Bally High Profile Unit Cooler Operation manual

High Profile
Unit Cooler
High & Medium
Temperature
Air Defrost
BulletinB30-BHPA-PDI-50
1081587-50-1
PRODUCT DATA &
INSTALLATION
CONTENTS Page
Nomenclature........................................................................................................................ 2
Features&Options..............................................................................................................2
CapacityData...................................................................................................................... 3
ElectricalData...................................................................................................................... 3
WiringDiagram................................................................................................................... 4
DimensionalData................................................................................................................ 5, 6
Specifications....................................................................................................................... 6
InstallationInstructions......................................................................................................... 7, 8
ServicePartsList................................................................................................................. 9
Warranty................................................................................................................................ 11
ProjectInformation................................................................................................................ 11
“AsBuilt”ServicePartsList................................................................................................ BACK
Electrical Power:
200-220/3/50, 380-400/3/50
®

- 2 -
STANDARD FEATURES
OPTIONAL FEATURES
•Heavy gauge textured aluminum cabinet
with galvanized steel hangers, support channels
and end plates
•Hinged access panels with removable hinge
pins and captive fasteners.
•Hinged drain pan with removable hinge pins
•Rugged heavy-gauge galvanized steel rail
motor mount / support.
•Stackable design
•Schrader fitting and external equalizer line.
•Factory installed solenoid valve wire harness
•Unit shipped upright for convenient handling
and quick installation.
•Factory mounted TX valve, solenoid valve
and thermostat
•Throw boosters
•Insulateddrain pan
•TEFC motors
•Optional fin spacing
•Optional fin materials
•Optional coil coating
BHP 216 LE- T5 A- SB
NOMENCLATURE
B = Bally
Application Range
H = Hi / Medium Temp 7 FPI (0°F to 35°F Evap Temp)
M = Medium Temp 6 FPI (0°F to 35°F Evap Temp)
P = Medium Temp 4 FPI (0°F to 35°F Evap Temp)
L = Low Temp 6 FPI (-5°F to -40°F Evap Temp)
V = Low Temp 4 FPI (-5°F to -40°F Evap Temp)
Nominal Capacity x 1000
(standard motor/fan blade) @ 10°F TD
High Profile Unit Cooler
Defrost
A = Air
E = Electric
T = 3 Pipe Hot Gas w/ Heater
G = Reverse Cycle Hot Gas w/ Heater
H = 3 Pipe Hot gas w/ Loop
R = Reverse Cycle Hot Gas w/ Loop
Motor Option:
S = Standard
T=TEFC
V = High Velocity†
† Not available on above
+15°F Evap. Temp. models
Throw Boosters:
N = None
B = Booster
Generation
A = 1st
Voltage:
T3 = 208-230/3/60
T4 = 460/3/60
T5 = 575/3/60
T7 = 200-220/3/50
T9 = 380-400/3/50

- 3 -
CAPACITY DATA 50Hz
High and Medium Temperature Models - Capacity @ 7 F.P.I.
Average Air Throw - ft (m)†
* Estimated, based on R404Aat +25° S.S.T. with coil 30% full.
Derate capacity by 0.92 and CFM by .85 for Throw Booster Option.
ELECTRICAL DATA
NOTE: 3+ indicates 3-fan “long” configuration (see dimen-
sional data for details)
†Measured in open space.Actual throw may be less in real
applications.
sledoM.pmeTmuideM/hgiHAH370AH680AH311AH031AH451AH071AH981AH332AH252AH872
yticapaC .D.TF°1@HUTB ).D.TC°55.0@STTAW( 0
276 )8691( 0197 )7132( 00401 )6403( 06911 )3053( 07141 )0514( 04651 )1854( 09371 )4905( 04412 )0826( 08132 )9876( 08552 )2947(
yticapaC .D.TF°01@HUTB ).D.TC°55.5@STTAW( 00276 )38691( 00197 )86132( 000401 )26403( 006911 )13053( 007141 )40514( 004651 )01854( 009371 )53905( 004412 )89726( 008132 )49876( 008552 )42947(
yticapaC .D.TF°51@HUTB ).D.TC°3
3.8@STTAW( 008001 )42592( 056811 )35743( 000651 )29654( 004971 )64525( 055212 )65226( 006432 )41786( 058062 )30467( 006123 )79149( 007743 )148101( 007383 )683211(
wolFriAMFC ()S/L 00631 )8146( 00621 )6495( 00921 )8806( 00981 )9198( 00
502 )4769( 00591 )2029( 00112 )7599( 00592 )12931( 00182 )06231( 00752 )82121(
*egrahCtnaregirfeR.BL )GK( 02 )9( 72 )21
(04 )81( 04 )81( 05 )32( 06 )72( 88 )04( 89 )54( 811 )45( 751 )17(
NAFDRADNATS ROTOMDNA LANOITPO RETSOOBWORHT
09 )72( 521 )83(
05/3/022-002
LEDOM NAF ROTOM YTQ PH ROTOM ALF LATOT
.CRIC.NIM YTICAPMA )A( .XAM ESUF )SPMA(
A7T-AH370PHB 21 6.98.0151
A7T-A
H680PHB 21 6.98.0151
A7T-AH311PHB 25.18.113.3151
A7T-AH031PHB 31 4.416.5102
A7T-AH451PHB 35.17.712.9152
A7T-AH071PHB 35.17.712.9152
A
7T-AH981PHB +35.17.712.9152
A7T-AH332PHB 45.16.321.5203
A7T-AH252PHB 45.16.321.5203
A7T-AH872PHB 45.16.321.5203
05/3/004-083
LEDOM NAF ROTOM YTQ PH ROTOM ALF LATOT
.CRIC.NIM YTICAPMA )A( .XAM ESUF )SPMA(
A9T-AH370PHB 21 2.47.451
A9T-AH
680PHB 21 2.47.451
A9T-AH311PHB 25.15 6.551
A9T-AH031PHB 31 3.68.651
A9T-AH451PHB 35.15.71.851
A9T-AH071PHB 35.15.71.851
A9T-AH981PHB +
35.15.71.851
A9T-AH332PHB 45.1016.0151
A9T-AH252PHB 45.1016.0151
A9T-AH872PHB 45.1016.0151

- 4 -
WIRING DIAGRAM

- 5 -
DIMENSIONAL DATA
2 Fan Models
3 Fan Models
Drainconnections1-1/4”FPT.

- 6 -
SPECIFICATIONS
DIMENSIONAL DATA
3 Fan (Long) Models
4 Fan Models
Drainconnections1-1/4”FPT.
sledoM.pmeTmuideM/hgiHAH370AH680AH311AH031AH451AH071AH981AH332AH252AH872
snaFfOrebmuN 222 3333 4 44
.nnoCrotubirtsiD )taewSDO( sehcnI )mm( 8/1-1 )92( 8/3-1 )53( 8/3-1 )53( 8/3-1 )53( 8/3-1 )53( 8/5-1 )14( 8/3-1 )53( 8/3-1 )53( 8/3-1 )53( 8/5-1 )14(
.n
noCnoitcuS )taewSDO( sehcnI )mm( 8/5-1 )14( 8/5-1 )14( 8/1-2 )45( 8/1-2 )45( 8/1-2 )45( 8/1-2 )45( 8/5-2 )76( 8/5-2 )76( 8/5-2 )76( 8/5-2 )76(
teN.xorppA thgieW .BL )GK( 076 )813( 247 )733( 738 )973( 1701 )584( 5411 )915( 8021 )845( 3921 )685( 0951 )127( 6961 )077( 9191 )078(

- 7 -
INSTALLATION INSTRUCTIONS
MOUNTING
Thisevaporatoris suppliedwithshipping legsto allow
units to be shipped in an upright position. Units can be
lifted into place with shipping skid attached to mounting
legs.
Hanger brackets take up to 5/8” (15.9 mm) hanger rods.
Aftertheevaporator ishung in place,remove thebolts
attaching the skid to the legs.
DRAIN LINE
Iftheevaporator ismountedflush to ceiling,the stag-
geredhanger willprovide apositive pitchfordrainage.
If units are suspended below the ceiling, the installer
must provide adequate pitch to the unit by adjusting the
locationofthe hangerrodnuts.
Note: Checkforadequatedrainageby pouringwater into
thedrainpan.
Ensure that the drain pan has sufficient slope for
proper drainage (prevention of ice build up /
blockage in pan).
Insulatedcoppertube shouldbe runfromthe drain
connection, sloping at least 4” (102mm) per foot.Atrap
locatedoutsideof theroom shouldbe providedto
preventwarm airenteringthroughthetubing.Connection
shouldbemade toproperdrainage facilities thatcomply
withlocalregulations.
Ifroomtemperatures arebelowfreezing, itisnecessary
toheatthe drainlineto preventcondensate from
freezing in the drain line. Electric heating cable or
electric tape (by others) is used for this purpose. The
drainlineheater shouldbe connectedforcontinuous
operation; it is also recommended that the drain line be
insulated.Aheat output of 20 watts per lineal foot of 1”
(25mm) drain line in a 0°F (-18 °C) room is usually
satisfactory. 115 voltcable andtapeis availablefrom
yourlocal refrigerationwholesaler.Two 115voltsheaters
(by others) of the same wattage may be wired in series
for use on 230 volt system
Theinstallation andstart-upof Unit Coolersshouldonly
be performed by qualified refrigeration mechanics.
This equipment should be installed in accordance with
all applicable codes, ordinances and local by-laws
INSPECTION
Inspectallequipment beforeunpacking forvisiblesigns of
damage or loss. Check shipping list against material
receivedtoensure shipmentiscomplete.
IMPORTANT: Remember, you,theconsignee, must make
any claim necessary against the transportation company.
Shippingdamageor missingparts, whendiscoveredat
the outset, will prevent later unnecessary and costly
delays.
If damage or loss during transport is evident, make
claim to carrier, as this will be their responsibility,
not the manufacturer’s.
Shouldcartonbe damaged,butdamage toequipmentis
notobvious,a claimshouldbe filedfor“concealed dam-
age”withthe carrier.
IMPORTANT: The electrical characteristics of the unit
should be checked at this time to make sure they corre-
spondtothose orderedand to electricalpower availableat
the job site.
Saveallshipping papers,tagsand instruction sheetsfor
referenceby installerand owner.
LOCATION
The unit location in the room should be selected to ensure
uniformairdistribution throughouttheentire spacetobe
refrigerated. Be sure that the unit does not draw air in, or
blowdirectlyout, throughanopened door andthat the
product does not obstruct the free circulation of air.
Considerationshouldbe giventothe coillocationin order
to minimize the piping run length to the condensing unit
andfloor drain
CLEARANCES
Thisevaporator drawsair throughthe coilanddischarges
airfromthe fanside,and thusadequateclearance should
bemadeon the enteringface of thecoilto ensureeven
unrestrictedairflow through thecoil.This distanceshould
be equal to the height of the coil or more.
Ensure enough room is left at the ends of the coil for
servicing.

- 8 -
INSTALLATION INSTRUCTIONS (cont’d)
PIPING
Refrigerant line sizes are important and may not be the
same size as the coil connections (depends on the
lengthofrun). Ifin doubt,consult“Recommended
refrigerantlinesizes” charts.
WIRING
Wiresystemin accordancewithgoverning standards
and local codes. Enclosed typical wiring diagrams are
forreferenceonly.Referto unitdataplatefor operating
current, minimum ampacity and maximum fuse sizing
forfanmotors.
NOTE: Electrical wiring is to be sized in accordance
with minimum ampacity rating.
Foreaseof identifyingtheproper wiringterminals,unit
wiring is colour coded and terminal block connections
areidentified.Whenfan delay thermostats (combina-
tionfandelay anddefrosttermination) areinstalled,on
start-up, the fans do not operate until the coil tempera-
ture is reduced to approximately 20 °F (-6.7 °C). It is
normal for the fans to cycle a few times until the room
temperatureis broughtdown.Athigher evaporating
temperatures this control is of an adjustable type, and
properadjustmentisrequired.
The defrost termination control is adjustable and may
be set at a minimum of 40 °F (4.4 °C) (fully CW) to a
maximum of 75 °F (23.8 °C) (fully CCW). Normal setting
is 55 °F (12.8 °C). This can be increased if the defrost
heaters are terminated too soon (frost still left) or if
terminated too long (steaming of coil). Time clock
shouldbeset fora fail-safe terminationof approximately
45minutes.
A hinged end panel provides quick access to the electri-
calcompartment.
SYSTEM CHECK
Before Start-Up:
1. All wiring should be in accordance with local codes.
2. Allrefrigerantlines shouldbeproperly sized.
3. Electric defrost systems should include a liquid line
solenoidvalve.
4. Thoroughevacuationanddehydrationhasbeen
performed.
5. Thesuction, dischargeand receiverservicevalves
must be open.
6. The system should include a liquid line drier moisture
indicatorandsuction filter.
7. Pourenoughwater intothedrain pantoallow agood
check on drainage and seal the trap.
After Start-Up:
1. If necessary, temporarily by-pass fan delay control to
runfansuntil roomtempis lowered.(Runjumper wire
from terminal N to F on circuit terminal block).
2. Check the compressor oil level to ensure the correct
oilcharge.
3. Be sure that the expansion valve is properly set to
providethecorrectamountof superheat(should be
around70% ofoperatingT.D.)
4. Heavymoisture loadsareusuallyencounteredwhen
starting the system for the first time. If the coil
temperature is below freezing, this will cause a
rapid build-up of frost on the coil. During the initial pull
down,frostbuild-upshouldbe watchedand defrosted
manuallyasrequired.
5. Checkfor properevaporator fanbladerotation.
MAINTENANCE
1. Periodic checking and cleaning of the coil surface
when necessary should be done, using a whisk or
brush.Drain pansare hingedto provideconvenient
access to the inside coil surface (except hot gas loop
pans).
2. Ensure coil and pan does not have any excessive ice
build-upfrom improperdefrost operation.Any build-up
of ice can cause fins and refrigerant tubes to be
crushed.Whenreplacingheaterelements, firstremove
heaterslotcovers andheaterclips
3. Motorsarepermanently lubricatedtype andrequire
nofurther lubrication.

- 9 -
SERVICE PARTS LIST
