AWA CM-P42PCN User manual

Operation Manual
CM-P42PCN
42” Plasma
12 Months Warranty
2007 – 07 – 28
Ver1.0

User’S Manual
106cm PDP TV

AWAHotIine
1300366144

Contents
2
Caution .......................................................................................................................................................... 4
Important Safety Instructions .................................................................................................................... 5
Precaution ..................................................................................................................................................... 6
Viewing the Control Panel .......................................................................................................................... 11
Viewing the Connecting Panel .................................................................................................................. 12
Viewing the Remote Control ...................................................................................................................... 13
Button Description ................................................................................................................................ 13
Loading the Batteries ........................................................................................................................... 15
Reception Range of Remote Control................................................................................................... 15
Table Stand Installation .............................................................................................................................. 16
Wall Mount Installation (Optional) ............................................................................................................. 16
Connecting the TV Cable ........................................................................................................................... 17
Connecting the VCR .................................................................................................................................... 18
Connecting the DVD .................................................................................................................................... 19
Connecting the Set Top Box ...................................................................................................................... 20
Connecting the PC [ D-Sub ] ..................................................................................................................... 21
Displayable TV Specification ..................................................................................................................... 22
Basic Operation ........................................................................................................................................... 23
Turning TV On/Off ................................................................................................................................. 23
Select Source ....................................................................................................................................... 23
Changing Picture Mode ............................................................................................................................... 24
Color Temperature Setting ......................................................................................................................... 25
DNR (Digital Noise Reduction) Setting ................................................................................................... 26
Advance Setting ........................................................................................................................................... 26
Adjusting the Equalizer ............................................................................................................................... 27
Editing the Channels ................................................................................................................................... 28
Searching and Label .................................................................................................................................... 28
Program Edit.................................................................................................................................................. 29
Foreword
Overview
Installation
Connections
Basic Operation
Picture Settings
Sound Setting
SETUP Setting

Contents
3
Setting The Timer.......................................................................................................................................... 30
Function Setting ........................................................................................................................................... 31
Other Signal Source Setting (AV, S-VIDEO) ............................................................................................ 32
Other Signal Source Setting (HDMI, COMPONENT) .............................................................................. 32
Other Signal Source Setting (VGA) .......................................................................................................... 33
Specification-42" PDP ................................................................................................................................. 35
Timer Setting
Function Setting
Other Signal Source Setting
Troubleshooting............................................................................................................. 34
Specification

Caution
4
CAUTION
- TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR
SHOCK HAZARD.
- DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
- SHOCK HAZARD DO NOT OPEN.
CAUTION
These servicing instructions are for use by qualified service
personnel only. To reduce the risk of electric shock, do not
perform any servicing other than that contained in the
operating instructions unless you are qualified to do so.
CAUTION
The stand intended for use only with this TV. Use with
other apparatus is capable of resulting in instability causing
possible injury.
WARNING
- Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases,
shall be placed on the apparatus.
- This is Class B product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
- To reduce the risk of fire and electric shock, do not expose this product to rain or moisture.
FCC NOTICE
This device has been tested and found to comply with the limits for a Class B device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in home environment as well as in a commercial, industrial or business environment. This equipment can
generate, use and radiate radio frequency energy and, if not installed and used in accordance with the
instruction, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes or modification not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Connecting of peripherals requires the use of grounded shielded signal cables.
This symbol is intended to alert the user to
the presence of uninsulated "dangerous
voltage" within the product’s enclosure that
may be of sufficient magnitude to constitute
a risk of electric shock to persons.
This symbol is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK), NO
USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Read all safety and operating instructions
before operating your the TV.
Keep the safety and operating
instructions for future reference.
Heed all warnings on the TV and
in the operating instructions.
Always be careful when using your the TV. To reduce the risk of fire, electrical shock, and other injuries, keep
these safety precautions in mind when installing, using, and maintaining your machine.
HEED ALL
WARNINGS ON
THE TV AND IN
THE OPERATING
INSTRUCTIONS.

ImportantSafetyInstructions
5
Always be careful when using your the TV. To reduce the risk of fire, electrical shock, and other injuries, keep
these safety precautions in mind when installing, using, and maintaining your machine.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a damp cloth.
7. Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that aproduce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. When the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use the attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. When installing the PDP TV, do not block the appliance coupler with any structure.
User can easily have access to the coupler to disconnect it from AC main power.

Precaution
6
In case of the following cases, unplug the unit from the wall outlet and contact qualified
service center.
- When power supply cord or plug is damaged.
- If liquid has been spilled on the unit or if alien objects have fallen into the unit.
- If the TV has been exposed to rain or water.
- If the TV does not operate normally by following the operating instructions.
- If the TV dropped or the cabinet has been damaged.
- When the TV exhibits a distinct change in performance.
Ground outdoor antennas. If an outside antenna or cable system is connected to the TV, be sure the
antenna or cable system is grounded so as to provide some protection against voltage surges and built-up
static charges. Section 810 of the National Electrical Code, ANSI/NFPA No.70-1984, provides information
about proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
Setting
CAUTION
Follow all operating and use
instructions.
Do not use the TV where contact with
or immersion in water is a possibility,
such as near bath tubs, sinks, washing
machines, swimming pools, etc.
Avoid overhead power lines. An outside
antenna system should not be placed in the
vicinity of overhead power lines or other
electric light or power circuits or where it
can fall into such power lines or circuits.
When installing an outside antenna system,
be extremely careful to keep from touching
the power lines or circuits. Contact with
such lines can be fatal.
NO!!
Bend antenna cable between inside
and outside building to prevent rain
from flowing in.
- This may cause water damaged inside
the TV and could give an electric shock.
Do not place an outside antenna in the
vicinity of overhead power lines, or
other electric light or power circuits.
- This may cause an electric shock.
There should be enough distance
between an outside antenna and
power lines to keep the former from
touching the latter even when the
antenna falls.
- This may cause an electric shock.
NO!!
THIS MAY CAUSE WATER DAMAGED
INSIDE THE TV AND COULD GIVE AN
ELECTRIC SHOCK.

Precaution
7
Setting
WARNING
When installing the TV on a table, be careful not
to place it too close to the edge of the table.
- This may cause the TV to fall, causing serious injury
to a child or adult, and serious damage to the TV.
Provide ventilation for the TV. The unit is designed with
slots in the cabinet for ventilation to protect it from
overheating. Do not block these openings with any
object, and do not place the TV on a bed, sofa, rug or
other similar surface. Do not place it near a radiator or
heat register. If you place the TV on a rack or
bookcase, ensure that there is adequate ventilation
and that you've followed the manufacturer's
instructions for mounting.
NO!!
This TV is designed to be mounted
horizontally (wide viewing). Any inquiry
regarding its vertical position should be
forwarded to the manufacture directly.
NO!!

Precaution
8
Power
CAUTION
Use only the accessory cord designed for this product to
prevent shock. The power supply voltage rating of this
product is AC100-240V, the power cord attached conforms
to the following power supply voltage. Use only the power
cord designated by our dealer to ensure Safety and EMC.
When it is used by other power supply voltage, power
cable must be changed. Consult your product dealer.
Unplug the TV from the wall outlet before cleaning.
Use a damp cloth; do not use liquid or aerosol cleaners.
Unplug the TV from the wall outlet and disconnect the
antenna or cable system during a lightning storm or
when left unattended and unused for long periods of
time. This will prevent damage to the unit due to
lightning and power-line surges.
NO!!
AC100-125V AC200-240V AC240 (SAA-TYPE)
NO!!
Protect the power cord. Power supply cords should be
routed so that they won't be walked on or pinched by
objects placed on or against them. Pay particular attention
to cords at plugs, convenience receptacles, and the point
where they exit from the unit.
Do not touch the plug with wet hand.
- It can make an electric shock.
AC100-240V

Precaution
9
Operation
CAUTION
Upon completion of any service or
repairs to this the TV, ask the service
technician to perform safety checks to
determine that the TV is in a safe
operating condition.
Do not place anything containing
liquid on top of the TV.
- This may cause a fire or could give
an electric shock.
Never add any attachments and/or
equipment without approval of the
manufacturer. Such additions can
increase the risk of fire, electric
shock, or other personal injury.
NO!!
NO!!
Operation
WARNING
When replacement parts are required,
be sure the service technician uses
replacement parts specified by the
manufacturer or those that have the
same characteristics as the original
part. Unauthorized substitutions may
result in additional damage to the unit.
If you make adjustments yourself,
adjust only those controls that are
covered by the operating instructions.
Adjusting other controls may result
in damage and will often require
extensive work by a qualified
technician to restore the TV to normal.
Do not let children hang on or
ride on the TV.
In case of smoke or strange smell from the
TV, switch it off, unplug it from the wall outlet
and contact your dealer or service center.
- This may cause a fire or could give an electric shock.
Do not insert anything through the openings
in the unit, where they can touch dangerous
voltage points or damage parts. Never spill
liquid of any kind on the TV.
NO!!

Precaution
10
Operation
WARNING
Do not use new battery with old one.
- This can lead a fire or electric shock
caused by leakage liquid from abused
batteries.
Put the batteries in right direction (+/-).
- Otherwise, it can make a fire, injury and
pollution caused by bursting of batteries.
Only use the specified batteries.
- This make cause damaged the TV
or could give an electric shock.
More than two people are necessary
to move or take off the package due
to the product’s weightiness.
- Otherwise, it can cause personal injury.
Keep the batteries out of reach of
children when exchanged.
- Seek urgent medical advice if child
swallows a battery.
The distance between eyes and the
screen should be about 5~7 times as
long as diagonal length of the screen.
- If not, eyes will strain.

ViewingtheControlPanel
11
OSD Button Position
INPUT SELECT/EXIT
Select the signal source from multiple input sources such as TV, SCART, S-VIDEO, AV, COMPONENT,
VGA and HDMI.
StTAND BY ON/OFF
Turn the TV on and off.
MENU/SET
Call the OSD Menu.
Front Panel
OSD Button
CH+
CH -
VOL +
VOL -
MENU
INPUT
POWER
1
2
3
4
5
6
7
Remote Control Power Cord Alkaline Batteries Owner's Manual
Accessories
Composite Cable

12
ViewingtheConnectingPanel
Back Panel and Jacks
VGA
S-VIDEO
COMPONENT 1
AV 1
HDMI
7
8
6
9
1
2
3
4
5
COMPONENT 2
AV 2
PC AUDIO IN
TV ANTENNA
Back panel of the TV

ViewingtheRemoteControl
13
Button Description
POWER
Turn the power on when pressed
MUTE
Temporarily cut the sound and restore it.
0-9
Digital key
HDMI
Switch to the HDMI mode.
FOUR COLOR BUTTONS
There are four color buttons in the last row of the
remote controller. They are red,green, yellow and
blue from left to right. By pressing these buttons,
you can enter relative pages fast which are
indicated in the last row of current teletext page.
16:9
Adjust aspect setting
TXT/CC
Display TELETXT signal, mixing teletext page
with TV signal, close teletext.
Call out picture mode menu, and adjust the picture
mode.
¥¥

: Channel up/Channel down
¥¥: Volume up/Volume down
SOUND
Call out sound mode menu, and adjust the sound
mode.
INDEX
Request index page
LUCIDITY
Switch to the Teletest with mix mode
Cancel
Change display size
HOLD
Toggle hold on or off for current display page
1
2
3
4
5
6
7
8
9
10
11
12
13
14
21
3
9
6
5
7
12
8
10
11
13
14
4

ViewingtheRemoteControl
14
18
26
19
23
24
25
22
21
20
17
16
15
Sleep
Set the sleeptime
NICAM/A2
Nicam function
STILL
Pause picture
SOURCE
Input source selection mode.
BUTTON
Switch to the last channel
DISPLAY
Call out info menu
MENU
The button to enter into or exit from menu
OK
to confirm that what made choice.
EXIT
Exit the menu
SUBPAGE
Some page attach sub-page.
Press "SUB-PAGE" button to view the sub-pages.
SIZE
Remove the Teletext & program
REVEAL
Show the hidden words
15
16
17
18
19
20
21
22
23
24
25
26
Button Description

ViewingtheRemoteControl
15
Press on the cover and slide in the direction of the arrow.
Load two AAA batteries, taking care that the + and - ends face the correct direction.
Close the cover until it clicks.
Loading the Batteries
Reception Range of Remote Control
1
2
3
Left 5m (Front) Right
Upper
Lower

Installation
16
Table Stand Installation
Wall Mount Installation (Optional)
4 inch (10.16cm)
2.36 inch
(5.99cm)
4 inch
(10.16cm)
4 inch
(10.16cm)
< The TV can be installed on the desk as shown above. >
• Table stand mount minimum allowable clearances for
adequate ventilation.
1.18 inch (Min)
(3cm)
< The TV can be installed on the wall as the picture above. >
1.18 inch (Min)
(3cm)
• Install this TV a only in a location where adequate
ventilation is available.
4 inch (10.16cm)
2.36 inch
(5.99cm)
4 inch
(10.16cm)
4 inch
(10.16cm)

ConnectingtheTVCable
17
Connect the TV Antenna cable to the TV input jack. Press TV/AV button on the remote control and select
TV on OSD.
Use button or numeric button to change TV programme for your programme selection.
Also, you can tune to cable service provided programmes using the cable box. For further information
regarding cable TV service, contact cable TV service provider(s).
TV Antenna Cable
Connection the TV Cable
1
2
3

ConnectingtheVCR
18
With AV1 Input
Connect a composite cable to the AV video jacks of the VCR and the TV.
Connect L (White), R (Red) sound cable (Composite) to the sound jacks of the VCR and the TV.
With AV2 Input
Connect a composite cable to the AV video jacks of the VCR and the TV.
Connect L (White), R (Red) sound cable (Composite) to the sound jacks of the VCR and the TV.
With S-VIDEO
Connect a S-Video cable to the S-Video jacks of the VCR and the TV.
Connect L (White), R (Red) sound cable (Composite) to the sound jacks of the VCR and the TV.
Press TV/AV button on the remote control and select video sources.
Insert a video tape into the VCR and press the PLAY button on the VCR.
Connecting the VCR
1
2
Watching VCR
AV Input
S-VIDEO Input
S-VIDEO
SOUND of
S-VIDEO/AV
AV Input
Notes
•To avoid picture noise (interference), leave an adequate distance (over 3m) between the VCR and TV.
• When connecting the TV with external equipment, match the colour of connecting ports (e.g. Video -Yellow,
Audio(L) - White, Audio(R) - Red).
•If you have a mono VCR, connect the audio cable from the VCR to the AUDIO (L/Mono) input of the TV.
• If you connect an S-VHS VCR to the S-VIDEO input socket, you can get a better picture quality than normal video
input (AV).
