Barnstead|Thermolyne SET-TEMP limit User manual

SET-TEMP®limit
OPERATING INSTRUCTIONS
1
BARNSTEAD|THERMOLYNE CORPORATION
LT1153X2 • 6/24/99

Safety Information ..............................................................................................................................................3
Alert Signals..................................................................................................................................................3
Intended Use ................................................................................................................................................3
General Usage..............................................................................................................................................3
Warnings ......................................................................................................................................................3
General Specifications ........................................................................................................................................4
Environmental Conditions ............................................................................................................................4
Principles of Operation........................................................................................................................................5
Installation ..........................................................................................................................................................6
Temperature Probe Connection and Placement ................................................................................................6
Connecting your Heater and Other Temperature Controls ................................................................................6
Operation ............................................................................................................................................................7
Maintenance and Servicing ................................................................................................................................8
Replacing Fuses ..........................................................................................................................................8
General CLeaning Instructions ....................................................................................................................8
Parts List ............................................................................................................................................................9
Accessories ..................................................................................................................................................9
Replacement Parts ....................................................................................................................................10
Ordering Procedures ........................................................................................................................................11
One Year Limited Warranty ..............................................................................................................................12
2
Table of Contents

Your SET-TEMP LIMIT has been designed
with function, reliability and safety in mind. It
is your responsibility to install it in confor-
mance with local electrical codes. For safe
operation, please pay attention to the alert
signals throughout the manual.
Intended Use
Set-Temp limit control must be connected in a
series with your heater and heater control.
This product, when used in conjunction with a
heater control, can be used to regulate the
heating in heating mantles, heating tapes, hot
plates, ovens, baths and other general heat-
ing equipment.
General Usage
Do not use this product for anything other
than its intended usage.
Warnings
To avoid personal injury:
1. Refer servicing to qualified personnel.
To avoid electrical shock:
1. Use a properly grounded electrical
outlet of correct voltage and current
handling capacity.
2. If power cord becomes damaged,
replace immediately.
3. Disconnect from power supply before
servicing.
3
Safety Information
Warning
Warnings alert you to a
possibility of personal injury.
Caution
Cautions alert you to a possibility
of damage to the equipment.
Note
Notes alert you to pertinent facts
and conditions.
Alert Signals

Sensor Type: Type-K (Chromel/Alumel) thermocouple
Probe Requirements: accepts any Type-K thermocouple with
miniature connector (not included)
Temperature Range*: 0-1,250°C (32-2,282°F)
Dimensions: 3.1”L x 5.5”W x 7.5”H (8L x 14W x 19H cm)
Capacity: heaters up to 1800 watts, 100-120 VAC
Shipping weight: 4.4 lb. (2 kg)
* Selected probe will dictate actual temperature range within range specified.
4
General Specifications
Environmental Conditions
Operating:
17°C - 27°C; 20% - 80% relative humidity,
non-condensing. Installation Category II
(over-voltage) in accordance with IEC 664.
Pollution Degree 2 in accordance with IEC
664.
Altitude limit: 2,000 meters.
Storage: -25°C - 65°C; 10% to 85% relative
humidity.

SET-TEMP LIMIT cuts off power to laboratory
heaters to guard against thermal runaway
when the temperature sensed by a thermo-
couple exceeds the dial setting. Heating will
not resume until the “RESET” key is pressed.
5
Principles of Operation

Plug SET-TEMP LIMIT into a grounded wall
receptacle. SET-TEMP LIMIT requires a 100-
120 Volt A/C power source. SET-TEMP LIMIT
consumes approximately 25 watts in addition to
the power used by your heating mantle or other
laboratory heater.
Temperature Probe Connection
and Placement
Plug any Type-K thermocouple into the connec-
tor marked “THERMOCOUPLE.” Place the tip of
thermocouple probe into the region in which you
need to limit the temperature. Give this place-
ment some thought. For example, if you are
heating liquid in a flask with a heating mantle, it
is probably a good idea to have the tip of the
probe resting on the inside bottom of the flask.
Then, should the liquid boil away, the sensing
probe will still be effectively heated by the man-
tle and SET-TEMP LIMIT will be able to turn off
your heating mantle before any damage occurs.
Connecting your Heater and
Other Temperature Controls
SET-TEMP LIMIT must be connected in series
with your heater and other heater controls.
Always plug SET-TEMP LIMIT directly into an
A/C wall receptacle. Then, plug other tempera-
ture controls and heaters in series with SET-
TEMP LIMIT in the following order:
1. wall receptacle
2. SET-TEMP LIMIT
3. Other temperature controls (if required)
such as electronic temperature controls,
variacs etc.
4. heater (heating mantle, hot plate, oven,
bath etc.)
6
Installation

1. Turn SET-TEMP LIMIT’s power on.
The red “ALARM” light will be on.
2. Set the limit temperature by adjusting
the dial. If necessary, use a flat blade
screwdriver to turn the dial.
Note that the temperature scale is in degrees
C and degrees F.
3. Press the reset key to energize SET-
TEMP LIMIT’s receptacle.
Note that each time SET-TEMP LIMIT looses
power or is turned off, the “RESET” key must
be pressed to resume heating. Similarly, if the
thermocouple disconnects or open-circuits,
the thermocouple problem must be corrected.
After correcting the problem, press the
“RESET” key to resume heating.
7
Operation

Replacing Fuses
There are two fuses located at the rear of the
unit. The main fuse for the unit is a 20 Amp,
fast-acting, type KLK midget fuse. A 0.5 Amp,
5x20mm, fast-acting fuse protects the unit’s low
power electronics. If this fuse blows, use a slot-
ted screwdriver to remove the old fuse and
install a new 0.5 Amp fast-acting fuse.
General Cleaning Instructions
Wipe exterior surfaces with a lightly dampened
cloth containing a mild soap solution.
8
Maintenance and Servicing

Accessories
Rigid Stainless-Steel Probes
Probes fit traditional apparatus and glassware
without modifications. Their rigid 316
Stainless-steel sheaths are .25”(6.4 mm) in
diameter, roughly the same as traditional
glass thermometers. Available with or without
Teflon coating, all have 6’ (183 cm) lead
wires.
GLASS-PROBE™ Quartz Glass
Probes
Electrothermal’s patented GLASS-PROBE is
highly resistant to most chemicals and ther-
mal shock. Sheath is the same diameter as
standard laboratory thermometers, .25” (6.4
mm) so it is compatible with common ther-
mometer adapters, clamps and apparatus.
The glossy quartz sheath may be cleaned
more thoroughly than metals, Teflon or other
glasses. Usable up to 500°C. Each thermo-
couple is individually tested and permanently
marked with a serial number for identification.
Bendable Stainless-Steel Probes
Probes have bendable 316 stainless-steel
sheaths that are 1.6 mm diameter. They may
be used straight or gently bent to suit your
application. Probe has connector that plugs
into extension cord.
Thermocouple Extension Cords
These extensions are made from appropriate
thermocouple wire to minimize their effect on
readings. Straight extension cords are 130 cm
9
Parts List

10
PARTS LIST
Accessories Parts List
8203 Adapter for 10/18 joints
8204 Adapter for 14/20 joints
8205 Adapter for 19/22 joints
8206 Adapter for 24/40 joints
8303 Rigid s/s probe,1/4” diameter x 12” long, Type-K Thermocouple
8304 Rigid s/s probe,1/4” diameter x 12” long, Type-J Thermocouple
8306 Rigid s/s probe,1/4” diameter x 12” long, Type-K Thermocouple with Teflon coating
8307 Rigid s/s probe,1/4” diameter x 12” long, Type-J Thermocouple with Teflon coating
8003 GLASS-PROBE,1/4” diameter x 12” long, Type-K Thermocouple
8004 GLASS-PROBE,1/4” diameter x 12” long, Type-J Thermocouple
8005 GLASS-PROBE,1/4” diameter x 18” long, Type-K Thermocouple
8007 GLASS-PROBE,1/4” diameter x 24” long, Type-K Thermocouple
8403 Bendable s/s probe,1/16” diameter x 12” long, Type-K Thermocouple, requires ext.
cord
8404 Bendable s/s probe,1/16” diameter x 12” long, Type-J Thermocouple, requires ext.
cord
8503 Straight extension cord 51” long, Type-K
8504 Straight extension cord, 51” long, Type-J
8505 Extendible extension, extended length 47”, Type-K
Replacement Parts List
FZX74 Fuse, .5A, 5x20 mm
FZX77 Fuse, 20A Midget
CN1153X1 Digital Controller, K-Type
CN1153X2 Digital Controller, J-Type
CR1153X1 Cordset, 120V
CNX159 Controller
CE1153X2 Heater Output Connector Assembly
RYX75 Relay
SWX146 Switch

long. Extendible cords stretch to 120 cm.
11
Please refer to the Specification Plate for the complete model number, serial number, and
series number when requesting service, replacement parts or in any correspondence
concerning this unit.
All parts listed herein may be ordered from the Barnstead|Thermolyne dealer from whom
you purchased this unit or can be obtained promptly from the factory. When service or
replacement parts are needed we ask that you check first with your dealer. If the dealer
cannot handle your request, then contact our Customer Service Department at
319-556-2241 or 800-553-0039.
Prior to returning any materials to Barnstead|Thermolyne Corp., please contact our
Customer Service Department for a “Return Goods Authorization” number (RGA). Material
Returned without an RGA number will be returned.
Ordering Procedures

Barnstead|Thermolyne Corporation warrants that if a product manufactured by
Barnstead|Thermolyne and sold by it within the continental United States or Canada
proves to be defective in material or construction, it will provide you, without charge, for a
period of ninety (90) days, the labor, and a period of one (1) year, the parts, necessary to
remedy any such defect. Outside the continental United States and Canada, the warranty
provides, for one (1) year, the parts necessary to remedy any such defect. The warranty
period shall commence either six (6) months following the date the product is sold by
Barnstead|Thermolyne or on the date it is purchased by the original retail consumer,
whichever date occurs first.
All warranty inspections and repairs must be performed by and parts obtained from an
authorized Barnstead|Thermolyne dealer or Barnstead|Thermolyne (at its own discre-
tion). Heating elements, however, because of their susceptibility to overheating and contam-
ination, must be returned to our factory, and if, upon inspection, it is concluded that failure is
not due to excessive high temperature or contamination, warranty replacement will be
provided by Barnstead|Thermolyne. The name of the authorized Barnstead|Thermolyne
dealer nearest you may be obtained by calling 1-800-446-6060 (319-556-2241) or writing
to: Barnstead|Thermolyne
P.O. Box 797
2555 Kerper Boulevard
Dubuque, IA 52004-0797
USA
FAX: [phone]
E-MAIL ADDRESS: [email protected]
Barnstead|Thermolyne’s sole obligation with respect to its product shall be to repair or (at
its own discretion) replace the product. Under no circumstances shall it be liable for
incidental or consequential damage.
THE WARRANTY STATED HEREIN IS THE SOLE WARRANTY APPLICABLE TO
Barnstead|Thermolyne PRODUCTS. Barnstead|Thermolyne EXPRESSLY DISCLAIMS
ANY AND ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR USE.
One Year Limited Warranty
