Axemen Power Equipment TAC81M User manual

Welcome
Thank you for your purchase of this quality AXEMEN POWER, Inc. product. We wish you years of
success using your new air compressor.
This manual contains general warnings about the inherent risks of operating air compressors and
specific warnings about the operation and maintenance of this particular air compressor. In addition, it
outlines important maintenance and storage procedures.
Please read it carefully before operating, maintaining, repairing, and storing your new air compressor.
Keep this owner’s manual handy so you can refer to it at any time. This owner’s manual is considered
a permanent part of the air compressor and should remain with the air compressor if resold.
The information and specifications included in this publication were in effect at the time of approval for
printing. AXEMEN POWER, Inc. reserves the right, however, to discontinue or change specifications
or design at any time without notice and without incurring any obligation whatsoever. No part of this
publication may be reproduced without written permission.
Thank you for your business.
Customer service
Consult an Authorized Service Dealer regarding maintenance or repair procedures.
Please contact us with service-related questions regarding operating and assembling your new air
compressor, including parts you may be missing.
Customer support: 1-888-929-3468
[e-mail]
www.Axemenpower.com
WARNING:
READ and UNDERSTAND the Owner’s Manual completely before using this air
compressor.
Assemble, test and use only in accordance with the Owner’s Manual instructions.
WEAR personal protective gear when filling, using, cleaning, and servicing the air compressor.
DO NOT START the air compressor until you have read, understood, and followed the
instructions in this manual.
Improper use of the air compressor could result in serious injury or illness to the operator or
nearby persons/animals, and cause property damage.

Retain for your records
Record your air compressor’s model number and serial number as well as the date you purchased the
air compressor below.
Retain this information for your records. You’ll need to refer to this information when ordering parts and
contacting customer service about maintaining your air compressor and its warranty.
Model number:
_________________________________________
Serial number:
__________________________________________
Date purchased:
________Month _____________Day _____________Year
TAC81M Nameplate
2

Contents
Welcome ................................................................................................................................................1
Customer service....................................................................................................................................1
Retain for your records...........................................................................................................................2
Important safety precautions...................................................................................................................5
Air Compressor Safety............................................................................................................................6
Carbon Monoxide WARNINGS...............................................................................................................9
Burn and fire WARNINGS.....................................................................................................................10
About your air compressor....................................................................................................................10
Reference manual contains critical information.....................................................................................10
What’s in the Box?................................................................................................................................11
Air Compressor Major Components and Controls Diagram...................................................................12
Engine Major Components and Controls Diagram................................................................................13
Engine Controls....................................................................................................................................14
Initial Set-Up.........................................................................................................................................14
Pre-operation check..............................................................................................................................17
Are you ready to get started?................................................................................................................17
Is your Air Compressor read to go?......................................................................................................18
Fuel and Oil Requirements...................................................................................................................20
Fuel Requirements ...............................................................................................................................20
Oil requirements...................................................................................................................................20
Monitoring the fuel level........................................................................................................................21
Using caution when refueling the tank..................................................................................................22
Inspect Fuel System/Check for Leaks...................................................................................................22
Operation..............................................................................................................................................23
Air Compressor Placement...................................................................................................................23
Air Hose and Tool Use..........................................................................................................................25
Attaching Air Hose and Tools ...............................................................................................................26
Using Compressor for Spraying............................................................................................................26
Shutdown Procedures ..........................................................................................................................27
Maintenance.........................................................................................................................................28
Importance of maintenance ..................................................................................................................28
Maintenance safety precautions ...........................................................................................................28
Air Compressor Maintenance Schedule................................................................................................29
Detailed Instructions – Maintenance & Repair ......................................................................................30
Inspect Safety/Relief Valve...................................................................................................................31
3

Inspect Air Filter....................................................................................................................................31
Inspect Compressor for Air Leaks.........................................................................................................31
Engine Maintenance.............................................................................................................................31
Change Pump Oil .................................................................................................................................32
Inspect & Clean Spark Arrestor (If equipped)........................................................................................33
Keep Compressor Clean ......................................................................................................................33
Between-Use Storage...........................................................................................................................34
Draining the Tank:................................................................................................................................35
Long Term Storage Preparation ...........................................................................................................35
Troubleshooting....................................................................................................................................36
Air compressor specifications:..............................................................................................................40
Engine assembly and parts list:............................................................................................................41
Contact information for Technical and Customer Assistance................................................................41
Locate an Authorized Service Dealer....................................................................................................41
Customer assistance............................................................................................................................41
Limited Warranty ..................................................................................................................................43
Appendix A: Lubricants and Compatibility.............................................................................................45
4

Important safety precautions
This manual contains critical safety information. Please read the entire manual closely.
Because safety is paramount and using an air compressor carries significant responsibilities, we have
outlined warnings and the general hazards of operating air compressors. In addition, we have
summarized the recommended procedures for operating, repairing, maintaining, and storing your
specific air compressor to keep you and others safe.
It would be impossible for us to warn you of each risk and all of the hazards involved in the use of air
compressors. Therefore, it’s essential that you use your best judgment and take precautions when
using, maintaining, repairing, and storing your air compressor.
There are many safety warnings in this manual and on the air compressor itself to guide you:
Air compressor safety labels: The safety labels on your air compressor warn of potential danger. It’s
critical that you read them. If any labels become difficult to read or have been removed, contact your
dealer for a replacement label.
Manual safety messages: This manual contains specific instructions and severe warnings about the
ramifications of using poor judgment and not following the instructions outlined in this manual. The
ramifications range from serious injury and losing consciousness to death. These messages are
preceded by a safety alert symbol and one of three signal words, DANGER, WARNING, or
CAUTION.
These signal words mean:
Manual headings and sections: We’ve devoted several sections of this manual to outline the risks,
hazards, and warnings when using, repairing, maintaining, and storing your air compressor.
Instructions: how to use this Air Compressor correctly and safely.
Pay attention to cautions such as, “Carbon monoxide WARNINGS” or “Burn and fire WARNINGS.”
Not following instructions or using poor judgment when using
and maintaining your air compressor can cause you or
someone else to be KILLED or SERIOUSLY INJURED.
DANGER
WARNING
CAUTION
You WILL be KILLED or SERIOUSLY HURT if you don’t follow
instructions
You CAN be KILLED or SERIOUSLY HURT if you don’t follow
instructions
You CAN be HURT if you don’t follow instructions
5

Air Compressor Safety
WARNING:
SPECIAL
HAZARDS
•CO Poisoning: Exhaust from engine contains carbon monoxide, a poisonous gas that
can cause carbon monoxide poisoning and possible death if inhaled.
•Injection Injury: High pressure air stream can pierce skin and underlying tissue, leading
to serious injury and possible amputation. Such an injection injury can result in blood
poisoning and/or severe tissue damage.
•Flying Debris: High-pressure air stream can cause flying debris and possible surface
damage.
•Electric Shock: Operating equipment in wet conditions or near water can cause electric
shock.
•Not For Breathing Air: AXEMEN Power Inc. compressors are NOT designed, intended,
or approved for supplying breathing air. No compressed air should be used for
breathing unless air is treated in accordance with applicable standards.
•Fire/Explosion: Sparks from air powered tool heads or attachments can ignite fuel or
other flammable liquids or vapors in the vicinity. Exceeding the maximum pressure for
air tools or attachments could cause them to explode.
•Burns: Compressor pump, engine, and discharge tubing are hot surfaces that can
cause burn injuries.
* Detailed safety information about these hazards appears throughout this manual.
Important Safety Information
AXEMEN POWER air compressors are designed to provide compressed air primarily used for
operating air tools and pressurizing other non-tool objects such as tires. Special precautions are
necessary when used for cleaning. This compressor is NOT to be used to supply breathing air.
Note: Do not use for other purposes, as unforeseen hazards or equipment damage may result.
Most injuries or property damage can be prevented if you follow all instructions in this manual and on
the air compressor. The most common hazards are discussed below, along with the best way to
protect yourself and others.
Operators Responsibility
It is the operator’s responsibility to provide the necessary safeguards to protect people and property.
Know how to stop the air compressor quickly in case of emergency. If you leave the air compressor for
any reason, always turn the engine off. Understand the use of all controls and connections.
Adult Control ONLY: Only trained adults should set up and operate the air compressor. Be sure that
anyone who operates the air compressor receives proper instruction. Do not let children operate the air
compressor. Keep children and pets away from the area of operation.
Personal Protection: Wear safety apparel during operation, including safety glasses with side and top
protection. Ear protection is also recommended if working near any operating engine.
6

Under the influence: Never operate, or let anyone else operate, the air compressor while fatigued or
under the influence of alcohol, drugs, or medication.
* Keep this manual for reference and review.
Air Compressor Operation
This air compressor is intended for outdoor use only.
This compressor is powered by a gasoline engine and therefore can only be operated outdoors.
This air compressor will require you to supply and install the following fluids and equipment:
•Compressor pump oil (as specified)
•Gasoline (as specified)
•Engine Oil (as specified)
•Personal Protection Equipment
* See “Specifications” section of this manual for more details.
Refuel With Care
Gasoline is extremely flammable, and gasoline vapor can explode. Refuel outdoors, in a well-ventilated
area, with the engine stopped and the air compressor on a level surface. Do not fill the fuel tank above
the fuel strainer shoulder. Never smoke near gasoline, and keep other flames and sparks away.
Remember, always store gasoline in an approved container. Make sure that any spilled fuel has been
wiped up before starting the engine.
Hot Exhaust
The muffler becomes very hot during operation and remains hot for a while after stopping the engine.
Be careful not to touch the muffler while it is hot. Let the engine cool down before transporting the air
compressor or storing it indoors.
To prevent fire hazards, keep the air compressor at least 7 feet (2 meter) away from building walls and
other equipment during operation. Do not place flammable objects close to the engine.
Carbon Monoxide Hazard
Exhaust contains poisonous carbon monoxide, a colorless and odorless gas. Breathing carbon
monoxide can cause loss of consciousness and may lead to death.
If you run the air compressor in an area that is confined, or even partly enclosed, the air you breathe
could contain a dangerous amount of exhaust gas.
Never run the engine inside a closed garage, house, or confined area.
7

NOTICE:
ATTENTION: Rental Companies and Private Owners who loan this equipment
to others!
•All persons to whom you rent/loan this air compressor must have access to and read
this manual. Keep this owner’s manual with the air compressor at all times and advise
all persons who will operate the machine to read and understand it. You must also
provide personal instruction on how to safely set-up and operate the air compressor
and remain available to answer any questions a renter/borrower might have. Owner’s
manuals are available from AXEMEN Power Customer Support at 1-888-929-3468 or
[e-mail]
8

Safety warnings
Carbon Monoxide WARNINGS
Only operate your air compressor outdoors.
Operating an air compressor carries serious responsibility. There are precautions that you need to take
when operating an air compressor:
•Never operate your air compressor indoors or near any windows
or doors.
•Never operate your air compressor in an enclosed or a partially
enclosed area such as a garage.
•Do not let the exhaust from your air compressor build up to
dangerous levels.
•Do not breathe the poisonous gas in your air compressor’s exhaust.
•Become familiar with your air compressor. Understand all of your air compressor’s controls,
connections, and outputs. Know how to quickly stop your air compressor in case of an emergency.
•If anyone else operates your air compressor, be sure he/she is properly instructed.
•Do not let children play with or operate your air compressor.
•Keep your air compressor at least three feet away from flammable materials.
WARNING:
The engine exhaust from this product contains chemicals known to the State of
California to cause cancer, birth defects or other reproductive harm.
The exhaust from your air compressor contains carbon monoxide.
Breathing this poisonous gas, which is odorless and colorless, can
cause unconsciousness and could even kill you.
9
