AYA ALF8201 User manual

FR 20
Protection de l'environnement
Mise au rebut correcte du produit.

Safety notices
Parts and features
Installation
The functions of the control panel
How to use washer
Cleaning and maintenance
Troubleshooting guide
Technical parameters
Electric Diagram
Correct Disposal Of This Product
-1-
-4-
-5-
-8-
-10-
-13-
-15-
-16-
-17-
-17-
1.
THIS PRODUCT IS FOR HOUSEHOLD
USE ONLY!
Please read these instructions carefully
before the first use of this product and save
this manual for your future reference.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
- Children of less than 3 years should be kept away unless continuously supervised.
- The new hose-sets supplied with the appliance are to be used and that old hose-sets
should not be reused. - This appliance is not designed for commercial use. It is
intended for household and indoor use only.
- If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
- The Maximum mass of dry cloth in kilograms is 8.0kg.
- The maximum inlet water pressure is 0.8MPa, and the minimum inlet water pressure
is 0.02MPa.
1

2.
3.
4.
5.
6.
10.
11.
12.
13.
14.
7.
8.
9.
15.
16.
17.
18.
19.
20.
21.
23.
22.
This appliance has been incorporated with a grounded plug. Please ensure the wall outlet
in your house is well earthed.
3
2
Before installing the washing machine, check it for any externally visible damage.
Do not install or use a damaged washing machine .
Before connecting the washing machine, ensure that the connection data on the plate (voltage
and current) match the electricity supply. If in any doubt, consult a qualified electrician.
The electrical safety of this washing machine can only be guaranteed when continuity is complete
between the appliance and an effective earthing system which complies with current local and
national safety regulations. It is important that this basic safety requirement is present and
regularly tested, and where there is any doubt the household wiring system should be inspected
by a qualified electrician. The manufacturer cannot be held liable for the consequences of an
inadequate earthing system.
Do not connect the washing machine to the mains electricity supply by an extension lead.
Extension leads do not guarantee the required safety of the appliance.
Unauthorised repairs could result in unforeseen dangers for the user, for which the manufacturer
cannot accept liability. Repairs should only be undertaken by an approved service technician.
Ensure current is not supplied to the machine until after maintenance or repair work has been
carried out.
If the connection cable is damaged or broken, it must only be replaced by an approved service
technician to protect the user from danger.
Faulty components must only be replaced by genuine manufacturer original spare parts. Only
when these parts are fitted can the safety standards of the machine be guaranteed.
To avoid the risk of personal injury or damage to the washing machine, do not install it in a
place that it is damp or at risk from rainfall.
Do not install the washing machine in direct sunlight, to avoid plastic or components
becoming damaged and shortening the life of your washing machine.
Do not install the washing machine in places where temperatures may drop below freezing.
Frozen hoses may burst or split . The reliability of the electronic control unit may be impaired
at temperatures below freezing point.
Do not shoot the washing machine with water when you clean it.
Keep the washing machine away from fire or heat sources.

5
4

7
6

9
8

11
10

13
12

15
14

Brand AYA
Model name ALF8201
Rated voltage 220-240V~50Hz
Rated power 2100W
Pressure 0.02-0.8MPa
Rated capacity (KG) 8
Energy efficiency class A+++
Annual Energy Consumption (kWh/annual)190
Energy Consumption (Et 60) (kWh) 1.0
Energy Consumption (Et 60 1/2) (kWh)0.74
Energy Consumption (Et 40 1/2) (kWh)0.72
Power Consumption of the off mode (W)0.48
Power Consumption of the left on mode (W)0.48
Annual water consumption (Litres/annum)10780
Spin drying efficiency class B
Maximum spin speed (rpm)1205
Remaining moisture content (%) 53%
Programme time of the standard 60 °C cotton programme at full load (minutes)300
Programme time of the standard 60 °C cotton programme at partial load (minutes)269
Programme time of the standard 40 °C cotton programme at partial load (minutes)249
Duration of the left on mode (minutes)NA
Airborne acoustical noise emissions (Washing phase) (dB)
Airborne acoustical noise emissions (Spinning phase) (dB)
Installation type Freestanding
Product size (mm)595x545x845
Net weight 65kg
60
75
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take this
product for environmental safe recycling.
