Baroness GM1700 Operation manual

Mid-Mount Rotary Mower
Owner's Operating Manual
Serial No. GM1700：21202-
"Required reading"
Read this manual before using the machine.
Original Instructions Ver.1.6

California Proposition 65
(For California, USA)
Operating, servicing and maintaining
a passenger vehicle or off-road
vehicle can expose you to chemicals
including engine exhaust, carbon
monoxide, phthalates, and lead,
which are known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Tominimize exposure, avoid
breathing exhaust, do not idle the
engine except as necessary, service
your vehicle in a well-ventilated area
and wear gloves or wash your hands
frequently when servicing your
vehicle. For more information go to
www.P65Warnings.ca.gov/passenge
r-vehicle.
WARNING:
318yi8-005
California Proposition 65_001
California Spark Arrester
(For California, USA)
Warning
Operation of this equipment may create
sparks that can start fires around dry
vegetation.
A spark arrester may be required.
The operator should contact local fire
agencies for laws or regulations relating to fire
prevention requirements.
It is a violation of California Public Resource
Code Section 4442 or 4443 to use or operate
the engine on any forest-covered, brush-
covered, or grass-covered land unless the
engine is equipped with a spark arrester, as
defined in Section 4442, maintained in effective
working order or the engine is constructed,
equipped, and maintained for the prevention of
fire pursuant to Section 4443.
The engine of this machine is not equipped with
a spark arrester.
In some areas there are local, state, or federal
regulations requiring that a spark arrester be
used on the engine of this machine.
The recommended spark arrester for this
machine is Part No.49024N Spark Arrester
made by Nelson Global Products.
Important Emissions Control
Information
(For USA)
This equipment does not meet California EVP
Emission Regulations.
This equipment is manufactured for the purpose
of use in the United States excluding California.
GM1700
Regulations

Thank you for purchasing the Baroness product.
This manual describes the proper handling,
adjustment, and inspection of your product.
We hope you will use the product safely, and take
advantage of its best performance.
For details on the handling, adjustment and
inspection of the attachments, refer to the
Owner's Operating Manual for the attachments.
Keeping the Owner's Operating Manual
Keep this Manual in the box on the hydraulic
tank.
1
bhf6qq-008
Keeping the Owner's Operating Manual_001
1Box
GM1700
Greeting

Read this manual carefully to ensure that you thoroughly understand how to properly operate and maintain the
product, and to avoid causing injury to yourself or others.
The operator is responsible for operating the product properly and safely.
Maintenance service for this machine should be performed by a mechanic with expertise.
If you have any questions concerning maintenance or genuine parts, please contact a Baroness dealer or
Kyoeisha.
When making inquiries about your product, please specify the model and serial number.
When loaning or transferring the product, please also provide this manual together with the product.
Kyoeisha Co., Ltd.
Warning Symbols
This manual uses the following warning symbols for handling precautions that are important for your
safety.
696cq5-001
Warning symbol
This symbol indicates the articles regarding “Danger,” “Warning,” or “Caution.”
Those articles describe important safety precautions and so read them carefully to understand completely before
operating the machine.
Failure to adequately follow these safety precautions may cause an accident.
Danger
Danger
This symbol indicates that serious injury or death will occur if the warning is ignored.
Warning
This symbol indicates that serious injury or death may occur if the warning is ignored.
Caution
This symbol indicates that injury or damage to property may occur if the warning is ignored.
Important
This symbol indicates precautions on the mechanism of the machine.
GM1700
Introduction

Precautionary Statement
Caution
The information described in this manual is
subject to change for improvement without
prior notice.
When replacing parts, be sure to use genuine
Baroness parts or parts designated by
Kyoeisha.
Note that the Baroness product warranty may
not apply to defects caused by the use of
parts from other companies.
Prior to use, carefully read the following
manuals to thoroughly understand the contents
for safe and correct operation.
Baroness Owner's Operating Manual
The Engine's Owner's Manual
The Battery's Owner's Manual
Purpose
This product is intended for cutting turf grass at
golf courses.
Do not use this product in any way other than its
intended purpose, and do not modify this
product.
Operating this product for other purposes and
modifying it may be very dangerous and may
cause damage to the product.
In addition, this product is not authorized for
operation as a special motor vehicle. Do not
operate it on public roads.
･
･
･
GM1700
Introduction

GM1700
Introduction

Safety .............................................................. Page 1-1
Safe Operating Practices ...............................Page 1-2
Disposal .......................................................... Page 2-1
Recycle and Waste Disposal ......................... Page 2-2
Product Overview .......................................... Page 3-1
Specifications .................................................Page 3-2
Sound Pressure Level ................................... Page 3-3
Sound Power Level ........................................Page 3-3
Vibration Level ............................................... Page 3-3
Names of Each Section ................................. Page 3-3
Regulation Decals ..........................................Page 3-4
Safety Signs and Instruction Signs ................ Page 3-8
Handling Instructions .................................... Page 4-1
Pre-installation Adjustments .......................... Page 4-2
Inspections .....................................................Page 4-2
Tightening Torques ......................................Page 4-11
Adjustment before Work .............................. Page 4-15
Procedure to Start/Stop Engine ................... Page 4-16
Operation Method ........................................ Page 4-17
Instruments .................................................. Page 4-25
Move ............................................................ Page 4-27
Cutting Work ................................................ Page 4-29
Transporting .................................................Page 4-29
Storage ........................................................ Page 4-29
Maintenance ................................................... Page 5-1
Maintenance Precautions .............................. Page 5-2
Maintenance Schedule .................................. Page 5-3
Jacking Up The Machine ............................... Page 5-5
Greasing ........................................................ Page 5-6
Lubrication ..................................................... Page 5-9
Maintenance Work .......................................Page 5-10
GM1700
Contents

GM1700
Contents

Safe Operating Practices ...................... Page 1-2
Training ..................................................Page 1-2
Preparation ............................................ Page 1-2
Operation ...............................................Page 1-3
Maintenance .......................................... Page 1-4
Storage .................................................. Page 1-5
Safety
GM1700
Safety
Page 1-1

Failure to adequately follow these safety
precautions may cause an accident resulting in
injury or death.
Danger
Danger
This product is designed to ensure safe
operation and has been tested and inspected
thoroughly before shipment from the factory.
The product is equipped with safety devices to
prevent accidents.
However, whether the product demonstrates
its original performance level depends on the
manner in which it is operated and handled,
as well as the manner in which it is managed
on a daily basis.
Inappropriate use or management of the
product may result in injury or death.
Observe the following safety instructions to
ensure safe operation.
Safe Operating Practices
Training
Read this manual and other training material
carefully.
Be familiar with the controls, safety signs,
and the proper use of the equipment.
If the operator or mechanic can not read the
language used in this manual, it is the
owner's responsibility to explain this material
to them.
All operators and mechanics should seek
and obtain professional and practical
instruction.
The owner is responsible for training the
users.
Such instruction should emphasize:
The need for care and concentration when
working with ride-on machines.
Control of a ride-on machine sliding on a
slope will not be regained by the
application of the brake.
The main reasons for loss of control are
Insufficient wheel grip
Being driven too fast
Inadequate braking
The type of machine is unsuitable for its
task
Lack of awareness of the effect of
ground conditions, especially slopes
Incorrect hitching and load distribution
1.
2.
3.
[1]
[2]
-
-
-
-
-
-
Never allow children or people unfamiliar
with these instructions to use or service the
machine.
Local regulations may restrict the age of the
operator.
The owner/user can prevent and is
responsible for accidents or injuries
occurring to themselves, other people, or
property.
Keep in mind that the owner, operator, and
mechanic are responsible for accidents or
hazards occurring to other people or their
property.
The ROPS is an integral and effective safety
device.
Do not remove or alter the ROPS.
Replace a damaged ROPS.
Do not repair or alter.
You can find additional safety information
where needed throughout this manual.
Determine the left and right sides of the
machine from the normal operating position.
Preparation
Evaluate the terrain to determine what
accessories and attachments are needed to
properly and safely perform the job.
Only use accessories and attachments
approved by the manufacturer.
While operating, always wear substantial
footwear, long trousers, hard hat, safety
glasses, mask, and ear protection.
Long hair, loose clothing, or jewelry may get
tangled in moving parts.
Do not operate the equipment when barefoot
or wearing open sandals.
Inspect the area where the equipment is to
be used and remove all objects such as
rocks, toys and wire which can be thrown by
the machine.
Keep children out of the operating area and
under the watchful care of a responsible
adult other than the operator.
Exercise care in the handling of fuel.
Warning
Fuel is highly flammable.
Take the following precautions:
Store fuel in containers specifically
designed for this purpose.
4.
5.
6.
7.
8.
9.
10.
1.
2.
3.
4.
5.
[1]
GM1700
Safety
Page 1-2 Safe Operating Practices

Add fuel before starting the engine.
Never remove the cap of the fuel tank or
add fuel while the engine is running or
when the engine is hot.
Refuel outdoors only and do not smoke
while refueling.
If fuel is spilled, do not attempt to start the
engine but move the machine away from
the area of spillage and avoid creating any
source of ignition until petrol vapours have
dissipated;
Replace all fuel tanks and container caps
securely.
Check that operator's presence controls,
safety switches and shields are attached and
functioning properly.
Do not operate unless they are functioning
properly.
If the brake operation is faulty, be sure to
adjust or repair them before operating the
machine.
If the handlebar has noticeable play, be sure
to adjust or repair them before operating the
machine.
Replace faulty mufflers.
Before using, always visually inspect to see
that the rotary knives, rotary knife bolts, and
cutter assembly are not worn or damaged.
Replace worn or damaged rotary knives and
bolts in sets to preserve balance.
On multi-rotary knife machines, take care as
rotating one rotary knife can cause other
rotary knives to rotate.
Operation
Do not operate the machine under the
influence of alcohol or drugs.
Do not operate the engine in a confined
space where dangerous carbon monoxide
fumes can collect.
Be sure all drives and shift are in neutral and
parking brake is engaged before starting
engine.
Only start engine from the operator's
position.
Use seat belts if provided.
Do not change the engine governor settings
or overspeed the engine.
Operating the engine at excessive speed
may increase the hazard of personal injury.
[2]
[3]
[4]
[5]
6.
7.
8.
9.
10.
11.
1.
2.
3.
4.
Never operate the machine with damaged
guards, shields, or without safety protective
devices in place.
Be sure all interlocks are attached, adjusted
properly, and functioning properly.
Keep hands and feet away from the rotating
parts.
Do not carry passengers.
Never operate while people, especially
children, or pets are nearby.
Only operate in good light, keeping away
from holes and hidden hazards.
Do not operate the machine when there is
the risk of lightning.
Do not stop or start suddenly.
Look behind and down before backing up to
be sure of a clear path.
Slow down and use caution when making
turns and crossing roads and sidewalks.
Use care when approaching blind corners,
shrubs, trees, or other objects that may
obscure vision.
Do not take your eyes off the road ahead.
Do not operate the machine with no hands.
Remember there is no such thing as a safe
slope.
Travel on grass slopes requires particular
care.
To guard against overturning, follow these
instructions.
Do not stop or start suddenly when going
up or downhill.
Engage clutch slowly, always keep
machine in gear, especially when traveling
downhill.
Machine speeds should be kept low on
slopes and during turns.
Stay alert for humps and hollows and
other hidden hazards.
Never use the machine on a slope with an
angle of gradient that is greater than that
specified or in a place where there is a
danger of the machine slipping.
Use extra care while operating machine with
a grass catcher or other attachments.
They can affect the stability of the machine.
Disengage drive to the cutting unit(s), when
other than operating.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
[1]
[2]
[3]
[4]
17.
18.
19.
Safety
GM1700
Safety
Page 1-3
Safe Operating Practices

Do the following before leaving the
operator's position.
Stop on level ground.
Disengage the all drives.
Lower the bucket.
Set the parking brake.
Stop the engine.
Remove the ignition key.
Stop the engine in the following conditions.
Before refuelling.
Before removing the grass catcher.
Before making height or depth adjustment
unless adjustment can be made from the
operator's position.
Before clearing blockages.
Before checking, cleaning or working on
the machine.
After striking a foreign object or if an
abnormal vibration occurs.
Inspect the machine for damage and
make repairs before restarting and
operating the equipment.
Reduce the throttle setting during engine
run-out.
Never operate with the discharge deflector
raised, removed or altered, unless using a
grass catcher.
Never raise mower deck with the rotary
knives running.
Do not mow in reverse unless absolutely
necessary.
Do not direct discharge material toward
anyone.
Avoid discharging material against a wall or
obstruction.
Material may ricochet back toward the
operator.
Take care when loading or unloading the
machine into a trailer or a truck.
Load or unload the machine in a flat and
safe place.
Before loading or unloading, set the parking
brake on the truck or trailer, stop the engine,
and chock the wheels.
20.
[1]
[2]
[3]
[4]
[5]
[6]
21.
[1]
[2]
[3]
[4]
[5]
[6]
22.
23.
24.
25.
26.
27.
When transporting the machine on a truck or
a trailer, set the parking brake, stop the
engine, and fasten the machine to the truck
with a rope or other suitable restraining
device that has sufficient strength.
When using a running board, select one with
sufficient strength, length, and width and that
will not cause the machine to slip.
Close the fuel valve before transporting the
machine.
Maintenance
Never allow untrained personnel to service
machine.
Implement the following work before
adjusting, cleaning or repairing.
Stop the machine on level ground.
Disengage drive to the cutting unit(s).
Lower the cutting unit(s) and/or
attachment(s).
Set the parking brake.
Stop the engine.
Remove the ignition key.
Wait for all movement to stop.
Allow the engine/muffler to cool before
checking/maintenance.
To reduce the fire hazard, keep hot parts
such as the engine and silencer/muffler,
battery compartment and fuel storage area
free of grass, leaves, or excessive grease.
Clean up oil or fuel spillage.
Appropriately manage and correctly use the
tools necessary for servicing or adjusting the
machine.
Disconnect battery before making any
repairs.
Disconnect the negative terminal first and
the positive last.
Reconnect positive first and negative last.
Use jack stands to support components
when required.
Keep hands and feet away from moving
parts.
If possible, do not make adjustments with the
engine running.
Make sure that parts such as wires are not
touching each other and that their covers
have not come off.
Keep all parts in good working condition and
all hardware tightened.
Replace all worn or damaged decals.
28.
1.
2.
[1]
[2]
[3]
[4]
[5]
[6]
[7]
3.
4.
5.
6.
7.
8.
9.
10.
GM1700
Safety
Page 1-4 Safe Operating Practices

Keep all nuts, bolts and screws tight to be
sure the equipment is in safe working
condition.
Carefully release pressure from components
with stored energy.
Be sure to depressurize the hydraulic system
before performing maintenance operations
on it such as removing hydraulic equipment.
Check whether line connectors in the
hydraulic system are properly tightened.
Before applying hydraulic pressure, check
the connections of the hydraulic pressure
lines and the condition of the hoses.
When checking the hydraulic circuit for
pinhole leaks or oil leakage from nozzles, do
not use your hands.
Use items such as paper or corrugated
cardboard to find leakage points.
Be extremely careful with high-pressure oil
as it may pierce your skin, resulting in an
injury.
If fluid is injected into the skin it must be
surgically removed within a few hours by a
doctor familiar with this form of injury or
gangrene may result.
Use care when checking the rotary knives.
Wrap the rotary knives or wear gloves, and
use caution when servicing them.
Only replace rotary knives.
Never straighten or weld them.
On multi-rotary knife machines, take care as
rotating one rotary knife can cause other
rotary knives to rotate.
Check the grass catcher frequently for wear
or deterioration.
Charge batteries in an open well ventilated
area, away from spark and flames.
Unplug charger before connecting or
disconnecting from battery.
Wear protective clothing and use insulated
tools.
If the fuel tank has to be drained, do this
outdoors.
Storage
When machine is to be parked, stored, or left
unattended, lower the cutting unit(s) and/or
attachment(s) unless a positive mechanical
lock is provided.
Allow the engine to cool before storing in any
enclosure.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
1.
2.
Only cover the machine with a sheet after
hot parts have sufficiently cooled down.
Never store the equipment with fuel in the
tank inside a building where fumes may
reach an open flame or spark.
If the engine is provided with a shut-off
valve, shut off valve while storing or
transporting.
Do not store fuel near flames.
Swallowing engine coolant can cause injury
or death; keep out of reach from children and
pets.
3.
4.
5.
6.
7.
Safety
GM1700
Safety
Page 1-5
Safe Operating Practices

GM1700
Safety
Page 1-6 Safe Operating Practices

Recycle and Waste Disposal ................ Page 2-2
About Recycle ........................................Page 2-2
About Waste Disposal ........................... Page 2-2
Disposal
GM1700
Disposal
Page 2-1

Recycle and Waste Disposal
About Recycle
Recycling battery etc. is recommended for
environmental conservation and economical
use of resources.
It may be required by local laws.
About Waste Disposal
Make sure that waste generated when
servicing or repairing the machine is disposed
of in accordance with local regulations.
(e.g. waste oil, antifreeze, rubber products, and
wires etc.)
GM1700
Disposal
Page 2-2 Recycle and Waste Disposal

Specifications ........................................ Page 3-2
Specifications .........................................Page 3-2
Sound Pressure Level ........................... Page 3-3
Sound Pressure Level ........................... Page 3-3
Sound Power Level ................................Page 3-3
Sound Power Level ............................... Page 3-3
Vibration Level ....................................... Page 3-3
Hand-Arm Vibration ............................... Page 3-3
Whole Body Vibration ............................ Page 3-3
Names of Each Section ......................... Page 3-3
Regulation Decals ..................................Page 3-4
Positions of Regulation Decals ..............Page 3-4
Description of Regulation Decals .......... Page 3-4
Safety Signs and Instruction Signs ..... Page 3-8
About Safety Signs and Instruction
Signs ......................................................Page 3-8
Positions of Safety Decals and
Instruction Decals .................................. Page 3-8
Description of Safety Decals and
Instruction Decals .................................. Page 3-9
Product Overview
GM1700
Product Overview
Page 3-1

Specifications
Specifications
Model GM1700
Name Mid-Mount Rotary Mower
Dimensions
Total length 255 cm 100.39 in
Total width 154 cm 60.63 in
Total height Roof 197 cm 77.56 in
Steering wheel 121 cm 47.64 in
Weight
Machine
(empty fuel
tank)
with ROPS 730 kg 1609.35 lb
Minimum turning radius 298 cm 117.32 in
Engine
Model Kubota D1105
Type Vertical Water-cooled 4-cycle diesel engine
Total displacement 1,123 cm3 (1.123 L) 68.52 cu.in.
Maximum output -
Rated output 18.1 kW (24.6 PS)/2,800 rpm
Fuel tank capacity Diesel 23.0 dm3 (23.0 L) Diesel 6.08 U.S.gal.
Fuel consumption 280 g/kW・h (rated output) 206 g/PS・h (rated output)
Engine oil capacity 3.0 dm3 (3.0 L) 0.79 U.S.gal.
Coolant volume 6.0 dm3 (6.0 L) 1.59 U.S.gal.
Hydraulic tank capacity 22.0 dm3 (22.0 L) 5.81 U.S.gal.
Transmission oil capacity 0.45 dm3 (0.45 L) 0.12 U.S.gal.
Operating width (Mowing width) See the mower deck's specifications.
Operating height (Mowing height) See the mower deck's specifications.
Number of Blades See the mower deck's specifications.
Drive Traveling HST (2WD/4WD selectable)
Mowing Mechanical
Speed (HST)
Forward 2WD 0 - 16.0 km/h 0 - 9.94 mph
4WD 0 - 8.0 km/h 0 - 4.97 mph
Reverse 2WD 0 - 14.0 km/h 0 - 8.70 mph
4WD 0 - 7.0 km/h 0 - 4.35 mph
Speed (Mechanical) -
Efficiency See the mower deck's specifications.
Maximum inclination for operation 25 degrees
Tire size Front wheel 21 x 11.00 - 10
Rear wheel 21 x 11.00 - 10
Tire pneumatic
pressure
Front wheel 140 kPa (1.4 kgf/cm2)20.30 psi
Rear wheel 140 kPa (1.4 kgf/cm2)20.30 psi
Battery 80D26R
Engine plug -
The factory default maximum engine rpm is 2,800 rpm.
GM1700
Product Overview
Page 3-2 Specifications

Sound Pressure Level
Sound Pressure Level
This machine was confirmed to have a
continuous A-weighted sound pressure level of
93dB by measuring identical machines in
accordance with the procedure specified in ISO
5395-1:2013.
Sound Power Level
Sound Power Level
This machine was confirmed to have a sound
power level of 105dB by measuring identical
machines in accordance with the procedure
specified in ISO5395-1:2013.
Vibration Level
Hand-Arm Vibration
This machine was confirmed not to exceed a
vibration level of 2.5 m/s2 to hands and arms
by measuring identical machines in
accordance with the procedure specified in ISO
5395-1:2013.
Uncertainty K = 0.8 m/s2
Whole Body Vibration
This machine was confirmed not to exceed a
vibration level of 0.5 m/s2 to the whole body by
measuring identical machines in accordance
with the procedure specified in ISO
5395-1:2013.
Uncertainty K = 0.2 m/s2
Names of Each Section
16
15
3
5
6
7
8910
11
13
12
14
4
12
quwxcl-160
Names of Each Section_001
1Hood
2 Steering wheel
3 Seat
4 2WD/4WD selector lever
5 Fuel tank
6 Brake pedal
7 Front wheel
8 Knife rotation lever
9 Meter panel
10 Throttle lever
11 Forward pedal
12 Reverse pedal
13 Center cover
14 Rear wheel
15 Hydraulic tank
16 Rear cover
Product Overview
GM1700
Product Overview
Page 3-3
Sound Pressure Level

Regulation Decals
Positions of Regulation Decals
F,G
AE B,C
L,M
D
K
I,J
H
8BC1C63A
Positions of Regulation Decals_001
ASerial number plate
B Specification decal
C UKCA mark
D Noise emission decal
E Year of manufacture decal
F ROPS compliance decal
G ROPS caution decal
H Battery capacity decal
I Recycle decal
J Battery danger decal
K Indicating diesel fuel decal
L Spark arrester warning decal
MCalifornia Proposition 65 decal (riding
type)
Description of Regulation Decals
Serial Number Plate
The serial number plate indicates the model
and serial number of the machine.
4ogipb-001
Serial Number Plate_001
Specification Decal
(For Europe)
CE mark indicates that the machine sold in
the EU nations complies with the EU
requirements.
The Specification decal indicates the CE
marking, model , and weight, etc.
450597AD
Specification Decal_001
GM1700
Product Overview
Page 3-4 Regulation Decals
