User’s Guide
VFP20 FAMILY
20” FLAT
PANEL DISPLAY
Document No. 150-VF20-001 Rev. (A), July 2005

150-VF20-001(A).doc 2
NOTICE
This manual is subject to change without notice and should not be construed to be a
commitment in any form by Aydin Displays.
Aydin Displays reserves the right to make improvements to the product at any time. It is
understood that the delivered product will be of the latest possible design and that it may not
be exactly as stated herein. This manual may contain descriptions of functions not
implemented at time of distribution, unless prior contractual arrangements have been made.
Aydin Displays reserves the right to modify or revise the content of this manual. It is further
understood that in consideration of the receipt or purchase of this manual, the recipient or
purchaser agrees not to reproduce, disseminate the information herein, or copy it by any means
whatsoever, nor to permit such actions by others, for any purpose, without the written
permission of Aydin Displays.
All trademarks and registered trademarks are recognized as the property of their respective
owners.

150-VF20-001(A).doc 3
FEDERAL COMMUNICATIONS COMMISSION REQUIREMENTS
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
♦ Use the specified cables with the VFP20 display so as not to interfere with radio and television
reception.
♦ Use the supplied power cable or equivalent to ensure FCC compliance
♦ Use the shielded video cable
♦ Series VFP20 products have been tested and found to comply with the limits for Class A,
pursuant to part 15 of FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in strict accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
♦ Reorient or relocate the receiving antenna
♦ Increase the separation between the equipment and the receiver
♦ Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
♦ Consult the dealer or an experienced radio/TV technician for help

150-VF20-001(A).doc 4
WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
ALSO DO NOT USE THIS UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR
OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED.
DO NOT OPEN THE CABINET. THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK, NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol warns the user that uninsulated voltage within
the unit
may be large enough to cause electric shock. Therefore, it is
dangerous to touch any part inside the unit.
This symbol alerts the user that important literature about the
operation and maintenance of this unit has been included. Read it
carefully to avoid any problems.
!
!
!

150-VF20-001(A).doc 5
PRODUCT SAFETY PRECAUTIONS
♦ The socket-outlet of power supply shall be installed near the equipment and shall be easily accessible.
♦ Follow all warnings and instructions marked on the display.
♦ Do not attempt to service this display yourself. There are no user replaceable parts inside and removing
the display cover or back will expose you to dangerous voltage or other risks. Refer all servicing to
qualified service personnel.
♦ Adequate ventilation must be maintained to ensure reliable and continued operation and to protect the
display from overheating. Do not block ventilation slots and openings or install the display in a place
where ventilation may be hindered.
♦ To protect from electrical shock, unplug the display’s power supply from the wall outlet before
relocating.
♦ Do not expose this display to direct sunlight or heat. Hot air may cause damage to the cabinet and other
parts.
♦ This display should be operated from the type of power source indicated on the display’s rating label.
♦ Do not allow metal pieces or objects of any kind to fall into the display through the ventilation holes.
♦ The inside of the fluorescent tube located within the LCD monitor contains mercury. Please follow the
bylaws or rules of your municipality to dispose of the tube properly.
♦ Do not use this display near water.
♦ Do not place any heavy objects on the power cord. Damage to the cord may cause shock or fire.
♦ When operating the LCD monitor with its AC 220-240V power supply; use a power cord that matches
the power supply voltage of the AC outlet being used. The power supply cord you use must have been
approved by and comply with the safety standards of your country.
♦ In UK, use a BS-approved power cord with molded plug having a black (5A) fuse installed for use with
this monitor.
♦ Unplug this display’s power supply from the wall outlet and refer servicing to qualified service
personnel in the event that:
 Power cord or plug is damaged or frayed.
 Liquid is spilled into the display or the display is exposed to rain or water.
 The display does not operate normally when the operating instructions are followed.
 The display has been dropped or the cabinet damaged.
 The display exhibits a distinct change in performance, indicating a need for service.

150-VF20-001(A).doc 6
Thank you for purchasing the Aydin Displays VECTOR Display.
This carton contains the items listed below:
♦ VFP20 LCD Display
♦ Power cord
♦ Video signal cable (HD15 male to DVI-A)
♦ Video signal cable (DVI-D to DVI-D cable)
♦ Capacitive Touch Option Interface Cable (if applicable)
♦ Mounting hardware (if applicable)
♦ Product CD containing:
– This User’s Guide
– Warranty Guide
– Touch Accessories (if applicable)
Please check the carton and its content for damage that may have occurred during shipment.
Report any damage to the shipping agent immediately and do not operate the display if it
appears to have been damaged. All warranty returns must use the original shipping carton and
packaging materials to prevent shipping damage.

150-VF20-001(A).doc 7
DISPLAY CONNECTIONS AND ADJUSTMENTS:
If you have any problems connecting, setting up, or operating the display, please refer to the
Troubleshooting section of this guide.
VIDEO INPUT 1 - DVI-I Connector:
For Analog Video input, connect the DVI-A connector of the video cable to the DVI-I connector on the
rear of the display and the other end to the HD15 connector on the computer.
For Digital Video input, connect one end of the DVI-D Digital video cable to the DVI-I connector on
the rear of the display and the other end to the DVI connector on the computer.
VIDEO INPUT 2 - DVI-D Connector and HD15 Connector:
For Analog Video input, connect one end of a VGA video cable (not supplied) to the HD15 connector
on the rear of the display and the other end to the HD15 connector on the computer.
For Digital Video input, connect one end of the DVI-D Digital video cable to the DVI-D connector on
the rear of the display and the other end to the DVI connector on the computer.
If a Touch Screen option has been provided, connect the interface cable from the touch interface
connector on the rear of the display to the proper RS232 Serial Controller.
Plug the power cord into the rear of the display and then plug the cord into an AC power source. Turn
on the display. The Green ON LED should light. If the Amber NO SYNC LED is lit, refer to the
Troubleshooting section.
CONTROLS:
On-Screen-Menu (OSM) Controls:
The OSM controls on the front of the monitor function as follows:
To access OSM menu, press any of the control buttons (LEFT, RIGHT, UP, DOWN)
To change signal input, press the “SELECT” button when OSM is NOT selected.
Control Main Menu Sub-Menu
EXIT Exits the OSM menu. Exits to the OSM sub-menu
LEFT, RIGHT Moves the highlighted area left/right to Moves the highlighted area left/right
select desired sub-menus. to select one of the functions.
DOWN, UP Moves the bar left/right to increase or decrease Moves the bar left/right to increase
the selected adjustment. or decrease the selected adjustment.
SELECT Active Auto Adjust function. Enter the OSM control. Enter the OSM Sub menu.
RESET Resets the highlighted control menu to the factory
setting.
Note: When “RESET” is pressed in the main or sub-menu, a warning window will appear allowing you to cancel the reset function
by pressing the EXIT button.

150-VF20-001(A).doc 8
BRIGHTNESS/CONTRAST CONTROLS:
BRIGHTNESS:
Adjusts the overall image and background screen brightness.
CONTRAST:
Adjusts the image brightness in relation to the background.
AUTO CONTRAST (ANALOG INPUT ONLY):
Adjust the image displayed for non-standard video inputs.
AUTO BRIGHTNESS:
This function adjusts the brightness automatically for the best CONTRAST and BRIGHTNESS setting based on the
white display area.
AUTO ADJUST (ANALOG INPUT ONLY):
Automatically adjusts the Image Position, the Horizontal Size, and Fine settings.
IMAGE CONTROLS:
LEFT/RIGHT:
Controls Horizontal Image Position within the display area on the LCD.
UP/DOWN:
Controls Vertical Image Position within the display area of the LCD.
H. SIZE (ANALOG INPUT ONLY):
Adjusts the horizontal size by increasing or decreasing this setting.
FINE (ANALOG INPUT ONLY):
Improves focus, clarity and image stability by increasing or decreasing this setting.
ACCUCOLOR CONTROL SETTING:
Six color presets select the desired color settings (sRGB and NATIVE color presets are standard and
can not be changed). Color temperature increases or decreases, in each preset. R, Y, G, C, B, M, S:
Increases or decreases Red, Yellow, Green, Cyan, Blue, Magenta, and Saturation depending upon
which is selected. The change in color will appear on the screen and the direction (increase or decrease)
will be shown by the color bars. NATIVE: Original color presented by the LCD panel that is non-
adjustable
TOOLS 1:
SHARPNESS: This function is continuously adjustable to get a sharp or soft image as needed and is set
independently of different timings. The number of adjustment steps is different depending on whether
EXPANSION Mode is OFF, FULL, ASPECT (1600x1200 corresponds to OFF mode).
EXPANSION MODE: Sets the zoom method.
FULL: The image is expanded to 1600 x 1200, regardless of the resolution.
ASPECT: The image is expanded without changing the aspect ratio.
OFF: The image is not expanded.
CUSTOM (Digital input and Resolution of 1600 x 1200 only): Select one of seven expansion rates.
In this mode the resolution may be low and there may be blank areas. This mode is for use
with special video cards.

150-VF20-001(A).doc 9
VIDEO DETECT: Selects the method of video detection when more than one computer is connected.
FIRST DETECT: The video input has to be switched to “FIRST DETECT” mode.
When the current video input signal is not present, the monitor
searches for a video signal from the other video input. If the video signal is
present in the other port, then the monitor will automatically switch to the
new video source. The monitor will not look for other video signals while
the current video source is present.
LAST DETECT: The video input has to be switched to “LAST DETECT” mode.
When the monitor is displaying a signal from the current source and a new
secondary source is supplied to the monitor, then the monitor will
automatically switch to the new video source. When current video input
signal is not present, then the monitor searches for a video signal from the
other video input port. . If the video signal is present in the other port, then
the monitor will automatically switch to the new video source.
NONE: The monitor will not search the other video-input port unless the monitor is
turned on.
DVI SELECTION: This function selects the DVI input mode (Input 1). When the DVI selection has been
changed, you must restart the computer.
AUTO: By using the DVI-D to DVI-D cable, the DVI selection is DIGITAL. By using the HD15 to
DVI-A cable, the DVI selection is ANALOG.
DIGITAL: DVI digital input is available.
ANALOG: DVI analog input is available.
NOTE: Depending on the PC/Video card or video signal cable used, this function may not operate.
OFF TIMER: Monitor will automatically power down when the end user has selected a predetermined amount
of time.
TOOLS 2:
LANGUAGE: OSM control menus are available in seven languages.
OSM POSITION: You can choose where you would like the OSM control window to appear on your screen.
Selecting OSM location allows you to manually adjust the position of the OSM control menu left, right, up or
down.
OSM TURN OFF: The OSM control menu time out is selectable from the following preset choices: 10, 20, 30,
45, 60 and 120 seconds.
OSM LOCK OUT: This control completely locks out access to all OSM control functions. When attempting to activate
OSM controls while in the Lock Out mode, a screen will appear indicating the OSM controls are locked out. To activate the
OSM Lock Out function, simultaneously press and hold the SELECT and UP buttons. To deactivate the OSM Lock Out
function, simultaneously press and hold the SELECT and UP buttons.
RESOLUTION NOTIFIER: This optimal resolution is 1600 x 1200. If ON is selected, a message will appear on the screen
after 30 seconds, notifying the operator that the resolution is not at 1600 x 1200.
HOT KEY: You can adjust the brightness and contrast directly. When this function is set to ON, the brightness
can be adjusted with the LEFT and RIGHT keys, the contrast can be adjusted with the UP and DOWN keys,
while the OSM menu is off.
FACTORY PRESET: Selecting Factory Preset resets most OSM control settings back to the factory settings. Individual
settings can be reset by highlighting the control to be reset and pressing the RESET button.

150-VF20-001(A).doc 10
CLEANING AND CARE OF PROTECTIVE DISPLAY LENS:
• Always damp-dust the acrylic protective lens. For best results, mix a solution of one teaspoon of mild
dishwashing liquid and one pint of water. Apply this solution with spray bottle and wipe dry with a clean
cotton cloth.
• Do-Not Use: Window cleaning fluids, scouring compounds, gritty cloths, leaded or ethyl gasoline or strong
solvents such as alcohol, acetone, carbon tetrachloride, etc.

150-VF20-001(A).doc 11
TOUCH-SCREEN INFORMATION:
This information only applies to customers who have ordered a flat panel with a touch screen installed.
Due to the constantly changing world of PC operating systems, it is recommended by the manufacturer of touch screens to
download the latest driver and user’s manual to insure proper operation and system compatibility.
The Touch screen driver software provided on Product CD is a downloaded copy from the following listed company. Aydin
Displays Inc does not warrant any of the touch software. The driver software has been downloaded from the appropriate web
sites and is only updated every January. Please refer to the appropriate web site for the latest updates.
Prior to utilizing these drivers, please read the enclosed End-User License Agreement in the Read Me File.doc included on
the Product CD. If you do not agree with any part off or all the agreements, contact the listed Software/Touch Screen
Company.
The names of actual companies and products mentioned herein may be trademarks of their respective owners.
♦ For Capacitive touch screens, refer to:
http://www.3m.com/3MTOUCHSYSTEMS/

150-VF20-001(A).doc 12
VECTOR 20 SPECIFICATIONS:
Visual Performance:
Display Type: 20.1” TFT Active-Matrix LCD
Active Display Area: 408mm x 306mm (16.1in x 12.0in)
Pixel Pitch: 0.255 mm
Luminance: 250cd/m2(typical)
Contrast Ratio: 400:1 (typical)
Resolutions Supported:
720x400 VGA text
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832x624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 870 @ 75Hz
1280 x 1024 @ 60-85 Hz
1600 x 1200 @ 60Hz
Input Signal:
Video: Analog: RGB, 0.7 Vp-p/75 Ohms
Digital: DVI
Sync: Separate Sync TTL Level
Horizontal Sync Positive/Negative
Vertical Sync Positive/Negative
Composite Sync Positive/Negative
Sync on Green Video 0.7 Vp-p and sync Negative 0.3 Vp-p
Input:
Digital: DVI
Analog: HD15 and DVI-I
Scanning Frequency: Horizontal: 31.5 kHz to 91.1 kHz
Vertical: 50.0 Hz to 85.0 Hz
View Angle: +/-880all directions
User Controls: On Screen Menu (OSM) Brightness, Contrast,
Horizontal &Vertical Position, Width, Focus and Reset

150-VF20-001(A).doc 13
Environmental:
Operating Temperature: 0°C to 50°C
Storage Temperature: -20°C to 60°C
Operating Humidity (Non-condensing): 30% to 80%
Storage Humidity: (Non-condensing): 10% to 90%
Operating Altitude: 0 to 12,000 ft
Storage Altitude: 0 to 40,000 ft
Shock: 30G, 11ms, ½ Sine
Vibration: 1G RMS 20-500HZ
Power Supply: Internal 100 – 240VAC, 50/60 Hz
Current Rating: 0.7 / 0.4 A
EMI: FCC Class A

150-VF20-001(A).doc 14
TROUBLESHOOTING:
NO PICTURE:
• If the Amber NO SYNC LED is lit, verify that the signal cable is properly connected to the display and
computer.
• The Green ON LED should be lit.
IMAGE PERSISTENCE:
• Image persistence is when a “ghost” of an image remains on the screen even after the monitor has been turned
off. Unlike CRT monitors, LCD monitors’ image persistence is not permanent. To alleviate image
persistence, turn the monitor off for as long as an image was displayed. If an image was on the monitor for
one hour and a “ghost” of that image remains, the monitor should be turned off for one hour to erase the
image.
IMAGE IS UNSTABLE, UNFOCUSED OR SWIMMING IS APPARENT:
• Signal cable (video) should be completely attached to the computer and display.
• Use the OSM Image Adjust controls to focus and adjust display by increasing or decreasing the FINE setting.
When the display mode is changed, the OSM Image Adjust settings may need to be re-adjusted.
DISPLAY IMAGE IS NOT SIZED PROPERLY:
• Use the OSM Image Adjust controls to increase or decrease the H. SIZE setting.
CUSTOMER SERVICE CONTACT INFORMATION:
Phone: [phone]
E-mail: [e-mail]

150-VF20-001(A).doc 15
VFP20 RACK MOUNT FRONT AND REAR VIEWS

150-VF20-001(A).doc 16
VFP20 PANEL MOUNT FRONT AND REAR VIEWS

150-VF20-001(A).doc 17
VFP20 WALL MOUNT FRONT AND REAR VIEWS
