Baby Lock Altair 2 User manual

1
Thank you for purchasing this machine. Before using this
machine, carefully read the “IMPORTANT SAFETY
INSTRUCTIONS”, and then study this manual for the
correct operation of the various functions.
In addition, after you have finished reading this manual,
store it where it can quickly be accessed for future
reference.
Please read these safety instructions before attempting to
use the machine.
DANGER
- To reduce the risk of electric shock
1Always unplug the machine from the
electrical outlet immediately after using,
cleaning, making any user servicing
adjustments mentioned in this manual,
or if you are leaving the machine
unattended.
WARNING
- To reduce the risk of burns, fire, electrical shock, or
injury to persons.
2Always unplug the machine from the electrical
outlet, or when making any adjustments mentioned
in the instruction manual.
• To unplug the machine, switch the machine to the
symbol “O” position to turn it off, then grasp the
plug and pull it out of the electrical outlet. Do not
pull on the cord.
• Plug the machine directly into the electrical outlet.
Do not use an extension cord.
• Always unplug your machine if there is a power
failure.
3Electrical Hazards:
• This machine should be connected to an AC power
source within the range indicated on the rating
label. Do not connect it to a DC power source or
inverter. If you are not sure what kind of power
source you have, contact a qualified electrician.
• This machine is approved for use in the country of
purchase only.
4Never operate this machine if it has a damaged cord
or plug, if it is not working properly, has been
dropped or damaged, or water is spilled on the unit.
Return the machine to the nearest authorized Baby
Lock retailer for examination, repair, electrical or
mechanical adjustment.
• While the machine is stored or in use if you notice
anything unusual, such as an odor, heat,
discoloration or deformation, stop using the
machine immediately and unplug the power cord.
• When transporting the machine, be sure to carry it
by its handle. Lifting the machine by any other part
may damage the machine or result in the machine
falling, which could cause injuries.
• When lifting the machine, be careful not to make
any sudden or careless movements, which may
cause a personal injury.
5Always keep your work area clear:
• Never operate the machine with any air openings
blocked. Keep ventilation openings of the machine
and the foot controller free from the build up of lint,
dust, and loose cloth.
• Do not store objects on the foot controller.
• Never drop or insert foreign object into any
opening.
• Do not operate where aerosol (spray) products are
being used or where oxygen is being administered.
• Do not use the machine near a heat source, such as
a stove or iron; otherwise, the machine, power cord
or garment being sewn may ignite, resulting in fire
or an electric shock.
• Do not place this machine on an unstable surface,
such as an unsteady or slanted table, otherwise the
machine may fall, resulting in injuries.
INTRODUCTION
IMPORTANT SAFETY
INSTRUCTIONS

2
6Special care is required when sewing:
• Always pay close attention to the needle. Do not use
bent or damaged needles.
• Keep fingers away from all moving parts. Special
care is required around the machine needle.
• Switch the machine to the symbol “O” position to
turn it off when making any adjustments in the
needle area.
• Do not use a damaged or incorrect needle plate, as
it could cause the needle to break.
• Do not push or pull the fabric when sewing, and
follow careful instruction when free motion stitching
so that you do not deflect the needle and cause it to
break.
7This machine is not a toy:
• Your close attention is necessary when the machine
is used by or near children.
• This product contains small parts. Keep the product
out of the reach of children to prevent accidental
ingestion of small parts.
• The plastic bag that this machine was supplied in
should be kept out of the reach of children or
disposed of. Never allow children to play with the
bag due to the danger of suffocation.
• Do not use the seam ripper in any other way than
how it is intended.
• Do not use outdoors.
8For a longer service life:
• When using and storing this machine, avoid direct
sunlight and high humidity locations. Do not use or
store the machine near a space heater, iron, halogen
lamp, or other hot objects.
• Do not use cleansers or organic solvents, such as
thinner, petroleum ether or alcohol, to clean the
machine. Otherwise, the finish may peel off or
become scratched.
• Always consult the Instruction and Reference Guide
when replacing or installing any assemblies, the
presser feet, needle, or other parts to assure correct
installation.
9For repair or adjustment:
• If the light unit is damaged, it must be replaced by
an authorized Baby Lock retailer.
• In the event a malfunction occurs or adjustment is
required, first follow the troubleshooting table in the
back of the Instruction and Reference Guide to
inspect and adjust the machine yourself. If the
problem persists, please consult your local
authorized Baby Lock retailer.
Use this machine only for its intended use as described
in the manual.
Use accessories recommended by the manufacturer as
contained in this manual.
The contents of this manual and specifications of this
product are subject to change without notice.
For additional product information and updates, visit
our website at www.babylock.com
SAVE THESE
INSTRUCTIONS
This machine is intended
for household use.
FOR USERS IN COUNTRIES EXCEPT
EUROPEAN COUNTRIES
This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to
ensure that they do not play with the
appliance.
FOR USERS IN EUROPEAN
COUNTRIES
This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.

3
FOR USERS IN THE UK,
EIRE, MALTA AND
CYPRUS ONLY
IMPORTANT
• In the event of replacing the plug fuse, use a fuse
approved by ASTA to BS 1362, i.e. carrying the
mark, rating as marked on plug.
• Always replace the fuse cover. Never use plugs with
the fuse cover omitted.
• If the available electrical outlet is not suitable for the
plug supplied with this equipment, you should
contact your authorized Baby Lock retailer to obtain
the correct lead.
Federal Communications
Commission (FCC)
Supplier’s Declaration of
Conformity (For U.S.A.
Only)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the authorized Baby Lock retailer or an
experienced radio/TV technician for help.
• This transmitter must not be co-located or operated
in conjunction with any other antenna or
transmitter.
Important
Changes or modifications not expressly approved by
Tacony Corporation could void the user’s authority to
operate the equipment.
This equipment complies with FCC/IC radiation
exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF)
Exposure Guidelines and RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment should
be installed and operated keeping the radiator at least
20cm or more away from person's body.
Responsible Party: Tacony Corporation
1760 Gilsinn Lane, Fenton,
Missouri 63026, U.S.A.
declares that the product
Product Name:
Model Number:
Baby Lock Sewing Machine
BLTA2

4
For Users in Canada
This device complies with Industry Canada’s licence-exempt
RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
This equipment complies with FCC/IC radiation exposure
limits set forth for an uncontrolled environment and meets the
FCC radio frequency (RF) Exposure Guidelines and RSS-102
of the IC radio frequency (RF) Exposure rules. This equipment
should be installed and operated keeping the radiator at least
20cm or more away from person's body.
For Users in Mexico
The operation of this equipment is subject to the following
two conditions:
(1) it is possible that this equipment or device may not cause
harmful interference, and
(2) this equipment or device must accept any interference,
including interference that may cause undesired
operation.
Para usuarios en México
La operación de este equipo está sujeta a las siguientes dos
condiciones:
(1) es posible que este equipo o dispositivo no cause
interferencias perjudiciales y
(2) este equipo o dispositivo debe aceptar cualquier
interferencia, incluyendo la que pueda causar su
operación no deseada.
Laser Notices (For U.S.A.
only)
Laser Safety
This sewing machine is certified as a Class 1 laser product
under the U.S. Department of Health and Human Services
(DHHS) Radiation Performance Standard according to the
Radiation Control for Health and Safety Act of 1968. This
means that the sewing machine does not produce hazardous
laser radiation.
IEC 60825-1 Specification
This machine is a Class 1 laser product as defined in IEC
60825-1:2007 and IEC 60825-1:2014 specifications.
The laser beam emitted by the laser unit installed in this
machine is restricted to an output at a safe level. However, the
machine contains 6-milliwatt, 630-640 nanometer
wavelength, 6-12 degree at parallel divergence angle, 28-40
degree at perpendicular divergence angle, InGaAlP laser
diodes. Therefore, eye damage may result from disassembling
or altering this machine.
Safety precautions have been designed to prevent any
possible laser beam exposure to the operator.
FDA Regulations
U.S. Food and Drug Administration (FDA) has implemented
regulations for laser products manufactured on and after
August 2, 1976. Compliance is mandatory for products
marketed in the United States. The label shown on the back of
the sewing machine indicates compliance with the FDA
regulations and must be attached to laser products marketed
in the United States.
Tacony Corporation
1760 Gilsinn Lane, Fenton, Missouri 63026, U.S.A.
This product complies with FDA performance standards
for laser products except for conformance with IEC
60825-1 Ed. 3., as described in Laser Notice No. 56,
dated May 8, 2019.
CAUTION
• Use of controls, adjustments or the
performance of procedures other than those
specified in this manual may result in
hazardous radiation exposure.

5
Laser Notices (For
countries except U.S.A.)
IEC 60825-1 Specification
This machine is a Class 1 laser product as defined in IEC
60825-1:2007 and IEC 60825-1:2014 specifications.
The laser beam emitted by the laser unit installed in this
machine is restricted to an output at a safe level. However, the
machine contains 6-milliwatt, 630-640 nanometer
wavelength, 6-12 degree at parallel divergence angle, 28-40
degree at perpendicular divergence angle, InGaAlP laser
diodes. Therefore, eye damage may result from disassembling
or altering this machine.
Safety precautions have been designed to prevent any
possible laser beam exposure to the operator.
WPA™ and WPA2™ are trademarks of Wi-Fi Alliance®.
Any trade names and product names of companies appearing on
Baby Lock products, related documents and any other materials are
all trademarks or registered trademarks of those respective
companies.
This product includes software developed by the following
vendor: ©2008 Devicescape Software, Inc.
CAUTION
• This sewing machine has a Class 3B Laser
Diode in the Laser Unit. The Laser Unit should
not be opened under any circumstances.
• Use of controls, adjustments or the
performance of procedures other than those
specified in this manual may result in
hazardous radiation exposure.
TRADEMARKS
IMPORTANT:
READ BEFORE DOWNLOADING, COPYING,
INSTALLING OR USING.
By downloading, copying, installing or using the
software you agree to this license. If you do not
agree to this license, do not download, install,
copy or use the software.
Intel License Agreement For Open
Source Computer Vision Library
Copyright © 2000, Intel Corporation, all rights reserved. Third party
copyrights are property of their respective owners.
Redistribution and use in source and binary forms,
with or without modification, are permitted provided
that the following conditions are met:
• Redistribution’s of source code must retain the
above copyright notice, this list of conditions and
the following disclaimer.
• Redistribution’s in binary form must reproduce the
above copyright notice, this list of conditions and
the following disclaimer in the documentation and/
or other materials provided with the distribution.
• The name of Intel Corporation may not be used to
endorse or promote products derived from this
software without specific prior written permission.
This software is provided by the copyright holders and
contributors “as is” and any express or implied
warranties, including, but not limited to, the implied
warranties of merchantability and fitness for a
particular purpose are disclaimed. In no event shall
Intel or contributors be liable for any direct, indirect,
incidental, special, exemplary, or consequential
damages (including, but not limited to, procurement of
substitute goods or services; loss of use, data, or profits;
or business interruption) however caused and on any
theory of liability, whether in contract, strict liability,
or tort (including negligence or otherwise) arising in
any way out of the use of this software, even if advised
of the possibility of such damage.
All information provided related to future Intel products and plans is
preliminary and subject to change at any time, without notice.
COPYRIGHT AND LICENSE

6
Make sure you use a router or firewall when connecting
your machine to the Internet to protect it against
unauthorized access from the Internet.
PRECAUTION FOR WIRELESS
CONNECTION

CONTENTS
7
1
2
3
4
5
6
7
Chapter 1 GETTING READY 9
NAMES OF MACHINE PARTS................................ 9
INCLUDED ACCESSORIES ................................. 11
Included Accessories ........................................................... 11
Options................................................................................ 15
Using the Multi-Purpose Screwdriver ................................... 17
Using the Spool Stand.......................................................... 17
TURNING THE MACHINE ON/OFF .................. 19
LCD SCREEN ...................................................... 21
Using the Machine Settings Key ........................................... 25
Using the Machine Help ...................................................... 29
Using the Stitch Pattern Explanation Function ...................... 31
WIRELESS NETWORK CONNECTION FUNCTIONS ... 31
Operations Available with a Wireless Network Connection ... 31
Enabling a Wireless Network Connection ............................ 32
Using the Wizard to Set Up the Wireless Network Connection ... 32
CONNECTING THE ACCESSORY TO THE
MACHINE .......................................................... 34
Using a USB Mouse ............................................................. 34
WINDING/INSTALLING THE BOBBIN.............. 35
Winding the Bobbin............................................................. 35
Setting the Bobbin................................................................ 39
Pulling Up the Bobbin Thread.............................................. 40
UPPER THREADING .......................................... 41
Upper Threading.................................................................. 41
Using the Twin Needle Mode .............................................. 43
Using the Spool Stand.......................................................... 45
CHANGING THE NEEDLE.................................. 46
FABRIC/THREAD/NEEDLE COMBINATIONS .... 48
CHANGING THE PRESSER FOOT ...................... 49
Replacing the Presser Foot ................................................... 49
Attaching the Presser Foot with the Included Adapter .......... 49
Using the Compact Digital Dual Feed Foot .......................... 50
Chapter 2 SEWING BASICS 53
SEWING ............................................................. 53
Stitch Types ......................................................................... 53
Basic Sewing........................................................................ 53
Using Advanced Multi-Function Foot Controller .................. 55
Combining Stitch Patterns .................................................... 57
Sewing Reverse Stitches/Reinforcement Stitches................... 59
Automatic Reverse/Reinforcement Stitching ......................... 59
Automatic Presser Foot Lowering Function and Thread Cutting
Function .............................................................................. 61
STITCH SETTINGS.............................................. 61
Setting the Stitch Width/Stitch Length/“L/R Shift”.................. 61
Setting the Thread Tension................................................... 62
Saving Your Stitch Settings ................................................... 63
USEFUL FUNCTIONS......................................... 64
Automatic Thread Cutting .................................................... 64
Adjusting the Needle Drop Point with the Guideline Marker ... 64
Pivoting ............................................................................... 65
Using the Knee Lifter............................................................ 66
Automatic Fabric Sensor System (Automatic Presser Foot
Pressure) .............................................................................. 66
Needle Position - Stitch Placement ...................................... 66
Using the Straight Stitch Needle Plate and the Straight Stitch Foot ... 67
USEFUL SEWING TIPS ....................................... 68
Sewing Tips ......................................................................... 68
Sewing Various Fabrics ........................................................ 69
Sewing Decorative Stitch Patterns ........................................ 70
Chapter 3 VARIOUS STITCHES 71
UTILITY STITCHES ............................................. 71
Straight Stitches.................................................................... 71
Zigzag Stitches..................................................................... 75
Overcasting.......................................................................... 76
Quilting................................................................................ 77
Blind Hem Stitches............................................................... 83
Shell Tuck Stitches ............................................................... 85
Scallop Stitches .................................................................... 85
Smocking Stitches ................................................................ 85
Fagoting ............................................................................... 86
Attaching Tape or Elastic ...................................................... 86
Heirloom.............................................................................. 87
One-Step Buttonholes .......................................................... 88
Four-Step Buttonholes .......................................................... 90
Bar Tacks ............................................................................. 92
Button Sewing ...................................................................... 93
Eyelet ................................................................................... 94
Multi-directional Sewing (Straight Stitch and Zigzag Stitch) ... 95
Zipper Insertion.................................................................... 95
Changing the Start and End Angles of the Stitch Pattern (Stitch
Tapering Function) ............................................................... 97
MAKING ADJUSTMENTS ................................ 100
MAKING STEP STITCH PATTERNS (FOR 7MM
SATIN STITCH PATTERNS ONLY) ................... 101
USING THE MEMORY FUNCTION ................. 102
Saving Stitch Patterns ......................................................... 102
Retrieving Stitch Patterns .................................................... 102
Chapter 4 BASIC EMBROIDERY 105
BEFORE EMBROIDERING................................ 105
Embroidery Step by Step..................................................... 105
Attaching Embroidery Foot “W+” with LED Pointer ............ 105
About the Embroidery Unit................................................. 106
SELECTING PATTERNS .................................... 107
Selecting Embroidery Patterns ............................................ 108
Selecting Character Patterns ............................................... 109
Selecting Frame Patterns..................................................... 111
Combining Patterns ............................................................ 111
EDITING PATTERNS ........................................ 113
Previewing the Pattern........................................................ 115
Changing the Size and the Density of the Pattern ............... 116
Creating Repeated Patterns................................................. 116
Embroidering the Pattern Repeatedly.................................. 120
Deselect Region Setting (No Sew Setting) ........................... 121
EDITING COLORS........................................... 122
Changing the Thread Color ................................................ 122
Finding New Color Schemes with the Color Visualizer Function ... 123
Thread Color Sorting .......................................................... 125
VIEWING THE EMBROIDERY SCREEN............ 126
PREPARING THE FABRIC ................................ 128
Attaching Iron-on Stabilizers (Backing) to the Fabric........... 128
Hooping the Fabric in the Embroidery Frame ..................... 129
ATTACHING THE EMBROIDERY FRAME ........ 131
CONFIRMING THE PATTERN POSITION ....... 132
Checking the Needle Drop Point with the Embroidery Foot “W+”
with LED Pointer ................................................................ 132
Displaying a Background Image ......................................... 133
Checking the Pattern Position............................................. 134
THE 2-POINT EMBROIDERY POSITIONING
FUNCTION...................................................... 135
EMBROIDERING A PATTERN.......................... 139
Embroidering Attractive Finishes ........................................ 139
Embroidering Patterns ........................................................ 140
Using Appliqués................................................................. 141
ADJUSTMENTS DURING THE EMBROIDERY
PROCESS ........................................................... 143
If the Thread Breaks or the Bobbin Runs out of Thread During
Embroidering...................................................................... 143
Resuming Embroidery after Turning off the Power .............. 144
CONTENTS

CONTENTS
8
Chapter 5 ADVANCED EMBROIDERY 145
VARIOUS EMBROIDERING FUNCTIONS........ 145
Basting Embroidery ............................................................ 145
Creating an Appliqué Piece ................................................ 146
MAKING EMBROIDERY ADJUSTMENTS ......... 149
Adjusting Thread Tension................................................... 149
Adjusting the Alternate Bobbin Case (with No Color on the
Screw) ................................................................................ 150
Using the Automatic Thread Cutting Function
(End Color Trim)................................................................. 151
Using the Thread Trimming Function (Jump Stitch Trim) .... 152
Adjusting the Embroidery Speed......................................... 152
Changing the Thread Color Display.................................... 153
Aligning the Pattern and the Needle................................... 153
Embroidering Linked Characters......................................... 154
USING THE MEMORY FUNCTION.................. 155
Saving Embroidery Patterns ................................................ 155
Retrieving Embroidery Patterns........................................... 156
EMBROIDERY APPLICATIONS......................... 157
Using a Frame Pattern To Make an Appliqué...................... 157
Embroidering Couching Patterns ........................................ 158
Creating Stippling, Echo Quilting, or Decorative Fill Patterns
around a Design................................................................. 161
Embroidering Split Embroidery Patterns.............................. 162
Chapter 6 IQ DESIGNER 163
ABOUT IQ DESIGNER ..................................... 163
PATTERN DRAWING SCREEN ......................... 163
Before Creating Designs ..................................................... 165
Drawing Lines .................................................................... 165
Drawing Regions................................................................ 166
Using the Stamp Key .......................................................... 167
Using the Erase Key............................................................ 168
Using the Select Key........................................................... 168
STITCH SETTINGS SCREEN.............................. 169
Specifying Individual Stitch Settings ................................... 169
Specifying Global Stitch Settings ........................................ 170
Loading the Background Image .......................................... 171
LINE CONVERSION ......................................... 172
Create a Pattern with Line Conversion................................ 172
ILLUSTRATION CONVERSION........................ 174
Create a Pattern with Illustration Conversion ...................... 174
STIPPLING........................................................ 176
Basic Stippling with IQ Designer ........................................ 176
Decorative Stitching around a Pattern in Embroidery
(a Quilting Function) .......................................................... 178
IQ INTUITION- MONITORING APP ............... 180
IQ INTUITION- POSITIONING APP................ 181
Chapter 7 APPENDIX 183
CARE AND MAINTENANCE............................. 183
Cleaning the LCD............................................................... 183
Cleaning the machine surface ............................................ 183
Restrictions on Oiling......................................................... 183
Precautions on Storing the Machine ................................... 183
Cleaning the Race ............................................................. 183
Cleaning the Bobbin Case .................................................. 184
Cleaning the Cutter in the Bobbin Case Area...................... 185
BEFORE LENDING OR DISPOSING OF THE
PRODUCT ........................................................ 185
ADJUSTING THE SCREEN................................ 186
Touch Panel is Malfunctioning ........................................... 186
TROUBLESHOOTING ...................................... 186
Frequent Troubleshooting Topics ....................................... 186
Upper Thread is Too Tight.................................................. 186
Tangled Thread on Wrong Side of Fabric ........................... 187
Incorrect Thread Tension.................................................... 187
Fabric is Caught in the Machine and Cannot Be Removed ... 188
If the Thread Becomes Tangled Under the Bobbin
Winder Seat ....................................................................... 189
List of Symptoms................................................................ 190
ERROR MESSAGES........................................... 194
SPECIFICATIONS............................................. 196
UPDATING YOUR MACHINE’S SOFTWARE... 198
Update Procedure Using USB Media ................................. 198
Update Procedure Using Wireless LAN Connection .......... 198
STITCH SETTING CHART ................................ 199
INDEX.............................................................. 206

NAMES OF MACHINE PARTS
GETTING READY
9
1
Main Parts
1Top cover
2Pretension disk (page 36)
3Thread guide for bobbin winding (page 36)
4Spool pin (page 41)
5Spool cap (page 35)
6Supplemental spool pin (page 35)
7Bobbin winder (page 35)
8LCD (liquid crystal display) (page 21)
9Speaker
0Knee lifter (page 66)
AKnee lifter slot (page 66)
BOperation buttons and sewing speed controller
(page 10)
CFlat bed attachment with accessory compartment
(page 11)
DThread cutter (page 42)
EThread guide plate (page 38)
FConnector for the presser foot (page 51, page 106)
GHandle
Carry the machine by its handle when transporting the
machine.
HPresser foot lever
You cannot use the presser foot lever after the presser foot has
been raised using (Presser foot lifter button).
IAir vent
The air vent allows the air surrounding the motor to circulate.
Do not cover the air vent while the machine is being used.
JMain power switch (page 19)
KFoot controller (page 55)
LPower cord receptacle (page 19)
MFoot controller jack (page 55)
NUSB port for mouse (page 34)
OUSB port
PHandwheel
Turn the handwheel toward you (counterclockwise) to raise and
lower the needle.
Needle and Presser Foot Section
1Buttonhole lever (page 89)
2Presser foot holder screw (page 49, page 105)
3Presser foot holder (page 49)
4Presser foot locking pin (page 69)
5Presser foot
The presser foot consistently applies pressure to the fabric as
sewing takes place. Attach the appropriate presser foot for the
selected stitch.
6Feed dogs
The feed dogs feed the fabric in the sewing direction.
7Bobbin cover (page 39)
8Needle plate (page 72)
9Needle bar thread guide (page 42)
0Needle clamp screw (page 47)
Chapter 1GETTING READY
Note
• Be sure to install the latest software.
Refer to “UPDATING YOUR MACHINE’S
SOFTWARE” on page 198.
NAMES OF MACHINE PARTS
a
bcdef
g
h
i
j
k
l
m
n
o
p
q
r
s
t
u
v
w
x
y
a
b
c
d
e
f
g
h
i
j

NAMES OF MACHINE PARTS
10
Measurements on the needle plate and the bobbin cover
(with mark)
The measurements on the bobbin cover and needle plate are
references for stitch patterns with a left or middle (center)
needle position.
1For stitches with a middle (center) needle position
2For stitches with a left needle position
3Left needle position on the needle plate <inch>
4Left needle position on the needle plate <cm>
5Middle (center) needle position on the bobbin cover
(with mark) <inch>
6Middle (center) needle position on the needle plate
Embroidery unit
1Carriage
The carriage moves the embroidery frame automatically when
embroidering.
2Release lever (located under the embroidery unit)
Press the release lever to remove the embroidery unit.
3Embroidery frame holder
Insert the embroidery frame into the embroidery frame holder
to hold the frame in place.
4Frame-securing lever
Press the frame-securing lever down to secure the embroidery
frame.
5Embroidery unit connection
Insert the embroidery unit connection into the connection port
when attaching the embroidery unit.
Operation Buttons
1“Start/Stop” button
Press the “Start/Stop” button to start or stop sewing. The
button changes color according to the machine’s operation
mode.
2Reverse stitch button
Press the reverse button to sew reverse or reinforcement
stitches depending on the selected stitch pattern. (page 59)
3Reinforcement stitch button
Press the reinforcement button to sew a single stitch
repeatedly and tie-off. (page 59)
For character/decorative stitches, press this button to end with
a full stitch instead of at a mid-point.
The LED beside the button automatically lights up while the
stitch is being sewn and goes off when sewing is finished.
4Needle position button
Press the needle position button to raise or lower the needle
position. Pressing the button twice sews a single stitch.
5Thread cutter button
Press the thread cutter button after sewing to automatically
trim the excess thread.
6Presser foot lifter button
Press the presser foot lifter button to lower the presser foot and
apply pressure to the fabric. Press this button again to raise the
presser foot.
7Sewing Speed controller
Use the sewing speed controller to adjust the sewing speed.
Move the slide to the left to sew at slower speeds. Move the
slide to the right to sew at higher speeds.
8Automatic threading button
Use the automatic threading button to automatically thread the
needle.
a
e
dc
b
Green: The machine is ready or is operating.
Red: The machine is not ready.

INCLUDED ACCESSORIES
GETTING READY
11
1
Using the Flat Bed Attachment
Pull the top of the flat bed attachment to open the
accessory compartment.
1Presser foot storage tray
2Presser foot storage space of the flat bed attachment
Using the Accessory Case
Opening the accessory case
Fully slide the bar on each side of the accessory case to
the unlocked position, and then lift off the lid to open the
case.
The case can only be opened or locked correctly if both
bars are slid in the same direction.
1Bars
Closing the accessory case
aFully slide the bar on each side of the accessory case
lid to the unlocked position.
bPlace the lid on top of the case so that the notches in
the lid align with the tabs on the case, and then slide
the bar on each side back to the locked position.
Included Accessories
After opening the box, check that the following accessories
are included. If any item is missing or damaged, contact your
authorized Baby Lock retailer.
INCLUDED ACCESSORIES
a
b
a
Part Name
Part Code
1.
Zigzag foot “J” (on machine)
XF3022-001
2.
Advanced monogramming foot “N+”
BLSA-MF
3.
Overcasting foot “G”
XC3098-051
4.
Zipper foot “I”
X59370-051
5.
Buttonhole foot “A”
X57789-351
6.
Blind stitch foot “R”
X56409-051
7.
Button fitting foot “M”
130489-001
J
N+
G
I
A
R
M

INCLUDED ACCESSORIES
12
8.
Compact digital dual feed foot
BLSA-DDF
9. Regular sole for digital dual feed foot (on
compact digital dual feed foot)
XF4419-101
10.
Straight stitch foot
XD0826-051
11.
Free motion open toe quilting foot “O”
XF4873-001
12.
Free motion quilting foot “C”
XF4737-001
13. Free motion echo quilting foot “E”
* Attach the included adapter (reference item
#19) to use this product.
XE0766-001
14.
Embroidery foot “W+” with LED pointer
BLTY-EF
15.
1/4 Quilting foot with guide
XC6800-251
16.
Embroidery couching foot “Y”
XH1815-101
Part Name
Part Code
O
O
C
E
E
W+
Y
17.
Yarn guide for embroidery couching
XH3803-001
18.
Yarn threader
XF7187-001
19.
Adapter
XF3613-001
20.
Screw (small)
XA4813-051
21. Needle set
75/11 2 needles
90/14 2 needles
90/14 2 needles: Ball point needle (gold
colored)
XE4962-001
22. Twin needle
2/11 needle
XE4963-001
23. Ball point needle set
75/11 2 needles:
Ball point needle for embroidery
XD0705-151
24.
Bobbin × 10 (One bobbin is in machine.)
X52800-120
25.
Seam ripper
XF4967-001
26.
Scissors
XF2052-001
Part Name
Part Code

INCLUDED ACCESSORIES
GETTING READY
13
1
27.
Cleaning brush
X59476-051
28.
Eyelet punch
XG7791-001
29.
Screwdriver (small)
X55468-051
30.
Screwdriver (large)
XC4237-021
31.
Disc-shaped screwdriver
XC1074-051
32.
Multi-purpose screwdriver
BLMPD2
33.
Spool cap (small)
130013-157
34. Spool cap (medium) × 2 (One spool cap is on
machine.)
X55260-156
35.
Spool cap (large)
130012-027
36.
Thread spool insert (mini king thread spool)
XA5752-121
Part Name
Part Code
37.
Spool felt (on machine)
X57045-051
38.
Spool net × 2
XA5523-050
39.
Embroidery needle plate cover
XE5131-001
40.
Touch pen (stylus)
XA9940-051
41.
Knee lifter
XA6941-052
42. Advanced multi-function foot controller
- Main foot controller
- Side pedal
- Mounting plate
- Mounting screw × 2
BLSA3-AMFC
43. Standard bobbin case (green marking on the
screw) (on machine)
XE5342-101
44.
Alternate bobbin case (no color on the screw)
XC8167-651
45.
Straight stitch needle plate
D02LH8-001
46.
Cord guide bobbin cover
XE5992-001
Part Name
Part Code

INCLUDED ACCESSORIES
14
47.
Bobbin cover (with mark) (on machine)
D02T27-001
48.
Bobbin cover (on straight stitch needle plate)
D02T26-001
49. Embroidery frame with decal set
36 cm (H) × 24 cm (W)
(approx. 14 inches (H) × 9-1/2 inches (W))
EF95S: Frame
EF96: Embroidery sheet
50. Embroidery frame with decal set
24 cm (H) × 24 cm (W)
(approx. 9-1/2 inches (H) × 9-1/2 inches (W))
EF97S: Frame
EF98: Embroidery sheet
51. Embroidery frame with decal set
18 cm (H) × 13 cm (W)
(approx. 7 inches (H) × 5 inches (W))
EF75S: Frame
EF79: Embroidery sheet
52. Embroidery frame with decal set
10 cm (H) × 10 cm (W)
(approx. 4 inches (H) × 4 inches (W))
EF74S: Frame
EF78: Embroidery sheet
53.
Embroidery positioning sticker sheets × 4
XE4912-501
54.
Lens calibration sheet
XH4336-001
55.
Embroidery bobbin thread (#60, white)
BBT-W
56.
Stabilizer material
X81176-001
Part Name
Part Code
57.
Chalk pencil
XE8568-001
58.
Bobbin center pin and instruction sheet
XF5048-001
59.
Accessory case
D02RM5-001
60.
Soft cover
XG0717-001
61.
Power cord
XC6052-121
62.*Telescopic thread guide
XE0776-001
63.*Spool support
XE4958-101
64.*Spool pin × 2
XA6313-051
65.*Screw and washer
XC7568-051
Part Name
Part Code

INCLUDED ACCESSORIES
GETTING READY
15
1
* For the spool stand
Options
The following are available as optional accessories to be
purchased separately from your authorized Baby Lock retailer.
* These embroidery frames can be used for general
embroidery but cannot be used with the application (IQ
Intuition).
66.*Spool cap (XL) × 2
XE0779-001
67.*Spool holder × 2
XA0679-050
68.*Spool cap base × 2
XE0780-001
69.*Spool felt × 2
XC7134-051
70.*Ring × 4
026030-136
71.
Instruction and Reference Guide
D02M47-001
72.
Quick Reference Guide
D02M4E-001
Memo
• (For U.S.A. only)
Foot controller: Model X
This foot controller can be used on the machine
with product code 882-W74. The product code is
mentioned on the machine rating plate.
• Please visit www.babylock.com to download the
Embroidery Design Guide.
Part Name
Part Code
Part Name
Part Code
1.*Embroidery frame set
30 cm (H) × 20 cm (W)
(approx. 12 inches (H) × 8 inches (W))
EF92: Frame
EF94: Embroidery sheet
2.*Embroidery frame set
20 cm (H) × 20 cm (W)
(approx. 8 inches (H) × 8 inches (W))
EF91: Frame
EF93: Embroidery sheet
3.*Embroidery frame set
15 cm (H) × 15 cm (W)
(approx. 6 inches (H) × 6 inches (W))
BLMA-150
4.*Embroidery frame set
2 cm (H) × 6 cm (W)
(approx. 1 inch (H) × 2-1/2 inches (W))
EF73: Frame
EF77: Embroidery sheet
5.*Border embroidery frame
30 cm (H) × 10 cm (W)
(approx. 12 inches (H) × 4 inches (W))
BLMA-CBH
6. Magnetic frame
300 mm (H) × 180 mm (W)
(approx. 12 inches (H) × 7 inches (W))
EMF300
7. Magnetic frame 18 cm (H) × 13 cm (W)
(approx. 7 inches (H) × 5 inches (W))
EMF180
8.
Magnifying lens
BLMA-ML
9.
10 spool stand
BLMA-TS

INCLUDED ACCESSORIES
16
10.
Extension table
BLMA-ET
11.
Embroidery bobbin thread (#60, black)
BBT-B
12.
Embroidery foot “W”
XF4012-101
13.
Seam guide
BLG-SG
14.
Walking foot
BLG-WF
15. Dynamic walking foot set
* Includes standard and open toe soles.
BLSA-WF
16. Interchangeable sole set for Dynamic walking
foot
* Includes 1/4-inch sole, stitch-in-the-ditch
sole, and quilting guide.
BLSA-WFS
17.
Quilting guide
BLG-QG
18.
Side cutter foot
BLG-SCF
Part Name
Part Code
W
19.
Free-motion quilting foot
BLG-FM
20.
Circular sewing attachment
BL-CSA
21.
Edge Joining foot
ESG-EJF
22.
Open toe sole for dual feed foot
BLTY-OTDF
23.
Stitch in the ditch sole for dual feed foot
BLDY-SDDF
24.
1/4" Sole with guide for dual feed foot
BLDY-QFDF
25.
Couching foot
BLTY-CCF
Memo
• To obtain optional accessories or parts, contact
your authorized Baby Lock retailer or visit our site
www.babylock.com.
• All specifications are correct at the time of printing.
Please be aware that some specifications may
change without notice.
• A variety of feet are available to enable different
types of stitching and finishes. Visit your nearest
authorized Baby Lock retailer or our site
www.babylock.com for a complete listing of
optional accessories available for your machine.
• Always use accessories recommended for this
machine.
Part Name
Part Code

INCLUDED ACCESSORIES
GETTING READY
17
1
Using the Multi-Purpose Screwdriver
Since the screwdriver can be changed to three different
positions, it can be extremely useful for the various machine
preparations. With this machine, position “1” and position
“3” are used.
Using the Spool Stand
The included spool stand is useful when using thread spools
with a large diameter (cross-wound thread). The spool stand
can hold two spools of thread.
How to Assemble the Spool Stand
aFully extend the telescopic thread guide shaft, and then
rotate the shaft until the two internal stoppers click
into place.
bInsert the telescopic thread guide into the round hole
at the center of the spool support, and then use a
screwdriver to securely tighten the screw from the
reverse side.
1Screw
Position “1” You can install/remove the presser foot holder,
needle clamp screw or needle plate.
Position “3” The multi-purpose screwdriver can be
positioned over the screw on the embroidery
frame to tighten the screw after hooping the
fabric or when removing the fabric.
123
456
789
No. Part Name
1 Telescopic thread guide
2 Spool support
3 Spool pin × 2
4 Screw and washer
5 Spool cap (XL) × 2
6Spoolholder×2
7 Spool cap base × 2
8Spoolfelt×2
9Ring×4
IMPORTANT
• Do not lift the handle of the machine while the
spool stand is installed.
• Do not push or pull the telescopic thread
guide or spool pins with extreme force,
otherwise damage may result.
• Do not place any object other than spools of
thread on the spool support.
• Do not try to wind thread on the bobbin while
sewing using the spool stand.
Note
• Make sure that the stoppers on the telescopic
thread guide shaft are firmly in place and that the
thread guide openings are directly above the two
holes for spool pins in the spool support. In
addition, check that the shaft is securely tightened
in the spool support.

INCLUDED ACCESSORIES
18
cFirmly insert the two spool pins into the two holes in
the spool support.
dOpen the upper cover of the machine, and then pull
the upper cover up to remove it from the machine.
eInsert the spool stand onto the notches of the machine.
How To Remove
aPull the spool stand up to remove it from the machine.
bAttach the upper cover to the machine.
