DeVilbiss MGP-XE-WB-C1D User manual

SPECIFICATION CHART
*A circuit breaker is preferred. Use only a fuse or circuit breaker that is the same
rating as the branch circuit the air compressor is operated on. If the air compressor
is connected to a circuit protected by fuses, use quick acting fuses.
MGP-XE-WB-C1D 11/5/97
SAFETY GUIDELINES - DEFINITIONS
IMPORTANT SAFETY INFORMATION - A
HAZARD THAT MIGHT CAUSE SERIOUS
INJURY OR LOSS OF LIFE.
Information that you should pay
special attention to.
URGENT SAFETY INFORMATION - A HAZ-
ARD THAT WILL CAUSE SERIOUS INJURY
OR LOSS OF LIFE.
This manual contains information
that is important for you to know
and understand. This information
relates to protecting YOUR
SAFETY and PREVENTING
EQUIPMENT PROBLEMS. To
help you recognize this informa-
tion, we use symbols to the right.
Please read the manual and pay
attention to these sections.
Information for preventing damage
to equipment.
OWNERS MANUAL FOR
PERMANENTLY LUBRICATED
AIR COMPRESSOR
Model No.
Horsepower
SCFM @ 40 psig
SCFM @ 90 psig
Bore
Stroke
Voltage-Single Phase
Minimum Branch Circuit Requirement
*Fuse Type
WB100D-2
3/4
3.0
2.2
1 3/4"
1 1/4"
120
15 AMPS
Quick Acting
XE-7D-2
3/4
3.0
2.2
1 3/4"
1 1/4"
120
15 AMPS
Quick Acting
IRC1D-2
----
3.0
2.2
1 3/4"
1 1/4"
120
15 AMPS
Quick Acting
MODEL NOS.
WB100D-2 — XE-7D-2 — IRC1D-2
(For Home Use Only)
213 Industrial Dr. • Jackson, TN 38301-9615

2 — ENG
TABLE OF CONTENTS
SAFETY GUIDELINES . Cover Page
WARRANTYSTATEMENT ..................................... 3
WARNINGCHART ............................................... 4-5
GLOSSARY ......................................................... 5
DUTYCYCLE ...................................................... 5
DESCRIPTION OF OPERATION ........................... 6
INSTALLATION AND BREAK-IN
PROCEDURES ................................................. 6-7
Location of Air Compressor ........................ 6
Page
Extension Cords ......................................... 6
Grounding Instructions ................................ 6-7
Air Hose ...................................................... 7
OPERATING PROCEDURES ............................... 7
STORAGE ........................................................... 8
AIR COMPRESSOR
DIAGRAM ............................................................ 9
TROUBLESHOOTING GUIDE .............................. 10
HOW TO ORDER REPAIR PARTS .......... Back Cover
Page

3 — ENG
LIMITED WARRANTY
ONE YEAR FROM DATE OF PURCHASE
All merchandise manufactured by DeVilbiss Air Power Company is warranted to be free of defects in workmanship
and material which occur during the first year from the date of purchase by the original purchaser (initial user). Products
covered under this warranty include: air compressors, *air tools, accessories, service parts, pressure washers, and
generators used in consumer applications (i.e., personal residential household usage only).
Air compressors, *air tools, accessories, service parts, pressure washers, and generators used in commercial
applications (income producing) are covered by a 90 day warranty.
DeVilbiss Air Power will repair or replace, at DeVilbiss's option, products or components which have failed within the
warranty period. Repair or replacement, and service calls on 60 and 80 gallon air compressors, will be handled by
Authorized Warranty Service Centers and will be scheduled and serviced according to the normal work flow and
business hours at the service center location, and depending on the availability of replacement parts.
All decisions of DeVilbiss Air Power Company with regard to this policy shall be final.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
RESPONSIBILITY OF ORIGINAL PURCHASER (Initial User):
THIS WARRANTY DOES NOT COVER:
DeVilbiss Air Power Company
213 Industrial Drive • Jackson, TN 38301-9615 • Telephone: [phone] , Ext. 2 • FAX: [phone]
❏Retain original cash register sales receipt as proof of purchase for warranty work.
❏Use reasonable care in the operation and maintenance of the product as described in the Owners Manual(s).
❏Deliver or ship the product to the nearest DeVilbiss Air Power Authorized Warranty Service Center.
Freight costs, if any, must be paid by the purchaser.
❏Air compressors with 60 and 80 gallon tanks only will be inspected at the site of installation. Contact the nearest
Authorized Warranty Service Center, that provides on-site service calls, for service call arrangement.
❏If the purchaser does not receive satisfactory results from the Authorized Warranty Service Center, the purchaser
should contact DeVilbiss Air Power Company.
❏Merchandise sold as reconditioned, floor models and/or display models. Any damaged or incomplete equipment
sold "as is".
❏Merchandise used as "rental" equipment.
❏Merchandise that has become inoperative because of ordinary wear, misuse, freeze damage, use of improper
chemicals, negligence, accident, improper and/or unauthorized repair or alterations including failure to operate
the product in accordance with the instructions provided in the Owners Manual (s) supplied with the product.
*Air Tools: O-Rings and driver blades are considered ordinary wear parts, therefore, they are warranted for a
period of 45 days from the date of purchase.
❏An air compressor that pumps air more than 50% during a one hour period is considered misuse because
the air compressor is undersized for the required air demand. Maximum compressor pumping time per hour is
30 minutes.
❏Merchandise sold by DeVilbiss Air Power which has been manufactured by and identified as the product of
another company. The product manufacturer's warranty will apply.
❏Repair and transportation costs of merchandise determined not to be defective.
❏Cost associated with assembly, required oil, adjustments or other installation and start-up cost.
❏ANY INCIDENTAL, INDIRECT OR CONSEQUENTIAL LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM
ANY DEFECT, FAILURE OR MALFUNCTION OF THE PRODUCT. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
❏IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED TO ONE YEAR FROM THE DATE OF ORIGINAL PURCHASE. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitations may not apply to you.
Form: SP-100-E - 4/25/96

4 — ENG
ATTACHMENTS & ACCESSORIES
EXCEEDING THE PRESSURE RATING OF AIR
TOOLS, SPRAY GUNS, AIR OPERATED
ACCESSORIES, TIRES AND OTHER
INFLATABLES CAN CAUSE THEM TO EX-
PLODE OR FLY APART, AND COULD RESULT
IN SERIOUS INJURY.
USE OF UNAUTHORIZED REPLACEMENT
AIR HOSE COULD PRODUCE EXCESSIVE
SYSTEM PRESSURE AND CAUSE
DAMAGES TO THE COMPRESSOR AND
HOSE FAILURE WHICH COULD RESULT IN
SERIOUS INJURY.
IT IS NORMAL FOR ELECTRICAL
CONTACTS WITHIN THE MOTOR AND PRES-
SURE SWITCH TO SPARK.
IF ELECTRICAL SPARKS FROM COMPRES-
SOR COME INTO CONTACT WITH
FLAMMABLE VAPORS, THEY MAY IGNITE,
CAUSING FIRE OR EXPLOSION.
RESTRICTING ANY OF THE COMPRESSOR
VENTILATION OPENINGS WILL CAUSE SERI-
OUS OVERHEATING AND COULD CAUSE
FIRE.
UNATTENDED OPERATION OF THIS PROD-
UCT COULD RESULT IN PERSONAL INJURY
OR PROPERTY DAMAGE.
YOUR AIR COMPRESSOR IS POWERED BY
ELECTRICITY. LIKE ANY OTHER ELECTRI-
CALLY POWERED DEVICE, IF IT IS NOT USED
PROPERLY IT MAY CAUSE ELECTRIC
SHOCK.
REPAIRS ATTEMPTED BY UNQUALIFIED
PERSONNEL CAN RESULT IN SERIOUS
INJURY OR DEATH BY ELECTROCUTION.
ELECTRICAL GROUNDING: FAILURE TO
PROVIDE ADEQUATE GROUNDING TO THIS
PRODUCT COULD RESULT IN SERIOUS
INJURY OR DEATH FROM ELECTROCU-
TION. SEE GROUNDING INSTRUCTIONS.
FOLLOW THE EQUIPMENT MANUFACTUR-
ERS RECOMMENDATION AND NEVER EX-
CEED THE MAXIMUM ALLOWABLE PRES-
SURE RATING OF ATTACHMENTS. NEVER
USE COMPRESSOR TO INFLATE SMALL
LOW-PRESSURE OBJECTS SUCH AS
CHILDREN’S TOYS, FOOTBALLS,
BASKETBALLS. ETC.
HOSE IS PERMANENTLY ATTACHED TO
THE COMPRESSOR AND SHOULD ONLY
BE REPLACED BY AUTHORIZED SERVICE
CENTER PERSONNEL USING CERTIFIED
REPLACEMENT PARTS.
ALWAYS OPERATE THE COMPRESSOR IN
AWELL VENTILATED AREA FREE OF
COMBUSTIBLE MATERIALS, GASOLINE
OR SOLVENT VAPORS.
IF SPRAYING FLAMMABLE MATERIALS,
LOCATE COMPRESSOR AT LEAST 20
FEET AWAY FROM SPRAY AREA. AN
ADDITIONAL LENGTH OF HOSE MAY BE
REQUIRED.
STORE FLAMMABLE MATERIALS IN A
SECURE LOCATION AWAY FROM
COMPRESSOR.
NEVER PLACE OBJECTS AGAINST OR ON
TOP OF COMPRESSOR. OPERATE COM-
PRESSOR IN AN OPEN AREA AT LEAST 12
INCHES AWAY FROM ANY WALL OR
OBSTRUCTION THAT WOULD RESTRICT
THE FLOW OF FRESH AIR TO THE
VENTILATION OPENINGS.
ALWAYS REMAIN IN ATTENDANCE WITH
THE PRODUCT WHEN IT IS OPERATING.
UNPLUG COMPRESSOR WHENEVER IS
NOT BEING USED.
NEVER OPERATE THE COMPRESSOR OUT-
DOORS WHEN IT IS RAINING OR IN WET
CONDITIONS.
ANY ELECTRICAL WIRING OR REPAIRS
REQUIRE ON THIS PRODUCT SHOULD BE
PERFORMED BY AUTHORIZED SERVICE
CENTER PERSONNEL IN ACCORDANCE
WITH NATIONAL AND LOCAL ELECTRICAL
CODES.
MAKE CERTAIN THAT THE ELECTRICAL
CIRCUIT TO WHICH THE COMPRESSOR IS
CONNECTED PROVIDES PROPER ELEC-
TRICAL GROUNDING, CORRECT VOLT-
AGE AND ADEQUATE FUSE PROTEC-
TION.
HAZARD WHAT CAN HAPPEN HOW TO PREVENT IT
• SAVE THESE INSTRUCTIONS •
IMPORTANT SAFETY INSTRUCTIONS
IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT IN SERIOUS
INJURY AND PROPERTY DAMAGE. READ AND UNDERSTAND ALL WARNINGS AND OPERATING
INSTRUCTIONS BEFORE USING THIS EQUIPMENT.
CONTINUE NEXT PAGE *
RISK OF BURSTING
RISK OF
EXPLOSION OR FIRE
RISK OF
ELECTRICAL SHOCK

5 — ENG
GLOSSARY
SCFM or CFM: Standard Cubic Feet per Minute; a unit
of measurement of air delivery.
PSIG or PSI: Pounds per square inch gauge.
U.L. Listed: Products with the U.L. mark are listed by
Underwriters Laboratories, Inc. (U.L.). Samples of these
products have been evaluated by U.L. and meet the
applicable U.L. Standards for Safety.
DUTY CYCLE
All DeVilbiss Air Power manufactured air compressors
should be operated on not more than a 50% duty cycle.
This means an air compressor that pumps more than 50%
of one hour, is considered misuse, because the air
compressor is undersized for the required air demand.
Maximum compressor pumping time per hour is 30 min-
utes.
HAZARD
RISK FROM
FLYING OBJECTS
RISK TO BREATHING
RISK FROM
MOVING PARTS
RISK OF BURNS
WHAT CAN HAPPEN
YOUR AIR COMPRESSOR IS POWERED BY
THE COMPRESSED AIR STREAM CAN
CAUSE SOFT TISSUE DAMAGE TO EX-
POSED SKIN AND CAN PROPEL DIRT,
CHIPS, LOOSE PARTICLES AND SMALL
OBJECTS AT HIGH SPEED, RESULTING IN
PROPERTY DAMAGE OR PERSONAL INJURY.
THE COMPRESSED AIR FROM YOUR
COMPRESSOR IS NOT SAFE FOR BREATH-
ING! THE AIR STREAM MAY CONTAIN
CARBON MONOXIDE, TOXIC VAPORS OR
SOLID PARTICLES.
SPRAYED MATERIALS SUCH AS PAINT,
PAINT SOLVENTS, PAINT REMOVER,
INSECTICIDES, WEED KILLERS, ETC..
CONTAIN HARMFUL VAPORS AND POI-
SONS.
MOVING PARTS CAN CAUSE SERIOUS
INJURY OR DAMAGE IF THEY COME INTO
CONTACT WITH YOU OR YOUR CLOTHING.
ATTEMPTING TO OPERATE OR REPAIR
COMPRESSOR WITH PROTECTIVE
SHROUDS REMOVED CAN EXPOSE YOU
TO MOVING PARTS AND ELECTRICAL
SHOCK.
A PORTABLE COMPRESSOR CAN FALL
FROM A TABLE, WORKBENCH OR ROOF
CAUSING DAMAGE TO THE COMPRESSOR
WHICH COULD EXPOSE YOU TO HAZARD-
OUS MOVING OR ELECTRICAL PARTS.
TOUCHING EXPOSED METAL SUCH AS THE
COMPRESSOR HEAD OR OUTLET TUBE
CAN RESULT IN SERIOUS BURNS.
HOW TO PREVENT IT
ALWAYS WEAR ANSI Z87.1 APPROVED
SAFETY GLASSES WITH SIDE SHIELDS
WHEN USING THE COMPRESSOR.
NEVER POINT ANY NOZZLE OR SPRAYER
TOWARD ANY PART OF THE BODY OR AT
OTHER PEOPLE OR ANIMALS.
NEVER INHALE AIR FROM THE COMPRES-
SOR EITHER DIRECTLY OR FROM A
BREATHING DEVICE CONNECTED TO THE
COMPRESSOR.
WORK IN AN AREA WITH GOOD CROSS-
VENTILATION. READ AND FOLLOW THE
SAFETY INSTRUCTIONS PROVIDED ON THE
LABEL OR SAFETY DATA SHEETS FOR THE
MATERIAL YOU ARE SPRAYING. USE A
NIOSH/MSHA APPROVED RESPIRATOR
DESIGNED FOR USE WITH YOUR SPECIFIC
APPLICATION.
ALWAYS TURN OFF THE COMPRESSOR,
BLEED PRESSURE FROM THE AIR HOSE,
AND UNPLUG FROM ELECTRICAL OUTLET
BEFORE PERFORMING MAINTENANCE OR
ATTACHING TOOLS AND ACCESSORIES.
DO NOT REMOVE THE PROTECTIVE
COVERS FROM THIS PRODUCT. NEVER
OPERATE THE COMPRESSOR WITH
GUARDS OR COVERS WHICH ARE DAM-
AGED OR REMOVED.
ANY REPAIRS REQUIRED ON THIS PROD-
UCT SHOULD BE PERFORMED BY AUTHO-
RIZED SERVICE CENTER PERSONNEL.
ALWAYS OPERATE COMPRESSOR IN A
STABLE SECURE POSITION TO PREVENT
ACCIDENTAL MOVEMENT OF THE UNIT.
NEVER OPERATE COMPRESSOR ON A
ROOF OR OTHER ELEVATED POSITION.
USE ADDITIONAL AIR HOSE TO REACH
HIGH LOCATIONS.
NEVER TOUCH ANY EXPOSED METAL
PARTS ON COMPRESSOR DURING OR
IMMEDIATELY AFTER OPERATION. COM-
PRESSOR WILL REMAIN HOT FOR SEV-
ERAL MINUTES AFTER OPERATION.
COMPACT — 5/1/97

6 — ENG
Air Compressor Pump: To compress air, the piston
moves up and down in the cylinder. On the downstroke,
air is drawn in through the air intake muffler (valves). The
exhaust valve remains closed. On the upstroke of the
piston, air is compressed. The intake valves close and
compressed air is forced out through the exhaust valve
and then through the air hose.
Adjustable Pressure Valve: The pressure valve controls
the amount of pressure going from the air compressor to
the accessory. The pressure adjusting valve can be used
to set approximate pressure between 10 and 125 P.S.I.
(125 P.S.I. is the highest pressure this compressor will
deliver). It is normal for the adjustable pressure valve to
release air during operation.
DESCRIPTION OF OPERATION
ALWAYS SET THE PRESSURE VALVE AT OR BE-
LOW THE REQUIRED PRESSURE FOR THE AC-
CESSORY BEING USED BEFORE STARTING YOUR
COMPRESSOR. FOR INFLATION OR OTHER USES
REQUIRING ACCURATE PRESSURE, USE A PRES-
SURE GAUGE.
INSTALLATION AND BREAK-IN PROCEDURES
Location of the Air Compressor
Your compressor comes to you completely assembled
and ready for use. Operate the air compressor in a dry,
clean, cool and well ventilated area. The air compressor
pump and case are designed to allow for proper cooling.
Clean or blow off dust or dirt that collects on the air
compressor. A clean air compressor runs cooler and
provides longer service. The ventilation openings on your
air compressor are necessary to maintain proper operat-
ing temperature. Do not place rags or other containers on
or near these openings.
Extension Cords
Use extra air hose instead of an extension cord to avoid
voltage drop and power loss to the motor. Low voltage can
cause damage to the motor.
If an extension cord must be used, be sure it is:
• a 3-wire extension cord that has a 3-blade grounding
plug, and a 3-slot receptacle that will accept the plug on
the compressor
• in good condition
• no longer than 50 feet
• 14 gauge (AWG) or larger. (Wire size increases as gauge
number decreases.) 12 AWG, 10 AWG and 8 AWG may
also be used. DO NOT USE 16 OR 18 AWG.
GROUNDING INSTRUCTIONS
RISK OF ELECTRICAL SHOCK! In the event of a
short circuit, grounding reduces the risk of shock
by providing an escape wire for the electric
current. This air compressor must be properly
grounded.
The air compressor is equipped with a cord having a
grounding wire with an appropriate grounding plug. The
plug must be used with an outlet that has been installed
and grounded in accordance with all local codes and
ordinances. The outlet must have the same configuration
as the plug. See illustration. DO NOT USE AN
ADAPTER.
Inspect the plug and cord before each use. Do not use if
there are signs of damage.
IMPROPER GROUNDING CAN RESULT IN
ELECTRICAL SHOCK.

7 — ENG
Air Hose
The air hose attached to your compressor has an integral
pressure adjusting valve at the working end of the hose.
Should service or replacement be required, make sure that
the pressure adjusting valve is present in the air hose line.
It is normal for the adjustable pressure valve to release air
during operation.
Do not modify the plug that has been provided. If it
does not fit the available outlet, the correct outlet
should be installed by a qualified electrician.
If repairing or replacing cord or plug, the grounding
wire must be kept separate from the current-carrying
wires. Never connect the grounding wire to a flat blade
plug terminal. The grounding wire has insulation with
an outer surface that is green - with or without yellow
stripes.
If these grounding instructions are not completely
understood, or if in doubt as to whether the compres
sor is properly grounded, have the installation checked
by a qualified electrician.
Do not allow hose to become kinked or pinched
at any time. This is important to avoid damage
to your compressor and to maintain pressure
adjusting valve control.
120 Volts, 15 Amps
120 Volt Models
Compressed air from the outfit may contain water
condensation. Do not spray unfiltered air at an item
that could be damaged by moisture. Some air
operated tools or devices may require filtered air.
Read the instructions for the air tool or device.
1. Before plugging in the air compressor, set the adjust-
able pressure valve to "10" PSI. Make sure the "ON/
OFF" switch is in the "OFF" position.
2. Connect the air tool or accessory to the air hose.
Tighten securely.
3. Plug the power cord into the grounded outlet.
4. Start the compressor by setting the "ON/OFF" switch
to the "ON" position.
5. Check the manufacturer's maximum pressure rating
for the air tool, accessory or vehicle tire being used.
The air compressor outlet pressure must never exceed
the maximum pressure rating.
6. Slowly increase the pressure setting of the adjustable
pressure valve. You should be able to hear and feel air
pressure being relieved by the adjustable pressure
valve. If pressure is not being relieved, turn the air
compressor off immediately. The pressure valve must
be replaced.
OPERATING PROCEDURES
INSTALLATION AND BREAK-IN PROCEDURES
DO NOT REPLACE THE HOSE WITH STAN-
DARD HOSE THAT IS NOT EQUIPPED WITH
THE PRESSURE ADJUSTING VALVE. THE
APPROPRIATE HOSE ASSEMBLY FOR YOUR
COMPRESSOR IS AVAILABLE AT SEARS.
TOO MUCH AIR PRESSURE COULD CAUSE AN
AIR TOOL OR VEHICLE TIRE TO RUPTURE OR
EXPLODE. CAREFULLY FOLLOW STEPS 5 AND 6
EACH TIME YOU USE YOUR COMPRESSOR.

8 — ENG
When you have finished using the air compressor:
1. Set the "ON/OFF" switch to "OFF" and unplug the
cord.
2. Relieve all pressure from the air compressor head
and air hose by setting the adjustable pressure valve
to 10 P.S.I.
3. Protect the electrical cord and air hose from damage
by winding them loosely around the air compressor.
4. Store the air compressor in a clean and dry location.
STORAGE

9 — ENG
AIR COMPRESSOR DIAGRAM
PARTS AVAILABLE FOR THIS UNIT
DESCRIPTION PART NUMBER
Pressure Valve Assembly.......................CAC-4324
Connecting Rod Kit ................................KK-4926
Fastener Kit ............................................KK-4929
Isolator Kit ...............................................KK-4930
Pressure Valve Assembly
ON/OFF SWITCH

10 — ENG
High discharge pressure.
Cannot be adjusted lower.
Adjustable pressure valve not func-
tioning.
Air Leaks Hose fitting loose.
Prolonged excessive use of air. Decrease the amount of air usage. Your com-
pressor is not large enough for the air require-
ment.
Tighten fitting.
Compressor is not delivering
enough air.
Replace the hose.
Hole in hose.
Air leaks. Tighten fittings.
1. Check fuse box for blown fuse and replace as
necesssary. Reset circuit breaker. Do not
use a fuse or circuit breaker with higher rating
than that specified for your particular branch
circuit.
2. Check for proper fuse. You should be using
a Quick Acting fuse.
3. Check for low voltage problem.
4. Check the extension cord.
5. Disconnect the other electrical appliances
from circuit or operate the compressor on its
own branch circuit.
Fuse blown, circuit breaker tripped.Motor will not run.
Extension cord is wrong length or
gauge.
Check the extension cord.
Loose electrical connections. Check wiring connection inside terminal box
Faulty motor. Have checked at a local Service Center.
TROUBLESHOOTING GUIDE
VOLTAGE SOURCES, MOVING PARTS OR COMPRESSED AIR SOURCES ARE EXPOSED
WHEN REPAIRING THE COMPRESSOR. PERSONAL INJURY CAN OCCUR. UNPLUG THE
COMPRESSOR BEFORE ATTEMPTING ANY REPAIRS.
RISK OF BURSTING. DO NOT OPERATE
THE COMPRESSOR IF THIS PROBLEM
EXISTS. ADJUSTABLE PRESSURE VALVE
MUST BE REPLACED.
CORRECTIONCAUSEPROBLEM

11 — ENG
SERVICE NOTES

DeVilbiss Company Air Power • 213 Industrial Dr. • Jackson, TN 38301-9615
Call our Toll Free Number 1-800-888-2468, Ext 2, then 1, to obtain the
location of the nearest Authorized Service Center for ordering repair parts
and for warranty repairs.
When ordering repair parts from your local Authorized Service Center,
always give the following information:
• Model number of your product
• Part number and description of the item you
wish to purchase
WARRANTY
This product is covered by the DeVilbiss
one year limited warranty. The warranty
can be found on page 3 or is available
upon request.
Attach Sales Receipt Here.
Retain Original Sales Receipt as Proof of
Purchase for Warranty Repair Work.
OWNERS MANUAL FOR
PERMANENTLY LUBRICATED AIR COMPRESSOR
MODEL NOS.
WB100D-2 — XE-7D-2 — IRC1D-2
(For Home Use Only)
