Axio MET AX-WS100 User manual
Model AX-WS100
INSTRUCTION MANUAL
2
Operation Instruction
I. Main Functions:
1. weather forecast for 4 states: sunny, semi-sunny, cloudy, rainy
2. seven languages to show the day: English, ermany, French, Italian, Spanish, Dutch, Danish
3. indoor temperature range: 0℃--50℃, sampling cycle: 12 seconds
4. indoor humidity range: 20%-----95%
5. outdoor temperature with RF: up to 3 channels
6. in/out trend indication of temperature/humidity
7. indication of the comfort index
8. the function of Alarm/ Snooze
9. 12/24 hour selectable
10. moon phase
11. LED light
12. world time zone set, -12/+12 hours
II. ower-On and reset
1. When Power-On and reset, LCD full display for 3 seconds enter the normal state after “Beep”
check temperature and humidity
2. The calendar defaults 0:00 January 1, 2000
3. Alarm defaults 0:00
4. The weather icon defaults semi-sunny
5. Temperature scales defaults Celius degree ℃. Time system defaults 24Hr.
III. Instruction of operating the KEYS
3.1. Key functions
Eight functional keys: Set, Alm, Up, Down, Snooze/Light, Channel, Alert, Max/Min
function
operation
Set Alm Up Down SNZ/LI H
T
Channel Alert Max/Min
standard
mode
Clic
k
----- Alarm
on/off
12hr/24hr
switchable
°C/°F
switchable
Back
Light/
enter
Snooze
Switch to
CH1,CH2,CH
3
On/Off
temperatur
e Alarm
Switchabl
e
between
CH1, 2, 3
3
Hold enter
into
clock
setting
enter
into
alarm
setting
----- ----- ----- Clear
current
registered
Into
temperatur
e alarm
setup
clear
max/ min
Time set
Clic
k
Confirm
the
setting
item
---
--
one step
forward
one step
backward
----- --------- ---------- ----------
Hold ----------
-
---
--
8steps/secon
d forward
8steps/secon
d backward
----- --------- ----------- ----------
Alarm set
Clic
k
---------- confir
m the
setting
item
one step
forward
One step
backward
----- --------- ------------ --------
Hold ---------- ---
--
8steps/secon
d forward
8steps/secon
d backward
----- --------- ------------ -----
Temp alert set
Clic
k
----------
-
----
-
one step
forward
one step
backward
-----
Choose
needed
channel
Confirm the
Setting
item
---------
Hold
----------
---
---
8steps/secon
d forward
8steps/secon
d backward
-----
------
------
---------
-
3.2. Normal states
1. hold “SET” for 2 seconds to enter into time setting
2. click “Alm” to switch the alarm on/off
3. hold “Alm ” for 2 seconds to enter into Alarm setting
4. click “Up” to switch between 12hr/24hr
5. press “Down” to switch between °C/°F
6. press”SNOOZE/LI HT”to turn on the back light 5 seconds
7. when ALARM rings, click “SNOOZE/LI HT” to enter into the snooze state every 5 minutes
8. press “Channel” to switch RF channel, CH1 CH2CH3
9. hold “Channel” key for 2 seconds to clear out all data of current “Channel”
10. press”ALERT”key to switch temperature alarm on/off
11. hold”ALERT”key 2 seconds to enter temperature alarm setting
12. press”MAX/MIN”key to check maximal and minimum of temperature and humidity
13. hold”MAX/MIN”key 2 seconds to clear all record of temperature and humidity
4
3.3. Time set
1. hold “SET” key for 2 seconds to enter into time setting
2. the sequence of time setting: Year(2000-2099) Month Date Language Hour Minute
Time zone Exit
3. there will have 1Hz flashing during setting
4. press “SET” to confirm the setting, and enter the next setting state
5. press “Up” one time, the setting will go ahead for one step; hold the key for 2 seconds, it will run
forward by 8 steps/second.
6. press “Down” one time, the setting will backward for one step; hold for 2 seconds, it will run
back by 8 steps/second.
7. moon phase is changed accordingly time changed.
8. the system will exit automatically if no key is operated in 8 seconds.
3.4. Alarm set
1. hold “Alm” key for 2 second to enter into alarm setting
2. the sequence of alarm setting: Hour Minute exit
3. there will have 1Hz flashing during setting
4. press “Alm” to confirm the setting, and enter the next setting state
5. press “Up” one time, the setting will go ahead for one step; hold the keys for 2 seconds, it will
run forward by 8 steps/seconds.
6. press “Down” one time, the setting will backward for one step; hold for 2 seconds, it will run
back by 8 steps/second.
7. the system will exit automatically if no key is operated in 8 seconds.
3.5. Temperature alarm setting
1. hold”ALERT”2 second into ALERT setting
2. setting sequence: upper limited lower limitexit
3. press”CHANNEL”key when setting upper limited and lower limited to change different channel.
4. default of upper limited is:+70°C ,lower limited is -50°C
5. there will have 1Hz flashing during setting
6. press”ALERT”key confirm the end of setting then enter next item setting
7. press “Up” one time, the setting will go ahead for one step; hold the keys for 2 seconds, it will
run forward by 8 steps/seconds.
8. press “Down” one time, the setting will backward for one step; hold for 2 seconds, it will run
back by 8 steps/second.
9. the system will exit automatically if no key is operated in 8 seconds.
10. Alert will automatically turn on when setting is finished.
5
IV. Function and effect
4.1. The receiving function of RF
1. after installing the battery and checking temperature/humidity, it will enter RF receiving state
automatically for 3 minutes.
2. under normal display mode, hold the “Channel” key for 2 seconds to clear out the channel
information
3. if there is no effective signal with same ID code received for the current channel in 35 minutes,
the temperature of that CH will shows “--.-“.
4. the temperature display will resume back when the correct signal is received again
4.2. The function of alarm
1. the BUZZER will ring for 2 seconds as below:
a. 0 – 10 sec.: one “beep” per second
b. 10 – 20 sec.: two “beep” per second
c. 20 – 30 sec.: four “beep” per second
d. after 30 sec.: “beep” continuously
2. when ringing, click “SNZ/LI HT” key once to enter into 5 minutes snooze states, exit if any other
key is clicked.
4.3 The function of temperature and humidity
1. the indoor temperature display range: 0°C -- +50°C (32°F -- +122°F)
2. the indoor temperature proposed operating range: 0° C-- +40°C (3°F -- +104°F)
3. the outdoor temperature display range: - 50°C -- +70°C(-58°F -- +158°F)
4. the outdoor temperature proposed operating range: -5°C -- +45°C(23°F -- +113°F)
5. the temperature resolution: 0.1°
6. the indoor humidity range: 20% --- 95%
7. the humidity resolution: 1%RH
8. sampling period: 12 seconds.
9. the temperature and hygrometer sampling will be held when the alarm is ringing
10. the RF Transmission Frequency: 433.92MHz
11. No. of Remote unit: Up to 3units
4.4 The function of weather forecast
1. weather icons for 4 states: sunny semi-sunny cloudy rainy
Operated by: Main Unit 3XAAA battery(not included)
Transmitter 2XAAA battery(not included)
CAUTION:
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDIN TO THE INSTRUCTIONS
