awave DSP-12AD User manual

Ower s Manual
,
DSP Car Power Amplifiers
D04-MEN123-00
-12AD

PRODUCT BRIEF INTRODUCTION
[ 1 ]
PRODUCT BRIEF INTRODUCTION
[ 2 ]
INDEX
1. PRODUCT DESCRIPTION-PRECAUTIONARY NOTES............................02
2. PACKAGING CONTENTS........................................................................02
3. DSP AND DRC INSTALLATION...............................................................03
4. CONNECTION PANELS-DESCRIPTION..................................................04
4.1 Input signals ............................................................................................04
4.2 Output signals ..........................................................................................05
4.3 Input -remote control outputs and power supply..........................................05
5. CONNECTIONS.......................................................................................06
5.1 Power supply and remote turn on ..............................................................06
5.2 Personal computer and Digital Remote Coontrol(DRC) ..............................07
5.3 High-Level input signals ............................................................................07
5.5 Low-Level input signals ............................................................................08
5.6 Output signals ..........................................................................................08
1.PRODUCT DESCRIPTION-PRECAUTIONARY NOTES
The DSP is a digital signal processor essential to maximize the acoustic performance of your car audio system.
It consists of a 32-bit DSP processor and 24-bit AD and DA converters.
It can connect to any factory system,even in vehicles featuring featuring an intergrated audio processor,since,thanks to the.
De-equalization function,the DSP will send back a linear signal.
It features selectable High and low level inputs as well as 3.5MM Aux and digital inputs that feed 8 completely variable output
channels. Each output channel has a 31-band equalizer available.it also features a 66-freqency electronic crossover as well as .
BUTTERWORTH or LINKWITZ filters with 6-24dB slopes and a digital time delay line.the user canselect adjustments.
That allow him or her to interact with the DSP through a remote control device called DRC.
WARNING: 1-a PC provided with Windows XP,Windows Vista or Windows 7 operating system,1.5GHz minimum.
Processor speed ,1 GB RAM minimum memory and a graphics card with a minimum resolution.
Of 1024x600 pixels are required to install the software and setup the DSP.
2-Before connecting you DSP, carefully read this manua .Improper connections may cause damage to
The DSP or to the speakers in the car audio system.
2.PACKAGING CONTENTS
- DSP- Signal Interface Processor
- Power supply cable Inputs/speaker output
- 5.0m USB cable
- 4 of 4.0*15 mm/8of 3.0*6mm self-tapping,
Cross-head fixing screws,
OPTIONAL:
- DRC(Digital Remote Control)control panel:
- 5.0 m DRC-AC Link cable
- Control High Level /wifi Input
6. GUI OPERATION INSTRUCTION............................................................. 9
6.1 Guide to GUI after installation ................................................................... 9
6.2 Interface introduction ......................................................................... 9-14
7. REMOTE INTRODUCTION.......................................................................15
8. TECHNICAL FEATURES......................................................................... 16
5.4 High-output input signals ...........................................................................07

PRODUCT BRIEF INTRODUCTION
[ 3 ]
PRODUCT BRIEF INTRODUCTION
[ 4 ]
3.DSP AND DRC INSTALLATION
External dimensions
How to install
WARNING: do not use aggressive cleaning agents or abrasive cloth to clean the display.Simply use
a soft cotton colth lightly damped with water.
4.CONNECTION PANELS-DESCRIPTION
4.1 Input signals
1-2-3-4-5-6-7-8-9-10-11-12
196mm
50mm
307mm
2. OUTPUT; CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11 CH12
LIN E INPU TS
MAI N HIGH LE VEL INP UTS
10
9 11
12
SPE AKER O UTP UTS SP EAKE R OUTP UTS
CH1 ~CH8 C H9~ CH12
12

PRODUCT BRIEF INTRODUCTION
[ 5 ]
PRODUCT BRIEF INTRODUCTION
[ 6 ]
For convenience most AutoSound amplifiers utilize common automotive ATC type
3. FUSE
only with the same value.
fuses. For Continued protection in the event that a fuse blows, replace the fuse
25A x3
LIN E INPU TS
MAI N HIGH LE VEL INP UTS
10
9 11
12
LIN E INPU TS
MAI N HIGH LE VEL INP UTS
10
9 11
12
SPE AKER O UTP UTS SP EAKE R OUTP UTS
CH1~CH8 CH9~CH12

PRODUCT BRIEF INTRODUCTION
[ 7 ]
PRODUCT BRIEF INTRODUCTION
[ 8 ]
5.2 Personal computer and Digital Remote Coontrol(DRC)
5.3 High-Level input signals
1.SPEAKERS IN HI-LEVEL STEREO FRONT+REAR+SUBWOOFER .
5.5 MAIN LEVEL INPUT
5.6 Low-Level ,BLUETOOCH input signals
Sensitivity is adjusttable from 0.6 to 5V RMS .
BlueTooth IN :
Insert the Bluetooth control module into the DSP .
turn on your mobile phone and find the Bluetooth control mode.
Click on the Bluetooth . When the control mode is automatically
Paired successful . Then you can play the music.
DO NOT INSERT THE USB.
5.4 High-Level output signals
LIN E INPU TS
MAI N HIGH LE VEL INP UTS
10
9 11
12
SPEAKER OUTP UTS SP EAK ER OUT PUTS
CH1~CH8 CH9~CH12
LIN E INPU TS
MAI N HIGH LE VEL INP UTS
10
9 11
12
LIN E INPU TS
MAI N HIGH LE VEL INP UTS
10
9 11
12
LIN E INPU TS
MAI N HIGH LE VEL INP UTS
10
9 11
12
LINE OUTPUTS
1 INPUT +
2 INPUT +
3 INPUT +
4 INPUT +
5 INPUT +
6 INPUT +
1 INPUT -
2 INPUT -
3 INPUT -
4 INPUT -
5 INPUT -
6 INPUT -
7 INPUT +
8 INPUT +
9 INPUT +
10 INPUT +
11 IN PUT +
12 INPUT +
7 INPUT -
8 INPUT -
9 INPUT -
10 INPUT -
11 IN PUT -
12 INPUT -
+
+
+
+
+
+
+
+
CH9
CH10
CH11
CH12
CH9
CH10
CH11
CH12
+
+
+
+

PRODUCT BRIEF INTRODUCTION
[ 9 ]
PRODUCT BRIEF INTRODUCTION
[ 10 ]
6.GUI OPERATION INSTRUCTION
6.1 Guide to GUI after installation
1. Double - click icon of DSP-CONTROL
2. Enter the GUI you long for! Now you could tone every signal details as experts do
To bring sound effect on your beloved car to a higher level.If the password has been set,
You need to enter the password.
1.DSP interface guidance
6.2 Interface introduction
1. Connect(connect to the DSP)
1
2. FILE MAIN MENU
RE SET SS _M/M P0
DG ND
DV DD XTA LIN /MC LK XTA LOU T CL KOU T MO SI_ M/MP 1 SC L_M/ SCL K SD A_M/ MIS O
MI SO/ SDA
SC LK/ SCL MO SI/ ADD R1 SS /AD DR0 SE LFB OO T DV DD DG ND DG ND
DSP 12AD

PRODUCT BRIEF INTRODUCTION
[ 11 ]
PRODUCT BRIEF INTRODUCTION
[ 12 ]
5. Save as(To save another file setting to PC)
3. Open(To load preset file in PC folder)
4. Save(To save setting to PC)
6. Restore Factory(To save preset file in DSP)
7.Modify Password
8. Write To Device
9. Read From Device
11. Exit
3. INPUT MODE.
To select different input devices.
10. About
2. Language(choose you need language)
CH mode(2CH 4CH 6СH 12CH).
1
4. CHANNAL SETING.
1.2.3.4.5.6.7.8.9.10.11.12
1
2
Options on the Link are for combine setting for Left CH and Right CH .
Options on the Left CH/right CH allow you tone each selected channel respectively.
5. CROSSOVER X-TPE.
To choose different crossover type, for example select CH selection on 3RD
spot .that would locate CH you want to choose for crossover configuration .
6. CROSSOVER FREQUENCY.
Set frequency of LP/HP individually .
3Output channel:FL FullRange.FR FullRange.
When you click the drop-down button, you can choose the state of the channel input.
There is : Null.Front.Rear.Center.Subwoofer and Full.Tweeter.Mid-T.Midrange.M-WF. Woofer.

PRODUCT BRIEF INTRODUCTION
[ 13 ]
PRODUCT BRIEF INTRODUCTION
[ 14 ]
7. GAIN.
0--40dB is optional range for gain control kf every CH.
8. DELAY.
1.Auto configuration(base on 1.5 setting).
2.Manual configuration, change specifications in selected CH manually.
9. LP/SLOPE.
1.6dB/oct 12dB/oct 18dB/oct 24dB/oct 30dB/oct
36dB/oct. 42dB/oct 48dB/oct are available.
10. HP/SLOPE.
1.6dB/oct 12dB/oct 18dB/oct 24dB/oct 30dB/oct
36dB/oct.42dB/oct 48dB/oct are available.
12. WRITE.
To Write To Device(POS1-POS8).
11. Filter Model.
To choose different Filter type Linkwitz Bessel Butterworth.
13. READ.
To Read From Device(POS1-POS8).

PRODUCT BRIEF INTRODUCTION
[ 15 ]
PRODUCT BRIEF INTRODUCTION
[ 16 ]
14. X-OVER AND EQ CHARTS.
15. EQ SETTING.
1.Red lines and slopes will change accordingly when
2.EQ all frequency points can be move left or right.For 20Hz-20KHz can be any Regulation.
Q volue=1-12.
HP/LP of crossover and EQ are modified.
7.REMOTE INTRODUCTION
8.TECHNICAL FEATURES
POWER SUPPLY
Voltange 9-16VDC
Idling current 1.5A
SIGNAL STAGE
Distortion - THD @ 1kHz, 1V RMS Output 0.05%
Bandwith @-3 dB 10-20kHz
Hight level input range 3V-15V
S/N ratio Full Power A-
INPUT STAGE
High Level(Speaker) 1.2.3.4.5.6.7.8.9.10.11.12
CONNECTION
From/To Personal Computer 1 x USB/B(1.1/2.0) 5M
CROSSOVER N.5(one each output channel)
Filter Type Full/High/Low Pass /Band Pass
Slope Setting 6/12/18/24/30/42/48 dB
68 steps @ 20- 20kHz
Phase control indepent setting for each channel 0 - 180
Crossover frequency
100 dB
THD+N VS Power 1%
(СH1-CH8)8X50W + (CH9-CH12) 4X100W ATTS
