2.5mm)
C7,8,011,40,45,50,51,54,56, ELECT CAP 100 MFD/16V +-20% (5x11) 006-81010AW16D 11
58,120 (TAPING PITCH:2.5mm)
C12,63,66,107,148 ELECT CAP 220 MFD/10V +-20% (6.3x11) 006-82210AW10D 5
(TAPING PITCH:2.5mm)
C65 ELECT CAP 47 MFD/25V +-20% (5x11) 006-84700AW25D 1
(TAPING PITCH:2.5mm)
C61,99 ELECT CAP 470 MFD 10V +-20% (6.3x12) 006-84710AW10F 2
(TAPING PITCH:2.5mm)
TRANSISTORS
Q27 TRANSISTOR-BUK&TO-126 B772 008-600772W000 1
Q001,007 TRANSISTOR 3CA8550/8550 008-685500W000 2
Q1,2,4,8,10,11 CHIP TRANSISTOR MMBT3904/MMBT3904LT1/ 008-A03904W000 6
3DG3904M/T3904 (T&W)
Q6 CHIP TRANSISTOR S8550LT1/A1298-IY 008-A08550W001 1
Q3 CHIP TRANSISTOR 3DA8050M-C/8050M-C 008-AJ8050W000 1
CRYSTALS
X2 CRYSTAL 32.768 kHz 12.5 pF +-5ppm (2x6mm) 009-332768W400 1
(COMMUTEK)
X11 CRYSTAL 12 MHz HC-49US (3x9mm) 009-612000W201 1
INTEGRATED CIRCUITS
IC8 IC AMS1117-1.5/D1117-1.5V (SOT-223) 010-001117W006 1
IC3 IC MFI341S2162 (w/135-003660W000 OR 001) 010-243411W007 1
U005 IC ME6118A33B3G (SOT223) (MICRONE) 010-246118W000 1
LOW CURRENT (WORLD ELITE)
IC1 IC SC9671-B CD & MP3 DECODER (QFP-128) 010-519671W000 1
(NANFENG)
IC2 IC SA1466TR (HSOP28) (NANFENG) 010-921466W000 1
IC03 IC GD25Q40 (SOP-8) (NANFENG) 045-F08512W101 1
DIODES
D5 CHIP ZENER DIODE UDZ3.9V/ZMM5228BST 011-040039W120 1
3.9V 1/2W (LL-34)
D1,4,6 CHIP DIODE (SMT) LS4148(KT)/LL4148 011-044148W002 3
D3 CHIP DIODE 1N5819WB (SOD-123) 011-045819W000 1
INDUCTORS
L003,4,5,7,8,9,10,11,014,28 CHIP FERRITE BEAD GZ1608Y102T(f) (SUNLORD) 032-101608W015 12
L409R,L409L STGB1608-102PT
MISCELLANEOUS
CN5 HEADER 5 PINS PEC #2001-WS-5 PITCH:2mm VERTICAL 135-2001WSW050 1
CN1,501 HEADER 6 PINS PEC #2001-WS-6 PITCH:2mm 135-2001WSW060 2
VERTICAL REPLACE:135-PHS060-060
CN006 HEADER 10 PIN SPEC #2001-WS-10 PITCH:2mm 135-2001WSW100 1
VERTICAL REPLACE:135-PHS100-100
CN009 FFC/FPC CONNECTOR 16 PINS PITCH:1mm 135-D100SSW160 1
#D100-SSA-16 VERTICAL/TOP CONTACT
NEC-N CD MECHANISM #DA11VZ--N 153-00DA11W003 1
CD LOADER MODULE JL-021 w/FCC CABLE 16P 165-0JL021W005 1
L=220mm 5P=200mm, 6P=140mm
iPod DOCK SECTION
RESISTORS
R487 CHIP RESISTOR 0 ohm +-5% 1/16W (0603/1608) 001-300052W016 1
R484,496,498 CHIP RESISTOR 100 ohm +-5% 1/16W (0603/1608) 001-310152W016 3
R479,481 CHIP RESISTOR 10 Kohm +-5% 1/16W (0603/1608) 001-310352W016 2
R480,483 CHIP RESISTOR 100 Kohm +-5% 1/16W (0603/1608) 001-310452W016 2

ELECTRICAL PARTS LIST - CONTINUED
9
Ref. No. Description Mfr's Part No. Qty.
R3 CHIP RESISTOR 100 Kohm +-5% 1/16W (0402/1005) 001-310456W016 1
R428 CHIP RESISTOR 43.2 Kohm +-1% 1/16W (0603/1608) 001-343B12W016 1
R147 CHIP RESISTOR 470 Kohm +-5% 1/16W (0402/1005) 001-347456W016 1
R419,477 CHIP RESISTOR 49.9 Kohm +-1% 1/16W (0603/1608) 001-350312W016 2
R420 CHIP RESISTOR 549 Kohm +-1% 1/16W (0603/1608) 001-355412W016 1
R478 CHIP RESISTOR 75 Kohm +-1% 1/16W (0603/1608) 001-375312W016 1
CAPACITORS
C9,906 CHIP CAP 0.1 uF/16V +-10% (0603/1608) 003-510412W016 2
(87-A10-260-08G) (C1608JB1C104K) (TDK)
C26,2,28,101,109 CHIP CAP 100 pF/50V +-10% NPO (0402/1005) 003-610114W050 5
C430,433,435,439,440,441, CHIP CAP 22 pF/50V +-5% NPO (0603/1608) 003-622052W050 9
442,443,444 (GRM39C0G220J50PT)
TRANSISTORS
Q406,410 TRANSISTOR 2SK3018 (ROHM) (SMD) 008-903018W000 2
SMALL SWITCHING N-CHANNEL MOSFET
Q07 CHIP TRANSISTOR MMBT3904/MMBT3904LT1/ 008-A03904W000 1
3DG3904M/T3904 (T&W)
DIODE
D12 CHIP ZENER DIODE 2.0V UDZ2.0B-TRB (ROHM) 011-010020W001 1
INDUCTORS
L013,32 FERRITE BEAD INDUCTOR #P10243NL/ 032-100243W000 2
Z1RH3.5x5x8w/FBS 75-350850 T5-R
L2,20,25,26 CHIP FERRITE BEAD GZ1608Y102T(f) (SUNLORD) 032-101608W015 4
STGB1608-102PT
L401,402 CHIP FERRITE BEAD PZ2012U601-1R5T(F)/ 032-102012W002 2
HCB2012KF-601T20 (0805/2012)
WIRE
CP7 HSG (2mm) PEC 2001H-12 w/220mm FLAT CABLE 136-F11222W000 1
AWG26#UL2651/GREY SLDG.:4mm
MISCELLANEOUS
J1 30 PINS iPod SOCKET BY AVNET MFI514S0117 135-003660W000 1
(APPLE NR.514S0117) VERTICAL
CN4 HEADER 12 PINS PEC #2001-WS-12 PITCH:2mm 135-2001WSW120 1
VERTICAL
KEY SECTION
RESISTORS
R201 CHIP RESISTOR 0 ohm +-5% 1/8W (1206/3216) 001-300051W018 1
FB1,2,3,4,5,6,7,8,9,10,11,12, CHIP RESISTOR 0 ohm +-5% 1/16W (0603/1608) 001-300052W016 18
13,17,18,19, R807,808
R702,789,790,791,792 CHIP RESISTOR 100 ohm +-5% 1/16W (0603/1608) 001-310152W016 5
R782 CHIP RESISTOR 1 Kohm +-5% 1/16W (0603/1608) 001-310252W016 1
R700,738 CHIP RESISTOR 10 Kohm +-5% 1/16W (0603/1608) 001-310352W016 2
R739,740 CHIP RESISTOR 6.8 Kohm +-5% 1/16W (0603/1608) 001-368252W016 2
R787 CHIP RESISTOR 82 Kohm +-5% 1/16W (0603/1608) 001-382352W016 1
S701 ROTARY ENCODER EC121102X2B-HA1-106 030-H12000W200 1
CAPACITORS
C727,739,740,759,760 CHIP CAP 0.001 uF/50V +-10% (0603/1608) 003-510212W050 5
(MCH185C102KK/GRM39X7R102K50PT)
C725 CHIP CAP 0.1 uF/16V +-10% (0603/1608) 003-510412W016 1
(87-A10-260-08G) (C1608JB1C104K) (TDK)
C726,728,751,752,753 CHIP CAP 0.1 uF/50V +80-20% (0603/1608) 003-510482W050 5
(GRM188F11H104ZA01D+C1) (MURATA)
C707,708 CHIP CAP 0.047 uF/50V +-10% (0603/1608) 003-547312W050 2
(GRM39B103K50PT)
C710,711,712,714 CHIP CAP 33 pF/50V +-5% NPO (0603/1608) 003-633052W050 4
(GRM39COG330J50PT/MCH185A330JK)

ELECTRICAL PARTS LIST - CONTINUED
10
Ref. No. Description Mfr's Part No. Qty.
C758 ELECT CAP 2.2 MFD/50V +-20% (5x11) 006-802000W50D 1
(TAPING PITCH:5mm)
C730,756 ELECT CAP 47 MFD/16V +-20% (5x11) 006-847000W16D 2
(TAPING PITCH:5mm)
INTEGRATED CIRCUIT
IC701 IC DISPLAY DRIVER-VFD CS16315 (LQFP44) 010-411631W000 1
DIODES
D707,708,709,710,711,712, DIODE IN-4148 ROHM/TELEFUNKEN TAP**50 011-004148W000 11
713,714,715,716,760 KEL(NS)T:52mm/NS(FAIRCHILD)/SEMTECH
SWITCHES
SW701,702,703,704,705, TACT SW SKQNABD010 (ALPS) G20D00000220 021-SKQNABW000 20
706,707,708,709,710,711,
713,714,717,718,719,720,
721,722
WIRES
CP2 HSG (2mm) PEC 2001H-06 w/120mm GREYx6 136-F10612W000 1
AWG26#UL2651 SLDG:3.5mm (P/N: AH700508)
CP3 HSG (2mm) PEC 2001H-10 w/115mm FLAT CABLE 136-F11011W500 1
AWG26#UL2651/TAT GREY SLDG.:3.5mm
MISCELLANEOUS
D726 LED 3mm RED BT-202D-31 (FOSHAN)/ 110-033040W003 1
1L034XH11A0DA002 (BRIGHTEK)
IR701 REMOTE/CONTROL INFRARED RECEIVER MODULE 111-003575W001 1
(SM3573JM3) (56.7kHz) (SILAN OPTRONICS)
DS701 VACUUM FLUORESCENT DISPLAY VFD25-1014FN 115-251014W000 1
(BOE)
NJ602 HEADPHONE JACK 3.5mm TC38-103-01 116-038103W350 1
w/SWITCH BLACK COLOUR VERTICAL TYPE
POWER SECTION
MISCELLANEOUS
POWER SUPPLY MODULE 038-CD2961W001 1
POWER CORD SAA-MG2.05mm7.5A H03VVH2-F MIG. 134-B11551W01U 1
w/SR250mm+HSG, w/TERM BLK (YIP CHUN)
RADIO SECTION
RESISTORS
L1,3 CHIP RESISTOR 0 ohm +-5% 1/16W (0603/1608) 001-300052W016 2
R85,86,87,88,89,100,105 CHIP RESISTOR 1 Kohm +-5% 1/16W (0402/1005) 001-310256W016 7
R77,84 CHIP RESISTOR 10 Kohm +-5% 1/16W (T&W) (0402/1005) 001-310356W016 2
R5,083 CHIP RESISTOR 200 ohm +-5% 1/16W (0402/1005) 001-320156W016 2
R107 CHIP RESISTOR 22 Kohm +-5% 1/16W (0402/1005) 001-322356W016 1
R90,91 CHIP RESISTOR 47 Kohm +-5% 1/16W (0402/1005) 001-347356W016 2
CAPACITORS
C031,77,78 CHIP CAP 1000 pF/50V +-10% (0402/1005) 003-510214W050 3
C09,15,21,25,33,39 CHIP CAP 0.1 uF/16V +-10% (0402/1005) 003-510414W016 6
L13,14, C75,76 CHIP CAP 1 uF/10V +-10% (0402/1005) 003-510514W010 4
C30,72,55,57,67,79,80 CHIP CAP 47 pF/50V +-10% (0402/1005) 003-547014W050 7
C14,29 CHIP CAP 15 pF/50V +-5% NPO (0402/1005) 003-615054W050 2
(GRM36C0G150J50PT)
C47 ELECT CAP 100 MFD/16V +-20% (5x11) 006-81010AW16D 1
(TAPING PITCH:2.5mm)
TRANSISITORS
Q101 CHIP TRANSISTOR MMBT3904/MMBT3904LT1/ 008-A03904W000 1
3DG3904M/T3904 (T&W)
Q102 TRANSISTOR 3CA8550M-C/8550M-C 008-A08550W000 1
INTEGRATED CIRCUIT
IC7 IC SI4702 010-514702W000 1
!

Ref. No. Description Mfr's Part No. Qty.
CRYSTAL
XT1 CRYSTAL 32.768 kHz +-20ppm (CSA206) 009-332768W100 1
(COMMUTEK) (87-A70-170-01C)
DIODES
D2 CHIP ZENER DIODE 3.3V 1/2W ZMM3.3HSA 011-010033W125 1
D7,8 CHIP DIODE (SMT) LS4148(KT)/LL4148 011-044148W002 2
INDUCTORS
L6 CHIP INDUCTOR 270 nH +-5% (0603/1608) 018-040270W100 1
SDCL1608CR27JT(f) (SUNLORD)
L12,17,18 CHIP FERRITE BEAD GZ1608Y102T(f) (SUNLORD) 032-101608W015 3
STGB1608-102PT
WIRE
FMANT1 JP WIRE AWG26#UL1007 3.5xDIA.6mm 1500mm 051-679A50W009 1
BLACK WITH BLACK H.S.T TUBE DIA.:2mm
ELECTRICAL PARTS LIST - CONTINUED
11
Notes: Symbol in parts list represent safety parts.
!

PRINTED CIRCUIT BOARDS
iPod PCB (TOP VIEW)
CD2961I-01-02
iPod PCB (BOTTOM VIEW)
CD2961I-01-02
12

13
KEY PCB (TOP VIEW)
CD2961I-01-03

14
KEY PCB (BOTTOM VIEW)
CD2961I-01-03

MAIN PCB (TOP VIEW)
CD29611-01-01
15 16

17 18
MAIN PCB (BOTTOM VIEW)
CD29611-01-01

19 20
WIRING DIAGRAM
[D] MAIN PCB
[A] KEY PCB
FM ANT.
[C] iPod PCB
CP2
CP3
N501
CN006
CP7
CN603
CN602
CN1
CN5
CN009
FM-ANT1
[F] POWER PCB
CN4
CN2
CN4
[G] CD MOTOR PCB
[B] CD PICK UP PCB
RED
BLK
MOTOR
HSG (2mm) PEC 2001H-06 w/120mm GREYx6
AWG26#UL2651 SLDG.:3.5mm (P/N: AH700508)
HSG (2mm) PEC 2001H-10 w/115mm FLAT CABLE
AWG26#UL2651/TAT GREY SLDG.:3.5mm
HSG (2mm) PEC 2001H-12
w/220mm FLAT CABLE
AWG26#UL2651/GREY SLDG.:4mm
JP WIRE AWG26#UL1007 3.5xDIA.6mm 1500mm
BLACK WITH BLACK H.S.T TUBE DIA.:2mm
[D] DOOR SENSOR PCB
FFC CABLE 16 PINS
2 PINS BLACK WITH RED
6 PINS CABLE
FLAT CABLE 5 PINS
12 PINS CABLE
4 PINS CABLE
+
-

AUDIO SECTION
21 22
SCHEMATIC DIAGRAMS
NOTES:
1. All resistance values are indicated in "ohms"(k=1000 ohms. M=1000 Kohms).
2. All capacitance values are indicated in "µF" (p=10 µF).
-6
R105
1K
Q102
8550
R100
1K Q101
3904
3
2
1
4
CN602
TO-POWER
C612
104
C33
104
C47
10uF
C57
47pF
R89
4.7K
R88
4.7K
C55
47pF
R91
47K
R90
47K
1NC_
2FMANT
3RFGND
4AMANT
5RST
15
DOUT
14
LOUT
13
ROUT
12
GND
11
VDD
16
DFS
17
GP03DCLK
18
GP02INT
19
GP01
20
NC
10 VIO
9RCLK 8SDIO 7SCLK 6SEN
C29
15pF
XT1
32.768KHz
C14
15pF
C031
102P
FMANT1
D8
IN4148
D7
IN4148
C39
104
R85
1K
R87
1K
R84
10K
R77 10K
L12
FB1K
R86
1K
+
-
3
2
1
4
8
+
-
5
6
7
C103
1U
C104
1U
C105
1U
L22
FB1K
L24
FB1K
C480
22p
C106
100P
C116
100P
R106
4K7
R116 15K
R126 15K
R93 4K7
R124 4K7
R94 100R
R95 470K
R117
470K
R118 820K
R121
820K
R122
820K
R96 820K R112 470K
R123 470K
R125 4K7
+
C120
220U/16V
C123
104
C16
104
+
C121 47U/10V
C86
1uF
C87
1uF
C88 47P
C119 47P
R102
10K
R103
10K
L15
FB1K
C83
1U
C84 1U
C81
1U
R42 NC
C102 22P
C108
22P
C115
22P
C118
22P
SR69 3R3
SR53 NC
1
_
+
1000uF/50V
SC139
1NF/100V
1
_
SR63 NC
SR94
3R3
1
_
SC10233nF/50V
100nF/100V
SL6
SC89
100nF/100V
SC90
100nF/100V
+SC99
1000uF/50V
SR52
100R
SR50 NC
SL7
SR71 3R3
SR79
NC
SC92
100nF/100V
SC120
10NF/100V
SC108
10NF/100V
1OC-ADJ
2RESET
3C-STARTUP
4INPUT-A
5INPUT-B
6VI-CM
7GND
8AGND
9VREG
10 INPUT-C
11 INPUT-D
12 FREQ-ADJ
13 OSC-IO+
14 OSC-IO-
15 SD
16 OTW1
17 OTW2 18 CLIP 19 READY 20 M1 21 M2 22 M3 23 GND 24 GND 25 GVDD-C 26 GVDD-D 27 BST-D 28 OUT-D 29 OUT-D 30 PVDD-D 31 PVDD-D 32 GND-D
33
GND-D
34
GND-C
35
GND-C
36
OUT-C
37
OUT-C
38
PVDD-C
39
PVDD-C
40
BST-C
41
BST-B
42
PVDD-B
43
PVDD-B
44
OUT-B
45
OUT-B
46
GND-B
47
GND-B
48
GND-A
64
VDD 63
PSU-REF 62
NC 61 NC 60 NC 59 NC 58
GND 57 GND 56
GVDD-B 55 GVDD-A 54
BST-A 53
OUT-A 52 OUT-A 51
PVDD-A 50 PVDD-A 49
GND-A
1
_
SC109
10NF/100V
SR64 10K
SR93
3R3
SC101
100nF/100V
SR81
NC
SC94
33nF/50V
SR86
100R
SR84 NC
SC125
1
_
SC137
1NF/100V
SL8
SC136
SC98
100nF/100V
SC87 33nF/50V
SR65
0R
SR59 30K
SC113
1NF/100V
SC93
100nF/100V
SR62
100R
SR80
NC
SC134
SR95
3R3
1
_
SR72 3R3
SR49
100R
1
_
SR96
3R3
SC138
SC135
1NF/100V
SC95
33nF/50V
SC100
100nF/100V
SR61
47K
SR70
3R3
SR82
NC
SL5
SC112
10NF/100V
R0106 1K +C650
47uF
SR1
4.7K
Q504
3904
SQ3
3904
SR74
4.7K
SQ4
8550
SR66
1K
SR67
47K
15
BOUT(L)
16
NC16
17
NC17
18
TREBLE(L)
19
TREBLE(R)
20
DIG-GND
21
SCL
22
SDA
23
CREF
24
VS
25
AGND
26
ROUT
27
LOUT
28
R-IN4
14 BIN(L)
13 BOUT(R)
12 BIN(R)
11 MUXOUT(R)
10 IN(L)
9MUXOUTL 8R-IN4 7L-IN4 6L-IN3 5L-IN2 4L-IN1 3R-IN1 2R-IN2 1R-IN3
D403
LL4148
R0420
100R
R401R 10K
R402R
15K
C402R
1UF
C402L
1UF
R401L 10K
R402L
15K
C407R1
220NF
C411R
1UF
C410R
1UF
C410L
1UF
C404R
5N6F
C404L
5N6F
C453R 1UF
C411L
1UF
C125
1UF
R403R
5K6
C408R1
220NF
C401L1UF
C453L
1UF
C409R
1UF
C409L 1UF
R1 1K
R2 1K
C02
100PF
C3
100PF
+
C400 100UF/10V
C061R 1NF
C408R2
150NF
C407R2
220NF
R403L
5K6
+
C1
47UF/25V
SC73
10uF
78 100PF SC77
100PF
SC70
10uF
SC129
10uF
SC124
100PF
SC123 100PF
SC127
10uF
SC110
100PF
Sc81 4.7NF
Sc82 1NF
SC83 0.1uF
SC86
0.1uF
SC85
0.1uF
SC118
NC
SC119
NC
SC117 NC
SC116 NC
SC103
0.1uF
SC104
0.1uF
SC106
10uF
SC105
330PF
SC107 0.1uF
4OUTO
2OUT 3
IN
1
GND
C89
470uF/16V
C34
104
SR73 NC
1
2
SP901
1
2
SP1
D9
8.2V
R251
820R
+
C515
47uF/16V
SR75 NC
R5
200R
D2
3.3V
SR57
100R
SR85 10K
SR88
10K
SR87 10K
SR83 10K
SR58
NC
SC74
10uF
SC133
150PF
SC76
100P
SC131 150PF
1ch
2ch
1234
5 6 7 8
SR8 2.2K
SR6
2.2K
SR9
2.2K
SR7
2.2K
+
SC111
220uF/16V
SC128
10uF
SR92 33K
SR91
33K
SR55
100R
SR48
10K
SR54
10K
SR51 10K
SR47 10K
SR56 NC
SC69
10uF
SC132
150PF
SC75
100P
SC130
150PF
1ch
2ch
1234
5 6 7 8
SR4
2.2K
SR2
2.2K
SR5
2.2K
SR3 2.2K
+12VB
SC126
10uF
SR8933K
SC121
33K
C09
104
R083
200R
R107
22K
L6
270nH
L3
0R
L1
0R
C41 NC
C72
47P
C67
47P
C30
47P
C75
2.2uF
C76
105
L14
FB1K
L13
FB1K
C78
102P
C77
102P
C80
47pF
C79
47pF
SR68
10K
SD4
IN4148
SC79
104
SC80
104
+
SC84
100uF
13
24
L30
27uH
13
24
L29
27uH
SC1
NC
SC2
NC
SC3
NC
SC4
NC
SC5
NC
SC6
NC
C135
47P
C124
47P
L23
FB1K
+
C071
47uF/16V
R431R
10K
R431L 10K
R430L 3.9K
R430R 3.9K
Q811
NC
R800
0R
R528
NC
C081
102P
C810
470uF/16V
SQ1
3904
SQ2
3904
SR10
47K
SR11
100R
SR12
3.9K
D11
4.7V
Q11
8050
L355
EC309
2.2uF/50V
R8 100K
C414
100NF/100V
R9 5.6K
D310
R10 68K
FB86 0R
C326 0.1uF
C327 10uF
C422 47PF
C423 10NF/50V
1 BST
2GND
3FB 4
EN
5
VIN
6
SW
L356
R24 3.3K
+ SC810
220uF/10V
R25 56K
C418 0.1uF
3
2
1
4
5
6
7
8
9
10
CP1
R30
2K
D13
8.2V
D502R
NC
R506R
NC
R506L
NC
D502L
NC
R503
NC
R504
NC
R505
NC R509
NC
Q503
NC
Q502
NC
R517
NC R516
NC
R518
NC
Q507
NC
1
2N502
NC
+C503
NC
R506
NC
Q506
NC
TUNERPOWER-AA
+36V
+36V
GND
+8V
TU+3.3V
TU+3.3V
RADIO_L
RADIO_R
RADIO_RST SCL SDA
IP_AGND
IPOD_ROUT
IPOD_LOUT
IP/R
IP/L
+12V
VREG
PVDD
VREG
GVDD
GVDD
RESET VREG
APMUTE
RESET
GVDD
+12V
AGND
RSCL
RSDA
AUDIO_R
AUDIO_L
IP/L
IP/R
CD-R
CD-L
AGND
LINE_R
LINE_L
+8V
RADIO_L
RADIO_R
+12V
+5V
RIGHT+
LIGHT+
RELON-STB1
B
A
+12V
+8V
+12V
+12VB
AC3
AC3V
-27V
P+5V
AUDIO_R
AUDIO_L
RELON-STB1
RELON-STB
+12V
P+5V
+12V
PVDD
AMP-CT/RELON-STB
VCC-PC
+12VB +33V
LIGHT+
RIGHT+
+12V
+8V
APMUTE
AGND
+12VB
IC9-B
D4558
IC9-A
D4558
U1
MP2451
IC406
CD1117(5V)_/NC
IC7
SI4702
U5
D4558
U4
D4558
U3
TAS5611PHD
IC12
TDA7440D

23 24
NOTES:
1. All resistance values are indicated in "ohms"(k=1000 ohms. M=1000 Kohms).
2. All capacitance values are indicated in "µF" (p=10 µF).
-6
CD SECTION
IP_DET
ROUT
LOUT
IP_GND
IP_TX
IP_RX
ACC_DET
ACC_POWER
IP+5V
GND
CONNECT TO CD BOARD CN7
102
SDCLK
101 VSS..
100 SD_CSN
99 SVODEBUGEN
98 SVOTESTEN
97 PE0
96 PE1
95 SFDI
94 SFDO
93 SF_CSN
92 SF_CLK
91 AVDD15
90 AVSS
89 DMO
88 SLO
87 FOO
86 TRO
85 TP3.
84 TP3
83 TP2
82 TP1
81 REX
80 AN_CC
79 BK_INP
78 BK_INN
77 RFI
76 RFO
75 LDO
74 MD
73 V21O
72 V165O
71 A
70 B
69 C
68 D
67 E
66 F
65 AV3DD
1
NC
2
VSS
3
PE3
4
LINEOUT_R
5
DAC_VSS
6
DAC_VDD
7
LINEOUT_L
8
VIMD
9
AVSS,,
10
KEYADC0
11
KEYADC1
12
KEYADC2
13
KEYADC3
14
AVDD
15
AVDD_MTR
16
FMIN
17
AMIN
18
AGND_MTR
19
AVSS_DC
20
LX
21
AVDD_DC
22
VOUTFB
23
DN
24
DP
25
VPP
26
CLK12MXI2
27
CLK12MXO2
28
VSS.
29
RESETN
30
POWERON
31
PD7
32
PD6
33
PD5
34
VDD15
35
VDD33
36
VSS,
37
PB0
38
PB1
128
RTC
127
OSC_OUT
126
OSC_IN
125
CONFIG1
124
DEBUG_TEST
123
VDD15,
122
PC7
121
PC6
120
PF1
119
PF0
118
PA7
117
PA6
116
PA5
115
PA4
114
PA3
113
PA2
112
PA1
111
PA0
110
VDD33,.
109
VSS,.
108
VDD33.
107
VSS,,
106
VDD33,
105
SDI
104
SDO
103
VDD15,,
39
PB2
40 PB3 41 PB4 42 PB5 43 PB6 44 PB7 45 PC0 46 PC1 47 PC2 48 PC3 49 PC4 50 PC5 51 VDD33.. 52 PD0 53 PD1 54 PD2 55 PD3 56 TEST 57 CONFIG0 58 CONFIG2 59 VDD15., 60 VSS' 61 PF4 62 PF3 63 PF2 64
AGND
R1R
1K
R2R
1K
C002
472
C004
472
C7
100uF
C005
104
C011
100uF
R3R
68R
R005
2R2
C035
104
C039
104
C036
104
C07
104
X1
12MHz
R18
330
R19
100K
C18
22pF
C012
22pF
Q1
3904
C19
10uF
C009
104
R007
1K
R054
10K
D1
IN4148
R012
10k
C027
104
C032
104
C008
104
C023
104
C024
104
X2
32.768Hz
C020
15pF
C015
15pF
C97
104
C033
104
C053
104
C018
104
C021
104
16
FOC-
15
RAD-
14
RAD+
13
FOC+
12
MON
11
VR
10
LD
9
GND
8
F
7
C
6
B
5
A
4
D
3
E
2
RFVCC
1
VCOM
CN009
1
VINFC
2
TRB_1
4
VINSL
3
REG03
5
REG01
6
FWD
7
REV
8
VCC1
9
VOTR-
10
VOTR+
11
VOSL+
12
VOSL-
13
VOFC-
14
VOFC+
15 VOTK+
16 VOTK-
17 VOLD+
18 VOLD-
19 VCC2
20 NC
21 VCTL
22 GND
23 VINLD
24 NC.
25 TRB_3
26 VINTK
27 BIAS
28 MUTE
1
CSN
2
DO
3
W
4
VSS
5DI
6CLK
7HOLD
8VCC
C35
104
L4
FB1K
R45 4K7
R46 4K7
R47 4K7
R48 4K7 R49 1K
R50 1K
R51 1K
R52 1K
C36
470P
C37
470P
C38
470P
C093
104
C40
100uF
C42
104
C041
104
R53 20K
C43 18P
R54 10K
R55 10K
R56
10K
R57
10K
C44
102
L5
FB
C45
100uF
C46
104
C037
104
C100
104
R60
22K
R61
3K3
3
2
1
4
5
6
CN1
R62
1K
C049
104
Q001
8550
Q007
8550
R63
20K
64
12K
R65
2K
R75
10K
C50
100uF
C51
100uF
C74
104
Q6
9015
C026
104 C54
100uF
C016
104
C56
100uF
C034
104
R71
10R
R79
2K
C58
100uF
C59
102
C62
104
C71
104
Q27
772
Q8
3904
R59
10k
R108
100k
R109
470R
R110
4.7k
D3
IN5819
C098
104
C003
104
L7
FB1K
L8
FB1K
L9
FB1K
L10
FB1K
L11
FB1K
C007
4.7uF
C006
4.7uF
C107
220uF
C66
220uF
R067 1K
R039R 1K
R042R 1K
C52
104
C61
470uF
R67
0R
C63
220uF
4OUTO
2OUT 3
IN
1
GND
TEST3
TEST4
TEST5
TEST6
R176
10K
R178
10K
D5
3.9V
R5R
100
R7R
1K
R8R
1K
R9R 1K
R27 1K
R4
NC
C93
104
R192
10K
R193
10K
R065
1K
R14
1K
4
OUTO 2
OUT
3IN
1
GND
C94
104
C96
104 C050
104
C99
470uF
R0631
1K
R217
1K
R048
10K
R049
10K
R247
10K
1
E0
2
E1
3
E2
4
VSS
8VCC
7WC
6SCL
5SDA
J130
NC
J131
NC
C95
NC
3
2
1
4
5
6
7
8
9
10
CN006
L32 FB
R051
1K
R068
1K
1
NC
2
MODE1
3
NC
4
NRST
5
VCC
15 NC
14 SODE0
13 SDA
12 ISCL
11 VSS
16
NC
17
NC
18
NC
19
NC
20
NC
10 NC
9NC 8NC 7NC 6NC
C127
104
R16
1K
R13
1K
R15
1K
R11
10K
L26 FB1K
L25 FB1K
L21 FB1K
L20 FB1K
L2 FB1K
R3
100K
R6
100K
R147
470K
Q07
3904
R148
100K
C65
47uF
R38
100K
R39
10K Q3
8050
R41
1K
R43
1K
Q2
3904
Q4
3904
Q5
3904
C32
1uF
C136
1uF
C128
102P
C138
1000P
R22
3.3M
R70
3.3M
R21
100K
R113
100K
R82
47K
R83
47K
C131
1uF
C132
1uF
R81
5.6M
R99
100K R114
1K
C133
102P
C229
0.1U
D6
1N4148
C137
2.2uF
C129
2.2uF
L28
600R/500mA
D4
1N4148
3
2
1
4
5
6
N501
1
2
3
4
5
CN5
C2
22P
C110
22P
C5
22P
C11122P
C22
22P
C9
104P
C24
100P
C13
22P
C23
22P
1
2
3
4
5
6
7
8
9
10
11
12
CN4
R17
1K
R23
1K
C126
100uF
R20
10K
R12
10K
R006
2R2
C12
220uF
R047
10K
R040R
10K
R041R
10K
C109
22P
C101
22P
C28
22P
C26
22P
C27
22P
R58
2.2K
C8
100uF
L013
Q09
3904
R026
1K
R028
1K
D10
2V
VDD3V3
VDD3V3
VDD3V3
RESET
VDD3V3
VDD3V3
VDD1.5V
VDD3V3
VDD1.5V
VDD3V3
VDD1.5V
VDD1.5V
VDD3V3 VDD3V3
VDD3V3
VDD3V3
VDD3V3
VDD3V3
SE_DI
SE_DO
SE_CSN
SE_CLK
SFAGND
TRO
FOCO
SLO
DMO
SFAGND
SF12
SFAGND
SFAGND
VCC15
AN_REX
AN_CC
MOTO+.
MOTO-.
A
B
C
D
E
FF
SFAGND
PD1
MGND
SLEDSW
SLED-
SLED+
SLED+
MOTO-
MOTO+
RAD+
RAD-
FOC+
MGND
MGND
CD5V
MGND
MGND
MGND
VCC3
VCC3
MGND
VCC15
CD5V
FOC-
SFAGND
SFAGND
FF
C
B
A
D
E
SFAGND
POWGND POWGND
PD0
MGND
MGND
POWGND
PROTECT
AMP-CT/RELON-STB
NRST
IR
VCC3V3
VDD3V3
MGND
SLED-
CD5V
VDD3V3 SLIDER-UP1
SLIDER-DN
IR
VOL-
VOL+
CD_R
DACGND
CD_L
CD_PWR
APMUTE
-30V
TUNERPOWER-AA
VDD1.5V
POWGND
VOL+
VOL-
VDD3V3
APMUTE
DISC-SW
PLATTER-SW
SLIDER-DN
GND
SCL SDA
GND
IR
VFD_CS
VFD_CLK
VFD_DIO
-30V
FIL-
AGND
P+5V
FIL+
VCC3V3
RSCL
RSDA
VDD3V3
NRST
PE1
PE0
VDD3V3
PE0
PE1
RADIO_RST
VDD3V3
IPOD_ROUT
IP_AGND
IPOD_LOUT
USB+5V
AGND AGND AGND
VDD3V3
AGND
AGND
AGND
VOL-
VOL+
GND
LINE_R
GND
LINE_L
A
B
P+5V
+8V
DTRAY+
DTRAY-
MGND
DTRAY+
DTRAY-
+5V
DOORCL
DOORCL
STDBY_DET
SLIDER-DN
SLIDER-DN1
DOOROP1
DOOROP
VDD3V3
RSCL
AMP-CT
VCC-PC
TO AUDIO DECODE
IC1
SC9671
U004_NC
IC03
GD25Q40
IC8
AMS1117(1.5V) U005
ME6118A33B3G
IC3
MFI341S2162
IC2
SA1466TR

NOTES:
1. All resistance values are indicated in "ohms"(k=1000 ohms. M=1000 Kohms).
2. All capacitance values are indicated in "µF" (p=10 µF).
-6
DISPLAY / KEY & iPod SECTION
25 26
30 F 29 P18 28 P17 27 P16 26 P15 25 P14 24 P13 23 P12 22 P11 21 P10 20 P9 19 P8 18 P7 17 P6 16 P5 15 P4 14 P3 13 P2 12 P1 11 10G 10 9G
98G 87G 76G 65G 54G 43G 32G 21G 1F DS701
1LED1
2LED2
3LED3
4LED4
5OSC
6DOUT
7DIN
8CLK
9STB
10 KEY1
11 KEY2
33
SEG19/G10
32
SEG18/G11
31
SEG17/G12
30
VEE
29
SEG16/K16
28
SEG15/K15
27
SEG14/K14
26
SEG13/K13
25
SEG12/K12
24
SEG11/K11
23
S10/K10
34
S20/G9
35
SEG21/G8
36
SEG22/G7
37
SEG23/G6
38
SEG24/G5
39
GRID4
40
GRID3
41
GRID2
42
GRID1
43
VDD.
44
GND.
22
S9/K9
21 SEG8/K8 20 SEG7/K7 19 SEG6/K6 18 SEG5/K5 17 SEG4/K4 16 SEG3/K3 15 SEG2/K2 14 SEG1/K1 13 VDD 12 GND
C739
102P
R738
10K
SW709
CLOCK
SW718
PROG
SW717
OPEN/CLOSE
SW720
FF/TUN UP
SW701
PRESET DNFOLEDR DN
SW706
FR/TUN DN
D712 IN4148 D713 IN4148
D711 IN4148
D709 IN4148
D716 IN4148 D760 IN4148 D715 IN4148
D714 IN4148
SW716
SOURCE
SW711
ON/STANDBY
SW714
EQ
SW719
PRESET UP FOLDER UP
SW704
STOP
SW705
PLAY/PAUSE
D726
POWER R782
1K
C740
102P
R700
10K
GND
VCC
OUT
IR701
R789
100
R790
100
R791
100
R792
100
R787
82K
C711
33pF
C712
33pF
C714
33pF
C710
33pF
FB10 FB
FB9 FB
FB8 FB
FB7 FB
FB6 FB
FB5 FB
FB4 FB
FB1 FB
FB3 FB
C707
473
C708
473
FB2 FB
R702
100R
C751
104
C730
47uF/16V
C756
47uF/16V
C726
104
C728
104
V- V+
S701
FB19 FB
FB18 FB
FB17 FB
FB13 FB
FB12 FB
FB11 FB
NJ602
R807
0R
R808
0R
C759
102
C760
102
C752
104
C753
104
3
2
1
4
5
6
7
8
9
10
CP3
3
2
1
4
5
6
CP2
R740
6.8K
R739
6.8K
SW708
TIMER
SW721
SLEEP
D707 1N4148
D710 1N4148
SW702
PLAY MODE
D708 1N4148
SW722
FM.ST
SW710
AUTO PROG/BAND
SW713
BASS
SW703
MUTE
SW707
DISPLAY
P+5V
P+5V
VFD5V
1G 2G 3G 4G 5G 6G 7G 8G 9G
10G
P1 P2 P3 P4 P5 P6 P7 P8 P9
P10 P11 P12 P13 P14 P15 P16 P17 P18
FIL-
-27V
VFD_DIO
VFD_CLK
VFD_CS
IR
GND
GND
P+5V
FIL+
VOL-
VOL+
GND
LINE_R
GND
LINE_L
IP_DET
ROUT
LOUT
IP_GND
IP_TX
IP_RX
ACC_DET
ACC_POWER
IP+5V
GND
CONNECT TO CD BOARD CN7
1
GND1
2
GND2
3
TPA+
4
USBD+
5
TPA-
6
USBD-
7
TPB+
8
+5V
9
TPB-
10
UART
11
POW/IN
12
POW.IN
13
3V3OUT
14
15
UGND
16
VGND
17
18
IPRX
19
IPTX
20
ACCDET
21
YOUT
22
COUT
23
VIDEO
24
SENSER
25
LIN
26
RIN
27
LOUT
28
ROUT
29
AGND
30
DET
J1
R419
49.9K 1%
R420
549K1%
R428
43.2K 1%
R477
49.9K 1%
R478
75K 1%
Q406
2SK3019
R479
10k
R480
100k
Q410
2SK3019
R481
10k
R483100k
R484
100R
R4870R
R488
NC
R496
100R
R498
100R
C430
22P
C441
22P
C440
22P
C433
22P
C442
22P
C435
22P
C444
22P
C439
22P
C443
22P
1
2
3
4
5
6
7
8
9
10
11
12
CP7
L401
102012w002
L402
102012w002
IP_AGND
IC701
CS16315
